tropitone Matrix KD Table User manual

4
MORE INFORMATION
For care and cleaning instructions, refer to the Tropitone® Care,
Maintenance, Safety & Warranty Information guide included with your
furniture and available at www.tropitone.com/warranty.
Additional care information, “How To” videos and assembly instructions
for Tropitone Outdoor Furniture and Basta Sole shade products are also
available at our website.
If you have difficulty understanding any of the instructions and need
assistance while assembling your Matrix Tables, please call Tropitone’s
Customer Service Center at 949-951-2010.
Tropitone Furniture Co., Inc.
5 Marconi, Irvine, CA 92618
949 951 2010 phone
www.tropitone.com
Part # R9T00056
Revised: 10.25.2019
2019 Tropitone Furniture Co., Inc.
1
Matrix KD Table
Assembly Instructions
Congratulations on the purchase of your Tropitone®Matrix KD Table. Read
through all steps before fastening components together.
CAUTION: Do not try to lift or flip furniture components with only one
person. Components may be heavy and awkward to handle and may
result in injury to persons or damage to property if not lifted properly.
Once the Table Top has been installed, use 2 persons to turn the
assembled table over to an upright position.
Tools Required
5/32” Socket Head Wrench
5/16” Socket Driver or Flathead
Screwdriver
Safety Glasses
Base Parts List-Coffee, Chat,
Dining Height
Base Parts List-Counter, Bar Height
(4) Legs
(1) Table Top Frame
(8) ¼ x 7/8” Button Head Bolts
(8) ¼” Lock Washers
(8,12,16) 5/8” Self Tapping Screws
for various size tables
(4) Legs
(1) Table Top Frame
(1) Center Brace
(16) ¼ x 7/8” Button Head Bolts
(16) ¼” Lock Washers
(8,12,16) 5/8” Self Tapping Screws
for various size tables
Check that all items listed in the Parts List are in your carton.
Prepare a smooth, non-scratch work surface (shipping carton, a tarp or pools
towels can be used).
Assembled furniture is
heavy. Assemble at
place of use.

2
Coffee, Chat, Dining Height Base Assembly
Place Table Top Frame upside down on the prepared work surface. Mounting Post should
be facing upwards.
Place one leg onto a corner mounting post aligning attachment holes in the leg to the holes
in the mounting post.
Attach leg with two bolts and two
washers and fully tighten. Repeat for the
remaining three legs.
Check 8 bolts to ensure that all are fully
tightened.
Counter, Bar Height Base Assembly
Place one leg onto the Cross Brace at
mounting bracket.
Loosely attach with two bolts and two
washers. Do not fully tighten at this
point. Repeat process until all four legs
are loosely attached to the Cross Brace.
Place Table Top Frame upside down on
the prepared work surface. Mounting
poata should be facing upwards.
With the Cross Brace attached, place
the four legs onto the four corner
mounting posts of the Table Top Frame.
Loosely attach each leg with two bolts
and two washers. Do not fully tighten
until all four legs are attached.
Fully tighten all bolts. Check 16 bolts to
ensure that all are fully tightened.
3
Step 1
CAUTION: It is the assembler’s and user’s responsibility to
confirm and install proper length screws to prevent damage
to the Top.
Place one screw into the Table Base. Measure the length of the
screw threads to insure they stick up 3/8” –1/ 2”.
x If the screw sticks up more than 1/2”, do NOT proceed. The screws are too
long and will stick up through the Top surface.
x If the screw sticks up less than 3/8”, do NOT proceed. The screws are too
short and will not properly secure the Top.
Step 2
Prepare a smooth, non-scratch work surface (shipping container, a tarp or pool towels can
be used). With two persons, place the Table Top upside down on the prepared work
surface. With two persons, gently place the Base upside down onto the Top.
Step 3
Tops with Umbrella Hole
Center the Base on the underside of the Top; sight down through the umbrella support ring
in the Base and align it to the Top.
 Square, Rectangular Tops: Align the Base to the corners of the Top.
 Round Tops: Continue to step 4.
Tops without Umbrella Hole
Center the Base on the underside of the Top.
 Square, Rectangular Tops: Align the Base to the corners of the Top. Measure
equal distances at (4) places from the corner of the Top to the leg mount.
 Round Tops: Measure equal distances at (4) places from the edge of the Top to
the leg mount.
Step 4
Attach the Base to the Top using the supplied screws at (8), (12) or (16) places.
NOTE: After assembling one Table, turn the Table upright. Confirm the screws have
not penetrated up through the top surface.
With two persons, lift the table upright while holding the Base near the (4) outermost Base
to Top connection points.
Check that all the screws are firmly tightened at (8), (12) or (16) places to retain the Top.
