VERTIV™ CYBEX™ SC 840D/845D
AND 940D/945D KVM SWITCHES
Quick Installation Guide for 4-Port DisplayPort
The following instructions will help
you install your Vertiv™ Cybex™SC
840D/940D/845D/945D switch.
WARNING: This product is equipped
with active intrusion protection. Tamper-
ing may permanently disable the switch
and void the warranty. If the enclosure
appears to have been tampered with or
if all the port LEDs ash continuously,
please contact Technical Support. This
product also has tamper evident seals.
Broken or removed seals will void the
warranty.
1. Connecting local peripherals
Turn o all computers you
plan to use with your SC
840D/940D/845D/945D switching
system. Plug the monitor cable
into the appropriate CONSOLE
port on the back of the switch.
Plug the USB or PS/2 keyboard
and mouse cables, speaker or
headset cable and Common
Access Card (CAC) device into the
appropriate ports.
2. Turning on your system
Turn the monitor on. Plug the
power supply cord into the switch.
Plug the other end of the power
supply cord into an AC wall outlet.
The display diagnostic LED should
be solid green a few seconds after
power is applied. This indicates the
display EDID information has been
captured and secured.
3. Connecting computers to the
switch
Make sure all computers are turned
o. Plug the monitor, speaker,
keyboard and mouse cables from
the corresponding computer into
one of the ports on the switch.
Repeat for all computers.
NOTE: The cables must be
connected directly to a free USB
port on your computer with no USB
hubs or other devices in between.
4. CAC device conguration
and operation (applies to SC
845D and SC 945D models
only)
Using a USB cable, connect one
end of the cable to the computer
that requires CAC, and the other
end to the CAC port on the
switch that corresponds to the
computer. Enable CAC for the
port connection by switching the
CAC switch to the right. Repeat
the previous steps for additional
computers that require CAC.
1
1
3
4
2
Vertiv™ Cybex™ SC 945D Switch Shown

VertivCo.com |Vertiv Headquarters, 1050 Dearborn Drive, Columbus, OH, 43085, USA
© 2017 Vertiv Co. All rights reserved. Vertiv and the Vertiv logo are trademarks or registered trademarks of Vertiv Co. All other names and logos referred to are trade names, trademarks or
registered trademarks of their respective owners. While every precaution has been taken to ensure accuracy and completeness herein, Vertiv Co. assumes no responsibility, and disclaims all
liability, for damages resulting from use of this information or for any errors or omissions. Specications are subject to change without notice.
590-1485-501A
2
VERTIV™ CYBEX™ SC 840D/845D AND 940D/945D KVM SWITCHES
Quick Installation Guide for 4-Port DisplayPort
NOTE:Make sure that the CAC
switch is disabled (switched left)
for all other non-connected CAC
systems.
Once congured, the CAC
connection will be switched only
when required by the connected
computer. When switching from a
CAC enabled port to a non-CAC
enabled port, the CAC connection
will remain with the last previously
selected port where the CAC was
enabled.
5. Turning on the computers
Turn on all the attached
computers and check for display
and peripheral functionality.
6. Switching your computers
When you turn on your computers,
the computer connected to the
front panel will be displayed.
Press the corresponding front
panel button (1 through 4) on the
switch to access the computers
on your SC switching system. The
front panel button of the selected
computer will illuminate.
Supported Hardware
The SC switches support most DVI,
HDMI, VGA monitors and video cards
(with adaptors), headsets, speakers,
USB and PS/2 keyboards and USB
mice.
Environmental
Operating temperature is 32° to 104° F
(0° to 40° C).
Storage temperature is -4° to 140° F
(-20° to 60° C).
Humidity requirements are 0-80%
relative humidity, non-condensing.
MECHANICAL
Approximate Dimensions
W x D x H : 13.5 x 5 x 2.2 inches
(
342 x 125 x 56.6 mm)
Weight: 4 lbs (1.85 kg)
Supported Resolution
Supports 4K HDMI resolutions at 30
Hertz.
Cables
Users can choose from 6 ft. or 10 ft.
cables and select whether or not to
use CAC functionality.
Contact a Vertiv representative for
ordering details.
