Uplift Desk ACU021-60x27.4x31 User manual

© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Flathead Screws
(qty 12)
Clamp Bracket
(qty 6)
Support Bracket
(qty 6)
3-Sided Tall Acoustic Privacy Screen
ACU021-60x27.4x31, ACU021-72x27.4x31
Package Contents
Box 3Box 2Box 1
Back Panel
(qty 1. in 60’’ or 72” width)
Side Panel
(qty 2)
Corner Connector
(qty 2)
Step 2
Line up the pegs on the Support Bracket with a set of holes on a
Panel, and push them inside so the Support Bracket is ush with
the Panel. The long end of the Support Bracket should extend
towards the closest edge as shown in the rst image. From the
other side, line the Clamp Bracket up with the holes. Insert the
Flathead Screws and tighten until snug. Do not over tighten.
Repeat this for the second set of holes on the Panel.
Repeat this step for all Panels, so that each panel has two Sup-
port Brackets and two Clamp Brackets attached.
Step 3
Loosen all Clamps so that the openings are wide enough to
slide onto your desktop. The included Mounting Hardware will
t desktops between 0.75’’ and 1.75’’ thick.
Step 1
Remove the material from the pre-cut holes in the Acoustic
Panels with your ngertip or pencil. There are four holes per
Panel, they’re near the bottom of the panel at each end.
Step 4
Note: If you have a desk that isn’t an UPLIFT Desk or you have
a desktop that extends further than 2” from the desk frame side
bracket and you can’t slide the Clamp Bracket around the desk
frame side bracket, you can proceed to step 5.
Starting with a Side Panel, slide the front Clamp Bracket around
and inside of the front end of the desk frame side bracket as
shown.
Next, slide the back Clamp Bracket around and inside of the
back end of the desk frame side bracket.
Please note, the Privacy Screen can be installed with one person but it will be considerably easier to install the Privacy
Screen with the help of a friend during the later steps.

© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
CAUTION: Read all instructions before assembly. Failure to assemble properly may result in damage.
CAUTIONS & WARNINGS
!
!
Copyright Notice: This guide is a component of the UPLIFT Desk Product. This guide is a part of the scope of delivery, even if the item is resold. This guide is also available on the UPLIFT Desk website: upliftdesk.com. Ex-
cerpts or copies may not be forwarded to third parties or used in any other published form without the prior written consent of UPLIFT Desk. These instructions are subject to United States copyright law.
©
ACU021-60x27.4x31, ACU021-72x27.4x31-1.0
Step 6
The 90 degree bend of the Corner Connectors should be facing
the side of the Panel that the Clamp Brackets are on so they can
attach to the Side Panels. Press the Corner Connectors onto
the sides of the Back Panel so that they are equally spaced be-
tween the top and bottom edges of the Panel.
Repeat this on the other side of the Back Panel.
Step 7
Slide the Back Panel onto your desk bringing the Clamp Brack-
ets ush against the back of the desktop.
Hold the back panel steady and have a friend align and insert
the edges of the Side Panels into the Corner Connectors to
connect the Side Panels to the Back Panel.
Step 8
Once the Clamp Brackets are ush against the desktop and the
Side Panels are completely inserted into the Corner Connec-
tors, hold the Panels rmly in place while a friend tightens the
Clamps underneath the desktop.
Step 5
Once both Clamp Brackets are around the desk frame side
bracket, Align the back edge of the Panel with the back edge
of the desktop. Firmly press the Panel tight against the desktop
and tighten the Clamps to secure the Panel in place.
Note: When installed, the Side Panels will extend about one
inch past the front edge of a 30’’ desktop.
Repeat Steps 4 and 5 with the other Side Panel.
