LOBO Tables
Laminate/Phenolic & 1 Pc Butcherblock Tops
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key on next page) Any parts damaged during
shipment must be reported within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Step 1:
• Place the LOBO top face down on a protected at
surface.
Step 2:
• Place LOBO frame tabs down on top of the LOBO top and
align with pre-drilled pilot holes.
• If assembling a Stainless Steel top, see Stainless Steel
LOBO Table Assembly Instructions.
• If assembling an Epoxy top, see Epoxy LOBO Table
Assembly Instructions.
• If assembling a 2 piece Hardwood top, see Hardwood
LOBO Table Assembly Instructions.
Step 3:
• Starting at one corner, place the ⁄” bolt that is welded
to leg through corner support brace of frame. Repeat for
remaining legs.
Step 4:
• Using a # R2 square bit, secure the leg plate to the top
with #10 x ¾” square pan screws. Repeat for each leg
plate.
Step 5:
• Place the ⁄”lock washer and ⁄” hex nut onto the leg
bolt and tighten with ½”wrench. Repeat on remaining
legs.
• Adjust the leg to desired height.
Step 6:
• Using a # R2 square bit, secure frame to table top with
#10 x ¾” square pan screws. One screw per tab.
Step 7:
• With someone’s help, turn table upright.
Steps 3
Step 4
V031919 subject to change.
Step 6
Tools Required
• ½” wrench
• Screw gun
• # R2 square bit
• ⁄” hex bit
Steps 5

2
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Part # Description Qty.
0408231
#10 x ¾” Square pan screws
(Used to attach leg plates to laminate top)
(Used to attach frame to laminate and SS tops)
26
(Included in Hardware Pack located in leg box. May
need less depending on size and work service)
Hardware Pack
040379
⁄” Lock washers
⁄” Hex nuts
(Used to attach legs to frame)
4
4
Part Identifier Key
3” Heavy Duty Caster Hardware Pack (04066968) Used only with 2” adj. legs (-ALR & -ABP)
Part # Description Qty.
04067460
04067064
¼” Star washers
M6 1x18 screws
(Used in leg insert to prevent bending of the leg insert)
4 per set
4 per set
(Included in Hardware Pack located in leg box as
standard. Discard if casters are not installed.)
3” Heavy Duty Caster Hardware Pack (0402020) Used only with 1.5” adj. legs (-ADJ)
04067460
0401259
¼” Star washers
M6 1x14 screws
(Used in leg insert to prevent bending of the leg insert)
4 per set
4 per set
(Included in Hardware Pack located in leg box as
standard. Discard if casters are not installed.)
LOB -ADJ
LOB -ABP
LOB -ALR
LOB -FX
Adjustable Legs
Fixed Legs
Model #
Smooth Silver
Sku #
Black
Sku# Descripon Weight Height"
LOB -ADJ 0409195-G4 0409195 LOBO 1.5" (40mm) Square Adj. Leg 18 22 - 36.6
LOB -ALR 0409193-G4 0409193 LOBO 2" (50mm) Round Adj. Leg 20 22.25 - 36.25
LOB -ABP N/A 0409196 LOBO 2" (50mm) Big Paw Sq. Adj. Leg 20 22.25 - 36.25
Model #
Smooth Silver
Sku #
Black
Sku# Descripon Weight Height"
LOB -FX 0409194-G4 0409194 LOBO 1.5" (40mm) Square Fixed Leg 16 28.5
LOBO Legs
LOBO Tables
Laminate/Phenolic & 1 Pc Butcherblock Tops

3
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
LOBO Tables
w/ Gussets
Step 1:
• Make sure that legs are fully installed and adjusted to the
correct height.
Step 2:
• Place gusset in corner where leg and frame meet. Use
a rubber mallet to tap the #10 self-drilling screws into
place.
Step 3:
• Using a screw gun along with a ⁄”hex bit to nish
fastening the gussets to the leg and frame with the #10
self-drilling screws.
Step 4:
• Repeat for remaining gussets.
Gussets w/ Hardware Pack (04066920) Used only with square LOBO legs
Part # Description Qty.
04009742 #10 Self-drilling screws 8 per gusset
04066920 Gusset for square legs 1 per leg
Gussets w/ Hardware Pack (04066918) Used only with round LOBO legs
Part # Description Qty.
04009742 #10 Self-drilling screws 8 per gusset
04066918 Gusset for square legs 1 per leg
Part Identifier Key
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key below) Any parts damaged during shipment must
be reported within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Tools Required
• Screw Gun
• ⁄” Hex Bit
• Rubber Mallet

4
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
LOBO Tables
w/ Casters, Glides & Leg Info.
Step 1:
• Remove Nylon glide from leg by rotating counterclockwise until
glide is free.
Step 2:
• Place stem of optional footing into the hole on the leg. Rotate
clockwise until fully inserted into leg.
• Casters are NOT to be used as a leveling device.
Step 3:
• Tighten with a ½”wrench. (only with the Dual Wheel caster.)
Step 4:
• Repeat for each caster or Grand Hank glide.
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key below) Any parts damaged during shipment must
be reported within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Part # Description Qty.
040164 1⁄ Dia. Grand Hank glide, ⁄-16 x 1” 1 per leg
33021BK Dual wheel casters w/brake 1 per leg
04067195 Soft tread caster 1 per leg
LOB -ADJ
LOB -ABP
LOB -ALR
LOB -FX
Adjustable Legs
Fixed Legs
Model #
Smooth Silver
Sku #
Black
Sku# Descripon Weight Height"
LOB -ADJ 0409195-G4 0409195 LOBO 1.5" (40mm) Square Adj. Leg 18 22 - 36.6
LOB -ALR 0409193-G4 0409193 LOBO 2" (50mm) Round Adj. Leg 20 22.25 - 36.25
LOB -ABP N/A 0409196 LOBO 2" (50mm) Big Paw Sq. Adj. Leg 20 22.25 - 36.25
Model #
Smooth Silver
Sku #
Black
Sku# Descripon Weight Height"
LOB -FX 0409194-G4 0409194 LOBO 1.5" (40mm) Square Fixed Leg 16 28.5
LOBO Legs
Part Identifier Key
Installing casters on tables with epoxy resin tops will void the Epoxy warranty.
Tools Required
• ½”Wrench

5
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Step 1:
• Twist the stem of the caster into the hole on the bottom of the leg. Applying
thread locking adhesive can help prevent unexpected loosening of the
caster.
Step 2:
• Lock the caster by pushing up on the brake lever.
• Casters are NOT to be used as a leveling device.
Step 3:
• Use ¾” wrench to tighten ¾” nut on stem of caster.
Step 4:
• If using adj. legs, insert star washer and M6 screw in hole closest to the
caster and tighten with 4mm hex wrench. DO NOT OVER TIGHTEN.
• If using a FIXED leg, you will NOT need to use a star washer and M6 screw.
Step 5:
• Repeat for remaining casters.
Step 4
Step 1
Step 2
Step 3
Part # Description Qty.
0400993 3” heavy duty locking casters 1 per leg
LOBO Tables
w/ Heavy Duty Casters
Part Identifier Key
3” Heavy Duty Caster Hardware Pack (04066968) Used only with 2” adj. legs (-ALR & -ABP)
Part # Description Qty.
04067460
04067064
¼” Star washers
M6 1x18 screws
(Used in leg insert to prevent bending of the leg insert)
4 per set
4 per set
(Included in Hardware Pack located in leg box)
3” Heavy Duty Caster Hardware Pack (0402020) Used only with 1.5” adj. legs (-ADJ)
04067460
0401259
¼” Star washers
M6 1x14 screws
(Used in leg insert to prevent bending of the leg insert)
4 per set
4 per set
(Included in Hardware Pack located in leg box)
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key below) Any parts damaged during shipment must
be reported within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Tools Required
• ¾”Wrench
• 4mm Hex Wrench
• Thread Locking Adhesive (optional)
Installing casters on tables with
epoxy resin tops will void the
Epoxy warranty.
