WB Mfg ELO Court Team Table User manual

1
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
V043019 subject to change.
ELO® Court Team Table
Step 2
Tools Required
• Screw gun
• 4mm Hex bit
• Drill bit extension
Model #
Smooth Silver
Sku #
Black
Sku# Descripon Height"
ELSG 04066821-G4 04066821 ELO® 2" Straight Round Adj. Leg (ELS) 21, 24, 28, 35 & 39
Part Identifier Key
H”
Pedestal
Base # Top D” Silver Sku # Black Sku#
Pedestal
Base # Top D” Silver Sku # Black Sku#
Pedestal
Base # Top D”
Silver
Sku #
Black
Sku#
22.25 1844 24, 30, 36 0409895-21-S 0409895-21-B 2244 42, 48 0402016-21-S 0402016-21-B 2267 60
25.25 1844 24, 30, 36 0409895-24-S 0409895-24-B 2244 42, 48 0402016-24-S 0402016-24-B 2267 60
29.25 1844 24, 30, 36 0409895-28-S 0409895-28-B 2244 42, 48 0402016-28-S 0402016-28-B 2267 60
36.25 1844 24, 30, 36 0409895-35-S 0409895-35-B 2244 42, 48 0402016-35-S 0402016-35-B 2267 60
40.25 1844 24, 30, 36 0409895-39-S 0409895-39-B 2244 42, 48 0402016-39-S 0402016-39-B 2267 60
Part # Description Qty.
04009023 ¼”-20x15mm joint connector bolts
(Used to fasten leg to top)
• 6 per leg
• 12 per pedestal
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key) Any parts damaged during shipment must be
reported within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Step 1:
• Place top face down on protected surface so threaded
inserts are facing up.
Step 2:
• Align ELO straight leg with threaded inserts.
• Connect leg to desktop with the ¼-20x15mm joint
connector bolts.
• Use a screw gun, 4mm Hex bit and a drill bit extension
to tighten the joint connector bolts to the desktop.
• Repeat this for the rest of the legs and pedestal.
Step 3:
• Adjust legs to match the height of the pedestal and
then with someone’s help, ip table over.

2
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
ELO® Court Team Table
with 2.5” Grand Hank Glides
Step 1:
• Remove Nylon glide from leg by rotating counterclockwise until
glide is free.
Step 2:
• Place stem of Grand Hank glide into the hole on the leg. Rotate
clockwise until fully inserted into leg.
Step 4:
• Repeat for each Grand Hank glide.
Step 1:
• Place top face down on protected surface.
Step 2:
• Align tabs of the backpack hook with the metal inserts.
Step 3:
• Use ¼-20x15mm joint connector bolts to fasten both of the tabs
of the backpack hook to the top.
ELO® Court Team Table
with Backpack Hook
Tools Required
• ½”Wrench
Tools Required
• Screw gun
• 4mm Hex bit
Part # Description Qty.
040164 1⁄ Dia. Grand Hank glides, ⁄-16 x 1” 1 per leg
04009308-X1 (black)
04009308-G4 (smooth silver)
Backpack hook
(Needs (2) ¼”-20x15mm joint connector bolts) 1
04009023 ¼”-20x15mm joint connector bolts
(Used to fasten backpack hook) 2 per backpack hook
Part Identifier Key
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key) Any parts damaged during shipment must be
reported within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
