WB Mfg EPIC Laminate Top User manual

1
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specications are subject to change. Product
images are for illustrative purposes only and may
dier from the actual product.
Before you begin, please make sure all parts and proper quantities are included. (See Part Identier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
EPIC Tables
Laminate/Phenolic/Butcherblock/Stainless Steel Tops
Assembly Instructions
Step 1:
• Place EPIC frame leg with plate facing down on a at surface.
Step 2:
• Align holes in the end plate of the cross bar with the frame.
Make sure the tabs on the cross bar are facing down.
• Connect cross bar to the frame using ¼”-20 x 50mm joint
connector bolts and ¼”-20 joint connector nuts.
• Use a screw gun and a 4mm Hex bit to tighten the joint
connector bolts to the nut. We suggest using a 4mm Hex
wrench to hold the nut in place while tightening the bolt.
• Repeat for other frame leg.
Step 3:
• Place the EPIC top face down on a protected at surface
so threaded inserts(marked in green) and pre-drilled pilot
holes(marked in yellow) are facing up.
Step 4:
• Place frame leg/cross bar on the top and align with threaded
inserts & pre-drilled pilot holes.
• Using a screw gun and a 4mm Hex bit, secure both frame legs
to top with ¼”-20 x 15mm joint connector bolts. Use eight
bolts for each frame leg.
Step 5:
• Using a screw gun and a # S2 square bit, secure cross bar to
top with #10 x ¾” square pan screws. Use one screw per tab
with a total of six screws being used (3 per side).
Step 6:
• Before placing caster in the bottom of the frame leg, lock the
caster by pushing down on the brake lever.
• Twist the stem of the caster into the hole on the bottom of
the leg frame. Applying thread locking adhesive can help
prevent unexpected loosening of the caster.
• Use ¾” wrench to tighten ¾” nut on stem of caster.
• Repeat for remaining casters.
Step 7:
• With someone’s help, turn table upright.
Tools Required
• Screw gun
• # S2 square bit
• 4mm Hex bit
• 4mm Hex wrench
• ¾”Wrench
• Thread Locking
Adhesive (optional)
Step 6
Step 4
Step 7
EPIC frame leg
Step 1Step 2
Cross bar
Tab
Joint connector bolt
Joint connector nut
Step 5
Step 3
V012821 subject to change.

2
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specications are subject to change. Product
images are for illustrative purposes only and may
dier from the actual product.
EPIC Tables
Laminate/Phenolic/Butcherblock/Stainless Steel Tops
Assembly Instructions
Part # Description Qty.
04067960 ¼”-20 x 50mm joint connector bolts 2 per leg frame (4 total)
04009022 ¼”-20 joint connector nuts
(Used to attach cross bar to leg frame) 2 per leg frame (4 total)
04009023 ¼”-20 x 15mm joint connector bolts
(Used to attach leg plates to top) 8 per leg plate (16 total)
0408231 #10 x ¾” Square pan screw
(Used to attach cross bar to top) 3 per side of the cross bar (6 total)
0400993 3” heavy duty locking casters 1 per leg (4 total)
Part Identifier Key
Model # Sku # Descripon
EPC -FX 04067852 EPIC xed frame leg w/3” heavy duty locking casters
EPC -WFX 04067853 EPIC xed frame leg w/3” heavy duty locking casters
EPC -SFX 04067854 EPIC xed frame leg w/3” heavy duty locking casters
EPIC Frame Legs
Standard Frame Color
G4
Smooth Silver
B
Blue
G
Green
Additional Colors
Orange
O
Red
R
Purple
P
Textured Black
09
