Trinity TBFPBR-0943 User manual

OWNER’S MANUAL
TRINITY 4-TIER NSF 36" x 14" x 54"
WIRE SHELVING RACK w/LINERS
Model # TBFPBR-0943

Your TRINITY 4-Tier NSF Wire Shelving Rack w/Liners should include the following parts. Please inspect
box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online at
www.trinityii.com (Help & More, Contact Us).
You will need no additional tools for assembly.
PARTS LIST
AB
SHELF (4)
C
D
SLIP SLEEVE
(32) + (2) extra
Note: The black circular plastic tops in between the Shelves are used only for packaging purpose. They
are NOT NEEDED. Please discard.
TOP POLE (4)
End Cap (4) and
Pole Connector (4)
are pre-installed
BOTTOM POLE (4)
Threaded Insert (4) and
Feet Leveler (4)
are pre-installed
© 2018 TRINITY - 800.985.5506
1
E
SHELF LINER (4)

© 2018 TRINITY - 800.985.5506
ASSEMBLY INSTRUCTIONS
Note: There will be a very small gap in-between two locked SLIP SLEEVES (D)—this is normal.
2
A (4) D (8)
C (1)
Place SHELF (C) on its side and slide (4) BOTTOM
POLES (A) through the holes in SHELF (C). Make
sure that SHELF (C) corner cylinders are
positioned over SLIP SLEEVES (D).
Stand the unit upright.
Note
•The level side of SHELF (C) is the TOP side (the
TRINITY logo on the corner cylinders should
be right-side up).
•Use a rubber mallet, if needed, to secure
SHELF (C).
For easiest assembly, do not attach TOP (B) and BOTTOM (A)
POLES until instructed. Once connected, these will be the posts
for the rack.
Note that each POLE (A+B) has slight horizontal line
indentations at 1” intervals. Each SLIP SLEEVE (D) has raised
horizontal lines inside designed to lock them in place on POLE
(A+B).
On BOTTOM POLE (A), place 1 pair of SLIP SLEEVES (D) at the
desired level no higher than the 3rd indentation from the
bottom. Please make sure the arrow faces up and that the
word “TOP” is right side up. Do this for each BOTTOM POLE (A)
and make sure that SLIP SLEEVE (D) heights are identical for all
(4) BOTTOM POLES (A).
Slide the pair of SLIP SLEEVES (D) until you hear a click to
confirm the pair is locked onto BOTTOM POLE (A). DO NOT
place more than one pair on each POLE (A) at a time.
STEP 1
STEP 2

© 2018 TRINITY - 800.985.5506
ASSEMBLY INSTRUCTIONS
3
Screw TOP POLE (B) into BOTTOM POLE (A).
The tops of these poles are indicated by the
BLACK END CAP.
Repeat for remaining 3 TOP POLES (B).
B (4)
On BOTTOM POLE (A), place 1 pair of SLIP SLEEVES (D) at the
desired height between SHELVES (C). Please make sure the
arrow faces up and that the word “TOP” is right side up. Do
this for each BOTTOM POLE (A), and make sure that the
heights are identical for each BOTTOM POLE (A).
Carefully lower SHELF (C) over BOTTOM POLES (A) so that the
corner cylinders of SHELF (C) are positioned over SLIP
SLEEVES (D).
Repeat Step 3 to install other SHELVES (C) as desired.
Note: Use a rubber mallet, if needed, to secure SHELVES (C).
D (8) C (1)
STEP 3
STEP 4

© 2018 TRINITY - 800.985.5506 4
ASSEMBLY INSTRUCTIONS
Feet Levelers are already screwed into BOTTOM POLES (A).
Adjust as needed to ensure your shelving rack is level.
D (16) C (2)
On POLE (A+B), place 1 pair of SLIP SLEEVES (D) at the desired
height between SHELVES (C). Please make sure the arrow
faces up and that the word “TOP” is right side up. Do this for
each POLE (A+B), and make sure that the heights are
identical for each POLE (A+B).
Lower SHELF (C) over TOP POLES (B) so that the corner
cylinders of SHELF (C) are positioned over SLIP SLEEVES (D).
Repeat Step 5 to install other SHELVES (C) as desired.
Note: Use a rubber mallet, if needed, to secure SHELVES (C).
STEP 5
STEP 6

© 2018 TRINITY - 800.985.5506
5
ASSEMBLY INSTRUCTIONS
E (4)
STEP 7
Place each SHELF LINER (E) onto each
SHELF (C) as shown.

TRINITY Customer Service provides the following replacement parts:
SERVICE PARTS LIST –TBFPBR-0943
© 2018 TRINITY - 800.985.5506 6
Part Number Description Part Number Description
1) XBK-01-012-2543 Slip Sleeve 5) XBK-98-003-2538 Feet Leveler
2) PBR-04-025-2650 Top Pole 6) XCL-22-002-
3614
Shelf Liner
3) ZSV-01-029-2523 Pole Connector 7) XBK-23-004-2517 End Cap
4) PBR-04-027-2650 Bottom Pole
8)
PBR-03-007-3614 Shelf
2
1
3
4
5
7
8
6

© 2018 TRINITY - 800.985.5506
7
WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of the
environment where the product will be placed and make sure to use the product in a safe
and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
4. Check for damaged parts.Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
5. Do NOT overload the product.
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals
•This item is not certified for outdoor use
Weight capacity per Shelf (evenly distributed) 350 lb
Total weight capacity of Shelving Rack
(evenly distributed)
1400 lb

Thank you for purchasing a TRINITY 4-Tier NSF Wire Shelving Rack w/ LINERS. In order to register your
product and receive streamlined customer service, please fill out the following Product Registration
Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at
www.trinityii.com or (3) scan and email the form to [e-mail]. Include a copy of
your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: TBFPBR-0943 Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
PRODUCT REGISTRATION
© 2018 TRINITY - 800.985.5506 8

© 2018 TRINITY - 800.985.5506
9

1 YEAR LIMITED WARRANTY
TRINITY 4-Tier NSF Wire Shelving Rack w/ Liners
Model # TBFPBR-0943
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the
TRINITY 4-Tier NSF Wire Shelving Rack w/ Liners (“Product”) that each Product shall be free from defects in
workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s obligation
under this warranty shall be limited to repair or replacement of, or adequate compensation for the Product
which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity,
during the warranty period. All replaced parts and Products become the property of Trinity and must be
returned to Trinity.
This warranty excludes normal wear and tear of the Product and its parts or components, and damage arising
from any of the following: negligent use or misuse of the Product, use contrary to this User’s Manual, or
alteration by any one other than Trinity. The warranty period of 1 year shall not be extended or renewed by
the repair or replacement of, or compensation for, the Product. Any warranty implied by applicable law is
limited in duration to one year from the date of purchase and is subject to the same conditions and
limitations as is provided for our express warranty.
Except as set forth herein, and to the extent of applicable there are no warranties on this Product either
express or implied, and Trinity disclaims all warranties including, but not limited to, any implied warranties of
merchantability, infringement or fitness for a particular purpose. No warranty or guarantee given by any
person, firm, or corporation with respect to this product shall be binding on Trinity.
If your Product is defective or otherwise requires service or parts, please call TRINITY Customer Service toll-
free at [phone], between 5:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased,
the date of the purchase, and the problem with your Product. A copy of your original purchase receipt must
accompany your service request.
LIMITATION OF REMEDIES AND LIABILITY
Trinity (and its employees, officers, members, managers, affiliates an assigns) shall not be liable for any
incidental, consequential, special, indirect, remote, special or punitive damages for breach of any warranty,
express or implied, including, but not limited to, lost profits, lost savings, loss of anticipated benefits and
attorneys’ fees, which arise out of the purchase, use or inability to use the Product, whether arising out of
contract, negligence, strict tort, product liability, or any other legal theory on which a claim is based. As
noted above, to the extent damages are allowed by our express warranty or by applicable law, those
damages may not exceed the purchase price paid for the Product. Without limiting the foregoing Purchaser
assumes all risk and liability for loss, damage or injury to Purchaser and Purchaser’s property and to others
and their property arising out of the use, misuse, or inability to use this Product. This limited warranty shall
not extend to anyone other than the original purchaser of this product, is nontransferable and states your
exclusive remedy.
Some states do not allow the exclusion or limitation of incidental, consequential, special, or punitive
damages, so the above limitation or exclusion may not apply to you. The above warranty gives you specific
legal rights, and you may have other rights which vary from state to state.
© 2018 TRINITY - 800.985.5506 10

TRINITY Customer Service
TEL: [phone]
FAX: [phone]
EMAIL: [e-mail]
Monday through Friday
5:00 AM –5:00 PM (PST)
www.trinityii.com
QUESTIONS? NEED PARTS?
WE ARE HERE TO HELP!
Please feel free to contact us. There are no questions too small, or
any problems too big. We’re committed to providing our customers
with the highest level of service.
CONTACT US
