True TPP-44 User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
TPP-44
TPP-44
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Pans
(top)
Cabinet Dimensions
(inches)
(mm)
L** D†H*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TPP-44 1 11.4
323
2644
1/2
1131
321/4
820
353/4
909
1/3
1/3
115/60/1
230-240/50/1
8.6
3.8
5-15P
▲
9
2.74
305
139
6/07
Pizza Prep Table:
Soild Door Refrigerator
R
®
True’s pizza prep tables are
designed with enduring quality
that protects your long term
investment.
Oversized, environmentally
friendly (R134A) forced-air
refrigeration system holds 33°F
to 41°F (.5°C to 5°C).
Complies with and listed under
ANSI/NSF-7-1997-6.3.
All stainless steel front, top
and cabinet ends. Matching
aluminum finished back.
Stainless steel, patented, foam
insulated flat lid keeps pans’
temperature colder, locks
in freshness, and minimizes
condensation.
Extra-deep 191/2" (496 mm)
full length removable cutting
board included. Sanitary, high-
density, NSF approved white
polyethylene provides tough
preparation surface.
Foamed-in-place, high density
polyurethane insulation (CFC
free).
Heavy duty PVC coated wire
shelves.
** Length does not include 1/4
" (7 mm) each side for cutting board brackets and thumb screws. ▲Plug type varies by country.
†Depth does not include 1
" (26 mm) for rear bumpers and 3 " (77 mm) for cutting board.
*Height does not include 61/4
" (159 mm) for castors or 6 " (153 mm) for optional legs.

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
123/4"
(324 mm)
81/4"
(210 mm)
DESIGN
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures, lower
utility costs, exceptional food safety and
the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained
capillary tube system using
environmentally friendly (CFC free)
R134A refrigerant.
• Oversized, factory balanced refrigeration
system with guided airflow to provide
uniform temperature in food pan rail
and cabinet interior.
• Forced-air design holds 33°F to 41°F
(.5°C to 5°C) product temperature in food
pans and cabinet interior. Complies with
and listed under ANSI/NSF-7-1997-6.3.
• Condensing unit accessed from front
behind removable panel on right hand
side of cabinet, slides out for easy
maintenance.
CABINET CONSTRUCTION
• Exterior - stainless steel front, top and
cabinet ends. Matching aluminum
finished back.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless floor
with coved corners.
• Insulation - entire cabinet structure and
solid door are foamed-in-place using
high density, CFC free, polyurethane
insulation.
• 5" (127 mm) diameter stem castors. 36"
(915 mm) work surface height.
DOOR
• Stainless steel exterior with white
aluminum liner to match cabinet
interior.
• Door fitted with 12" (305 mm) long
recessed handle that is foamed-in-place
with a sheet metal interlock to ensure
permanent attachment.
• Positive seal door swings within cabinet
dimensions.
• Magnetic door gasket of one piece
construction, removable without tools
for ease of cleaning.
SHELVING
• Two (2) adjustable, heavy duty PVC
coated wire shelves 25"L x 273/4"D
(635 mm x 705 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• Extra-deep 191/2" (496 mm) full length
removable cutting board included.
Sanitary, high-density, NSF approved
white polyethylene provides tough
preparation surface.
• Stainless steel, patented, foam insulated
flat lid keeps pan temperatures colder,
locks in freshness, and minimizes
condensation.
• Refrigerated pan rail comes standard
with six (1/3size) 123/4"L x 61/4"W x 6"D
(324 mm x 159 mm x 153 mm) NSF
approved clear polycarbonate insert pans.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase - 15 amp dedicated outlet. Cord
and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 230 - 240V / 50 Hz.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒3" (85 mm) diameter castors.
❒ Garnish rack.
❒ Pizza prep service shelf.
❒ Single utility shelf.
❒ Double utility shelf.
❒ 191/2" (496 mm) deep, 1/2" (13 mm)
thick, white polyethylene cutting board.
❒ 191/2" (496 mm) deep, 1/2" (13 mm)
thick, composite cutting board.
❒ Half bun tray rack. Holds up to eleven
18"L x 26"D (458 mm x 661 mm) sheet
pans (sold separately).
❒ Exterior round digital temperature
display (factory installed).
❒ Remote cabinets (condensing units
supplied by others; system comes
standard with 404A expansion valve and
requires R404A refrigerant). Consult
factory technical service department for
BTU information.
TPP-44 TFQY10E TFQY10S TFQY10P TFQY1733
TPP-44
115/60/1
NEMA-5-15R
ELEVATION PLAN VIEW
Pizza Prep Table:
Solid Door Refrigerator
441/2"
(1131 mm)
417/8"
(1064 mm)
281/4"
(718 mm)
293/4"
(756 mm)
1/4"
(7 mm)
25/8"
(67 mm)
RIGHT VIEW
4911/16"
(1263 mm)
417/8"
(1064 mm)
321/4"
(820 mm)
355/32"
(893 mm)
1"
(26 mm)
617/8"
(1572 mm)
3511/16"
(907 mm)
285/8"
(728 mm)
39/16"
(91 mm)
133/4"
(350 mm)
1/4"
(7 mm)
each side for
Cutting Board
Brackets and
Thumb Screws
63/16"
(158 mm)
3515/16"
(913 mm)
5"
(127 mm)
