UPPAbaby 2010 VISTA User manual

RumbleSeat

ENGLISH
WARNINGS + SAFETY INFORMATION Page 2
PARTS LIST Page 3
RUMBLESEAT ASSEMBLY Page 4
RUMBLESEAT OPERATION Page 5
RUMBLESEAT CONFIGURATIONS + CARE Page 6
TABLE OF CONTENTS
Please read these instructions carefully prior to assembly and use.

UPPAbaby RumbleSeat Instruction Manual
2
WARNINGS + GENERAL SAFETY
INFORMATION
WARNINGS
AVOID SERIOUS INJURY FROM FALLING OR SLIDING OUT–
ALWAYS USE THE SEAT HARNESS. NEVER LEAVE CHILD UNATTENDED!
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
NOTE: Throughout this document we will be
referring to the RumbleSeat and the main seat.
The main seat is the original seat that attaches
to your VISTA.
• Read all instructions before using this product.
Failure to follow instructions properly may result
in serious injury to your child.
• Intended for use with UPPAbaby 2009 model year
VISTA stroller or later (VISTA will have a
manufacture date of August 2008 or later).
NOTE: RumbleSeat can be used with earlier
models if the frame is modified by certified
UPPAbaby personnel.
• RumbleSeat is not recommended for children
under 6 months of age or over 35 pounds.
• Always fasten and secure 5-point harness system
when using this product.
• Never leave children unattended.
• Any load attached to the RumbleSeat may
affect the stability of the stroller. Do not
hang luggage or other bags on the seat.
• DO NOT allow child to stand while in the
RumbleSeat.
• Apply brakes when loading or removing
the children.
• DO NOT lean or press on the RumbleSeat
with excessive force. Please follow the
maximum weight guidelines.
• Always push the stroller with both hands when
using the RumbleSeat.
GENERAL SAFETY INFORMATION:
• Before each use, inspect your RumbleSeat to
make sure the brackets are fully engaged
by pushing down on the top of the RumbleSeat
firmly. NOTE: It should not move.
• Stroller can fold with footpad attached, however,
the RumbleSeat must be removed and the main
seat must be facing forward and in an upright
position.
IMPORTANT! LOAD YOUR FIRST
CHILD INTO THE MAIN SEAT
• After first child is secured in the main seat, place
your second child into the RumbleSeat.
• DO NOT place child in the RumbleSeat without
a child in the main seat.
• If loading your child into the RumbleSeat from the
top, be careful of recline handle on main seat.
WARNINGS + GENERAL SAFETY INFORMATION

3UPPAbaby RumbleSeat Instruction Manual
CANOPY
RUMBLESEAT
FOOTPAD
PARTS LIST

UPPAbaby RumbleSeat Instruction Manual
4
RUMBLESEAT ASSEMBLY
STEP 2: Fasten Velcro around inner basket bar.STEP 1: Attach plastic hook on end of footpad
around front basket bar.
INSTALLING FOOTPAD
STEP 3: After RumbleSeat is
attached, loop buckle around
VISTA frame and snap.
STEP 3: Snap plastic canopy tabs
into slots on sides of seat just above
attachment mechanism.
STEP 2: Once aligned, place your
foot on VISTA frame and pull down
on RumbleSeat to lock in place.
STEP 2: Wrap webbing strap around
frame and connect c-clip.
ATTACHING RUMBLESEAT TO vISTA FRAME
FASTENING SEAT STRAPS
STEP 1: Starting at footrest, slide
RumbleSeat up VISTA frame until
brackets are about 1” below heads
of screws.
STEP 1: Connect snaps on seat to
both sides of frame.
NOTE: Lock VISTA frame before attaching the RumbleSeat.
NOTE: Brackets should “snap” and lock into the VISTA frame.

5UPPAbaby RumbleSeat Instruction Manual
RUMBLESEAT OPERATION
STEP 2: Pull attachment loop from desired harness
loop. Reattach clip to the desired harness loop.
ADjUSTING THE HARNESS
STEP 1: Remove harness pad and detach metal
adjustment clip from upper attachment loop.
TO UNLOCK: Depress button at center and pull apart.
STEP 2: Slide RumbleSeat down and lift out in
one motion.
TO LOCK: Slide both belt ends together until they lock.
STEP 1: Detach loop buckle from VISTA frame. Place foot
on front cross-bar of VISTA frame and push on top of
RumbleSeat toward main seat.
USING THE HARNESS
REMOvING RUMBLESEAT FROM vISTA FRAME

UPPAbaby RumbleSeat Instruction Manual
6
RUMBLESEAT CONFIGURATIONS
MODE 1 (FORWARD FACING SEAT)
Seat forward facing (upright and reclined) from 0-6 months.
MODE (REAR FACING SEAT) MODE (INFANT CAR SEAT)
Seat rear facing (upright position only). Age based on manufacturers’ recommendations.
WARNING: RumbleSeat CANNOT be used with the Bassinet.
RumbleSeat CANNOT be used with the seat rear facing in reclined position.
In all modes, the RumbleSeat accomodates infants and toddlers from 6 months – 35 lbs.
CLEANING Spot clean gently with
mild detergent.
Dry flat and away from direct
sunlight before re-use or storage.
DO NOT bleach, iron
or dry clean.

7UPPAbaby RumbleSeat Instruction Manual
WARNINGS + GENERAL SAFETY
INFORMATION
LIMITED WARRANTY
Your UPPAbaby item is warranted to be free from any manufacturing defects for a period of 2 years from
the date of purchase under normal use and in compliance with the operating instructions.
This warranty extends ONLY to the original retail purchaser and is ONLY valid when supplied with proof
of purchase. Please retain proof of purchase with this Limited Warranty.
This warranty is subject to the conditions set forth by the country in which the items were purchased.
Conditions may vary.
Please note that a repair issue will NOT be covered by this warranty if:
• The issue is caused by misuse or poor maintenance. Please refer to this instruction booklet for guidance on item
use and maintenance.
• Damage is caused by improper installation of UPPAbaby parts and/or accessories. Please refer to this instruction
booklet for guidance on item assembly and use.
• Damage is corrosion caused by lack of maintenance or service.
• Damage is due to general wear and tear which is the result of everyday use or negligence.
• Damage is caused by sun intensity, sweat, detergents, damp storage or frequent washings.
• Repairs or modifications are carried out by a third party.
• Item is purchased from an unauthorized retailer. Approved retailers are listed on our website, www.uppababy.com
• Item is second hand.
• Item is damaged as a result of an accident, airline or freight damage.
UPPAbaby reserves the right to determine if warranty terms and conditions have been met.
Please contact us in the USA at 339-499-7455 or email us at [e-mail] if you have any questions
regardingyour warranty. In Canada, please contact 5514 Km Corporation at 888.502.5514 or email [email protected].
For a list of other countries and distributors please refer to our website at: www.uppababy.com/contact
CUSTOMER SERvICE
COUNTRY CONTACT TELEPHONE WEBSITE
US 60 Sharp Street Hingham, MA 02043 339.499.7455 www.uppababy.com
CANADA
Distributed by/Distribué par 5514KM
19 Industrial Street
Toronto, Ontario M4G 1Z2, Canada
416.422.2700
toll free: 1.888.502.5514 www.5514km.ca
IRELAND
Distributed by Kids Factory
Kinsealy Business Park
Kinsealy Co.Dublin
+ 353 (0) 818.227028 www.uppababy.ie
UK
Distributor Corporation UK Limited
5 Percy Street, Office 4
London W1T 1DG, UK
0845.618.5954 www.uppababy.co.uk
SPAIN
Distributed by Madu
Calle Edetania, 16
46160 Llíria (Valencia), España
(+34) 902.760.553 www.madu.es

www.uppababy.com
60 Sharp Street Hingham, MA 02043
781.413.3000
Model 0050 / Version 2
VISTA and UPPAbaby are trademarks and/or registered trademarks of Monahan Products LLC.
All other trademarks are the property of their respective owners.
