www.weg.net
Automatic Voltage Regulator – AVR-A-OPT-16 | 9
INDEX
1 SAFETY INFORMATION .......................................................................................... 11
2 STORAGE INFORMATION ....................................................................................... 11
3 INTRODUCTION ..................................................................................................... 11
4 TECHNICAL CHARACTERISTICS ............................................................................. 12
5 REGULATOR NAMEPLATE ...................................................................................... 12
6 BLOCK DIAGRAM ................................................................................................... 13
7 TRIMPOTS FUNCTION ............................................................................................ 13
8 TRIMPOTS ADJUSTMENT ....................................................................................... 13
OPERATION ........................................................................................................... 14
.1 VOLTAGE REGULATOR ......................................................................................................................... 14
.2 POWER CIRCUIT CONNECTION ........................................................................................................... 14
.3 FIELD FLASHING .................................................................................................................................... 14
.4 U/F OPERATION .................................................................................................................................... 14
.5 PARALLEL OPERATION FOR TWO OR MORE GENERATORS¹ ............................................................. 15
10 CONNECTION DIAGRAMS ...................................................................................... 16
11 DIMENSIONAL DRAWINGS (MM) ............................................................................. 17
12 IDENTIFICATION OF CONNECTION TERMINALS ...................................................... 17
13 DIAGRAM FOR TEST WITHOUT GENERATOR .......................................................... 17
14 PROBLEMS, CAUSES AND CORRECTIVE ACTIONS ................................................ 1
15 PREVENTIVE MAINTENANCE .................................................................................. 1
16 WARRANTY ........................................................................................................... 1
NOTES .......................................................................................................................... 20
