U-Line H-2450 User manual

0313 IH-2450PAGE 1 OF 4
GARMENT STORAGE
CENTER WITH BASKETS
H-2450
Pin x 12
Connector x 6
18 x 18" Frame x 2
36 x 18" Shelf x 1
Basket Support Bar (6 Sets)
Short Post x 2Tall Post Bottom x 6Tall Post Top x 6
18 x 18" Shelf x 6
Shelf Support (60 Sets)
Basket x 6
Garment Rod Hanger x 2
Garment Rod x 1
Self-leveler x 8
PARTS

0313 IH-2450PAGE 2 OF 4
POST ASSEMBLY
1. Connect tall post tops and tall post bottoms to each
other by screwing them together. (See Figure 1)
NOTE: Tall post tops have a black plastic cap in
the top of the post.
TO INSTALL SELF-LEVELERS
1. Make sure post is positioned as shown. (See Figure 2)
2. Insert self-leveler into open end of post. Tap on
ground to slide self-leveler into post.
3. Repeat step 2 for all other posts.
TO INSTALL OPTIONAL CASTERS
1. Make sure post is positioned as shown. (See Figure 3)
2. Engage the wheel brakes to keep casters from
rolling during assembly. Use a rubber mallet to tap
caster stem into posts. (See Figure 3)
UNIT ASSEMBLY
1. Snap shelf supports into the very bottom groove of
two short and two tall posts. (See Figure 4)
2. Slide posts through underside of square frame until it
slides firmly over the supports. (See Figure 5)
3. Take the other four tall posts, snap shelf supports into
the very bottom groove on all four posts. Slide posts
through underside of square frame until it slides
firmly over the supports. (See Figure 6)
4. Position each of the four posts as shown and snap
four sets of shelf supports into the groove directly
above the square frames of the inner four posts.
(See Figure 7)
5. Slide a square shelf onto the inner four posts until it
slides firmly over the supports. (See Figure 8)
ASSEMBLY
Figure 1
Figure 4 Figure 5
Figure 6
Figure 3
Figure 2
Figure 7
Figure 8

0313 IH-2450PAGE 3 OF 4
UNIT ASSEMBLY CONTINUED
6. Snap four sets of shelf supports onto the outer
posts with five grooves visible. And four sets of shelf
supports on the inner posts with three grooves visible.
(See Figure 9)
7. Slide four basket support bars onto the posts until
bars slide firmly over the supports. (See Figure 10)
NOTE: Make sure all the basket support bars
have the open end facing the same direction,
forward.
8. Snap eight sets of shelf supports onto the posts with
five grooves visible on all eight posts. Slide four
basket support bars onto the posts until bars slide
firmly over the supports. (See Figure 11)
9. Repeat step 8 one more time. (See Figure 11)
10. Snap eight sets of shelf supports directly above the
last set of basket support bars.
11. Slide two square shelves onto the posts until shelves
slide firmly over the supports. (See Figure 12)
LEFT SIDE OF THE UNIT
12. Snap four sets of shelf supports onto the left four
posts with twelve grooves visible between the lower
shelf.
13. Slide a square shelf onto the posts until it slides firmly
over the supports. (See Figure 13)
14. Repeat steps 12 and 13 twice. (See Figure 13)
ASSEMBLY CONTINUED
Figure 10
Fi g ure 11
Figure 12
Figure 9
Figure 13

0313 IH-2450PAGE 4 OF 4
RIGHT SIDE OF THE UNIT
15. Snap four sets of shelf supports at the top of the two
inner tall posts and two outer posts.
(See Figure 14)
16. Slide the rectangular shelf onto the posts until it
slides firmly over the supports. (See Figure 14)
17. Slide garment rod hangers onto garment rod.
(See Figure 15)
18. Slide the longer end of garment rod hangers
through the shelf wires. (See Figure 16)
19. Hook the short end of garment rod hangers onto the
center wire of the shelf. (See Figure 17)
20. Pull garment rod back and down, one side at a time,
until long end of garment rod hanger snaps into
place.
21. Once unit is assembled, slide the baskets in.
22. Insert pins in the center of the basket support bars.
ASSEMBLY CONTINUED
Figure 16
Figure 14
Figure 15
Fi gure 17
VIEW FROM THE BOTTOM
