WB Mfg ELO ELP3069-ADJ-RR6 User manual

1
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specications are subject to change. Product
images are for illustrative purposes only and may
dier from the actual product.
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
ELO® Ingenuity Table
Assembly Instructions
Step 1:
• Place top face down on protected at surface so threaded
inserts are facing up.
Step 2:
• Align leg with threaded inserts.
• Using a 4mm Allen wrench or 4mm hex bit and a screw gun,
fasten leg to top with the ¼-20 x 15mm joint connector bolts.
• Repeat this for the rest of the legs.
Step 3:
• Adjust legs to desired height and then with someone’s help,
turn table upright.
Step 4:
• Align pre-drilled holes in one of the long laminate rails with
the threaded inserts in the side of the top.
• Using a ¼-20x40mm joint connector bolt, insert the bolt
through the pre-drilled hole in the rail into the threaded
insert of the top. Use a 4mm Allen wrench or a 4mm hex bit
and a screw gun to fasten bolt into place.
• After the rst bolt is fastened, proceed attaching the
remaining bolts in the long rail.
• Repeat Step 4 for the remaining three rails.
V030121 subject to change.
Steps 1-2
Step 4
ELP3069-ADJ-RR6
Step 2
Part Identifier Key
Part # Description Qty.
04009023 ¼”-20 x 15mm joint connector bolts 6 per leg
0406526 ¼”-20 x 40mm joint connector bolts
(Used to attach rails to top) 16
Tools Required
• Screw gun
• 4mm hex bit
• 4mm Allen wrench

2
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specications are subject to change. Product
images are for illustrative purposes only and may
dier from the actual product.
ELO® Ingenuity Tables
w/ Casters & Glides & Leg Info.
Assembly Instructions
Step 1:
• Remove Nylon glide from leg by rotating counterclockwise until glide is free.
Step 2:
• Place stem of optional footing into the hole on the leg. Rotate clockwise
until fully inserted into leg.
• Casters are NOT to be used as a leveling device.
Step 3:
• Tighten with a 14mm open-ended wrench. (only with the Dual wheel soft
tread locking caster.)
Step 4:
• Repeat for each caster or glide.
Tools Required
• 14mm open-ended wrench
Part Identifier Key
Part # Description Qty.
040164 2.5” Grand Hank glide, ⁄-16 x 1” 1 per leg
04067920 1.5” Soft Touch glide 1 per leg
NSL-33056S 1.25” Steel glide 1 per leg
04067540 Dual wheel soft tread locking casters
(N/A on epoxy resin tops) 1 per leg
Adjustable Legs
Model #
Smooth Silver
SKU
Black
SKU Descripon
ELS -ADJ 04067832-G4 04067832 ELO® 2" Straight Round Adj. Leg
ELP -ADJ 04066829-G4 N/A ELO® 2" Straight Round Pin Adj. Leg
ELS -ADJ ELP -ADJ
ELS -FX ELS -FX-CA
Fixed Legs
Model #
Smooth Silver
SKU
Black
SKU Descripon
ELS -FX 04067792-G4 N/A ELO® 2" Round Fixed Leg w/Grand Hank Glide
ELS -FX-CA 04067839-G4 N/A ELO® 2" Round Fixed Leg w/Dual Wheel So Tread Locking Caster
Jr. & Mini Jr. Adjustable Legs
Model #
Smooth Silver
SKU
Black
SKU Descripon
ELS -EJA 04066652-G4 04066652 ELO® 2" Straight Round Jr. Adj. Leg
ELP -EJA 04066785-G4 N/A ELO® 2" Straight Round Pin Jr. Adj. Leg
ELS -MJA 04067425-G4 N/A ELO® 2" Round Jr. Adj. Mini Leg w/Grand Hank Glide
ELS -EJA ELP -EJA ELS -MJA
