Yale Real Living Assure Lock
®™
Key Free Touchscreen Deadbolt
Installation and Programming Instructions
( 246/ 446)YRD YRD
x4 x2
x3
#8-32 x 5/16"
Machine screws
#7 wood & #8-32
machine x 20mm
Combination screws
M6x55mm
Long through bolt
Optional
Network Module
Before you begin
for step-by-step installation
instructions & to register
your product
DOWNLOAD
THE BILT APP

P/N - - Rev EYRL KFTSINSTL FUL
2
Preparing Door

P/N - - Rev EYRL KFTSINSTL FUL
3
O
x4
1
d faute
2-3/8" position
2-3/4" position
Installing Latch & Strike Plate
Press
Pull
optional
Bolt must be in retracted
(unlocked) position. Note
horizontal orientation of
mechanism.

P/N - - Rev EYRL KFTSINSTL FUL
4
2Installing Touchscreen Escutcheon
Bolt must be in retracted (unlocked)
position. Note horizontal orientation
of mechanism.
Outside of DoorInside of Door

P/N - - Rev EYRL KFTSINSTL FUL
5
x2
3Installing Interior Mounting Plate
Loosen screw to
remove cover.

4Attaching the Cable Assembly
P/N - - Rev EYRL KFTSINSTL FUL
6

P/N - - Rev EYRL KFTSINSTL FUL
7
x3
5Installing Interior Escutcheon

3
Testing Operation
Bolt must be in retracted
(unlocked) position before
installing batteries.
P/N - - Rev EYRL KFTSINSTL FUL
8

P/N - - Rev EYRL KFTSINSTL FUL
9
6
7
Installing Batteries/Handing the Lock
Batteries must be removed
prior to removing and/or
inserting network module.
"Welcome to
Yale Real Living."
Lock automatically adjusts for proper handing.
Installing Optional Network Module

P/N - - Rev EYRL KFTSINSTL FUL
10
8
Congratulations, you've installed the Yale Real Living Assure Lock
®™
Key Free Touchscreen Deadbolt ( 246/ 446)!YRD YRD
Continue with Programming Instructions to customize your product.
Installing Cover
Tighten screw
to replace cover.
