WATSON Tonic Center Screen User manual

Tonic Center Screen Assembly Instructions
Pg. 1 of 2 INS-TNC TWTRC
26246 Twelve Trees Lane NW, Poulsbo, WA 98370 | 800.426.1202 | www.watsonfurniture.com
Tools Required
Cordless drill, magnetic insert-bit holder
Step 1 –Install one bolt
Lay the screen assembly on its side on a work surface. Position it so that the bottom edge (with the brackets) is hanging over
the edge of the work surface slightly. Hold the infill panel and align one of the small round holes with a corresponding hole in the
screen bracket. Be sure that the counter-bored side of the hole is on the side of the infill panel that is opposite the screen. Thread one
of the 5/16-18 bolts through the infill panel and into the screen bracket.
Figure 1
ITEM NO.
COMPONENT
QTY
A
TONIC BENCH INFILL PANEL
1
B
CENTER SCREEN ASSEMBLY
1
C
5/16-18 x 1 ¼” SHCS BUTTON HEAD SCREWS
2
A
B

Tonic Center Screen Assembly Instructions
Pg. 2 of 2 INS-TNC TWTRC
26246 Twelve Trees Lane NW, Poulsbo, WA 98370 | 800.426.1202 | www.watsonfurniture.com
Step 2 –Install second bolt
Lift the screen and align the second hole in the panel with the hole in the second bracket. Thread the second bolt. Tighten
both bolts
Figure 2
Step 3 –Place screen / infill assembly onto bench
Figure 3
Operating, maintenance, and installation instructions are available at https://watsonfg.box.com/installation
