iXchange® Wall
Assembly Instructions
SSW1202-AL
V121521 Version subject to change
Joint
connector
bolt
Joint
connector
nut
iXB3112-2
Before you begin, please make sure all parts and
proper quantities are included. (See Part Identifier Key)
Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information
regarding damages or if you have any questions,
please call 800.242.2303.
Tools Required
• Screw gun
• 4mm & 5mm Allen
wrench OR
• 4mm & 5mm hex bit
• #2 Phillips screwdriver
NOTE: The cabinets with the same model numbers are interchangeable and can be used in any location where
that model number is needed.
Step 1:
• Slide base cabinets together (in the order as shown below) and level in place. With cabinets aligned together,
place the ⁄”-20x30mm joint connector bolt w/ Loctite through pre-drilled hole on the inside of one of the cabinets
making sure bolt is pushed as far as it can go. While holding the joint connector bolt flush to the cabinet, take a
⁄”-20x17mm joint connector nut and attach it to the end of the bolt (through the other base cabinet) turing it
clockwise until it’s completely on. Use a 4mm Allen wrench or 4mm hex bit and a screw gun to tighten as needed.
• Repeat this for the (7) remaining attachment points.
iXB2400-2 iXB3112-2 iXB2400-2

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
2
iXchange® Wall
Assembly Instructions
SSW1202-AL
iXB3112-2iXB2400-2
Step 2:
• Place and center the LEFT base top (iXLBTop-71-4)on the farthest LEFT base cabinets (iXB2400-2 &
iXB3112-2). Align the threaded inserts in the bottom of the base top with the pre-drilled holes in the sub-tops
of the base cabinets. Use ¼”-20x30mm joint connector bolts w/ Loctite to fasten the base top to the base
cabinets as shown below.
JCB
iXLBTop-71-4

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
3
iXchange® Wall
Assembly Instructions
SSW1202-AL
Step 3:
• Place and center the RIGHT base top (iXRBTop-71-4)on the farthest RIGHT base cabinets (iXB3112-2 &
iXB2400-2). Align the threaded inserts in the bottom of the base top with the pre-drilled holes in the sub-tops
of the base cabinets. Use ¼”-20x30mm joint connector bolts w/ Loctite to fasten the base top to the base
cabinets as shown below.
iXB3112-2 iXB2400-2
iXRBTop-71-4
JCB

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
4
iXchange® Wall
Assembly Instructions
SSW1202-AL
iXW1155-3
JCB
Step 4:
• Locate wall cabinet (iXW1155-3). Place it on the LEFT side of base top (iXLBTop-71-4) aligning the
pre-drilled holes in the bottom of the wall cabinet with threaded inserts in the base top. Bolt into place using
¼”-20x30mm joint connector bolts.
NOTE: The cabinets with the same model numbers are interchangeable and can be used in any location where
that model number is needed.
iXLBTop-71-4

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
5
iXchange® Wall
Assembly Instructions
SSW1202-AL
JCB
Step 5:
• Locate the second wall cabinet (iXW1155-3). Place it to the right of wall cabinet (iXW1155-3) and on top of
base top (iXLBTop-71-4). Align the holes of both wall cabinets while also aligning the pre-drilled holes in the
bottom of (iXW1155-3) with threaded inserts in base top.
• Bolt wall cabinet (iXW1155-3) to the base top (iXLBTop-71-4) using ¼”-20x30mm joint connector bolts.
Step 6:
• With pre-drilled holes in wall cabinets aligned together, place the ⁄”-20x30mm joint connector bolt w/ Loctite
through pre-drilled hole on the inside of one of the cabinets making sure bolt is pushed as far as it can go. While
holding the joint connector bolt flush to the cabinet, take a ⁄”-20x17mm joint connector nut and attach it to
the end of the bolt (through the other wall cabinet) turing it clockwise until it’s completely on. Use a 4mm Allen
wrench or 4mm hex bit and a screw gun to tighten as needed.
• Repeat this for the (3) remaining attachment points.
iXW1155-3
iXW1155-3
JCBJCN
iXLBTop-71-4
NOTE: The cabinets with the same model numbers are interchangeable and can be used in any location where
that model number is needed.

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
6
iXchange® Wall
Assembly Instructions
SSW1202-AL
Step 7:
• Locate the third wall cabinet (iXW1155-3). Place it to the right of wall cabinet (iXW1155-3) on top of RIGHT
base top (iXRBTop-71-4). Align the holes of both wall cabinets while also aligning the pre-drilled holes in the
bottom of wall cabinet (iXW1155-3) with threaded inserts in the base top (iXRBTop-71-4).
• Bolt wall cabinet (iXW1155-3) to the base top (iXRBTop-71-4) using ¼”-20x30mm joint connector bolts.
Step 8:
• With pre-drilled holes in wall cabinets aligned together, place the ⁄”-20x30mm joint connector bolt w/ Loctite
through pre-drilled hole on the inside of one of the cabinets making sure bolt is pushed as far as it can go. While
holding the joint connector bolt flush to the cabinet, take a ⁄”-20x17mm joint connector nut and attach it to
the end of the bolt (through the other base cabinet) turing it clockwise until it’s completely on. Use a 4mm Allen
wrench or 4mm hex bit and a screw gun to tighten as needed.
• Repeat this for the (3) remaining attachment points.
JCB
iXW1155-3
iXW1155-3
JCBJCN
iXRBTop-71-4
NOTE: The cabinets with the same model numbers are interchangeable and can be used in any location where
that model number is needed.

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
7
iXchange® Wall
Assembly Instructions
SSW1202-AL
iXFEL
JCB
Step 9:
• Located finished wall panel (iXFEL). Align the threaded inserts in the panel to the pre drilled holes in cabinets
(iXW1155-3) and (iXB2400-2)on the LEFT side of the iXchange® Wall. Bolt wall panel to cabinets using
¼”-20x30mm joint connector bolts.
iXW1155-3
iXB2400-2

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
8
iXchange® Wall
Assembly Instructions
SSW1202-AL
iXLWTop_72
JCB
Step 10:
• Locate LEFT wall top (iXLWTop_72) and place on top of upper wall cabinets (iXW1155-3 &iXW1155-3) with the
threaded inserts facing down. Align the threaded inserts with the pre-drilled holes in the sub-tops of both wall
cabinets and bolt into place using ¼”-20x30mm joint connector bolts.
iXW1155-3
iXW1155-3

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
9
iXchange® Wall
Assembly Instructions
SSW1202-AL
Step 11:
• Locate RIGHT wall top (iXRWTop_72) and place on top of upper wall cabinets (iXW1155-3 &iXW1155-3) with
the threaded inserts facing down. Align the threaded inserts with the pre-drilled holes in the sub-tops of both
wall cabinets and bolt into place using ¼”-20x30mm joint connector bolts.
iXLWTop_72
JCB
iXW1155-3
iXW1155-3

wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
10
iXchange® Wall
Assembly Instructions
SSW1202-AL
Step 12:
• Locate the cork strip and double top track. Slide the cork strip into the channel on the front of the upper track.
Cut to fit.
Step 13:
• There will be a double top track with 2” Forbo insert and a double bottom track with blade tray. (Both tracks will
be pre-drilled. The cabinets will not have any pre-drilling.) Align the front edge of the double bottom track to
the front edge of the base tops (iXLWTop_72 & iXRWTop_72). Mount using ⁄” #8 truss head screws. Attach
double track with blade tray to the top of the base cabinets using ⁄” #8 flat head screws.
iXRWTop_72iXLWTop_72
iXLBTop_71 iXRBTop_71
