wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
1
Step 1:
• Place the top face down on a protected flat surface.
Step 2:
• Place LOBO frame tabs down on top of the top and align
the frame tabs with pre-drilled pilot holes in the top.
Step 3:
• Using a # S2 square bit, secure frame to top with #10 x
⁄” square pan screws using one screw per tab.
Step 4:
• Starting at one corner, place the ⁄” bolt that is welded
to leg through corner support brace of frame.
Step 5:
• Place the ⁄” lock washer and ⁄” hex nut onto the leg
bolt and tighten with ⁄” wrench. Repeat Steps 4 & 5 on
remaining legs.
Step 6:
• Use a ⁄” hex bit to secure the leg plate to the top with
#10 16x⁄” hex washer head self-drilling screws. Table
will not have pre-drilled holes for the leg plates.
Step 7:
• Adjust the leg to desired height.
Step 8:
• With someone’s help, turn table upright.
Steps 4 & 5
Step 3
Step 6
Assembly Instructions
LOBO Table
Stainless Steel Top
Before you begin, please make sure all parts and proper
quantities are included. (See Part Identifier Key) Any parts
damaged during shipment must be reported within 24 hours of
receipt. To report information regarding damages or if you have
any questions, please call 800.242.2303.
Tools Required
• ⁄” wrench
• Screw gun
• #S2 square bit
V122821 Version subject to change
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
2
Part # Description Qty.
0408231 #10 x ⁄” square pan screws
(Used to attach frame to top.)
26
(Included in hardware pack located in leg box. May
have extra depending on size of top.)
04009742 #10 16x⁄” hex washer head self-drilling screws
(Used to attach leg plates to top.)
16
(Hardware pack not included in leg box.)
Hardware
Pack
040379
⁄” lock washers 4
⁄” hex nuts
(Used to attach legs to frame.) 4
Part # Description Qty.
04066968
3” Heavy Duty Caster Hardware Pack - Used only with 2” adj. legs (-ALR & -ABP) (Discard if casters are not installed.)
⁄” star washers (04067460) 4 per set
M6 1x18 screws (04067064) 4 per set
Part # Description Qty.
0402020
3” Heavy Duty Caster Hardware Pack - Used only with 1.5” adj. legs (-ADJ) (Discard if casters are not installed.)
⁄” star washers (04067460) 4 per set
M6 1x14 screws (04067064) 4 per set
Part Identifier Key
Assembly Instructions
LOBO Table
Stainless Steel Top
Adjustable Legs
Model #
Smooth Silver
Sku #
Black
Sku# Description Weight Leg Height"
LOB -ADJ 0409195-G4 0409195 LOBO 1.5" (40mm) Square Adj. Leg 18 22.25 - 36.25
LOB -ALR 0409193-G4 0409193 LOBO 2" (50mm) Round Adj. Leg 20 22.25 - 36.25
LOB -ABP N/A 0409196 LOBO 2" (50mm) Big Paw Sq. Adj. Leg 20 22.25 - 36.25
Fixed Legs
Model #
Smooth Silver
Sku #
Black
Sku# Description Weight Leg Height"
LOB -FX 0409194-G4 0409194 LOBO 1.5" (40mm) Square Fixed Leg 16 28.75
LOB -FX
LOB -ADJ LOB -ABP
LOB -ALR
LOBO Legs
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
3
Part # Description Qty.
04066920
Gussets w/ hardware pack - Used only with square LOBO legs
#10-16 x ⁄” hex head self-drilling screws (04009742) 8 per gusset
Gusset for square legs 1 per leg
Step 1:
• Make sure that legs are fully installed and adjusted to the
correct height.
Step 2:
• Place gusset in corner where leg and frame meet. Use a
rubber mallet to tap #10-16 x 3/4” hex head self-drilling
screws into place.
Step 3:
• Using a screw gun along with a ⁄” hex bit. fasten the
gussets to the leg and frame with #10-16 x 3/4” hex head
self-drilling screws.
Step 4:
• Repeat for remaining gussets.
Gussets are only available on rectangle
and round shaped tables.
Part Identifier Key
Part # Description Qty.
04066918
Gussets w/ hardware pack - Used only with round LOBO legs
#10 Self-drilling screws (04009742) 6 per gusset
Gusset for round legs 1 per leg
Before you begin, please make sure all parts and proper
quantities are included. (See Part Identifier Key) Any parts
damaged during shipment must be reported within 24 hours of
receipt. To report information regarding damages or if you have
any questions, please call 800.242.2303.
LOBO Table
w/Gussets
Assembly Instructions
Tools Required
• Screw gun
• ⁄” wrench
• #S2 square bit
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
4
Step 1:
• Remove nylon glide from leg by rotating counter-clockwise until
glide is free.
Step 2:
• Place stem of optional footing into the hole on the leg. Rotate
clockwise until fully inserted into leg.
Step 3:
• Tighten with a 14mm open-ended wrench. (Only for the dual wheel
soft tread locking caster.)
Step 4:
• Repeat for each caster or glide.
Installing casters on tables with epoxy
resin tops will void the epoxy warranty.
LOB -FX
LOB -ADJ LOB -ABP
LOB -ALR
Fixed Legs
Model #
Smooth Silver
Sku #
Black
Sku# Description Weight Leg Height"
LOB -FX 0409194-G4 0409194 LOBO 1.5" (40mm) Square Fixed Leg 16 28.75
Adjustable Legs
Model #
Smooth Silver
Sku #
Black
Sku# Description Weight Leg Height"
LOB -ADJ 0409195-G4 0409195 LOBO 1.5" (40mm) Square Adj. Leg 18 22.25 - 36.25
LOB -ALR 0409193-G4 0409193 LOBO 2" (50mm) Round Adj. Leg 20 22.25 - 36.25
LOB -ABP N/A 0409196 LOBO 2" (50mm) Big Paw Sq. Adj. Leg 20 22.25 - 36.25
LOBO Legs
Part Identifier Key
NOTE: Casters are not to be used as a leveling device.
Loctite on casters will cause some resistance while
tightening, please make sure that casters are tightened all
the way to prevent possible damage to the stem of the caster.
Before you begin, please make sure all parts and proper
quantities are included. (See Part Identifier Key) Any parts
damaged during shipment must be reported within 24 hours of
receipt. To report information regarding damages or if you have
any questions, please call 800.242.2303.
LOBO Table
w/Casters/Glides
Assembly Instructions
Tools Required
• Screw gun
• ⁄” wrench
• #S2 square bit
Part # Description Qty.
040164 2.5” Grand Hank glide,⁄ x 1” 1 per leg
04067920 1.5” soft touch glide 1 per leg
NSL-33056S 1.25” steel glide 1 per leg
04067540 Dual wheel soft tread locking casters
(N/A on epoxy resin tops) 1 per leg
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
5
Step 1:
• Lock the caster by pushing down on the brake lever.
Step 2:
• Twist the stem of the caster into the hole on the bottom of the leg.
Pre-applied thread locking adhesive will help prevent unexpected
loosening and may cause slight resistance while tightening the
caster.
Step 3:
• Use 1⁄” wrench to tighten ⁄” nut on stem of caster.
Step 4:
• If using adj. legs, insert star washer and M6 screw in hole closest
to the caster and tighten with 4mm hex wrench. DO NOT OVER
TIGHTEN.
• If using a FIXED leg, you will NOT need to use a star washer and
M6 screw.
Step 5:
• Repeat for remaining casters.
Step 4
Step 2
Step 1
Step 3
Casters are NOT to be used as a leveling device.
Assembly Instructions
LOBO Table
w/Heavy Duty Casters
Part Identifier Key
Before you begin, please make sure all parts and proper
quantities are included. (See Part Identifier Key) Any parts
damaged during shipment must be reported within 24 hours of
receipt. To report information regarding damages or if you have
any questions, please call 800.242.2303.
Tools Required
• 1⁄” wrench
• 4mm hex wrench
Installing casters on tables with epoxy
resin tops will void the epoxy warranty.
Part # Description Qty.
0400993 3” heavy duty locking casters 1 per leg
Part # Description Qty.
0402020
3” Heavy Duty Caster Hardware Pack - Used only with 1.5” adj. legs (-ADJ)
⁄” star washers (04067460) 4 per set
M6 1x14 screws (0401259)
(Used in leg insert to prevent bending of the leg insert) 4 per set
Part # Description Qty.
04066968
3” Heavy Duty Caster Hardware Pack - Used only with 2” adj. legs (-ALR & -ABP)
⁄” star washers (04067460) 4 per set
M6 1x18 screws (04067064) 4 per set
