Viessmann Vitotrol 350-C Quick guide

Installation and service instructions
for contractors
Viesmann
Vitotrol 350-C
Remote control unit and cascade controller
For applicability, see the last page
VITOTROL 350-C
5778769 GB 6/2018 Please keep safe.

2
Please follow these safety instructions closely to
prevent accidents and material losses.
Safety instructions explained
Danger
This symbol warns against the risk of injury.
!Please note
This symbol warns against the risk of material
losses and environmental pollution.
Note
Details identified by the word "Note" contain additional
information.
Target group
These instructions are exclusively intended for author-
ised contractors.
■Work on electrical equipment must only be carried
out by a qualified electrician.
■The system must be commissioned by the system
installer or a qualified person authorised by the
installer.
Regulations to be observed
■National installation regulations
■Statutory regulations for the prevention of accidents
■Statutory regulations for environmental protection
■Codes of practice of the relevant trade associations
■All relevant safety regulations as defined by DIN, EN,
DVGW, VDE and locally applicable standards
aÖNORM, EN and ÖVE
cSEV, SUVA, SVTI and SWKI
Safety instructions for working on the system
Working on the system
■Isolate the system from the power supply (e.g. by
removing the separate fuse or by means of a mains
isolator) and check that it is no longer 'live'.
■Safeguard the system against reconnection.
Danger
Hot surfaces can cause burns.
■Before maintenance and service work, switch
OFF the appliance and let it cool down.
■Never touch hot surfaces on the boiler, burner,
flue system or pipework.
!Please note
Electronic assemblies can be damaged by elec-
trostatic discharge.
Prior to commencing work, touch earthed
objects such as heating or water pipes, to dis-
charge static loads.
Repair work
!Please note
Repairing components that fulfil a safety func-
tion can compromise the safe operation of the
system.
Replace faulty components only with genuine
Viessmann spare parts.
Auxiliary components, spare and wearing parts
!Please note
Spare and wearing parts that have not been tes-
ted together with the system can compromise its
function. Installing non-authorised components
and making non-approved modifications or con-
versions can compromise safety and may inva-
lidate our warranty.
For replacements, use only original spare parts
supplied or approved by Viessmann.
Safety instructions
Safety instructions
5778769

3
Safety instructions for operating the system
If you smell flue gas
Danger
Flue gas can lead to life threatening poisoning.
■Shut down the heating system.
■Ventilate the installation site.
■Close doors to living spaces to prevent flue
gases from spreading.
What to do if water escapes from the appliance
Danger
When water escapes from the appliance there is
a risk of electrocution.
Switch off the heating system by means of an
external isolator (for example fuse box, domestic
power distribution).
Flue systems and combustion air
Ensure that flue systems are clear and cannot be
sealed, for instance due to accumulation of conden-
sate or other causes. Ensure an adequate supply of
combustion air.
Instruct system users that subsequent modifications to
the building characteristics are not permissible (e.g.
cable/pipework routing, cladding or partitions).
Danger
Leaking or blocked flue systems, or an inade-
quate supply of combustion air can cause life
threatening poisoning from carbon monoxide in
the flue gas.
Ensure the flue system is in good working order.
Vents for supplying combustion air must be non-
closable.
Extractors
Operating appliances that extract air to the outside
(cooker hoods, extractors, air conditioning units, etc.)
can create negative pressure. If the boiler is operated
at the same time, this can lead to reverse flow of the
flue gas.
Danger
The simultaneous operation of the boiler and
appliances that extract air to the outside can
result in life threatening poisoning due to
reverse flow of the flue gas.
Fit an interlock circuit or take suitable steps to
ensure an adequate supply of combustion air.
Safety instructions
Safety instructions (cont.)
5778769

4
1. Information Disposal of packaging ............................................................................ 5
Symbols ................................................................................................. 5
Intended use .......................................................................................... 5
Product information ................................................................................ 6
2. Preparing for installation ................................................................................................................ 7
3. Installation sequence Installing the Vitotrol 350-C .................................................................... 8
Electrical connection of the Vitotrol 350-C ............................................. 8
■Connection diagram for Vitoligno 200-S, 300-C, 300-H ..................... 9
■Connection diagram for Vitoligno 250-S ............................................. 10
■Connection diagram for controller modules ........................................ 10
Installing the programming unit .............................................................. 12
Removing the programming unit ............................................................ 12
4. Commissioning Commissioning sequence ...................................................................... 13
Setting the language .............................................................................. 13
Defining the CAN modules .................................................................... 13
■System version without controller module .......................................... 13
■System version with controller module ............................................... 14
Configuring controller modules (if installed) ........................................... 14
Configuring the default display .............................................................. 15
Default display of the programming unit ................................................ 16
5. Codes Coding levels ......................................................................................... 18
Call up "Extended settings" ................................................................... 18
Overview "Extended settings" ................................................................ 18
■General settings ................................................................................. 19
■Actuator test ....................................................................................... 19
■Changing the password ...................................................................... 20
■Default settings ................................................................................... 20
■Configuring the regulated circuits ....................................................... 20
■DHW ................................................................................................... 25
■Local heating network supply ............................................................. 26
■Cascade settings ................................................................................ 27
■Settings for cascade charging ............................................................ 28
■Boiler changeover unit ........................................................................ 29
■Boiler changeover unit and discharge screw conveyor ...................... 30
■Boiler changeover unit and external charging .................................... 31
■Boiler changeover unit and changeover unit wands ........................... 32
■Boiler screw conveyors and silo discharge screw conveyor ............... 33
■Boiler screw conveyors and intermediate screw conveyor and silo
with discharge screw conveyor ........................................................... 34
■Boiler screw conveyor and 2 silos with discharge screw conveyors .. 35
■Boiler screw conveyors and AH silo discharge (screw and agitator) .. 36
6. Diagnosis Actuator test ........................................................................................... 37
7. Fault rectification Calling up the fault display ..................................................................... 38
Fault codes ............................................................................................ 38
■Information on fault codes .................................................................. 38
■Fault code table .................................................................................. 38
Acknowledging fault messages ............................................................. 45
Calling up acknowledged fault messages .............................................. 45
8. Specification ................................................................................................................ 46
9. Appendix Final decommissioning and disposal ..................................................... 47
10. Keyword index ................................................................................................................ 48
Index
Index
5778769

5
Please dispose of packaging waste in line with statu-
tory regulations.
DE: Use the disposal system organised by
Viessmann.
AT: Use the ARA statutory disposal system (Altstoff
Recycling Austria AG, licence number 5766).
CH: Packaging waste is disposed of by the HVAC
contractor.
Symbols
Symbol Meaning
Reference to other document containing
further information
1.
Step in a diagram:
The numbers correspond to the order in
which the steps are carried out.
Warning of material losses and environ-
mental pollution
Live electrical area
Pay particular attention.
■Component must audibly click into place.
or
■Acoustic signal
■Fit new component.
or
■In conjunction with a tool: Clean the sur-
face.
Dispose of component correctly.
Dispose of component at a suitable collec-
tion point. Do not dispose of component in
domestic waste.
Intended use
The appliance is intended solely for installation and
operation in sealed unvented heating systems that
comply with EN 12828, with due attention paid to the
associated installation, service and operating instruc-
tions.
Information
Disposal of packaging
5778769
Information

6
Depending on the version, the appliance can only be
used for the following purposes:
■Central heating
■DHW heating
■Cascade control
The range of functions can be extended with additional
components and accessories.
Intended use presupposes that a fixed installation in
conjunction with permissible, system-specific compo-
nents has been carried out.
Commercial or industrial usage for a purpose other
than central heating or DHW heating shall be deemed
inappropriate.
Any usage beyond this must be approved by the man-
ufacturer in each individual case.
Incorrect use or operation of the appliance (e.g. the
appliance being opened by the system user) is prohibi-
ted and will result in an exclusion of liability. Incorrect
use also occurs if the components in the heating sys-
tem are modified from their intended function.
Note
This appliance is intended exclusively for domestic
use. The appliance can also be operated safely by
untrained persons.
Product information
The Vitotrol 350-C can be used in connection with the following boilers:
■Vitoligno 200-S
■Vitoligno 250-S
Note
Use with the Vitoligno 250-S requires a connection adaptor, see page 10.
■Vitoligno 300-C
■Vitoligno 300-H
There are various application options for the Vitotrol 350-C:
■With a boiler
■With 1 to 5 controller modules
■With a boiler and up to 5 controller modules
Each controller module can regulate up to 4 heating circuits
■As a cascade controller for 2 to 4 boilers
For the Vitoligno 300-C, Vitoligno 300-H
Information
Intended use (cont.)
5778769
Information

7
Installation location
!Please note
The Vitotrol 350-C can be damaged by ingress
of moisture or water.
Install the Vitotrol 350-C exclusively in dry
rooms. Avoid installation outdoors or in humid
rooms.
1500
60
500
Fig. 1
■Weather-compensated operation
Installation in any room
■Operation with room temperature hook-up
–On an internal wall in the main living room, approx.
1.5 m above the floor
–Not near windows or doors
–Not above radiators
–Not near heat sources (direct sunlight, fireplace,
TV set, etc.)
Do not install additional control devices in this room. If
radiators are equipped with thermostatic valves, these
must always be fully opened.
■Operation as a cascade controller
–Installation in any room
However, ideally it should be installed close to the boil-
ers.
Preparing for installation
Preparing for installation
5778769
Installation

8
!Please note
Electronic assemblies can be damaged by elec-
trostatic discharge.
Prior to commencing any work, touch earthed
objects such as heating or water pipes to dis-
charge static loads.
Fig. 2
Electrical connection of the Vitotrol 350-C
CAN BUS cable
■LiCY 2 x 2 x 0.34 mm², screened
■Max. cable length 300 m
Note
Cable lengths in excess of 300 m or routing the BUS
near power cables can result in display interference.
Installation sequence
Installing the Vitotrol 350-C
5778769
Installation

9
Vitotrol 350-C connections
B C D
1 2 3 4 5 6 7 8
CH
CL GND +
A
Fig. 3
AUSB connection
BConnection for solid fuel boiler or controller module
CScreen
DEthernet connection
Danger
Parasitic voltages can result in life-threatening
electrocution.
Use the USB connection exclusively for USB
sticks (FAT32 format).
Make the electrical connection to the Vitotrol 350-C; for
this, observe the associated connection diagram as
indicated in the table.
Device Connection diagram on page
Vitoligno 200-S, 300-C, 300-H 9
Vitoligno 250-S 10
Controller module 10
Connection diagram for Vitoligno 200-S, 300-C, 300-H
CH CL GND +1 2 3 4 5
A B
Fig. 4
AConnection, Vitotrol 350-C
BConnection, CAN plug Vitoligno 200-S, 300-C,
300-H
Vitotrol 350-C assignment CAN plug boiler assignment Additional information
CH (CAN high) 3 Green
CL (CAN low) 4 Yellow
Installation sequence
Electrical connection of the Vitotrol 350-C (cont.)
5778769
Installation

10
Vitotrol 350-C assignment CAN plug boiler assignment Additional information
GND 2 White
+ 1 Brown
5 No assignment
Connection diagram for Vitoligno 250-S
For connection to the Vitoligno 250-S boiler, include a D-SUB9 connection adaptor in your order.
Part no., connection adaptor
Vitoligno 250-S technical guide
1
2
3
4
5
6
7
8
9
+
GND
CL
CH
A B
Fig. 5
AConnection, D-SUB9 connection adaptor for Vitoligno 250-S
BConnection, Vitotrol 350-C
Connection diagram for controller modules
Connection variant: Vitotrol 350-C as heating circuit controller without boiler
CH 1 2 3 4 5
CL GND [phone]
A B B
~
=
C
+
-
Fig. 6
AConnection, Vitotrol 350-C
BConnection, controller modules
A maximum of 5 controller modules with a maxi-
mum of 4 regulated circuits each is possible
C24 V DC power supply unit
Position of plug-in jumper
A plug-in jumper must be set. The position varies sub-
ject to system version.
The CAN bus plug-in jumper may only be inserted for
the first and last subscriber.
Controller module installation and service
instructions
Installation sequence
Electrical connection of the Vitotrol 350-C (cont.)
5778769
Installation

11
Connection variant: In series on the boiler
CH 1 2 3 4 5CL GND + 1 2 3 4 5 1 2 3 4 5
A B C
Fig. 7
AConnection, Vitotrol 350-C
BConnection, Vitoligno 200-S, 300-C, 300-H
CConnection, controller modules
A maximum of 5 controller modules with a maxi-
mum of 4 regulated circuits each is possible
Connection variant: Vitoligno 300-C, Vitoligno 300-H, controller modules, cascade controller
1 2 3 4 51 2 3 4 51 2 3 4 5 1 2 3 4 5
CH CL GND +
1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5
DCBA
EEF
Fig. 8
Note
Do not connect contact 1 with boilers 1 to 4.
A to DBoiler 1 to boiler 4
Up to 4 solid fuel boilers (300-C, 300-H) are
possible
EConnection, controller modules
A maximum of 5 controller modules with a
maximum of 4 regulated circuits each is pos-
sible
FConnection, Vitotrol 350-C
Vitotrol 350-C assignment Controller module assignment Boiler assignment
CH (CAN high) 3 3
CL (CAN low) 4 4
GND 2 2
+ 1 1
Installation sequence
Electrical connection of the Vitotrol 350-C (cont.)
5778769
Installation

12
1.
2.
Fig. 9
1. Lightly push the display onto the enclosure.
2. Insert the cover from below between display and casing.
Removing the programming unit
2.
1.
Fig. 10
1. Press lightly onto the centre of the cover and pull
away downwards.
2. Lift the display at the centre of the lower edge and
remove.
Installation sequence
Installing the programming unit
5778769
Installation

13
After the power supply is switched on, the user is gui-
ded through an automatic commissioning sequence.
Information
Not every element in the footer is available when first
commissioning the unit.
Setting the language
Shortly after switching the power on, the display shows
"Select language"
Fig. 11
1. Tap on the required field to select the language.
Note
A field with a highlighted frame is already enabled.
2. Press "OK" to confirm
Defining the CAN modules
The display shows the following screen:
Fig. 12
1. Use |/~ to select the number of controller mod-
ules.
2. Press "OK" to confirm
Selecting the system version
Without controller module: See page 13
With 1 to 5 controller modules: See page 14
System version without controller module
The following screen is displayed if no controller mod-
ule has been connected (number "0"):
Commissioning
Commissioning sequence
5778769
Commissioning

14
Fig. 13
1. Press "OK" to confirm or wait a few seconds.
2. Continue with instructions from chapter "Configur-
ing default settings", see page 15
System version with controller module
Continue with instructions from chapter "Configuring
controller modules (if installed)", see page 14
Configuring controller modules (if installed)
Up to 5 controller modules can be connected to one
Vitotrol 350-C.
Fig. 14
Tap on the field for the required controller module.
Fig. 15
Tap on the field for the required regulated circuit.
Fig. 16
Commissioning
Defining the CAN modules (cont.)
5778769
Commissioning

15
Note
The regulated circuit can be renamed.
1. Assign the regulated circuit to one of the assem-
blies displayed. For this, tap on "Heating group",
"DHW group", "Not assigned", or "Local heat-
ing network group".
2. Press "OK" to confirm
Fig. 17
1. Carry out the above steps for all required regulated
circuits.
2. Press "OK" to confirm
Fig. 18
Press "OK" to confirm
Configuring the default display
The display shows the following screen:
Fig. 19
Select "Default display settings".
Fig. 20 Example: With connected Vitoligno 300-C
The Vitotrol 350-C automatically recognises the con-
nected boiler. The boiler is shown on the display.
Note
A field with a highlighted frame is already enabled.
1. If the boiler is not recognised: Check the connec-
tion and routing of the CAN BUS.
2. If the Vitotrol 350-C is used without a boiler: Select
"No wood boiler connected".
3. Press "OK" to confirm
Commissioning
Configuring controller modules (if installed) (cont.)
5778769
Commissioning

16
Fig. 21
The display shows an overview of the regulated cir-
cuits registered to the wood boiler.
Press "OK" to confirm
Fig. 22
The boiler, cascade or one of the regulated circuits
must be selected as the default display.
Note
If the cascade is selected as the default display, only
the function of the cascade controller is enabled.
See page 17
Default display of the programming unit
Example: Heating circuit default display
Fig. 23
ACalls up the menu
BSet regulated circuit
CDate and time
DHeader
ESet room temperature
FButtons for adjusting temperature
GFooter
HCurrent room temperature
KFault message
LCurrent outside temperature
MDisplay, for example central heating with standard room temperature
NButtons for operating program
Highlighted frame = active operating program
Note
Default display can show various boiler types.
Commissioning
Configuring the default display (cont.)
5778769
Commissioning

17
Example: Cascade default display
Fig. 24
ACalls up the menu
BCalls up the cascade menu
CBoiler flow temperature
DDate and time
EHeader
FBoiler status display
GBoiler default output 0 - 100 %
HBoiler output indication
KBoiler number
Fig. 25
AStatus display for additional boiler
BTo scroll to the left
Commissioning
Default display of the programming unit (cont.)
5778769
Commissioning

18
Not all menus are available at every setting level. This
is to avoid incorrect operation of the remote control
and other system components.
The system user can make adjustments in the stand-
ard menu. The "Extended settings" level is reserved
for heating contractors and is password protected.
Additional functions are available in this level. Here,
control parameters can be corrected for example.
For main operating functions and displays:
Vitotrol 350-C operating instructions
For "Extended settings":
See from page 18
Call up "Extended settings"
1. "Menu"
2. "Settings"
3. "Extended settings"
4. Tap on field "ABC" or "123" to change to the
required keyboard.
5. Enter password "1234".
Note
Password "1234" is set as default for the
Vitotrol 350-C. To change the password, see
page 20.
6. "OK" to confirm.
The "Extended settings" overview is displayed.
Overview "Extended settings"
Fig. 26 Page 1 Fig. 27 Page 2
Possible settings Description
"Configuration CAN modules" From page 13
"Default display settings" From page 15
"Configuration regulated circuits" From page 20
"Settings general" From page 19
"Actuator test" From page 19
"Change password" From page 20
"Default settings" From page 20
"Settings cascade" From page 27
"Settings cascade charging" From page 28
Codes
Coding levels
5778769
Codes

19
General settings
Codes
These parameters are described in the installa-
tion and service instructions of the respective
boiler.
The following settings can be programmed:
Parameter Description
"Time constant, outside temp
adj"
Time constant for calculating the adjusted outside temperature
Subject to the set value, the flow temperature is adjusted quickly (low values)
or slowly (high values) if the outside temperature changes.
"Outside temp sensor offset" Correction of the outside temperature by the value set in °C.
"Minimum buffer temperature
top"
If a combined heating water buffer cylinder is installed, a minimum tempera-
ture can be set for the top of the buffer cylinder (captured by PTS 1).
"Delayed fault message" Minimum fault duration in seconds before a fault message is issued
"Log data to USB" Data can be saved to a USB stick (FAT32 format).
Note
Save data to the stick only where the individual case justifies it.
"Logging interval" for saving
[60 s]
Logging interval in seconds, in which the data is written to the USB stick.
"Delete message history" Deletes all messages in the history.
"Modbus TCP" Data exchange via Modbus TCP can be activated.
"Save settings on USB stick" All settings can be saved to a USB stick.
"Load settings from USB
stick"
All settings can be loaded from a USB stick.
Note
Current settings are overwritten.
Actuator test
1.
Fig. 28
Select required regulated circuit.
2.
Fig. 29
Select and execute the required actuator test.
Codes
Overview "Extended settings" (cont.)
5778769
Codes

20
Changing the password
1.
Fig. 30
Enter the new password.
Note
The default password for the Vitotrol 350-C is
"1234".
2. Press "OK" to confirm
The password has been changed. "Password has
been changed" appears briefly on the display.
Default settings
The default settings for the individual regulated circuits
can be loaded.
Configuring the regulated circuits
Heating circuit
Designation Factory
setting
Min. Max. Information
"Room sensor" No
Vitotrol 100
Note
Only possible for heating circuit connected via controller module
Vitotrol 200
Note
Only possible for heating circuit connected via boiler, detected
automatically.
Vitotrol 300
Note
Only possible for heating circuit connected via boiler, detected
automatically.
Vitotrol 350
Codes
Overview "Extended settings" (cont.)
5778769
Codes
