Wood Stone WS-CBO-2628 User manual

Installation and
Operation Manual
Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
www.woodstone-corp.com
SpeCialty ovenS modelS
WS-CBO-2628
WS-CBO-3728
WS-CBO-3738
Wood Stone Josper Charcoal Broiler Oven

This page intentionally left blank >

1
An ongoing program of product improvement may require us to change
specifications without notice. WS-CBO. Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charcoal Oven Installation and Operation Manual
taBle oF ContentS
TABLE OF CONTENTS
WOOD STONE JOSPER OVEN-------------------------------------------------------------------------------2
OVEN VENTING-----------------------------------------------------------------------------------------------4
INSTALLATION CLEARANCES -------------------------------------------------------------------------------5
OVEN PARTS DIAGRAM -------------------------------------------------------------------------------------6
ACCESSORIES AND PARTS----------------------------------------------------------------------------------7
WS-JCO-3728 SPECIFICATIONS----------------------------------------------------------------------------8
WS-JCO-3738 SPECIFICATIONS----------------------------------------------------------------------------9
OVEN STARTUP -------------------------------------------------------------------------------------------- 10
DAILY OPERATION ----------------------------------------------------------------------------------------- 12
OVEN MAINTENANCE-------------------------------------------------------------------------------------- 13
CARE AND CLEANING ------------------------------------------------------------------------------------- 14
SAFETY CONSIDERATIONS -------------------------------------------------------------------------------- 15
LIMITED WARRANTY--------------------------------------------------------------------------------------- 16

2
An ongoing program of product improvement may require us to change
specifications without notice. WS-CBO. Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charcoal Oven Installation and Operation Manual
Wood Stone JoSper oven
STONE-FIRED COOKING EQUIPMENT
WS-CBO MODELS
ADDITIONAL COPIES AVAILABLE UPON REQUEST
PRUDENCE: POUR RÉDUIRE LE RISQUE DE FEU, L'APPAREIL EST ÊTRE MONTÉ SUR LES PLANCHERS DE
CONSTRUCTION INCOMBUSTIBLEAVEC LE REVÊTEMENT DE SOL INCOMBUSTIBLES ET DE FIN DE SURFACE ET
AVEC LE MATÉRIEL NON COMBUSTIBLE CONTRE LE DESSOUS DE CELA, OU SUR LES DALLES OU LES ARCSN
COMBUSTIBLESAYANTLEMATÉRIELNONCOMBUSTIBLECONTRELEDESSOUSDECELA,TELLECONSTRUCTION
FAIT DANS TOUS CAS NE S'ÉTEND PAS MOINS QUE 12 POUCES AU-DELÀ DE L'ÉQUIPEMENT DE TOUS CÔTÉS.
CAUTION: TO REDUCE THE RISK OF FIRE, THE APPLIANCE IS TO BE MOUNTED ON FLOORS OF
NON-COMBUSTIBLE CONSTRUCTION WITH NON-COMBUSTIBLE FLOORING AND SURFACE FINISH AND WITH
NO COMBUSTIBLE MATERIAL AGAINST THE UNDERSIDE THEREOF, OR ON NONCOMBUSTIBLE STABS OR
ARCHES HAVING NO COMBUSTIBLE MATERIAL AGAINST THE UNDERSIDE THEREOF, SUCH CONSTRUCTION
SHALL IN ALL CASES EXTEND NOT LESS THAN 12 INCHES BEYOND THE EQUIPMENT ON ALL SIDES.
INSTALLATION AND OPERATION FOR THE
WOOD STONE JOSPER CHARCOAL BROILER OVEN
WOOD STONE JOSPER OVEN

3
An ongoing program of product improvement may require us to change
specifications without notice. WS-CBO. Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charcoal Oven Installation and Operation Manual
Wood Stone JoSper oven
INSTALLATION AND OPERATING INSTRUCTIONS FOR THE
WOOD STONE JOSPER CHARCOAL BROILER OVEN (WS-CBO).
Please read this entire manual before you install the oven. Failure to follow instructions may result in
property damage, bodily injury or even death. Contact your local building or fire officials about restrictions
and installation inspection in your area.
DO NOT THROW THIS MANUAL AWAY
RETAIN THIS MANUAL FOR FUTURE REFERENCE
Additional copies of this manual and prompt responses to service/maintenance
questions are available from Wood Stone @ 1-800-988-8103.
It is recommended that this oven be installed,
maintained and serviced by authorized professionals.
WARNING: Improper installation, adjustment, alteration,service or maintenance can result in property damage,
injury or death. Read the installation, operation and maintenance instructions thoroughly before installing or
servicing this equipment.
A MAJOR CAUSE OF OVEN-RELATED FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACES)
TO COMBUSTIBLE MATERIALS. IT IS OF THE UTMOST IMPORTANCE THAT THIS OVEN BE INSTALLED ONLY IN
ACCORDANCE WITH THESE INSTRUCTIONS.
Wood Stone's Charcoal-Fired Oven has been tested and approved by Intertek Testing Services. Outline of
investigation for Commercial Wood-Fired Baking Ovens - Refractory Type (UL Subject 2162; issued 08/28/0;
Ed: 2), Standard for Safety Solid Fuel Type Room Heaters (UL 1482 issued 02/16/1996: Ed 5, Rev. 01/25/08
and Space Heaters for Use With Particulate Solid Fuels (ULC ORD-C1482, issued 01/01/1990, and to ANSI/NSF
Standard 4 - 2007.
!WARNING: Please read this entire manual before you install the oven. Failure to follow
instructions may result in property damage, bodily injury or even death.
FOR YOUR SAFETY: Do not store gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.

4
An ongoing program of product improvement may require us to change
specifications without notice. WS-CBO. Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charcoal Oven Installation and Operation Manual
oven ventinG
The Wood Stone Josper Charcoal Broiler oven must be vented using a Listed Type 1 exhaust hood, or one
constructed and installed in accordance with NFPA 96 and all relevant Local and National Codes.
The Wood Stone Josper ovens including model numbers WS-CBO-2628, WS-CBO-3728 and WS-CBO-3738 must be
vented in accordance with codes concerning solid fuel appliances (NFPA 96). Due to the dangers of creosote buildup and
of sparks entering the duct, these models should be vented separately from all other non- solid fuel kitchen equipment
and in a manner acceptable to the authority having jurisdiction. The Wood Stone customer support staff is available to
answer any questions concerning installation and venting of the oven; call 1-800-988-8103 for assistance and technical
support.
When wood and charcoal is burned slowly, it produces tar. Solid fuel exhaust contains creosote and other
substances that accumulate in ducting, creating a risk of fire. The rate of accumulation will vary with respect
to flue gas temperature, wood type and moisture content. Frequent, regularly scheduled, thorough flue cleaning
is the best way to minimize the risk of flue fires.
Place the smoke outlet vent into the oven smoke outlet, then place the firebreak on top of the smoke outlet vent. Refer
to oven parts diagram on page 6
CALL WOOD STONE FOR INFORMATION AND INSTALLATION
SPECIFICATIONS ON GAYLORD HOODS.
OVEN VENTING

5
An ongoing program of product improvement may require us to change
specifications without notice. WS-CBO. Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charcoal Oven Installation and Operation Manual
inStallation ClearanCeS
CLEARANCES TO CONSTRUCTION
FLOOR: The Wood Stone Josper oven must be installed on a non-combustible floor that extends 36” to the front and 30”
to each side of the oven door.
SIDES: 18” to combustible materials
BACK: 6” to combustible materials
This oven must be installed under a Listed Type 1 exhaust hood, or one constructed in accordance with NFPA 96. The
hood must be installed and maintained in accordance with NFPA 96 and/or all relevant local and national codes.
IF THIS OVEN IS NOT PROPERLY INSTALLED A FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THESE
INSTALLATION INSTRUCTIONS. A MAJOR CAUSE OF OVEN RELATED FIRES IS FAILURE TO MAINTAIN REQUIRED
CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS OVEN BE
INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS.
!WARNING: Do Not pack required air space (clearance) with insulation or other materials.
When non-combustible building materials contact the body of the oven, the clearances to
combustibles are transferred to those non-combustibles.
INSTALLATION CLEARANCES

6
An ongoing program of product improvement may require us to change
specifications without notice. WS-CBO. Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charcoal Oven Installation and Operation Manual
oven partS diaGram
OVEN PARTS DIAGRAM

7
An ongoing program of product improvement may require us to change
specifications without notice. WS-CBO. Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charcoal Oven Installation and Operation Manual
aCCeSSorieS / partS
FOR MORE INFORMATION ABOUT THESE OR OTHER SPARE PARTS,
CONTACT WOOD STONE CORPORATION
WOOD STONE JOSPER CHARCOAL OVEN ACCESSORIES AND SPARE PARTS
Poker*
Meat Grill Rack*
Cast Iron Grate*
Grate / Meat Tongs*
Smoke Outlet Vent*
Firebreak*
Pressure Springs (door)*
Sharp Bristle Brush*
(*Supplied with the oven)
ACCESSORIES AND PARTS

8
An ongoing program of product improvement may require us to change
specifications without notice. WS-CBO. Revised February 2010
Wood Stone Corporation
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
Toll Free [phone]
Tel [phone]
Fax [phone]
[email protected] or visit www.woodstone-corp.com
Charcoal Oven Installation and Operation Manual
WS-JCo-3728 SpeCiFiCationS
WC-CBO-3728
WS-JCO-3728 SPECIFICATIONS
Side View
Front View
Rear View
Top View
