WB Mfg UNE-T User manual

1
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Fig. A
Step 2
Step 3
Step 3
V052819 subject to change.
• Screw gun
• 4mm Allen wrench OR
• 4mm Hex bit
• Phillips head screwdriver
Tools Required
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key page) Any parts damaged during shipment must
be reported within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Fig. B
Stand Up desk
Step 4
UNE-T Desk/Table/Workstations
w/ UNE Legs
Step 1:
• Place desk top face down on protected surface so threaded
inserts are facing up.
Step 2:
• Align legs with threaded inserts. Drilling is oset closer to
the back edge.
• Using a 4mm Allen wrench or 4mm Hex bit, secure top with
#10-24x1” joint connector bolts. DO NOT FULLY TIGHTEN
until Step 6.
Step 3:
• Using a 4mm Allen wrench or 4mm Hex bit, attach
connector bar(one piece) to the upper portion of the legs
with ¼-20x15mm joint connector bolts. The bar should rest
inside the legs. DO NOT FULLY TIGHTEN until Step 6. (Fig A)
• If you have an adjustable connector bar, use #12 star
washers and M6-1x14 screws to fasten the two connector
bars together. DO NOT FULLY TIGHTEN until Step 6. (Fig B)
Step 4:
• If assembling a Stand Up desk, use a 4mm Allen wrench or
4mm Hex bit to attach the foot rest bar to lower portion of
the legs using #12 star washers and M6 1x14 screws. DO
NOT FULLY TIGHTEN until Step 6.

2
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Step 1:
• Place top face down on protected surface.
Step 2:
• Align tab of the backpack hook on top of the metal leg plate.
Step 3:
• Using a 4mm Allen wrench or 4mm Hex bit, secure backpack hook to
the top leg plate with ¼-20x15mm joint connector bolt.
UNE-T Desk/Table
with Backpack Hook
UNE-T Desk/Table
with Dual Wheel Locking Casters
or 2.5” Grand Hank Glides
Step 5
Wire management
Step 7
Grommets
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key page) Any parts damaged during shipment
must be reported within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
• Screw gun
• 4mm Allen wrench OR
• 4mm Hex bit
Tools Required
• ½” wrench
Tools Required
UNE-T Desk/Table/Workstations
w/ UNE Legs
Step 1:
• Remove Nylon glide from leg by rotating
counterclockwise until glide is free.
Step 2:
• Place stem of optional footing into the hole on the leg.
Rotate clockwise until fully inserted into leg.
Step 3:
• Tighten with a ½”wrench. (for dual wheel caster only)
Step 4:
• Repeat for each caster/glide.
Step 5:
• If assembling a Workstation, align metal wire management
with pilot holes.
• Attach wire management to top using #8x¾”screws to fasten it
tightly down.
Step 6:
• Fully tighten leg, connector bar & foot rest(foot rest if
assembling a Stand Up) fasteners. Adjust leg height and glides
as needed.
• With someone’s help, turn table upright.
Step 7:
• If assembling a Workstation, insert black grommet/s in top.

3
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Part # Description Qty.
040164 1⁄ dia. Grand Hank glide, ⁄-16 x 1”
(Standard on Stand Up legs) 2 per leg
33021BK Dual wheel casters w/brake 2 per leg
04067195 Soft tread casters 1 per leg
04066852 (black)
04066852-G4 (smooth silver)
Backpack hook
(Needs ¼”-20x15mm joint connector bolts) 1
04009023 ¼”-20x15mm joint onnector bolt
(Used to attach backpack hook to top) 1 per backpack hook
0401158 10-24x1” joint connector bolt
(Used to attach leg to top) 6 per leg
04009770 (27”L top size) xed bar
04009771 (36”L top size) xed bar
04009772-G4 (48”L top size) xed bar
04009773 (54”L top size) xed bar
04077747-G4 (27”, 30” & 36”L top sizes) adj. bar
04066970 (27”-44”L top size) adj. bar
04066939 (38”-66”L top size) adj. bar
UNE-T connector bar (adj. or non-adjustable) 1
04009023 ¼-20x15mm joint connector bolt
(Used to attach connector bar to legs) 4
0401259 M6-1x14 screw
(Used to connect adjustable connector bar) 2
0404281 #12 star lock washer
(Used to connect adjustable connector bar) 2
04066605 UNE-T foot rest
(Standard on Stand Up legs only) 1
0401259 M6-1x14 screw
(Used to attach foot rest to legs) 4
0404281 #12 star washer
(Used to attach foot rest to legs) 4
04009316 (36”L)
04009242 (48”L)
04009241 (60”L)
0400081 (72”L)
Metal wire management
(Used only on UNE-T Workstations)
1
0404248 #8x¾” screws
(Used to attach metal wire management to top) 10
0406659 2⁄”D black gromment w/ cover
(Used only on UNE-T Workstations)
1 - 48”L
2 - 60” & 72”L
Part Identifier Key
UNE -ADJ
Model #
Smooth Silver
Sku #
Black
Sku# Descripon Height"
UNE -ADJ 04009776-G4 N/A UNE-T 1.25" Square Adj. Leg 21 - 30
UNE -ADJSU 04066604-G4 N/A UNE-T 1.25" Sq. Adj. Stand Up Leg 32 - 41
UNE F 04066605-G4-AE N/A Black Lotz AE™ footrest N/A
UNE -ADJ 04077761-G4 N/A UNE-T 1.25" Sq. Adj. Double T Leg 21 - 30
UNE -ADJSUF
Adj. Stand Up Leg requires
Black Lotz Armor Edge™ footrest
UNE-T Desk/Table/Workstations
