PROGRAMMING YOUR UPLIFT DESK
®
© UPLIFT Desk • 800-349-3839 • 512-614-3152 • [email protected]om • upliftdesk.com
V2 & V2 COMMERCIAL 2-LEG HEIGHT ADJUSTABLE FRAME
These UPLIFT Desk programming instructions
are compatible only with Memory keypads.
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
HEIGHT CALIBRATION
Make sure the numeric display matches the actual height of the desktop in its lowest position.
1. Hold the DOWN button on the Keypad until the desk reaches its lowest height, then release.
 2. Measuretheheightfromtheoortotheundersideofthedesktop.Ifthedisplayedheightdoes
not match your measurement, follow the next steps.
3. Hold the DOWN button again until the LED display reads “RST”.
 4. Pressthe“M”buttonuntilthenumericdisplaybeginsashing.
5. Press the UP or DOWN button to set the desk to the measured height.
6. Once display changes back to “RST”, Hold the DOWN button until the desktop lowers slightly,
then rises slightly and the display changes back to the numeric height setting, then release.
*Note: “RST” will look like
“ASr” on the display
KEYPAD LOCK
The Keypad can be locked to prevent accidental activation or movement of the desk and to pre-
vent desk settings from being accidentally changed by children or coworkers.
To lock: Press and hold “M” button until display changes to “LOC”.
To unlock: Press and hold “M” button until display changes to numeric height setting.
NOTE: If a power outage occurs, the program will automatically return to the unlocked setting.
MEMORY SETTINGS
Save up to four commonly used desk heights and recall them quickly.
l. Use the UP or DOWN button to move the desk to the desired height.
2. Press the “M” button.
3. Press the “1, 2, 3, or 4” button to assign the current height to a number on the keypad.
4. To bring the desk back to any of those assigned heights, press the numbered button.
CONSTANT-TOUCH & ONE-TOUCH
These steps allow the desktop to be set to either One-Touch or Constant-Touch. One-Touch requires
only a single touch of the “1, 2, 3, or 4” button to move the desktop to a preset memory location.
One-Touch is the default setting. Constant-Touch requires a continuous touch of the “1, 2, 3, or 4” but-
ton to move the desktop to a preset memory location.
Change between One-Touch and Constant-Touch:
l. Hold the DOWN button on the Keypad until the desk reaches the lowest height, then release.
 2. HoldtheDOWNbuttonagainuntildisplayashes“RST”.
3. Press the “1” button until display shows “10.1” (One-Touch) or “10.2” (Constant-Touch)
and goes back to “RST”.
Note:While“RST”isstillashing,youcanpressthe“1”buttonasmanytimesasyou’dlike
to toggle between the two settings.
4. Hold the DOWN button until the desktop lowers slightly, then raises slightly, and the display
changes back to the numeric height setting, then release.

DISPLAY UNITS
Change the numeric display to show heights in either inches or centimeters.
l. Hold the DOWN button on the Keypad until the desk reaches the lowest height, then release.
 2. HoldtheDOWNbuttonagainuntildisplayashes“RST”.
3. Press the “2” button until display shows “10.3” (centimeters) or “10.4” (inches) and goes
back to “RST”.
Note:While“RST”isstillashing,youcanpressthe“2”buttonasmanytimesasyou’dlike
to toggle between the two settings.
4. Hold the DOWN button until the desktop lowers slightly, then raises slightly, and the display
changes back to the numeric height setting, then release.
MINIMUM & MAXIMUM HEIGHT SETTINGS
The desk frame ships with default minimum and maximum height limits. These steps allow the upper
and lower limits to be changed to your preference.
Note: If memory settings were previously set outside of the new minimum and maximum height
settings, they will default to the new minimum and maximum settings. To set new minimum and
maximumheightsettingsoutsideofthecurrentsettings,youwillneedtorstremovethecurrent
minimum and maximum settings.
To set a new maximum desk height:
l. Use the UP or DOWN button to bring the desk to the desired maximum height.
2. Press the “M” button once, and “S-” will appear on the Display. Immediately follow by
  pressingtheUPbuttononce,sothe“S-”ashesonce.
3. Hold the “M” button until the Display shows “999” then changes to numeric value of new
upper limit.
To set a new minimum desk height:
l. Use the UP or DOWN buttons to bring the desk to the desired minimum height.
2. Press the “M” button once, and “S-” will appear on the Display. Immediately follow by
  pressingtheDOWNbuttononce,sothe“S-”ashesonce.
3. Hold the “M” button until the Display shows “000” then changes to numeric value of new
lower limit.
Removing adjusted maximum and minimum heights:
l. Press the “M” button once and the display will show “S-”.
2. Hold the “M” button again until the display shows “555” then changes to the current
numeric height setting.
CB-FRMA-2-1.0
DESK RESET PROCEDURE
If your desk stops functioning or you have an Advanced keypad and see an error code in the display,
try to reset your desk using the following reset procedure. Be sure to write down the error code as
you may need it later.
1. Press and hold the DOWN button for about 30 seconds,
or until the LED display reads “RST”.
2. Release the DOWN button.
3. Press and hold the DOWN button again until the desk lowers all the way down,
then rises slightly and stops.
4. Release the DOWN button again. At this point your desk should have been reset
and you should see a number in the display if you have an Advanced keypad.
If your desk still does not function after the reset procedure or if the reset procedure is not working,
please contact us at 800.349.3839 and have your error code available.
© UPLIFT Desk • 1-800-349-3839 • [email protected] • upliftdesk.com
*Note: “RST” will look like
“ASr” on the display
