Winix HR950 User manual

WINIX AIR CLEANE
R
HR950, HR951
User Manual
xPlease read and follow all safety rules and instructions in
this manual before operating.
xThe product warranty is printed on the back of this guide,
so please keep it in a safe place for future use.
xThis product is manufactured for use only in USA/CA
Model
Use & Care
Guide

2
English HR 950, HR 951
CONTENTS
Set Up
Where to use 5
Installing the filters 6
Safety Instructions
Safety and Cautions 8
Operation
Initial Operation 9
Modes of Operation 10
Features and Settings 11
Care and Maintenance
Filter Care 13
Smart Sensor Care 17
Cleaning Care 18
Troubleshooting
Frequently Asked Questions 19
Unit Specifications 21
Product Warranty 23
This product is suitable for 120V only.
5-Stage Air Purification 3
Controls 4
French 24
Spanish 4

3
English HR 950, HR 951
PACKAGE CONTENTS
WINIX AIR CLEANER
Model
Use& Care
Guide
HR950, HR951
Please read and follow all safety rules and instructions in
this manual before operating.
The productwarranty is printed on the back of this guide,
so please keep it in a safe place for future use.
This product is manufactured for use only in USA.
Product Pre-filter/CD Carbon Filter/
Anti-microbial True HEPA filter
(Included with the product.)
User Manual
PlasmaWave®
4 Anti-microbial coated
3 True HEPA filter
2 (CD) Coated Deodorization
Carbon filter
1 Pre-filter
5-STAGE AIR PURIFICATION
non-removable
replaceable
washable
replaceable
5
6

4
English HR 950, HR 951
Air
Outlet
Vent
Light Sensor
Detects the amount of ambient
light within the environment, to
adjust the brightness of the LED
indicators.
Timer Indicator
If timer has been set, the LED
light Indicates the set time of
operation.
PlasmaWave® Indicator
Indicates whether
PlasmaWave® is
enabled or disabled.
Smart Sensor
Automatically detects
indoor air quality.
Child Lock Indicator
LED light indicates
whether Child Lock mode
is enabled or disabled.
Child Lock Button
Press and hold for 3 seconds to enable
or disable the Child Lock mode.
Mode / Fan Speed Button
Every time the Mode button is
pressed, the Mode LED light will
cycle through the settings. (Auto,
Sleep, Low, Medium, High, Turbo)
Power Button
Turns the unit on or
off.
Timer / Air Quality
Button
Press to cycle through and set
desired length of operation (1hr,
4hr, 8hr, [NO TIMER]).
Press and hold for 3 seconds to
enable or disable the Air Quality
light.
PlasmaWave® Button
Enables or disables PlasmaWave®.
Check Filter Indicator
LED light indicates when it is
time to change the filter.
Reset Button
After replacing a filter, press
the RESET button for at least
5 seconds.
CONTROLS

Installation | Set up
5
English HR 950, HR 951
WARNING Follow these instructions to reduce the risk of serious
injury or death and to reduce risk of damaging the unit.
30~46 cm
10 cm
WHERE TO USE
Do not use around mist or fumes from
industrial oil or around large quantities of
metallic dust
Do not install in any sort of motor or
transport vehicle (trucks, boats, ships, etc.)
Do not place near any flammable materials
(aerosols, fuel, gases etc.)
Do not place below any electrical outlet
Do not place around heating elements
Do not place in an area with excessive
amounts of noxious gases
Do not have unit facing into wind or draft
Do not place in excessively humid areas
where unit may become wet
Allow 12 ~ 18 in. of space between TVs, radios, and other electronic products
electromagnetic interference from certain electronics may cause product malfunction.
Place indoors away from direct sun light
direct exposure may cause product malfunction or failure.
Only place on hard, flat surfaces
flimsy or slanted surfaces may result in abnormal noise and vibrations.
This unit is not intended to be used to preserve documents or in art conservation.

6
Set up | Installation
English HR 950, HR 951
3 Anti-microbial
True HEPA filter
2 CD Carbon
filter
1 Pre-filter
INSTALLING THE FILTERS
This product comes with all of the required filters. The protective plastic wrap must be
removed from the filters before use.
Operating the unit without removing the plastic wrap may result in product failure.
Unplug and make sure the unit is turned off before installing filters.
The unit will automatically power off when front panel is opened.
① Remove the front panel by grasping
its upper edge and gently pulling
towards yourself.
xTo remove the front panel, the latch
at the lower edge of the panel must
be released from its position. Latch
② Remove the filters from the unit,
they are protected inside a plastic
wrap.
③ Remove filters from protective
plastic wrap.
xOperating the unit without removing
lters from plastic may cause abnormal
noise, deformation, or re as a result of
overheating.
④ Install the filters until they fit
securely in place.
Filters must be installed in this order:
3Anti-microbial True HEPA filter
(rear)
2CD Carbon filter (middle)
1Pre-filter (front)
xTo install the pre-lter, insert
bottom tabs into the slots on either side
of the lower part of the unit, then rotate
upward to insert the upper tabs into the
slots at the top part of the unit until both
sides audibly click into place.

Installation | Set up
7
English HR 950, HR 951
⑤ Replace the front panel by first
inserting the latch at the bottom
edge into the base of the unit, then
rotate the panel upward toward the
top of the unit until it magnetically
snaps closed.
⑥ When to service and replace filters:
Filter Indicator Light When to
service
When to
replace
1Pre-filter none Clean once
every 14 days Permanent
2 CD Carbon filter
Can NOT be
WASHED
Lasts up to
12 months
3 Anti-microbial True
HEPA filter
Intervals between filter replacement may vary depending on environment.
For optimal use, Pre-filter can be cleaned every 14 days which can extend the life of
other filters.
▶Refer to pages 13-17 for detailed information on filter care and
how to replace them.
To purchase replacement Winix filters:
(877)-699-4649
www.winixamerica.com
INSTALLING THE FILTERS
this unit
is compatible
with this
filter
ITEM: 117130
FILTER
J

Safety Instructions | Operation
8
English HR 950, HR 951
SAFETY AND CAUTIONS
Before operating this equipment, carefully read and follow these safety cautions and
instructions to avoid damage and ensure safe use.
WARNING Follow these instructions to reduce the risk of serious
injury or death and to reduce risk of damaging the unit.
Do not pull on the power cord when
unplugging the unit
Do not touch the plug with wet hands
Do not plug additional appliances into the
same outlet or power supply
Unplug unit when not in operation for
extended periods of time
Do not tie or knot power cord when unit
is in operation
Do not unplug or move the unit while in
operation
If the unit becomes submerged in water,
unplug it and contact customer service
Cord can become damaged by forcefully
bending, pulling, twisting, bundling,
pinching or placing heavy objects on it
Ensure filters are inserted before running unit
running unit without filters can shorten the units life and cause electric shock or injury.
Be sure foreign objects are NOT inserted into the vents on the unit
objects can include pins, rods, and coins.
Do not touch any part of the interior of the unit with wet hands
the high voltage may cause electric shock.
Ensure unit intake and outlet vents do not become blocked
blockage may lead to increased internal temperatures causing product failure and deformation.
Do not use the unit as a step stool or place heavy objects on it
personal injury may occur or product failure and deformation.

Operating the air cleaner | Operation
9
English HR 950, HR 951
① Insert the unit plug into an electrical outlet.
xThe Control Panel lights will turn on and o.
② Press the [Power] button.
▶During the first 4 minutes of power up,
the Air Quality light will flash as the
Smart Sensors measure the air quality in
the environment, after which normal
operation will begin.
③ By default, when the unit first powers on, the mode will be set to Auto
with PlasmaWave® enabled.
xWhen in Auto Mode the fan speed will be automatically adjusted according to the
environments air quality.
xPlasmaWave® works to remove harmful airborne contaminants.
▶In Auto mode, as the indoor air quality improves, the fan speed
will automatically be reduced to Low.
▶When the unit is running, you may hear a chirping or buzzing
sound. The sound is from large particles passing through
PlasmaWave®, it is normal and does not signify product failure. To
disable PlasmaWave®, see page 11.
INITIAL OPERATION

Operation | Operating the air cleaner
10
English HR 950, HR 951
1. Auto Mode
Enables Auto operation based on the unit's air quality Smart Sensors.
① Press the Mode button to select Auto mode.
xThe mode LED light will indicate when‘Auto’ mode has been selected, and
operation will begin.
xEach time the Mode button is pressed, the modes will be cycled.
(Auto, Sleep, Low, Medium, High, Turbo).
▶
▶When in Auto Mode the fan speed is automatically adjusted
according to the indoor air quality. As the indoor air quality
improves, the fan speed will automatically be reduced. If the
indoor air quality decreases the fan speed will automatically be
increased.
▶When unit is first started, Auto Mode is enabled and set to Low
fan speed.
2. Sleep Mode
① Press the Mode button to select Sleep
mode.
xThe mode LED light will indicate when‘Sleep’
mode has been selected, and operation in
that mode will begin.
▶When Sleep mode is selected, the fan
speed is automatically set to Low. Fan
speed can be changed by pressing the
Fan Speed (Mode) Button.
▶When Sleep Mode is enabled, the Air
Quality light is disabled.
AUTO AND SLEEP
Every time the Mode button is pressed, the Mode LED light will cycle through the
settings. (Auto, Sleep, Low, Medium, High, Turbo)
