1
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Flip Top Table
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key on next page) Any parts damaged during
shipment must be reported within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Step 1:
• Place table top face down on protected surface so
threaded inserts are facing up.
Step 2:
• Remove Flip Top mechanism from box, place it on the
Flip table top making sure you align with threaded
inserts.
• Using a 4mm Allen wrench or 4mm Hex bit, secure
mechanism (base plate) to table top with 10-24 x 1”
joint connector bolts. Repeat for the 2nd mechanism
(base plate).
Step 3:
• Place leg on mechanism (base plate). Using ⁄” Ball
End Allen wrench extension and battery operated
hand drill to secure at head screws (in assembly kit)
into place. DO NOT FULLY TIGHTEN. See image to
right, screws are circled in red.
• Use a normal “L”shaped Allen Wrench to rmly tighten
4 screws. Do NOT use“T” shaped Allen wrench since
they twist and do not tighten screws properly.
• Repeat for other bases.
Step 4:
• Using #2 square bit, secure handle release to table top
using #10 x 1¼” square pan head screws.
Step 5:
• Attach cord to the top with cable clips using Phillips
head screws. See image to right for location of clips.
• The cord should be uid without any kinks
Step 6:
• With someone’s help, turn table upright.
V040219 subject to change.
Tools Required
• ⁄” Ball End Allen wrench extension
• Normal “L”shaped ⁄”Allen wrench
• Screw gun
• ⁄” Hex bit
• 4mm Allen wrench OR
• 4mm Hex bit
• Phillips head screwdriver
• #2 square bit
Step 2
Step 3
Step 5
Step 4
2
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Part # Description Qty.
0401158 10-24 x 1” joint connecor bolts
(Used to attach mechanism (bases plate) to top) 16
Flat head screws
(Used to attach leg on mechanism (base plate)
8
(Included in hardware pack located in leg box)
Hardware Pack
0404239 #10 x 1¼”square pan head screws
(Used to attach handle release to top)
4
Cable clips
(Used to hold down cable to top)
4 (min. of 2 at installation)
(Included in hardware pack located in leg box)
Phillips head screws
(Used to attach cable clips to top)
4
(Included in hardware pack located in leg box)
Part Identifier Key
Base # Part #: Table D”*
7722 04009399 24” & 30”
7726 04009880 36”
Tubular T-Bases
Base # Part #: Table D”*
7764 040197 24” & 30”
7768 04067272 36”
Arch T-Bases
Base # Part #: Table D”*
5054 04009811 24”
5056 04067307 30” & 36”
DuraCast T-Bases
*Depth is for each set of legs.
Flip Top Table
Parts/ Leg Info.
