OWNER’S MANUAL
TRINITY ECOSTORAGE® RECLINING ADIRONDACK CHAIR
ESPRESSO BROWN / SLATE GRAY
Model # THBBR-3103 / THBGR-3103
Important / Important / Importante
DOWNLOAD THE FREE APP | TÉLÉCHARGER L’APPLICATION GRATUITE| DESCARGUE LAAPLICACIÓN GRATUITA
Directives intelligentes
Instrucciones Inteligentes
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D

Your TRINITY EcoStorage®Adirondack Reclining Chair should include the following parts. Please inspect
box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online
via “Contact Us” section at www.trinityii.com.
You will NOT need additional tools for assembly.
PARTS LIST
SEAT (1)
A
LEFT ARMREST
(1)
CD
LEFT SUPPORT
(1)
SCREW (16)
M6 X 35
RIGHT ARMREST
(1) LEFT FRONT LEG (1)
RIGHT FRONT
LEG (1)
© 2020 TRINITY - 800.985.5506
1
BACKREST (1)
B
RIGHT SUPPORT
(1) NUT (2)
E
FGHJ
I
WASHER (2)
KLM
HEX KEY (1) WRENCH (1)

ASSEMBLY INSTRUCTIONS
STEP 1
G (1) K (7)
E (1)
C (1)
K
© 2020 TRINITY - 800.985.5506 2
L
L (1)
NOTE: Make sure you have parts labeled (C), (E) and
(G) for this step. They look very similar to parts (D),
(F), and (H).
Lay SEAT (A) on ground sideways as shown, orient (3)
insert nuts on LEFT FRONT LEG (E) to align with (3)
holes on SEAT (A). Insert (3) SCREWS (K), from inside,
through SEAT (A) and hand fasten to LEFT FRONT LEG
(E). Then with HEX KEY (L) tighten (3) SCREWS (K).
Orient (2) insert nuts on LEFT SUPPORT (G) to align
with (2) holes on SEAT (A). Insert (2) SCREWS (K),
from inside, through SEAT (A) and hand fasten to LEFT
SUPPORT (G). Then with HEX KEY (L) tighten (2)
SCREWS (K).
Put LEFT ARMREST (C) on LEFT FRONT LEG (E) and
LEFT SUPPORT (G), making sure holes are aligned with
insert nuts. Insert SCREW (K) through LEFT ARMREST
(C) and hand fasten to LEFT FRONT LEG (G). Insert
SCREW (K) through LEFT ARMREST (C) and hand
fasten to LEFT SUPPORT (G). Finally tighten both
SCREWS (K) with HEX KEY (L).
A(1)
Completed STEP 1 assembly
G
C
A
E
2
1
2
3
K
K

ASSEMBLY INSTRUCTIONS
STEP 2
H (1) K (7)
F (1)
D(1)
© 2020 TRINITY - 800.985.5506
L (1)
Flip over completed assembly from STEP 1 and lay on
ground as shown.
Orient (2) insert nuts on RIGHT SUPPORT (H) to align
with (2) holes on SEAT (A). Insert (2) SCREWS (K),
from inside, through SEAT (A) and hand fasten to
RIGHT SUPPORT (H). Then with HEX KEY (L) tighten (2)
SCREWS (K).
Orient (3) insert nuts on RIGHT FRONT LEG (F) to align
with (3) holes on SEAT (A). Insert (3) SCREWS (K),
from inside, through SEAT (A) and hand fasten to
RIGHT FRONT LEG (F). Then with HEX KEY (L) tighten
(3) SCREWS (K).
Put RIGHT ARMREST (D) on RIGHT FRONT LEG (F) and
RIGHT SUPPORT (H) ,making sure holes are aligned
with insert nuts. Insert SCREW (K) through RIGHT
ARMREST (D) and hand fasten to RIGHT SUPPORT (H).
Insert SCREW (K) through RIGHT ARMREST (D) and
hand fasten to RIGHT FRONT LEG (F). Finally tighten
both SCREWS (K) with HEX KEY (L).
Seat Assembly after STEP 2
F
H
3
K
L
D
1
2
3
K
K

ASSEMBLY INSTRUCTIONS
With 2 people, carefully hold BACKREST (B) over Seat
Assembly. Slide Back Support into notches on each
side of SEAT (A).
STEP 3
On left side, insert SCREW (K) through SEAT (A),
BACKREST (B) and WASHER (J). With WRENCH (M)
holding NUT (I) in place, tighten SCREW (K) onto
NUT (I) with HEX KEY (L).
Repeat for right side.
STEP 4
© 2020 TRINITY - 800.985.5506 4
B (1)
J (2) K (2) M (1)
I (2)
Seat Assembly
B
K
JIM
Back Support
B
L
L (1)

USAGE INSTRUCTIONS
There are 3 reclining positions. Lift BACKREST (B) and move Back Support to position you desire.
ADJUST SEAT BACK RECLINE POSITIONS
© 2020 TRINITY - 800.985.5506
5
POSITION 1 POSITION 2 POSITION 3
Back Support

SERVICE PARTS LIST- THBBR-3103 ESPRESSO BROWN
© 2020 TRINITY - 800.985.5506 6
Part Number Description Part Number Description
1) PBK-25-005-0002 Back Support 10) XXX-97-002-0006 Wrench
2) XBK-23-004-2540 End Cap 11) XXX-97-001-0001 Hex Key
3) XBR-25-005-0001 Backrest 12) XBR-25-004-0005 Right Front Leg
4) XBK-01-026-0635 Screw 13) XBR-25-004-0004 Right Armrest
5) XBR-25-004-0003 Left Support 14) XSV-01-018-0606 Nut
6) XBR-25-004-0001 Left Armrest 15) XSV-01-019-0612 Washer
7) XBR-25-004-0002 Left Front Leg 16) XBK-01-026-0620 Back Support Screw
8) XBR-25-003-0001 Seat 17) XBK-01-041-0615 Plastic Washer
9) XBR-25-004-0006 Right Support
TRINITY Customer Service provides the following replacement parts:
15
13
12
10
3
5
6
7
9
8
4
16
17
11
14
2
1

Part Number Description Part Number Description
1) PBK-25-005-0002 Back Support 10) XXX-97-002-0006 Wrench
2) XBK-23-004-2540 End Cap 11) XXX-97-001-0001 Hex Key
3) XGR-25-005-0001 Backrest 12) XGR-25-004-0005 Right Front Leg
4) XBK-01-026-0635 Screw 13) XGR-25-004-0004 Right Armrest
5) XGR-25-004-0003 Left Support 14) XSV-01-018-0606 Nut
6) XGR-25-004-0001 Left Armrest 15) XSV-01-019-0612 Washer
7) XGR-25-004-0002 Left Front Leg 16) XBK-01-026-0620 Back Support Screw
8) XGR-25-003-0001 Seat 17) XBK-01-041-0615 Plastic Washer
9) XGR-25-004-0006 Right Support
SERVICE PARTS LIST- THBGR-3103 SLATE GRAY
TRINITY Customer Service provides the following replacement parts:
© 2020 TRINITY - 800.985.5506
7
15
13
12
10
3
5
6
7
9
8
4
16
17
11
14
2
1
