WB Mfg Nucleus CLN7110-3/T3030-AC User manual

1
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specications are subject to change. Product
images are for illustrative purposes only and may
dier from the actual product.
V093020 subject to change.
Images of these base
cabinets are shown upside
down in Steps 1-4.
Nucleus
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
specifications
Step 1:
• Remove the two waste bins from the base cabinet.
• Place the base cabinet that has the totes in it upside down on a protected at surface with it’s sub-bottom facing up. (Upon
installer’s discretion, remove doors(excluding trash door), shelving & totes before turning any of the cabinets over to lessen
the weight of the cabinets.)
• Repeat above step for the other two base cabinets but when you’re placing it down on the protected surface, align the pre-
drilled holes on the sides of all three cabinets with each other.
• NOTE: Please use the below image for the correct placement of each cabinet.
Step 2:
• With cabinets aligned together, place the ¼-20 x 30mm joint connector bolt w/ loctite through pre-drilled hole on the inside of
one of the cabinets making sure bolt is pushed as far as it can go.
• While holding the joint connector bolt ush to the cabinet, take a ¼-20x17mm joint connector nut and attach it to the end of
the bolt (located in other base cabinet) turning it clockwise until it’s completely on. Use a 4mm Allen wrench or 4mm Hex bit
and a screw gun to tighten as needed.
• Repeat Step 2 with the remaining bolts and connector nuts so all three base cabinets are attached together.
• NOTE: If you did not remove the totes or waste bins in Step 1, you will need to remove them in order to gain access to the pre-
drilled holes located inside of all three cabinets.

2
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specications are subject to change. Product
images are for illustrative purposes only and may
dier from the actual product.
Step 3:
• With all three cabinets attached together, take caster base and center it on the cabinets with threaded inserts facing up.
• Using #2 square bit, attach caster base to the base cabinets using #10 1½”square-drive at head screws. (See image below;
pre-drilled pilot holes are marked in red as an example for assembly instructions ONLY.)
Step 4:
• Align caster with the threaded inserts.
• Use the ¼-20x25mm joint connector bolts to attach casters to the base cabinet.
• Repeat for the remaining casters. (See image below to see the location for the two locking casters.)
Nucleus
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
specifications
Locking caster
Locking caster

3
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specications are subject to change. Product
images are for illustrative purposes only and may
dier from the actual product.
Clear tab used to help open
cabinets w/ double doors.
Nucleus
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
specifications
Step 5:
• With someone’s help, position the cabinet right side up. Make sure to have all the locking casters’ levers pushed down to secure
cabinet in place.
Step 6:
• Place top on base cabinets. Align pre-drilled holes on the base cabinets with threaded inserts in the top.
• Using a ¼-20x35mm joint connector bolt, (going through one of the base cabinets) insert the bolt through the pre-drilled hole
up into the threaded insert of the top. Use a 4mm Allen wrench or 4mm Hex bit and a screw gun to fasten the bolt into place.
• After the rst bolt is fastened, proceed attaching the remaining bolts in that cabinet. (4 bolts per cabinet)
• Repeat Step 6 for the other two base cabinets.
• If shelving, doors, totes and trash bins were removed, place them back into place.
Step 7:
• Wire pulls are factory installed on the inside of doors to prevent damage intransit. (Use the clear tab to open the double doors.)
• Unscrew each wire pull handle using a Phillips drill bit and a screw gun.
• Reattach with wire pull on the outside of the cabinet.
• Repeat for each of the wire pulls for both base cabinets.
• Remove clear tab on door.
Step 7

4
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specications are subject to change. Product
images are for illustrative purposes only and may
dier from the actual product.
Part # Description Qty.
0400236 ¼-20x30mm joint connector bolt w/ loctite
(Used to attach 2 base cabinets together)
8
0404229 ¼-20x17mm joint connector nut
(Used to attach 2 base cabinets together)
8
040681 #10 1½” square-drive at head screw for wood
(Used to attach caster base to the 3 base cabinets)
12
0400484 3” heavy duty plate casters w/ out brake 4
0400485 3” heavy duty plate casters w/ brake 2
04066947 ¼-20x25mm joint connector bolt (black)
(Used to apply casters)
24
0406686-WO ¼-20x35mm joint connector bolt (black)
(Used to attach base cabinet to top)
12
Part Identifier Key
Tools Required
• 4mm Allen wrench OR
• 4mm Hex bit
• Drill extension
• Phillips drill bit
• Screw gun
• #2 square bit
Nucleus
specifications
