Uplift Desk UPL961 User manual

Height Adjustable Conference Tables
42" Wide and Ping-Pong Size
UPL961 and UPL962
For assembly assistance, visit upliftdesk.com/contact, call 800-349-3839, or email
[email protected] ©2024 UPLIFT Desk®. All Rights Reserved. The following U.S.
Patents apply to this product, Patent No.: US 11, 109, 672 B2
Two person
assembly
Scan QR code for
Conference Table
webpage
Scan QR code for
Ping-Pong Table
webpage
Ping-Pong Size Conference Table
shown with center leaf section installed
42" Wide Conference Table
shown with center leaf section installed

2
Safety and Warnings
Please read these instructions carefully. This desk is height adjustable to t the user’s height.
Inappropriate use of this desk can cause property damage and/or bodily injury. Under no circumstances
does the manufacturer accept warranty or liability claims for damages caused from improper use of this
desk. Please provide these instructions to any new user or owner of the desk.
WARNING: Read all instructions before assembly. Failure to assemble or operate the desk properly may result
in damage or personal injury. Retain this manual for future reference or owners.
WARNING: Keep ngers and body parts clear of the moving desk edges. Check the desk’s surroundings on all
sides before raising or lowering the desk to ensure there are no obstacles that can be damaged or damage the
desk.
WARNING: Ensure all desk and accessory cords have enough slack so they don’t pull as the desk moves up
and down.
WARNING: Keep children away from the desk unless supervised. Misuse of the desk can cause personal injury.
If children cannot be supervised at all times, use the desk’s safety lock feature or remove the power cord to
prevent its operation.
WARNING: The desk is designed for use in dry indoor environments only. Use of desk outdoors or in damp
locations will damage the desk and can cause risk of electric shock, re, or personal injury.
WARNING: Only plug the desk into a properly grounded 100-240V power outlet. Using a voltage converter is
considered improper use and can cause damage to the desk.
WARNING: Do not open or insert any object into any desk frame component such as the legs or control box.
Doing so may cause damage and can cause risk of electric shock.
WARNING: In case of spilled liquid on any electrical desk component, disconnect the desk from the power
outlet immediately. Clean up the spill with a dry cloth and plug the desk back into the power outlet. There is a
risk of desk failure or electric shock if desk components become wet.
WARNING: Never use the desk if the power cord or plug becomes damaged as this can cause a risk of re and
electric shock. Contact UPLIFT Desk for a replacement power cord if it is damaged in any way.
WARNING: Risk of serious injury or death. Adjusting the height of the desk can pinch or crush body parts
trapped between the desktop and stationary objects. Do not place feet or other body parts on any items located
under the desk other than on approved items such as foot rests and desk mats.
WARNING: Be sure there is a gap of at least 1” between the moving parts of the standing desk and objects
located next to it to avoid pinch and crush hazards. Move the desk through its full range of motion to ensure
the 1” gap is maintained above, below, and all around the desk.
WARNING: Persons with limited mental or physical capabilities who are unable to comprehend the safe
operation of the height adjustability feature must be supervised and must not operate the desk.
WARNING: Inspect the desk regularly and stop using immediately if you notice any damaged or loose parts.
Only replace damaged desk parts with authorized UPLIFT Desk parts.

3
© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Desk image is for reference only and may not match your desk model.
Max
Height
Min
Height
Keep a vertical gap
of greater than 1”
between items
on desk and any
obstructions above.
Keep a horizontal
gap of greater than 1”
from desk to wall and
other furniture.
Do not place feet on items
below the desk where they
can be injured.
Desk Spacing and Clearance Distances

4
Leg
qty 4 Crossbar End qty 4 Crossbar Rail qty 4 Side Bracket qty 2 Control Box Keypad
Type varies
Power Cable Leg
Extension Cable
qty 4
(2 long & 2 short)
Wire
Management Tray
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
Support
Bracket
qty 3
Foot
qty 2 Control
Box Bracket
M6 x 10 Screw
qty 24
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
M6 x 14 Screw
qty 16
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
M8 x 8
Set Screw
qty 16
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
#10-24 x 3/4"
Screw
qty 30
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
Washer
qty 30
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
4mm
Allen Wrench
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
Cable Mount
qty 20 #10 x 5/8’’
Wood Screw
qty 6
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
Allen
Wrench Handle
Small
Hole Plug
qty 4
Small16mm Plug
Small16mm Plug
Large
Hole Plug
qty 4
Large 22mm Plug
Large 22mm Plug
Components (packed in multiple boxes)
Hardware (packed in multiple boxes)
P9P7 P8 P10 P11
P4 P5 P6P3P1 P2
Package Contents
P12
Phillips Screwdriver
You’ll also need
H1
H9
H6H3
H15
H2
H14 H18
H4b
H17
H5

5
© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Parts Diagram
Foot
M6x10 Machine Screw
M6x10 Machine
Screw
Side Bracket
Side Bracket
M6x14 Machine Screw
M8x8 Set Screw
Support Bracket
Support Bracket
Support Bracket
Crossbar End
Crossbar Rail
Crossbar Rail
Leg

6
Assembly Instructions
Step 1 - Inventory of Parts
A. To avoid damage to the oor or tabletop, assemble the
conference table on a clean carpet or blanket.
B. Lay out all parts from each box and ensure you have
everything listed in the package contents of this
manual before throwing away any packaging.
If a part is missing, please triple check that the part
isn’t in a box. Check boxes thoroughly by removing all
packaging; check every nook and cranny. If the part is
still missing, email [email protected] or call
[phone] before beginning assembly.
Assembly Instructions
P2
H1
H1
P1
Step 2 - Attach Crossbar Ends
A. Place one of the Crossbar Ends (P2) upside down as
shown.
B. Align the back of the Crossbar End with the back of
one of the Legs (P1).
C. Using the 4mm Allen Wrench (H6), loosely insert four
M6x10 Screws (H1) through the Crossbar End holes and
into the leg as shown, but do not tighten them.
D. Once all four screws have been started, tighten them
using the Allen Wrench.
E. Repeat this step for the remaining three Legs and
Crossbar Ends.
Step 3 - Attach Side Brackets
A. Align the holes in one of the Side Brackets (P4) with
the threaded metal inserts in one of the main sections
of the tabletop as shown.
B. Using a Phillips Head Screwdriver, loosely insert
one #10-24x3/4" Screw (H4b) and one Washer (H5)
through each Side Bracket hole and into the threaded
insert as shown.
C. Once all four screws are started, tighten them
completely.
D. Repeat these steps to attach the second Side Bracket
to the other main section of the tabletop.
P4

7
© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
H4b
H5
P1
P1
Step 4 - Attach Legs
A. Slide two Leg Assemblies (P1) from Step 2 onto the
tabs of the Side Bracket (P4) as shown.
Step 5 - Insert Crossbar Rails
The optional center leaf section is not required, if you are
assembling without the center leaf section, the same
steps will apply. The tabletop leaf should be used for
regulation size ping-pong tables.
A. Position the tabletop sections and the four Crossbar
Rails (P3) as shown.
B. Slide the tabletop sections together ensuring that the
four Crossbar Rails are inserted into the Crossbars
Ends on each side.
Step 6 - Attach Crossbar Ends to
Tabletop
A. Using a Phillips Head Screwdriver, loosely insert
one #10-24x3/4" Screw (H4b) and one Washer (H5)
through each Crossbar End and into the tabletop as
shown.
B. Once all four screws are started, tighten them but be
careful to not overtighten to avoid stripping.
P3
H1
H1
B. Loosely insert two M6x10 Screws (H1) through the top
of each Crossbar End (P2) and into the Side Bracket as
shown. Once all four screws have been started, tighten
them using the 4mm Allen Wrench (H6).
C. Repeat these steps to attach the other two Leg
Assemblies to the other Side Bracket.

8
Step 8 - Position Crossbar Rail
A. Slide each Crossbar Rail (P3) left or right until the center
indicator mark is located approximately in the middle of
the Crossbar Ends (P2).
Step 7 - Attach Support Brackets
A. Align the holes in each of the Support Brackets (P10) with
the threaded metal inserts along the sides and in the
center of the tabletop sections as shown.
B. Using a Phillips Head Screwdriver, loosely insert one #10-
24x3/4" Screw (H4b) and one Washer (H5) through each
Support Bracket and into the threaded metal insert in the
tabletop as shown.
C. Once all screws are started, ensure the tabletop sections
are tight against each other with no gaps and tighten the
screws, being careful to not overtighten to avoid stripping.
Step 9 - Attach Feet
A. Place a Foot (P11) on top of two of the Legs (P1), with the
leveling glides facing up as shown.
B. Loosely insert eight M6x14 Screws (H2) through the holes
in the Foot and into the eight threaded holes in the ends
of the two Legs.
C. Once all eight screws have been started, tighten them
with the 4mm Allen Wrench.
D. Repeat the previous steps for the second Foot.
E. Do one nal tightening of all foot screws. Tight foot
screws signicantly improve stability.
Step 10 - Attach Keypad
UPLIFT Desk Conference Table tops include a set of Keypad
mounting holes on both the left and right hand sides of each
main section of the tabletop.
A. Align the mounting holes of the Keypad with the pre-
drilled holes in the tabletop.
B. Use a Phillips Screwdriver to attach the Keypad to the
tabletop with two #10 x 5/8" Wood Screws (H14). Be
careful not to overtighten the screws to avoid stripping.
Basic Display Angled Keypad
shown for reference
Advanced Comfort Angled
Keypad shown for reference
H3
H2
P11
B. Insert four M8x8 Set Screws (H3) into the holes in each
Crossbar End and tighten using the 4 mm Allen Wrench
(H6).
P3
Center indicator marks
P6
H14
P6
H14

9
© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Step 11 - Attach Control Box
A. If you are assembling with the center leaf section:
Align the Control Box Bracket (P12) with the pre-drilled
holes in the center leaf section as shown, you can
ignore the arrows in the image.
If you are assembling without the center leaf section,
attach the Control Box Bracket to the holes indicated
by the arrows.
B. Using a Phillips Head Screwdriver, attach the Control
Box Bracket to the tabletop with two #10x5/8" Wood
Screws (H14). Be careful to not overtighten to avoid
stripping.
Step 12 - Connect Cables
A. Connect the Power Cable (P7) to the port on the Control
Box labeled “AC”.
B. Connect the two long Leg Extension Cables (P8) to the
cables from the two front Legs.
C. Connect the two short Leg Extension Cables (P8) to the
cables from the two back Legs.
D. Connect the four Leg Extension Cables into the Control
Box ports marked M1, M2, M3, and M4 (it doesn't matter
which Leg Extension Cable is plugged into which M port).
E. Connect the Keypad cable into the Control Box port
labeled “HS”.
The Control Box port labeled “F” is used to connect the
Bluetooth Adapter (FRM125) for use with the UPLIFT Desk
App.
The Control Box port labeled “DC” is used to connect low
voltage accessories with compatible connectors.
P5
P12
H14
Mounting Hooks
AC Port
M1 M2 M3 M4
AC DC F HS
M1 M2 M3 M4
AC DC F HS
Leg Extension
Cable Channel
C. With the Control Box oriented with the bracket as
shown, slide it onto the bracket so that the mounting
hooks on the bottom of the Control Box are engaged
with the large raised section of the bracket.
AC
M1 M2 M3 M4
DC FHS

10
If you have purchased accessories that attach to your conference table such as Casters, Wire Management, CPU Holders,
or Desk Drawers, it is easiest to install them now before ipping the table over. Refer to the assembly instructions provided
with those products.
Attach Cable Mounts
Cable Mounts (H9) are provided to organize cables under the
tabletop. Organizing cables improves the appearance of your
table and prevents cables from snagging on anything while
the table is moving up and down.
IMPORTANT: The adhesive backing on the Cable Mounts
is very strong, so carefully consider where you would like to
locate them before attaching to the bottom of the tabletop or
table frame.
Hook and loop strips can be used without the plastic mounts
in places where they can be slid through the gap between the
underside of the tabletop and the frame.
A. Peel the backing off the back of the plastic mount to
expose the adhesive pad.
B. Position the mount where you would like to attach it and
press rmly for 10 seconds.
C. Take one of the hook and loop strips and slide it through
the openings in the plastic mount.
D. Bundle cables and wrap the hook and loop strip around
the bundle to secure it in place.
Caster Installation (optional)
If you purchased Casters for your table, we recommend
installing them now.
A. Remove the Leveling Glides from the Feet by rotating
them counterclockwise to unthread them from the
mounting holes.
B. Install a Caster in each of the mounting holes by
turning the stem of the Caster clockwise, threading it
into the hole. Use a 12 mm or ½" at wrench to tighten
Casters that include a hex nut on the threaded stem for
tightening. Tighten rmly.
Hook and loop strip
Plastic mount
H9
H9
Accessory Installation

11
© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Attach Wire Management Tray (optional)
A. Position the Wire Management Tray (P9) where you would
like to attach it to your table. The tray can be attached
with the opening facing the center (as shown) or the side.
Position the opening where it will be most convenient for
you to access.
B. Use a Phillips Screwdriver and two #10 x 5/8" Wood
Screws (H14) to attach the Tray to the tabletop.
IMPORTANT: Double Check Screws Are Tight
Since the table is upside down, take this opportunity to double
check that all of the screws are tight using the 4mm Allen
Wrench and Phillips Screwdriver.
his is an important step, and it is much easier to ensure they
are tight now before ipping the table upright. Loctite is pre-
applied to all screws to keep them tight over time, so if you
tighten thoroughly this one time, you’re all set.
Hole Plugs (optional)
If you prefer to cover the four large holes in the front and
back of the upper frame section, use the provided Small
Hole Plugs (H17) and Large Hole Plugs (H18). The smaller
plugs t in the holes that are closer to the side of the table
and the frame Side Bracket while the larger plugs t in the
holes further away from the sides of the table. See images for
reference.
Arrows are pointing to all screw locations to check. If
the center leaf section is not installed, there will be
six fewer screws.
H17
H18
Large 22mm Plug
Large 22mm Plug
Large Hole Plugs (H18).
Large Hole Plug
Small Hole Plug
Small16mm Plug
Small16mm Plug
Small Hole Plugs (H17).
P9
H14

12
Table Placement
To avoid injury or damage to the table, we recommend
using three to four people to ip the assembled
conference table over. When preparing to ip the table, be
aware of loose cables.
A. With one person located at each end of the table and
one or two people along the long side with the Keypad
as shown, begin to tilt the table up slowly so that the
Keypad is facing up and the far ends of the Feet are
touching the oor.
B. Readjust your grip and continue to rotate the table
until it is right side up with both Feet completely on
the oor.
C. Position the table where you would like it to be. Never
lift the table by just the tabletop—doing so puts undue
stress on the attachment screws. Be sure to hold the
frame Side Brackets when lifting.
If your table has Casters, moving is easy. If your Casters
include locks, make sure they are unlocked and roll
the table to the desired location. Be sure to relock the
Casters to keep the table stationary.
D. If your table does not have Casters, using two people,
lift your table (do not drag it) by holding onto the
tabletop and Side Brackets together.
Prepare Table & Surroundings
A. Check the table’s surroundings to make sure there will
be no obstacles within the table’s path while it is being
raised or lowered. Do not place any objects underneath
the table that are taller than 21" and be aware of any
accessories mounted above or below your table.
B. Adjust the Leveling Glides as needed to level the table.
Each Leveling Glide provides up to ⅜" of leveling.
C. Ensure that the table's Power Cord and all other power
cords used are long enough to accommodate the
height adjustment of the table.
D. Plug the table into a grounded, 100-240V power outlet.
If you have a Keypad with a display, you should see it
light up, conrming the table is powered. If you have
a Keypad without a display, look at the Control Box
under the table to see if the small indicator LED is
illuminated.
E. Perform the Table Reset Procedure below before regular
use.
F. Slowly lower and raise the table while watching all
cables and clearances to ensure there are no cable
snags or obstacles.
Power Indicator LED

13
© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Perform Table Reset Procedure
IMPORTANT: Before using your table, perform the Table Reset Procedure below to sync the Legs and Control Box.
1. Remove all items from under the table to allow it to travel to its lowest height.
2. Press the down button once.
3. Hold the down button until the table stops at its lowest position.
4. Hold the down button again for 30 seconds or until the display changes. (Keypads with a display will show “ASr”, Paddle
Keypads will show “RESET”).
5. Hold the down button again until the table lowers slightly, rises, and stops. If the table didn’t move, try this step again.
6. Try operating the table. If the table is working properly, you’re done. If the table is not working properly, continue with the
following steps.
7. Unplug the power cord from the electrical outlet.
8. Hold the down button for 10 seconds to discharge any stored power in the control box.
9. Plug the table back in and restart the reset process steps a second time.
10. Try operating the table again. If the table is working properly, you’re done and the table is ready to use.
If you have an Advanced Keypad, see the Programming section below for further information on how to use your Keypad.
Programming instructions for Paddle Keypads come with the keypad.
These UPLIFT Desk programming instructions are compatible with all UPLIFT Advanced Keypads except the Advanced
Paddle Keypad.
For Advanced Paddle Keypad programming steps, refer to the instructions provided with that Keypad.
Programming (Advanced Keypads only)
Set & Use Memorized Heights
Save heights on the keypad:
1. Hold the up or down button to move the desk to the
desired height.
2. Tap the “M” button followed by a number button (1, 2, 3,
or 4) to assign the current height to that number.
3. Once the memory buttons are programmed, tap a
numbered button and the desk will automatically
move to the preset height.
If you would rather the button be pressed and held
instead of tapped to make height adjustments, see One-
Touch or Constant-Touch below.
Keypad Lock
Lock the keypad to prevent accidental adjustments:
1. Hold the “M” button until the display shows “LOC.”
2. To unlock your keypad, hold the “M” button until the
display shows the current numeric height setting.
In the event of a power outage, the keypad will return to
the unlocked setting.

14
Calibrate Desk Height
Compare the desk height to the displayed height:
1. Press and hold the “down” button until the desk
reaches its lowest position.
2. Use a tape measure to check the height from the oor
to the top surface of the desktop. If the measurement
matches the displayed height, the desk is already
calibrated and ready for use.
Max/Min Height Limits
Set the desk’s maximum height limits:
1. Hold the up or down button to move the desk to the
desired height.
2. Tap the “M” button once and “S-” will appear on the
display.
3. Tap the up button and the display will ash “S-.”
4. Hold the “M” button until the display shows “999” and
changes to the numeric height of the now set upper
limit.
Remove the maximum and minimum height limits:
1. Tap the “M” button once and the display will show “S-.”
2. Hold the “M” button until the display shows “555” and
changes to the current numeric height setting.
If the displayed height doesn’t match the desk’s actual
height, follow these steps:
1. Hold the down button until the display ashes “ASr.”
2. Hold the “M” button until the numeric display begins
ashing.
3. Tap the up or down button to adjust the displayed
height to match your desk’s measured height.
4. Wait for the display to change back to “ASr.”
5. Hold the “down” button until the desktop lowers and
rises slightly and the display changes back to the
numeric height setting.
Set the desk’s minimum height limits:
1. Hold the up or down button to move the desk to the
desired height.
2. Tap the “M” button once and “S-” will appear on the
display.
3. Tap the down button and the display will ash “S-.”
4. Hold the “M” button until the display shows “000” and
changes to the numeric value of the now set lower
limit.
One-Touch, Constant-Touch,
or Double-Tap
One-touch is the default setting of the control box and
requires only a single touch of a keypad button to move
the desktop to a saved height. Constant-touch requires
the continuous hold of a button or paddle to move the
desktop to a saved height. Double-tap requires pressing
the keypad button twice to move the desktop to a saved
height. This helps avoid accidental activation of the desk
if a keypad button is bumped.
Toggle between one-touch and constant-touch modes:
1. Hold the down button until the desk reaches its lowest
position.
2. Hold the down button again until the display ashes
“ASr.”
3. Hold the “1” button until the display shows “10.1”
(one-touch), “10.2” (constant-touch), or “10.8” (double-
tap), and then goes back to “ASr.” While the display is
ashing “ASr,” hold the “1” button to toggle between
the three settings.
4. Wait for the display to change back to “ASr.”
5. Hold the “down” button until the desktop lowers and
rises slightly and the display changes back to the
numeric height setting.
Units of Measurement
Switch between inches and centimeters on your display:
1. Hold the down button until the desk reaches its lowest
position.
2. Hold the down button again until the display ashes
“ASr.”
3. Hold the “2” button until the display shows “10.3”
(centimeters) or “10.4” (inches) and then goes back to
“ASr.” While the display is ashing “ASr,” hold the “2”
button to toggle between the two settings.
4. Wait for the display to change back to “ASr.”
5. Hold the “down” button until the desktop lowers and
rises slightly and the display changes back to the
numeric height setting.

15
© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Anti-Collision System Sensitivity Adjustment
Adjust the sensitivity on your desk’s advanced anti-collision system:
1. Hold the down button until the desk reaches the lowest position.
2. Hold the down button again until the display ashes “ASr.”
3. Hold the UP button until the display shows “10.5,” “10.6,” or “10.7”. This is your current anti-collision sensitivity setting.
10.5 = most sensitive setting (possible false positives)
10.6 = moderate sensitivity setting
10.7 = least sensitive setting
While “ASr” is ashing, press the up button to toggle between the three settings.
4. Wait for the display to change back to “ASr.”
5. Hold the “down” button until the desktop lowers and rises slightly and the display changes back to the numeric height
setting.
Troubleshooting
Starting & Stopping
If your desk is continuously starting and stopping as you try to raise or lower it, check to make sure the Control Box is
securely attached to the frame. The Control Box MUST be attached to your frame in order for your desk to function properly.
Error Code Description Troubleshooting Solution
H01 Overheated The desk motor has a 10% duty cycle to protect from overheating. For example, in a 20
minute period if your desk motor is activated for 2 minutes you will want to let it rest for 18
minutes. Otherwise you may see an H01 code on your keypad
E01-E06 Firmware or
connectivity issues Check all cables to ensure they’re all rmly plugged in, and perform Reset Procedure above
E07-E012 Legs are uneven Perform Reset procedure
Desk Reset Procedure
If your keypad display shows any of the error codes listed, perform the Desk Reset Procedure provided at the end of the
desk assembly steps to clear it. If the error message persists after performing the reset procedure or if there is a height
difference between the Legs of more than 1.5”, email us at [email protected] or call 800-349-3839.
Perform the desk reset procedure any time the desk is unplugged or loses power.

SAVE THIS MANUAL
Study this manual carefully. If this product is sold, please provide this manual to the buyer, installers, or support personnel operating the product.
Copyright Notice: This manual is a component of this UPLIFT Desk product. This manual is a
part of the scope of delivery, even if the item is resold. This manual is also available on the
UPLIFT Desk website: upliftdesk.com. This manual is subject to United States copyright law.
©
upliftdesk.com
[email protected]
800-349-3839
512-614-3152
3293374182312 INS-UPL961-962-PPC
