Weider Pro 120 WEEVBE70200 User manual

¨
Part No. 172312 R1200A Printed in China © 2000 WEIDER is a registered trademark of ICON Health & Fitness, Inc.
Model No. WEEVBE70200
Serial No.
The serial number can be found in the
location shown below. Write the serial
number in the space above.
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Save this
manual for future reference.
USER'S MANUAL
Serial Number Decal (under bench)
ORDERING REPLACEMENT PARTS
If you encounter any difficulties or problems with this product, contact the ICON Fitness Lifestyle Ltd. office, or
write:
ICON Health & Fitness Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road
Leeds
LS11 8JG
Tel: Country Code: 0345-089009
Fax: [phone]
To help us assist you, please be prepared to give the following information:
¥ The MODEL NUMBER of the product (WEEVBE70200)
¥ The NAME of the product (WEIDER¨PRO 120 weight bench)
¥ The SERIAL NUMBER of the product (see the front cover of this manual)
¥ The KEY NUMBER and DESCRIPTION of the desired part(s) (see page 7 of this manual).
QUESTIONS?
As a manufacturer, we are
committed to providing
complete customer satisfaction.
If you have questions, or if
there are missing parts, we will
guarantee complete satisfaction
through our Customer Service
Department.
Please CALL:
Or WRITE:
ICON Health & Fitness Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road
Leeds
LS11 8JG
0345-089009
www.weiderfitness.com
Visit our website at

2
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ADJUSTING THE WEIGHT BENCH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
4
12
1
11
5
16
13
2
9
9
15
14
9
3
9
6
10
7
6
7
8
PART LIST and R1200A
EXPLODED DRAWINGÑModel No. WEEVBE70200
Note: Ò#Ó indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of this manual for information about ordering replacement parts.
Key
No. Qty. Description
1 1 Frame
2 1 Pivot Leg
3 1 Adjustment Leg
4 2 M6 x 50mm Screw
5 2 M6 x 16mm Screw
6 4 Foam Pad
7 4 3/4Ó Round Inner Cap
8 1 38mm x 50mm Inner Cap
9 4 50mm Round Outer Cap
Key
No. Qty. Description
10 2 Pad Tube
11 2 Lock Pin
12 1 Bench
13 1 M10 Nylon Locknut
14 1 M10 x 70mm Bolt
15 1 ÒLÓ Pin
16 1 38mm x 38mm Inner Cap
# 1 UserÕs Manual
7
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precautions
before using the weight bench.
1. Read all instructions in this manual before
using the weight bench.
2. Use the weight bench only as described in
this manual.
3. Use the weight bench only on a level surface.
Cover the floor beneath the weight bench for
protection.
4. Inspect and tighten all parts regularly.
Replace any worn parts immediately.
5. Keep children under the age of 12 and pets
away from the weight bench at all times.
6. Always wear athletic shoes for foot protec-
tion whilst exercising.
7. The weight bench does not include weights.
The weight bench is designed to support a
maximum of 300 pounds (135 kg), including
the user and weights.
8. When using the weight bench, make sure
that the lock pins are fully inserted and are
turned to the locked position.
9. If you feel pain or dizziness at any time
whilst exercising, stop immediately and
begin cooling down.
10. It is the responsibility of the owner to ensure
that all users of the weight bench are ade-
quately informed of all precautions.
11. The decals shown below have been placed
on the weight bench. If the decals are miss-
ing or illegible, please call our Customer
Service Department at 0345-089009 to order a
free replacement decal. Apply the replace-
ment decal in the location shown.
WARNING: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
Keep hands and
fingers clear of
this area.
¥ Misuse of this
product may result in
serious injury.
WARNING
!
¥ Read userÕs manual
and follow all warnings
and operating instruc-
tions prior to use.
¥ Replace label if
damaged, illegible,
or removed.
¥ Do not allow children
on or around machine.
Note: The decals are
shown at 65% of
actual size.

ADJUSTING THE PIVOT LEG
To change the position of the Pivot Leg (2), remove the
ÒLÓ Pin (15). Align the other set of holes in the Pivot Leg
and the Frame (1). Re-insert the ÒLÓ Pin.
ADJUSTING THE LEVEL OF THE BENCH
To change the level of the Bench (12), remove both
Lock Pins (11) from the Frame (1) and Adjustment Leg
(3). Align the set of holes in the Frame with another set
of holes in the Adjustment Leg. Re-insert the Lock Pins.
Always use both Lock Pins.
ADJUSTING THE WEIGHT BENCH
The weight bench is designed to be used with your own weights (not included). The steps below explain how the
weight bench can be adjusted. Refer to the accompanying exercise poster for exercise information.
Inspect and tighten all parts each time you use the weight bench. Replace any worn parts immediately. The
weight bench can be cleaned with a damp cloth and a mild, non-abrasive detergent. Do not use solvents.
2
1
1
15
11
12
3
6 3
BEFORE YOU BEGIN
Backrest
Lock Pins
Adjustment Leg
Pivot Leg
Thank you for selecting the WEIDER¨PRO 120 weight
bench. The PRO 120 weight bench is designed to be
used with your own weights (not included) to develop
several muscle groups. Whether your goal is a shape-
ly figure, dramatic muscle size and strength, or a
healthier cardiovascular system, the PRO 120 weight
bench will help you to achieve the specific results you
want.
For your benefit, read this manual carefully before
using the weight bench. If you have additional ques-
tions, please call our Customer Service Department.
To help us assist you, please note the product model
number and serial number before calling. The model
number is WEEVBE70200. The serial number can be
found on a decal attached to the weight bench (see
the front cover of this manual).
Before reading further, please review the drawing
below and familiarise yourself with the parts that are
labelled.
Foam Pads
Foam Pads

1. Before beginning assembly, be sure that you
have read and understand the information on
the previous page.
Press the 38mm x 38mm Inner Cap (16) into the
end of the Frame (1). Press two 50mm Round
Outer Caps (9) onto the Adjustment Leg (3). Press
the 38mm x 50mm Inner Cap (8) into the Adjustment
Leg.
Align the indicated holes in the Frame (1) and the
Adjustment Leg (3). Attach the Adjustment Leg to
the Frame with two Lock Pins (11).
2. Align the indicated holes. Attach the Pivot Leg (2) to
the Frame (1) with the M10 x 70mm Bolt (14) and
the M10 Nylon Locknut (13).
Secure the Pivot Leg (2) by inserting the ÒLÓ Pin
(15) through the indicated hole in the Pivot Leg and
the corresponding hole in the Frame (1).
Press two 50mm Round Outer Caps (9) onto the
Pivot Leg (2).
3. Press 3/4Ó Round Inner Caps (7) into the ends of
both Pad Tubes (10).
Insert the Pad Tubes (10) into the Adjustment Leg
(3).
Slide Foam Pads (6) onto the ends of both Pad
Tubes (10).
4. Attach the Bench (12) to the Frame (1) with two M6
x 50mm Screws (4) and two M6 x 16mm Screws (5). 4
1
1
8
16
11
9
3
2
3
54
ASSEMBLY
Before beginning assembly, carefully read the
following information and instructions:
¥ Place all parts in a cleared area and remove the
packing materials; do not dispose of the packing
materials until assembly is completed.
¥ Read each assembly step before you begin.
¥ For help identifying the small parts used in
assembly, use the part identification chart
below. The number in parenthesis below each
part refers to the key number of the part. The
second number refers to the quantity needed for
assembly. Note: Some small parts may have
been pre-attached for shipping. If a part is not
in the parts bag, check to see if it has been
pre-attached.
¥ Tighten all parts as you assemble them, unless
instructed to do otherwise.
¥ During assembly, make sure that all parts are ori-
ented as shown in the drawings.
THE FOLLOWING TOOLS (NOT INCLUDED)
ARE REQUIRED FOR ASSEMBLY:
¥ Two adjustable spanners
¥ One Phillips screwdriver
Assembly will be more convenient if you have the
following tools: A socket set, a set of open-end or
closed-end spanners, or a set of ratchet spanners.
38mm x 50mm Inner Cap (8)Ð1
M10 Nylon Locknut (13)Ð1
M6 x 16mm Screw (5)Ð2
38mm x 38mm Inner Cap (16)Ð1
50mm Round Outer Cap (9)Ð4
3/4Ó Round Inner Cap (7)Ð4
M6 x 50mm Bolt (4)Ð2
M10 x 70mm Bolt (14)Ð1
1
13
2
9
14
Align these
Holes
Align these
Holes
3
12
1
54
10
7
6
76
15
