1
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
Rhapsody® Bass Racks
Assembly Instructions
Before you begin, please make sure all parts and proper quantities are included. (See Part Identifier Key) Any parts damaged during shipment must be reported
within 24 hours of receipt. To report information regarding damages or if you have any questions, please call 800.242.2303.
Tools Required
• 4mm Allen
Wrench
• Phillips screw
driver
• Screw gun
• Square screw
driver
Step 1:
• With the help of another person, align the threaded inserts of one of the braces to one of the rails.
• Using a ⁄”-20x20mm joint connector bolt, insert the bolt going through the pre-drilled hole in the rail to the threaded insert of the brace. Use a 4mm
Allen wrench or 4mm hex bit and a screw gun to fasten the bolt into place. Repeat this step for the second joint connector bolt for this brace.
• After the first brace is attached on one side, repeat the above step for the remaining braces.
• Repeat this step for the second rail.
Step 2:
• Align the pre-drilled holes in the (right) side panel with the threaded inserts in one of the rails.
• Using a ⁄”-20x20mm joint connector bolt, insert the bolt going through the pre-drilled hole in the side panel to the threaded inserts of the rail. Use a
4mm Allen wrench or 4mm hex bit and a screw gun to fasten the bolt into place. Repeat for the remaining joint connector bolt.
• Repeat this step to attach the remaining rails and side panels until all points are connected.
Rails
(shown in
purple)
Braces
(shown in
blue)
Side panel
(shown in
yellow)
NOTE: Colored images are for
illustrative purposes only.
(Right)
(Left)
V071221 Version subject to change
2
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
Step 3:
• Align the pre-drilled holes in the (lower) back support rail with the threaded inserts in the (right) side panel. Using a ⁄”-20x20mm joint connector
bolt, insert the bolt going through the pre-drilled hole in the (right) side panel to the threaded inserts of the (lower) back support rail. Use a 4mm Allen
wrench or 4mm hex bit and a screw gun to fasten the bolt into place. You will repeat this step for the other joint connector bolt.
• After the first back support rail is attached on one side, repeat for the (left) side panel.
• Repeat this step for the (upper) back support rail.
Rhapsody® Bass Racks
Assembly Instructions
Back support rails
(shown in orange)
Side panel
(shown in
yellow)
(Upper)
(Lower)
(Right)
(Left)
NOTE: Parts shown in grey have been assembled in previous steps.
NOTE: Colored images are for illustrative purposes only.
3
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
Rhapsody® Bass Racks
Assembly Instructions
Step 4:
• Align the pre-drilled holes in the neck holder with the
threaded inserts in the (upper) back support rail.
• Using a ⁄”-20x20mm joint connector bolt, insert the bolt
going through the pre-drilled hole in the neck holder to
the threaded inserts of the (upper) back support rail. Use
a 4mm Allen wrench or 4mm hex bit and a screw gun to
fasten the bolt into place. You will repeat this step for the
remaining joint connector bolts.
• The holes in the side panels and the threaded inserts in
the neck holder should already be aligned.
• Using a ⁄”-20x20mm joint connector bolt, insert the bolt
going through the pre-drilled hole in the (right) side panel
to the threaded insert of the neck holder. Use a 4mm Allen
wrench or 4mm hex bit and a screw gun to fasten the bolt
into place.
• Repeat this step to attach the neck holder to the (left) side
panel.
Step 5:
• Align the pre-drilled holes in the bottom support rail with
the threaded inserts in the (lower) back support rail.
• Using a ⁄”-20x20mm joint connector bolt, insert the bolt
going through the pre-drilled hole in the bottom support
rail to the threaded insert of the (lower) back support rail.
Use a 4mm Allen wrench or 4mm hex bit and a screw gun
to fasten the bolt into place. Repeat for the remaining joint
connector bolts.
• The holes in the side panels and the threaded inserts in
the bottom support rail should already be aligned.
• Using a ⁄”-20x20mm joint connector bolt, insert the bolt
going through the pre-drilled hole in the bottom support rail
to the threaded insert of the (right) side panel. Use a 4mm
Allen wrench or 4mm hex bit and a screw gun to fasten the
bolt into place.
• Repeat this step to attach the bottom support rail to the
(left) side panel.
(Upper)
Back support rails
(shown in orange)
Neck holder
(shown in green)
Bottom support rail
(shown in blue)
Side panel
(shown in
yellow)
(Left)
(Right)
NOTE: Parts shown in grey have been assembled in previous steps.
NOTE: Colored images are for illustrative purposes only.
Step 4
Step 5
4
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
Step 6:
• With the help of another person, place the Bass Rack on its’ back on a
protected flat surface.
• Attach the reinforcement bracket to the side panel by using a
⁄”-20x20mm joint connector bolt going through pre-drilled hole in the
bracket and the side panel, making sure bolt is pushed as far as it can
go. While holding the joint connector bolt flush to the side panel, take
a ⁄”-20 joint connector nut and attach it to the end of the bolt turing it
clockwise until it’s completely on. Use a 4mm Allen wrench or 4mm hex
bit and a screw gun to tighten as needed.
• Repeat with the remaining (3) reinforcement brackets.
Step 7:
• Attach the 3” wheel caster by threading the stem of the locking caster
into the reinforcement bracket making sure it’s threaded all the way.
• Repeat for the remaining (3) locking casters.
Rhapsody® Bass Racks
Assembly Instructions
CUSTOMER REF. NO.
0400993
SHEET 1 OF 1
EMB
DWG. NO.
TITLE:
 
REV
SQUARE FOOT
Phone: 715-669-5360; Fax: 715-669-5929
ANGULAR:
3" wheel, 4" load height, 3" swivel rad.,
written permission of WISCONSIN BENCH
CUST. No.CUSTOMER NAME:
FILE LOCATION:
REF. NO.
xx-xx-xx
thereon to others without the expressed
NONE
SCALE:
reserves the right to change specifications,
disclose this drawing or any information
copy, distribute, reproduce, transmit or
and proprietary. WISCONSIN BENCH
in WISCONSIN BENCH. Holder may not
rights, title, and interest therein reside entirely
BENCH and are to be treated as confidential
unless the drawing is marked certified. All
1 °
DRAWN BY
REVISION DESCRIPTION BY DATE
DRAWN DATE
1.25" tread width, w/brake
PT
This drawing and the information contained
herein are the property of WISCONSIN
TOLERANCES:
2 PLC. DEC. .06
3 PLC. DEC. .031
507 E. Grant St., Thorp, WI 54771
3” wheel
caster
Reinforcement
bracket (shown
in red)
Step 6
Step 7
Step 8
(Upper) Back
support rail (shown
in orange)
NOTE: Colored images are for illustrative purposes only.
Hook, single utility
Step 8:
• Attach the hook, single utility to the (upper) back support rail by using two
hook screws per hook. There will be pre-drilled holes to guide you.
• With someones help, lift the Bass Rack to an upright position.
5
wibenchmfg.com 507 E. Grant St. Thorp, WI 54771 • P - 800.242.2303
Specifications are subject to change. Product
images are for illustrative purposes only and may
differ from the actual product.
Part # Description Qty.
Varies by Model # Side panel
(shown in yellow)2
Varies by Model # Rail
(shown in purple)2
Varies by Model # Brace
(shown in light blue)Varies
Varies by Model # Neck holder
(shown in green)1
Varies by Model # Back support rail
(shown in orange)2
Varies by Model # Bottom support rail
(shown in dark blue)1
0406517 Joint Connector Bolt,
⁄”-20 x 1⁄” Black 47
0406750 Hook Single Utility,
For Reference Only 4
0400706 Hook Screw,
6 x ⁄” SS 8
0400861 14 GA. Reinforcement
Bracket for 1” Legs 4
0404229 ⁄”-20 Joint
Connector Nut 8
0404228 Joint Connector Bolt
⁄”-20 x 20mm Black 8
Rhapsody® Bass Racks
Assembly Instructions
Part Identifier Key
