VWR CO2 Incubator Basic User manual

VWR CO2 Incubator Basic
50150229 Revision 0 December 2015

© 2015 VWR International, LLC. All rights reserved.
This Instruction Manual is copyright protected. Rights resulting thereof, particularly reprint, photomechanical
or digital post-processing or reproduction, even in part, are only allowed with the written consent of VWR
International, LLC.
This regulation does not apply to reproductions for in-plant use.
The contents of this document are subject to change without notice. Concerning translations into foreign
languages, the English version of these operating instructions is binding.
Trademarks
All trademarks mentioned in the operating instructions are the exclusive property of the respective
manufacturers.
VWR International, LLC
Radnor Corporate Center, Building One, Suite 200
100 Matsonford Road
Radnor, Pennsylvania 19087
United States
VWR International, LLC provides this document to its customers with a product purchase to use in the
product operation. This document is copyright protected This document is copyright protected and any
reproduction of the whole or any part of this document is strictly prohibited, except with the written
authorization of VWR International, LLC.
The content of this document are subject to change without notice.
All technical information in this document is for reference purposes only. System configurations and
specifications in this document supersede all previous information received by the purchaser.
This document is not part of any sales contract between VWR International, LLC and a purchaser. This
document shall in no way govern or modify any Terms and Conditions of Sale, which Terms and Conditions of
Sale shall govern all conflicting information between the two documents.

Table of Contents
Chapter 1 Important safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Instruction of the operating personnel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Applicability of the instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Explanation of Signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Overview safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
Intended purpose of the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9
Chapter 2 Delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Components standard equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Acceptance inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-12
Chapter 3 Installation of the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Ambient conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
Room ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
Space requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15
Stacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16
Modifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16
Chapter 4 Description of the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Views of device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-17
Safety devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-19
Work space atmosphere . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-19
Sensor system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-20
Door switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-21
Switchbox with supply interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-22
Work space components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-24
90 °C decontamination routine (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-27
Chapter 5 Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-29
Preparing the work space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-29
Installing the shelf system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-29
Gas connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-32
Power supply connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-33
RS 232 interface connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-34
Connecting the alarm contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-37
Chapter 6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-39
Preparing the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-39
Starting operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-40
Chapter 7 Handling and control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-41
Power switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-41

Operating panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-42
Control self-test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-43
Setting the nominal temperature value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-44
Setting the CO2nominal value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-44
Activating the auto-start routine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-45
Reading failure codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-46
Failure code list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-49
Resetting the thermal protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-50
Chapter 8 Shut-down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-51
Shutting the device down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-51
Turn device off using the power switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-51
Chapter 9 Cleaning and disinfection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-53
Decontamination procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-53
Wipe/Spray disinfection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-53
90 °C decontamination routine (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-57
Chapter 10 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-61
Inspections and checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-61
Service intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-61
Preparing the temperature calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-62
Temperature calibration procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-64
Preparing the CO2calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-65
CO2calibration procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-67
Replacing the sterile filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-68
Replacing the device fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-69
Replacing the door seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-70
Chapter 11 Parts and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-71
Lists of parts and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-71
Chapter 12 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-73
Chapter 13 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-77
Chapter 14 Device log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-79
Chapter 15 Certificate of decontamination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-81

VWR CO2 Incubator Basic | 3
Important safety information
Instruction of the operating personnel
These operating instructions describe the CO2incubator
Model VWR Air Jacketed CO2Incubator Basic
The CO2incubator has been manufactured in keeping with the latest technological developments
and has been tested before delivery for its correct function. It may, however, present potential
hazards if it is not used according to the intended purpose or outside of operating parameters
Therefore, the following procedures must always be observed to prevent accidents:
The CO2incubator must be operated only by trained and authorized personnel.
For any operation of this device, the operator must prepare clear and concise written
instructions in the language of the operating and cleaning personnel based on these
operating instructions, applicable safety data sheets, plant hygiene guidelines, and technical
regulations, in particular:
– Which decontamination measures are to be applied for the CO2incubator and
accessories
– Which protective measures are to be applied while specific agents are used
– Which measures are to be taken in the case of an accident
Repairs to the device must be carried out only by trained and authorized expert personnel.
Applicability of the instructions
The contents of the operating instructions are subject to change without further notice.
Concerning translations into foreign languages, the English version of these operating
instructions is binding.
Keep these operating instructions close to the device so that safety instructions and
important information are always accessible.
Should you encounter problems that are not detailed adequately in these operating
instructions, please contact VWR immediately for your own safety.

| Important safety information
4 | CO2 Incubator Basic VWR
Chapter 1
Warranty
VWR warrants the operational safety and functions of the CO2incubator only under the condition
that:
The device is operated and serviced exclusively in accordance with its intended use and as
described in these operating instructions
The device is not modified
Only original spare parts and accessories that have been approved by VWR are used
Inspections and maintenance are performed at the specified intervals
The warranty is valid from the date of delivery of the device to the operator.
Explanation of Signs
Symbols and signal words used in the operating
instructions
NOTICE
Indicates a situation which, if not avoided, could result in property damage!
NOTE
Is used for applicational hints and useful information.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury!
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury!

VWR CO2 Incubator Basic | 5
Important safety information | Chapter 1
Pictographs used in the operating instructions
Pictographs point to concrete facts of a safety message or a property damage message.
Signs on the device
Safety signs, test marks and marks of conformity placed on the device.
Electric shock!
Suffocation hazard!
Hot surfaces!
Wear safety gloves!
Wear safety goggles!
Harmful liquids!
Observe operating instructions!
CSA test mark:
Test certificate for USA/Canada, indicates that the product has met the requirements of nationally
recognized product safety standards.

| Important safety information
6 | CO2 Incubator Basic VWR
Chapter 1
Overview safety information
Overview of he most important safety information used in this operating instructions.
Carbon dioxide (CO2):
As CO2is rated as a harmful gas, certain safety instructions must be observed when the CO2
incubator is started up and when the device is operated.
NOTE!
Personnel instruction:
Personnel operating devices with CO2supply must be instructed about the particularities in the
handling of CO2before starting their work:
Correct operation of pressurized gas containers and gas supply systems
Obligation to report damages and shortcomings in CO2supply lines
Measures to be taken in case of accidents or failures
These instructions must be repeated in appropriate intervals and must comprise the particular
operating instructions of the gas supplier
NOTICE!
Overpressure:
The operating pressure of the gas applied to the device must not exceed 1 bar. If the gas is
supplied at a higher pressure, the valves integral to the device may not close correctly and the gas
supply control may be impaired!
Set the gas supply to a range between 0.8 bar min. and 1.0 bar max. and make sure that this
pressure setting cannot be changed!
Pressure compensation opening:
To ensure permanent pressure compensation, the pressure compensation opening must not be
connected to an exhaust air system. The pipe of the pressure compensation opening must not be
extended or redirected!
WARNING
Suffocation hazard:
CO2released in large amounts into the room atmosphere may cause suffocation.
If CO2is released, initiate safety measures immediately!
Leave the room immediately and do not allow others to enter the room!
Inform security service or fire department!

VWR CO2 Incubator Basic | 7
Important safety information | Chapter 1
Access port:
If the access port is not used, it must be capped during operation!
Gas quality:
CO2must be of the following qualities:
Purity 99.5% min
or
Medical grade
Health hazard:
The surfaces of the work space may be contaminated. Contact with contaminated cleaning liquids
may cause infections. Disinfectants may contain harmful substances.
When cleaning and disinfecting, always observe the safety instructions and hygiene regulations!
Wear safety gloves
Wear safety glasses
Wear mouth and respiratory system protection gear to protect the mucous membranes
Observe the safety instructions of the manufacturer of the disinfectant and of the hygiene
experts!
Contamination hazard:
The device can be used for preparing and processing infectious substances so that the device or
device components may become contaminated.
In case of a shut-down, the device must be decontaminated!
Before device components are discarded, they must be decontaminated!
The device components must be cleaned thoroughly; after the cleaning, they must be
disinfected or sterilized, as required by the application.
Discarded devices or device components must be provided with an appropriate certificate
showing the decontamination measures performed!
Hygiene regulations:
Prior to any operation, the user must clean and disinfect the work space in accordance with the
hygiene regulations set forth by the operator to protect the cultures.
CAUTION
Electric shock:
Contact with current-carrying components may cause a lethal electric shock.
Before connecting the device to the power supply, check plug and connection line for damage.
Do not use damaged components when connecting the device to the power supply!

| Important safety information
8 | CO2 Incubator Basic VWR
Chapter 1
NOTICE!
Incompatible cleaning agents:
Some device components are made of plastic. Solvents may dissolve plastics. Powerful acids or
bases may cause embrittlement of the plastics.
For cleaning the plastic components and surfaces, do not use hydrocarbon-containing solvents,
detergents with an alcohol content of more than 10% or powerful acids and bases!
Chloride-containing disinfectants:
Chloride-containing disinfectants may corrode stainless steel.
Use only disinfectants that do not affect stainless steel!
Do not use sodiumhypochlorite solutions such as Purex and Clorox. These can cause
corrosion and pitting of stainless steel.
Do not use steel wood pads such as Brillo. These pads deposit carbon particles in the work
space.
Alcoholic disinfectants:
Disinfectants with an alcohol content of more than 10% may form, in combination with air, easily
combustible and explosive gas mixtures.
When using such disinfectants, avoid open flames or exposure to excessive heat during the entire
disinfection process!
Use such disinfectants only in adequately ventilated rooms.
After the disinfectant has been allowed to react, wipe the cleaned device components
thoroughly dry!
Observe safety regulations to avoid fire and/or explosion hazard caused by alcohol-containing
disinfectants!
Water supply:
The water tray of the work space can hold up to 3.0 l of processed water. When the running
operation, always keep a sufficient quantity of processed water of the following quality available:
Demineralized and distilled or autoclaved for sterilization
or
Completely deionized and distilled or autoclaved for sterilization
When the water level falls below the lower limit, refill water!

VWR CO2 Incubator Basic | 9
Important safety information | Chapter 1
Intended purpose of the device
Intended use
The CO2incubator is a laboratory device for preparing and cultivating cell and tissue cultures. The
device allows the simulation of the special physiological ambient conditions for these cultures due
to the exact control of:
Temperature
CO2content
An increased relative humidity
The device has been designed for installation and operation in the following fields of application:
Laboratories for cytobiological and biotechnological experiments of safety levels L1, L2,
and L3
Medical-microbiological laboratories in accordance with DIN 58 956
Laboratories in the central area of clinics and hospitals
The CO2required for the incubator is supplied to the device from a separate gas supply system,
either from gas cylinders or from a central pressurized gas container.
The layout of the gas supply system must ensure that the operating pressure of the gas supply
lines can be set to a range between 0.8 bar (min.) to 1 bar (max.) and that the pressure cannot be
changed.
Depending on the capability of the gas supply system, several devices may be connected to one
gas cylinder.
The CO2incubator is suited for continuous operation.
Unintended use
Do not use cell or tissue cultures in the device that are not in accordance with the regulations of
safety levels L1, L2, and L3.
Do not use tissues, substances or liquids that:
Are easily ignitable or explosive
Release vapors that form combustible or explosive mixtures when exposed to air
Release poisons

| Important safety information
10 | CO2 Incubator Basic VWR
Chapter 1
Standards and directives
The device is in accordance with the following standards and guidelines:CAN/
CSA – C22.2 No. 61010-4-04
UL Std. No. 61010 (2nd Edition)
Safety specifications:
Indoor Use Only
Altitude – Up to 2.000 meters
Temperature – 5 °C to 43 °C
Humidity – Maximum RH 80% for temperatures up to 31 °C, decreasing linearly to 50% RH at
40 °C
Mains Supply Fluctuations – Mains supply voltage fluctuations not to exceed ±10% of the
nominal voltage
Installation Category II1
Pollution Degree 22
Class of Equipment I
1Installation category (overvoltage category) defines the level of transient overvoltage which the instrument is designed
to withstand safely. It depends on the nature of the electricity supply and is overvoltage protection means. For example,
in Cat II which is the category used for instruments in installations supplied from a supply comparable to public mains
such a hospital and research laboratories and most industrial laboratories, the expected transient over voltage is 2500 V
for a 230 V supply and 1500 V for a 120 V supply.
2Pollution degree describes the amount of conductive pollution present in the operating environment. Pollution degree 2
assumes that normally only non-conductive pollution such a dust occurs with the exception of occasional conductivity
caused by condensation.

VWR CO2 Incubator Basic | 11
Delivery
Packaging
The CO2incubator Helix is delivered in a stable packaging box. All packaging materials can be
separated and are reusable:
Packaging carton: Recycled paper
Foam elements: Styrofoam (CFC-free)
Pallet: Untreated wood
Packaging film: Polyethylene
Packaging ribbons: Polypropylene
Components standard equipment
Delivery CO2incubator with single glass door and with
continuous shelves (standard version)
Shelf 3
Shelf support post 4
Shelf support rail 6
Insert for pressure compensation opening 1
Plug for pipe channel 1
Power supply cable 1
Connector, potential-free contact 1
Spare caps, set 1
CO2connecting hose set 1
Immersion water pump 1
Open-end wrench, 24 mm 1
Allen wrench 2 mm for blower wheel 1
Allen wrench 3 mm for blower wheel cover 1
Operating instructions 1
Pump for water draining 1

| Delivery
12 | CO2 Incubator Basic VWR
Chapter 2
Acceptance inspection
After the device has been delivered, check the delivery immediately for:
Completeness
Possible damages
If damages are detected or if components are missing, please contact the carrier and
vendor immediately.

VWR CO2 Incubator Basic | 13
Installation of the device
Ambient conditions
The device must only be operated in locations that meet the particular ambient conditions listed
below.
Requirements:
Draft-free and dry location.
The minimal distance to adjacent surfaces must be observed on all sides (see Section
“Space requirements”).
The operating room must be equipped with appropriate room ventilation.
Solid, level, fire-proof surface.
Vibration-proof substructure (floor stand, lab table) capable of bearing the weight of the
device and accessories (particularly if several devices are stacked).
To ensure a constant incubation temperature of 37 °C, the ambient temperature must be
within a range of +18 °C to +33 °C.
Relative humidity up to 80% (max.).
Avoid direct exposure to sunlight.
Devices that produce excessive heat should not be used near the location of the CO2
incubator.
Room ventilation
When CO2is supplied, the work space of the incubator is slightly pressurized. The pressure is
released through the pressure compensation opening into the operating room.
As the pressure compensation and any opening of the glass door/gas tight screen during the
operation of the device will release very small quantities of CO2into the operating room, the room
ventilation must be capable of carrying the released gas safely off into the open.
In addition, heat dissipating from the device during permanent operation may cause a change in
the room climate.

| Installation of the device
14 | CO2 Incubator Basic VWR
Chapter 3
Therefore, the incubator must only be installed in rooms with sufficient ventilation.
Do not install the device in room recesses without ventilation.
The room ventilation should be a technical ventilation that is in accordance with the
requirements of DGUV Information 213-850 (Guidelines for laboratories) or some other
suitable ventilation system with appropriate capacity.
Space requirements
Figure 1 – Device dimensions
When installing the device, make sure that the installation and supply connections are freely
accessible.
The control box at the rear panel of the device may serve as a spacer to adjacent objects. The side
distances given are minimal distances.
To protect the CO2incubator against contamination, use a floor stand even if the device is installed
near the floor. The height of the floor stand should not be less than 200 mm.
Several floor stands and carriers are available as options from VWR (Part no. see Chapter 11
“Parts and accessories”).

VWR CO2 Incubator Basic | 15
Installation of the device | Chapter 3
NOTE!
Accessibility of the devices:
To ensure the accessibility for care and maintenance works, keep larger side and rear distances!
Transport
Figure 2 – Lift point
For transport do not lift the device using the doors or components attached to the device
(e.g. control box on rear panel) as lift points.
NOTE!
Lift points:
Lift the device only using the lift points shown in Figure 2.

| Installation of the device
16 | CO2 Incubator Basic VWR
Chapter 3
Stacking
Figure 3 – Stacking
Two Helix devices can be stacked on top of each other. The stacking elements [1] and [2] secure
the devices on top of each other.
If the devices are placed onto mobile racks, ensure that the rollers [3] are secured by an arresting
device during operation. For reasons of stability, the rollers should be oriented to the front.
NOTE!
Transporting stacked devices:
The stacking elements are not connecting elements. Therefore, the transport of stacked devices
on sloped surfaces is not allowed!
Modifications
NOTE!
Modifications:
Retrofits and modifications must only be performed by the Technical Service of VWR!

VWR CO2 Incubator Basic | 17
Description of the device
Safety devices
The device is equipped with the following safety devices:
A door switch interrupts the CO2 supply and the work space heating when the glass door is
opened
An independent thermal protection protects the samples from harmful overheating in the
event of a failure
A pressure compensation opening ensures pressure compensation in the device work space
Audible and visual alarms indicate failures during operation

| Description of the device
18 | CO2 Incubator Basic VWR
Chapter 4
Views of device
Figure 4 – General views of device
Front view:
[1] Stacking elements
[2] Plug caps
[3] Glass door
[4] Measuring cell with blower wheel and sensors
[5] Door switch
[6] Pressure compensation opening with insert
[7] Measuring opening
