weinor PergoTex Type A Manual

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 1/14
PergoTex
PergoTex Type A
Folding patio roof with
electric motor
ENGLISH
Important guidelines for the end user.
Please read these instructions and observe their contents and warnings before using
the equipment for the first time.

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 2/14
PergoTex
Contents
1Notes on Maintenance Instructions and Directions for Use.................................... 3
1.1Depiction................................................................................................................................3
1.1.1Warnings...........................................................................................................................3
1.1.2Tips and recommendations...............................................................................................3
1.1.3Illustrations........................................................................................................................3
1.1.4Instructions requiring action ..............................................................................................3
2Product description..................................................................................................... 4
2.1Exploded drawing ..................................................................................................................4
2.2Description of construction and function................................................................................5
3General safety notes ................................................................................................... 6
3.1Use.........................................................................................................................................6
3.2Use in winds...........................................................................................................................7
3.3Explanation of wind resistance classes .................................................................................7
3.4Use in rain..............................................................................................................................8
3.5Automatic controls .................................................................................................................8
3.6General notes on the fabric....................................................................................................8
4Specific safety notes................................................................................................... 9
4.1Checking and monitoring the PergoTex.................................................................................9
4.2Operation...............................................................................................................................9
4.3Disassembly and Disposal.....................................................................................................9
5Maintenance and care instructions.......................................................................... 10
5.1Cleaning and maintenance work in the opening space of the PergoTex.............................10
5.2Maintenance ........................................................................................................................10
5.3Foliage and foreign bodies...................................................................................................10
5.4PergoTex care .....................................................................................................................11
5.5Cleaning the powder-coated aluminium parts......................................................................11
5.5.1In saltwater areas............................................................................................................11
5.5.2In non-saltwater areas.....................................................................................................11
5.6Cleaning PVC fabrics...........................................................................................................11
6Rectifying Faults........................................................................................................ 13
6.1Troubleshooting...................................................................................................................13
7Retrofits...................................................................................................................... 13
8Noise Level................................................................................................................. 13
9Other weinor products .............................................................................................. 14

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 3/14
PergoTex
1 Notes on Maintenance Instructions and Directions for Use
You have chosen a high-quality weinor product. Many years of experience and the use of low-
wear, corrosion-resistant metals and high-strength plastics vouch for the product.
Care and quality are fundamental principles that weinor applies in making its products and which
have made them so popular.
To ensure you enjoy our product for many years to come, please observe the following
guidelines and instructions.
weinor, quality from the very beginning!
1.1 Depiction
1.1.1 Warnings
The warnings differentiate between personal injury and damage to property. The signal word
"Danger" is used for personal injury, and "Caution" for property damage.
Immediate danger to life and limb!
Immediate danger to product and environment!
1.1.2 Tips and recommendations
Highlights tips and information that make for correct use of the product.
1.1.3 Illustrations
Notes on item numbers can be found in the text in parentheses, e.g. (1).
1.1.4 Instructions requiring action
Instructions requiring action are written in bold print. If the instruction requiring action consists of
several individual steps, these have been numbered in the order in which they are to be carried
out, e.g. :
1. Mount wall brackets
1. Determine position
2. Prepare and drill holes
DANGER
IMPORTANT

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 4/14
PergoTex
2 Product description
2.1 Exploded drawing
Figure 1: Exploded drawing PergoTex
1 Gutter cap left 16 Transom 36x60
2
3 Gutter cap right End cap for cover 17 18 Transom 80x60 Transom cap 36x60
4
5 End cap for cover Wall connection capping 19 20 Transom cap 80x60 Side channel
6 Angle bracket locking bar 21 Trapezium-shaped sheeting
7 Guttering 22 Fabric roller
8 end cap 23 Fabric attachment profile outside
9
10 Bracket for PergoTex Type A Frame profile 80x50x2 24 25 Fabric attachment profile inside U profile 40x40x40x2
11 Beaded profile 26 Wall bracket
12
13
14
Carriage
Motor
Post
27
28
29
Wind protection seal strip
Angle bracket, 25x30x2
Angle bracket, 25x25x2
15 Post plate

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 5/14
PergoTex
2.2 Description of construction and function
The PergoTex is a sun and rain protection unit with a fabric that opens to protect against the sun
and rain.
The PergoTex can be fitted to any angle of pitch ranging between 8° and 45° depending on the
projection and installation height of the awning.
When the awning is closed, the protective roof extensively protects the fabric against
weathering.
Only high-quality corrosion resistant materials are used in the PergoTex. The profiles are made
of extruded aluminium, while the support brackets and other cast parts are made of aluminium.
All connecting parts, such as screws, are made of stainless steel.

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 6/14
PergoTex
3 General safety notes
Product and property damage
Risk of damage to the product and property due to improper use of the PergoTex.
Please read and observe the general safety notes contained in this section.
3.1 Use
Your weinor PergoTex has been made with great care; however, your PergoTex is and
always will be a sun and rain protection unit and must therefore be retracted immediately
during storms, snowfalls or strong winds (at and above wind strength 8). The leafs on the
glazing elements must be fully opened.
If the PergoTex is retracted when wet, it should be opened once it has stopped raining to
allow the fabric to dry.
The motor that is supplied as standard with the PergoTex has been designed to run for a
maximum of four minutes at a time. If the running time is exceeded – e.g. by frequently
opening and retracting the awning – the internal thermo protector may automatically switch
off the motor. In this case, please wait until the motor has cooled down (approx. 15 – 20
minutes depending on the outside temperature) and is ready for operation again.
If your PergoTex is fitted with a sun, wind or rain sensor, the controls will switch to automatic
control after a loss of power depending on the type of controls. Awning systems that had
previously been set to manual operation may therefore run automatically after a loss of
power.
If there is a risk of frost, the awning system must be switched from automatic to manual
control to prevent it from opening automatically. The system must not be used in frosty
conditions or if there is a risk of frost.
The PergoTex can be opened to any position up to its maximum length.
IMPORTANT

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 7/14
PergoTex
3.2 Use in winds
The PergoTex complies with the requirements of the wind resistance class shown on the EC
declaration of conformity printed in the instructions for assembly Instructions. The wind
resistance class achieved after assembly of the awning is heavily dependent on the type and
number of fixings used as well as the installation surface involved.
The PergoTex may only be used up to the wind resistance class specified by the company fitting
the awning. This may deviate from the wind resistance class stated by the manufacturer.
3.3 Explanation of wind resistance classes
Wind force
acc. to
the
Beaufort
scale
Description of
wind force Effect on land
0 Calm Calm, smoke rises vertically
1 Light air Barely noticeable, smoke drift indicates wind direction, still
wind vanes
2 Light breeze Leaves rustle, wind felt on face
3 Gentle breeze Leaves and small twigs constantly moving, light flags
extended
4 Moderate breeze Small tree branches move, loose paper lifted
5 Fresh breeze Larger twigs and trees in leaf move, wind clearly audible
6 Strong breeze Larger tree branches moving, telegraph masts whistle in the
wind
7 Near gale Trees sway, resistance felt walking against wind
8 Gale Large trees moving, shutters opening, twigs breaking off
trees, generally impedes progress

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 8/14
PergoTex
3.4 Use in rain
For best results when using the PergoTex and for best rain drainage, the PergoTex should be
set at an angle of more than 8°.
3.5 Automatic controls
A PergoTex must never be left unattended when open. The automatic controls may fail under
extreme conditions (e.g. power failures, defects, sudden storms). There is a risk that the
PergoTex could be damaged.
Our recommendation: if you vacate the area, switch the PergoTex from automatic to manual
control and leave it retracted.
3.6 General notes on the fabric
It is perfectly normal for a small amount of condensation to form on the fabric. This does not form
grounds for complaint, non-acceptance or price reductions.

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 9/14
PergoTex
4 Specific safety notes
Personal injury
Risk of personal injury due to improper use of the PergoTex.
Please read and observe the specific safety notes contained in this section.
4.1 Checking and monitoring the PergoTex
For personal safety, it is important that these safety notes are complied with and kept in a safe
place.
The performance of a product depends on how it is assembled and installed.
Check the awning system for signs of wear or damage.
On motorised systems, check the electrical leads for damage.
Do not use units that are in need of repair.
Monitor the PergoTex when it opens and retracts and keep people clear of the area until the
PergoTex has fully opened and retracted.
The assembly work may only be performed by trained personnel.
Guidelines for systems with automatic controls
When performing maintenance or installation work on the covered area of the PergoTex,
disconnect the awning from the power supply.
4.2 Operation
It must be ensured that no children or people unable to properly assess the risks of improper or
incorrect use are able to operate the PergoTex.
Remote controls must be kept out of reach of children.
The setting and operating instructions supplied separately by the manufacturer of the motor,
switches and controls must also be observed.
4.3 Disassembly and Disposal
Always secure the awning system before dismantling and disposing of it. A suitably qualified
company should be engaged to perform this task.
DANGER

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 10/14
PergoTex
5 Maintenance and care instructions
5.1 Cleaning and maintenance work in the opening space of the PergoTex
There is a risk of motorised sun protection units being activated unintentionally. Always ensure
that the PergoTex is completely switched off (e.g. by disconnecting the fuse) before performing
maintenance and cleaning work (e.g. building cleaners).
If awnings are operated by several users, a priority locking device must be activated (controlled
interruption of the power supply from outside), making it impossible to open or retract the awning
at all.
5.2 Maintenance
The safe and risk-free use of the Pergotex can only be guaranteed if the product is checked and
serviced on a regular basis. The following maintenance requirements must be observed.
Inspect the PergoTex at regular intervals for signs of wear and tear or damage to the awning
fabric and frame. Should you detect any damage, contact a specialist retailer or dealer or a
suitable service company to carry out the repairs. Do not use units that are in need of repair.
Inspect the PergoTex at regular intervals for signs of wear and tear or damage to the cables
and leads. Should you detect any damage, contact a specialist retailer or dealer or a suitable
service company to carry out the repairs.
Do not use units that are in need of repair.
Even a low-maintenance product needs to be cared for. For this reason, please carry out the
following maintenance and care tasks as required, once every spring, or whenever the awning
has not been in use for a long time. Performing these tasks will extend the operating life of your
awning system. Foliage and other foreign bodies as well as heavy dirt must be removed
immediately
5.3 Foliage and foreign bodies
Foliage and other foreign bodies as well as heavy dirt
in the gutter,
on the fabric, etc.
must be removed immediately.
Rainwater outlet holes
in the posts
must be kept unblocked at all times to ensure that water can drain off.

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 11/14
PergoTex
5.4 PergoTex care
Our recommendation:
Your PergoTex has been designed for low maintenance. In the unlikely event that it should fail,
the service work should be performed by a specialist company.
If lubricants are required during the service work, use greases, sprays or liquids that contain
elements of Teflon, PTFE or comparable agents. For best, long-lasting effects, the lubricant
must be water- and dirt-repellent. The manufacturer's guidelines must be observed at all times.
Do not use lubricants that corrode plastics.
5.5 Cleaning the powder-coated aluminium parts
5.5.1 In saltwater areas
Damage to the Product
Particularly in saltwater areas, there is a possibility that salt may disperse or accumulate on the
product.
Wash off any salt deposits at regular intervals or as required, but no less than twice a
year.
Recommendation: Call in a specialist company to do the work for you.
This is a good way to protect the aluminium parts and their surface from being
corroded by salty water.
5.5.2 In non-saltwater areas
Clean the aluminium parts at least once a year, and even more often if heavily soiled. To clean,
use clean water and add a few drops of pH-neutral or very slightly alkaline detergent.
5.6 Cleaning PVC fabrics
We strongly recommend that you use a cleaning agent, preferably liquid, in water solution to
clean the PVS-coated fabrics.
The concentration of the solution, the temperature and the pressure that can be exerted on the
surface have to be adjusted to the degree of soiling.
If the coated fabric is stored in a dirty condition, this can impair its duration and can favour the
formation of moulds and the absorbing of the dirt inside the material.
The cleaning should be done with soft, moist cloths. As an alternative,
hand brushes or rotating brushes with soft bristles can be used.
It is absolutely forbidden to use solvents such as: turpentine, nitre solvents, acetate, aromatic
compounds, hydrocarbons (petrol or diesel), acids and caustic products, because such products
corrode the surface of the fabric impairing the protection from the external influences.
IMPORTANT

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 12/14
PergoTex
At the end of the washing operations, the PVC-coated product must be rinsed with abundant
water in order to remove every trace of detergent. The last rinse has to be carried out with a
diluted 2% solution of sodium hypochlorite.
before storing the product, it is necessary to dry the entire surface without to overheating the
material. After that it can be folded and kept in a dry environment, protected from the sunlight.

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 13/14
PergoTex
6 Rectifying Faults
Only eliminate errors which can be rectified through maintenance and care. This includes, for
example, removing foreign bodies.
All other defects or malfunctions should only be repaired by your specialist retailer or partner.
Please bear in mind that faults which are not repaired properly will compromise the safety of
your awning system.
You should therefore call your specialist retailer immediately if a fault occurs. This person is your
local specialist and will gladly provide you with swift, professional advice. To help you
troubleshoot, a few errors are listed below.
6.1 Troubleshooting
Error Cause Remedy
System not running No power supply
Motor incorrectly connected
Motor is too hot and has
been shut down by the
thermo protector

Connect to the mains
Connect to the mains
(authorised personnel only)
Wait approx. 15 to 20
minutes until the motor has
cooled down
Squeaking Bearing surfaces not
lubricated

Maintenance and care (fitter)
7 Retrofits
Your PergoTex can also be retrofitted with automatic controls, e.g. with sun and rain sensors.
For more details, contact your specialist retailer, who will be happy to advise you.
8 Noise Level
When installed, the noise level of the PergoTex has been measured at below 70 dB(A).

Maintenance Instructions and Directions for Use
Item number 115024-0000 Subject to technical modifications
Version 4 12.07.2013 Page 14/14
PergoTex
9 Other weinor products
Your dream patio any time of year
No matter what you want to use your patio for, weinor has the right product for you – Pergotex,
patio roofs, Glasoase®, conservatories.
Your weinor partner is an experienced specialist who will gladly provide you with advice on
everything from planning to realising your product. They will help you turn your patio dreams into
reality and are there whenever you need help or advice –
to give you peace of mind from the very beginning.
1 Awnings
2 Patio roofs
3 Glasoase
4 Conservatories
weinor GmbH & Co. KG
Mathias-Brüggen Strasse 110
50829 Cologne (Germany)
www.weinor.de
Hotline: [phone]
Fax: [phone]
