Uberhaus SHOWER COLUMN 14925000 User manual


14925000
LIMITED LIFETIME WARRANTY
THANK YOU FOR PURCHASING THIS UBERHAUS SHOWER COLUMN. THIS PRODUCT HAS
BEEN MADE TO DEMANDING, HIGH-QUALITY STANDARDS AND ARE ONE YEAR GUARANTEED FOR
DOMESTIC USE AGAINST MANUFACTURING FAULTS. THIS WARRANTY DOES NOT AFFECT YOUR
STATUTORY RIGHTS.
IF THIS SHOWER COLUMN SHOULD EVER DEVELOP A LEAK OR DRIP DURING THE WARRANTY PERIOD,
WE WILL FREE OF CHARGE PROVIDE THE CARTRIDGES NECESSARY TO PUT THE FAUCET BACK IN
GOOD WORKING CONDITION UNDER NORMAL INSTALLATION, UES AND SERVICE. REPLACEMENT
PARTS MAY BE OBTAINED BY CALLING MECANAIR CUSTOMER SERVICE DIRECTLY AT 1-866-206-0888
OR VISIT WWW.MECANAIR.NET. PROOF OF PURCHASE (ORIGINAL SALES RECEIPT) FROM THE
ORIGINAL CONSUMER PURCHASER MUST ACCOMPANY ALL WARRANTY CLAIMS.
NORMAL WEAR AND TEAR, INCLUDING ACCESSORY WEAR, IS NOT COVERED UNDER THIS WARRANTY.
THE SHOWER COLUMN IS GUARANTEED IF USED FOR NORMAL TRADE PURPOSES, AND IS VALID FOR
THE ORIGINAL BUYER ONLY. ANY WARRANTY IS DEEMED INVALID IF THE FAUCET HAS BEEN USED
IMPROPERLY, OR SUBJECT TO NEGLECT. RONA IS NOT RESPONSIBLE FOR ANY COCTS RELATED TO
LABOUR, INJURIES OR ANY OTHER LOSS INCURRED DURING THE PRODUCT INSTALLATION, REPAIR
OR REPLACEMENT, INCLUDING ANY INDIRECT OR CONSEQUENTIAL DAMAGES.
DUE TO CONTINUOUS PRODUCT IMPROVEMENT, WE RESERVE THE RIGHT
TO CHANGE THE PRODUCT SPECIFICATIONS WITHOUT PRIOR NOTICE.
Installation instructions
SHOWER COLUMN
14925000 MODEL

/ (H)98cmx(W)14cmx(D)6.5cm
(1.5m)
±2.2

3
FEATURES
English
ingle-piecurvinaneesign
ultainlesteeasin
ingerprinesistananotechnologoating
justablprays
0-nozzlrainfallhowe


asnstalrackeystenonnectio
xistinhoweeautlet


)RUVDIHW\LWLVKLJKO\UHFRPPHQGHG\RXIDPLOLDUL]H\RXUVHOIZLWKDOODSSOLFDEOHORFDOSOXPELQJFRGHVDQG
WHPSHUDWXUHVDIHW\JXLGHOLQHVIRU\RXUDUHDEHIRUHVHWWLQJWKHWHPSHUDWXUHRQWKHVKRZHUSDQHOHVSHFLDOO\IRU
YHU\KRWZDWHUVHWWLQJV
Maximum operating pressure:
Recommended pressure:
Test pressure:
Max. hot water temperature:
Recommended hot water temperature:
Flow rate @ 80 psi:
Maximum operating pressure:
Recommended pressure:
Test pressure:
Max. hot water temperature:
Recommended hot water temperature:
Flow rate @ 80 psi:
125psi
50~80psi
20psi ,125psi
176 °F/80°C
120~160°F
<2.5gpm

117 Metal reinforcement band
su l
cr a
Chrome-plated PVC hand shower
g
g
pc
cc
h
cc w
p c t s h o c
c
r g
n c f

17

Groove Joint Pliers
that
The filter gasket (Part # 11)
The O ring gasket (Part # 6) must be installed to prevent water leakage. Manufacturer will not
install the O ring gasket correctly.

extender joint (Part # 4)

Installation Position
Body Height
Recommended range
area for user's height
(measured from top of
the tallest user's head)
MIN ½ Inch





STEPS TO USE TEMPLATE:
lace the template guide on the shower wall over the desired position for the shower panel.
ave the tallest user at home stand next to the template guide against the shower wall.
eeping the top of the tallest user's head level within the Recommended Range Area (marked as
darkened section at 25 1/4" and 31 1/3" height on template), find the desired height level relative
to the position of the 5 holes on top of the template).
etermine which of the five holes above the template is closest to the outlet of the existing
shower \ head with brass extender joint attached in Installation Part 3.
ark which hole is closest to the correct desired position and place the template against the
shower wall with shower head outlet/brass extender joint inside the hole marked.
ne the template position is selected and the shower head outlet is inside the selected hole,
double check to make sure the tallest persons' top-of-head level is still within the gray marked
area printed on the template.
Installation Template Guide
epending on user's height within
the grayed area of the Template
Guide, select the hole number
closest to the location of the
shower head outlet/brass
extender joint (Part 4)
An Installation Template Guide
is included with your shower
panel as a convenient method
of determining the correct
position of the shower panel
and drill in screw anchors/
screws.
INSTALLATION
English

17
(Part 17&Part 7).
17
required length of the main PVC supply line
(Part 8) relative to the final position of the
template guide
,
Cut
direction
O
e main PVC supply line hose
10

Hole


