Yardistry 1902316 User manual

Step 9
Square Post to Trellis A and attach Long Gusset
2- 5/16 x 5 ¼ (5/16 flat, lock washer and T-nut)
Predrill 1 - 5/16 x3 ,1/4 shank hex lag screw (5/16 flat washer)
Show squaring unit should be 152¾ diagonally from post to post
3.6m x 3.6m (12’ x 12’) Pergola
Installaon and Operang Instrucons – YM12775
Revised 07-31-2020
Height: 2.59 m (8’ 6”)
(12’)
(12’)
3.658 m
3.658 m
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Yardistry – North America
Toll Free Customer Support:
1.888.509.4382
[e-mail]
www.yardistrystructures.com
Y40000-775P
ITM./ART. 1902316
Regular Hours: Mon - Fri, 8:30 am - 5:00
pm EST (excl. holidays)
(For extended hours see our website)
English and French Spoken

2 [email protected]
Important Safety Notice!
Yardistry components are intended for privacy, decorative and ornamental use only.
Product is NOT INTENDED for the following:
• A safety barrier to prevent unsupervised access to pools, hot tubs, spas or ponds.
• As load bearing support for a building, structure, heavy objects or swings.
• Used in structures that trap wind, rain or snow that would create extra load on the
product.
Accumulated snow must be removed from roof.
DO NOT climb or walk on roof for any reason.
Permanent structures may require a building permit. As the purchaser and or installer of this
product you are advised to consult local planning, zoning and building inspection departments for
guidance on applicable building codes and/or zoning requirements.
Wood is NOT ame retardant and will burn. Grills, re pits and chimineas are a re hazard if
placed too close to a Yardistry structure. Consult user’s manual of the grill, re pit or chiminea
for safe distances from combustible materials.
Wear gloves to avoid injury from possible sharp edges of individual elements before assembly.
During installation, follow all safety warnings provided with your tools and use OSHA
approved safety glasses. Some structures may require two or more people to install safely.
Check for underground utilities before digging or driving stakes into the ground!
During assembly it is important to closely follow the instructions. Complete the assembly
on a solid, level surface and follow the instructions to square up, level and anchor the structure.
This will reduce the gaps at wood connections during assembly.
General Information: Wood components are manufactured with Cedar (C. Lanceolata)
which is protected with factory applied water-based stain. Knots, small checks (cracks)
and weathering are naturally occurring and do not a󰀨ect the strength of the product.
Annual application of a water-based water repellent sealant or stain is important and will
help reduce weathering and checks.
www.yardistrystructures.com
General Information
Regular Hours: Mon - Fri, 8:30 am - 5:00 pm EST
(excl. holidays)
(For extended hours see our website)
English and French Spoken
Questions?
Call toll free or write us at:
1 [phone]
[email protected]
Patents Pending

3 [email protected]
July 27, 2018
Limited Warranty
This Warranty gives you specic legal rights. You may have other rights as well which vary from state to state
or province to province. This warranty excludes all consequential damages, however, some states/provinces
do not allow the limitation or exclusion of consequential damages, and therefore this limitation may not apply
to you.
Yardistry warrants that this product is free from defect in materials and workmanship for a
period of one (1) year from the original date of purchase. In addition, for any product with
lumber, all lumber is warranted for ve (5) years against rot and decay. This warranty applies
to the original owner and registrant and is non-transferable.
Regular maintenance is required to assure the integrity of your product and is a requirement of
the warranty. This warranty does not cover any inspection costs.
This Limited Warranty does not cover:
• Labour for replacement of any defective item(s);
• Incidental or consequential damages;
• Cosmetic defects which do not a󰀨ect performance or integrity;
• Vandalism; improper use or installation; acts of nature, including but not limited to wind,
storms, hail, oods, excessive water exposure;
• Minor twisting, warping, checking or any other natural occurring properties of wood that do
not a󰀨ect performance or integrity.
Yardistry products have been designed for safety and quality. Any modications made to
the original product could damage the structural integrity of the product leading to failure
and possible injury. Yardistry cannot assume any responsibility for modied products.
Furthermore, modication voids any and all warranties.
This product is warranted for RESIDENTIAL USE ONLY. Yardistry disclaims all other
representations and warranties of any kind, express or implied.

4 [email protected]4 [email protected]
Instructions for Proper Maintenance
Your Yardistry structure is designed and constructed of quality materials. As with all outdoor
products it will weather and wear. To maximize the enjoyment, safety and life of your structure
it is important that you, the owner, properly maintain it.
Symbols:
Throughout these instructions symbols are provided in the top, right-hand corner of the page.
If you dispose of your Yardistry structure: Please disassemble and dispose of your unit
so that it does not create any unreasonable hazards at the time it is discarded. Be sure to
follow your local waste ordinances.
HARDWARE:
• Check metal parts for rust. If found, sand and repaint using a non-lead paint complying
with 16 CFR 1303.
• Inspect and tighten all hardware after completion of assembly; after rst month of use; and
then annually. Do not over-tighten as to cause crushing and splintering of wood.
• Check for sharp edges or protruding screw threads, add washers if required.
WOOD PARTS:
• Applying a water repellent or stain (water-based) on a yearly basis is important
maintenance to maintain maximum life and performance of the product.
• Check all wood members for deterioration, structural damage and splintering. Sand down
splinters and replace deteriorated wood members. As with all wood, some checking and
small cracks in grain is normal
• Some gapping may occur at some wood connections.
• Tape Measure
• Carpenters Level
• Standard or Cordless Drill
• 7/16” & 1/2” Wrench
• 7/16” & 1/2” Socket
Assembly Guides
• Ratchet
• Safety Glasses
• Adult Helper
• Safety Gloves
• Hard Hat
Tools Required:
• Use Help, where this is shown, 2, 3 or 4
people are required to safely complete
this step. To avoid injury or damage to the
assembly make sure to get some help.
• Use a measuring tape to assure proper
location
• Pre-drill a pilot hole before fastening
screw or lag to prevent splitting of wood.
• 72” Step Ladder x 2
• Square
• Check that assembly is square before
tightening bolts

5 [email protected]
Following are some helpful tips to make the assembly process smooth and e󰀩cient.
PRE-ASSEMBLIES:
(i.e. Post and Beam Assemblies, Roof Rafter Assembly, etc)
• Work on a raised, solid and at surface such as, a table or saw horse.
• Keep all connections ush where shown in the instructions.
• When assembling the beams keep parts at, straight and snug when
connecting.
Assembly Tips

6 [email protected]
Step 9
Square Post to Trellis A and attach Long Gusset
2- 5/16 x 5 ¼ (5/16 flat, lock washer and T-nut)
Predrill 1 - 5/16 x3 ,1/4 shank hex lag screw (5/16 flat washer)
Show squaring unit should be 152¾ diagonally from post to post
Note: It is critically important you start with square, solid and level footings, concrete
pad or deck to attach your Pavilion.
We supply Post Mounts with this structure which gives you the exibility to permanently install your structure
to a pre-existing or new wood or concrete surface.
• The hardware to attach the Post Mount to the structure is included.
• The hardware to mount the structure permanently will need to be purchased separately at your local
hardware store.
If you are mounting to concrete footers see below for the correct locations and placement. Please double
check for possibility of any underground utilities such as gas, telephone, cable or sprinkler lines.
Following are some examples of how to mount the structure to wood or concrete surfaces.
Refer to your local building and city codes, ordinances, neighbourhood covenants, or height restrictions
regarding this type of structure for guidance on acceptable installation requirements.
Permanent Installation Examples
Concrete Footer
To
Required
Depth
Anchoring Hardware not included
Post Mount
(106-1/2”)
Plinth to Plinth
Plinth to Plinth
(12’ 8-3/4”)
Post to Post
(108”)
Post to Post
(106-1/2”)
(108”)
Post to Post
2.743 m
2.743 m
2.705 m
2.705 m
3.88 m

7 [email protected]
Permanent Installation Examples cont.
Concrete Patio [min. 3.353 m x 3.353 m (11’ x 11’)] with 15.24 cm (6”) clearance on all sides
Wood Deck [min. 3.353 m x 3.353 m (11’ x 11’)] with 15.24 cm (6”)clearance on all sides
Anchoring Hardware not included
Anchoring Hardware not included
Anchoring Hardware (not included)
Post
Mount
Post Mounts have a 1.27 cm (1/2”) diameter
hole for anchoring hardware.

8 [email protected]
(Y70800-104)
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
Part Identification ( )
8pc. (913) - Trellis Joist A-1898.7mm (74-3/4") (Y50229-913)
8pc. (914) - Trellis Joist B -1898.7mm (74-3/4") (Y50229-914)
(Y70819-288)
1pc. Trellis Bracket (26 pk)
(Y70819-109)
1pc. Post Mount (8 pk)
10pc. (916) - Long Trellis -2051.8mm (80-3/4") (Y50229-916)
10pc. (915) - Short Trellis -1491.2mm (58-3/4") (Y50229-915)
1pc. Gazebo ID Plaque
2pc. (921) - Beam Middle - 2133.6mm (84") (Y70229-921)
4pc. (902) - Pergola Post - 2235.2mm (88") (Y70229-902)
4pc. (905) - Beam End - 762mm (30") (Y70229-905)
4pc. (909) - Long Gusset - 1015mm (39-15/16") (Y70229-909)
4pc. (899) - Gusset - 812.8mm (32") (Y70229-899)
4pc. (920) - Post Block - 533.4mm (21") (Y50229-920)
4pc. (912) - Connector Block - 508mm (20") (Y50229-912)
8pc. (918) - Splice - 1016mm (40") (Y50229-918)
8pc. (919) - Top Post Block
190.5mm (7-1/2")
(Y50229-919)
16pc. (422) - Plinth
190.5mm (7-1/2")
(Y50229-422)
16pc. (917) - Post Trim
190.5mm (7-1/2")
(Y50229-917)

9 [email protected]
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
Part Identification ( )
8pc. 5/16 x 6" Hex Bolt (Y07718-360)
16pc. 5/16 x 5 1/4" Hex Bolt (Y07718-351)
24pc. 5/16 x 4" Hex Bolt (Y07718-340)
88pc . 5/16" Lock Washer (Y05318-300)
32pc. 5/16 x1 1/2" Hex Bolt (Y07718-312)
8pc. 5/16 x1 1/4" Hex Bolt (Y07718-311)
18pc. 1/4" Lock Nut (Y08318-203)
136pc. 5/16" Flat Washer - (Y05118-203)
88 pc. 5/16" T-Nut (Y08518-300)
10pc. 1/4 x1 3/4" Hex Bolt (Y07718-213)
8pc. 1/4 x 2" Hex Bolt (Y07718-220)
28pc. 5/16 x 3" Lag Screw (Y06218-330)
70pc. Wood Screw #10 x 4" (Y06091-740)
80pc. Wood Screw #8 x 3" (Y06091-530)
112pc. Wood Screw #8 x 1-1/2" (Y06091-512)
44pc. Pan Screw #10 x 1-1/4" (Y06491-711)
1pc. - #2 x 2" Robertson Driver (Y00400-005)
1pc. - 1/8" Drill Bit (Y00400-002)

10 [email protected]
PRODUCT NUMBER: YM12775
CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 1)
CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 2)
CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 3)
STOP STOPSTOP STOP
1-888-509-4382
[email protected]
C. Read the assembly manual completely, paying special attention to ANSI
warnings; notes; and safety/maintenance information on pages 1 - 4.
• Follow the instructions in order.
• This structure is designed to be assembled and installed ideally by four
people, DO NOT attempt to install alone.
• Consider the slope of elevation where you plan to install the structure. Also, check
for gas, telephone, other utilities or sprinkler line locations prior to excavating any
holes.
D. Before you discard your cartons ll out the form below.
• The carton I.D. stamp is located on the end of each carton.
• Please retain this information for future reference. You will need this information if
you contact the Consumer Relations Department.
• Each step indicates which bolts and/or screws you will need for assembly, as well
as any at washers, lock washers, t-nuts or lock nuts.
A. This is the time for you to inventory all your hardware, wood and accessories,
referencing the parts identication sheets. This will assist you with your
assembly.
Step 1: Inventory Parts - Read This Before Starting Assembly
B. If there are any missing or damaged pieces or you need assistance with
assembly please contact the consumer relations department directly. Call us
before going back to the store.

11 [email protected]
Step 1
Post Mount to Post 2 - 5/16 x 1¼ Hex Bolt (5/16 flat, lock washer and t-nut)
4 - #8x1½ wood screw
4 - # 10x1¼ Pan screw
Step 1
Post Mount to Post 2 - 5/16 x 1¼ Hex Bolt (5/16 flat, lock washer and t-nut)
4 - #8x1½ wood screw
4 - # 10x1¼ Pan screw
A: At the bottom of one (902) Pergola Post insert two 5/16” T-Nuts as shown in F2.2.
B: At the bottom of (902) Pergola Post place two Post Mounts tight to the bottom and inside faces as shown in
F2.1 and F2.2. Loosely attach with one 5/16 x 1-1/4” Hex Bolt (with 5/16” lock washer and 5/16” at washer) per
mount so they connect to the T-Nuts.
Step 2: Post Assemblies, Part 1
HardwareWood Parts
F2.1
4 x (902) Pergola Post
Top
Bottom
F2.2
8 x 5/16” T-Nut
8 x 5/16 x 1-1/4” Hex Bolt
(with 5/16” lock washer, 5/16” at washer)
8 x Post Mount
Post
Mount
5/16”
T-Nut
(902)
Pergola Post
Post
Mount
5/16” Flat
Washer
5/16” Lock
Washer
5/16 x 1-1/4”
Hex Bolt
5/16”
T-Nut
(902)
Pergola Post
5/16 x 1-1/4”
Hex Bolt
5/16” Lock
Washer

12 [email protected]
Step 1
Post Mount to Post 2 - 5/16 x 1¼ Hex Bolt (5/16 flat, lock washer and t-nut)
4 - #8x1½ wood screw
4 - # 10x1¼ Pan screw
C: From the inside attach two #10 x 1-1/4” Pan Screws per mount These screws are installed at a slight angle.
(F2.3)
D: From the bottom attach Post Mounts to posts with two #8 x 1-1/2” Wood Screws per mount. Tighten all bolts.
(F2.3)
Step 2: Post Assemblies, Part 2
Hardware
#8 x 1-1/2” Wood Screws
(x 2 per Post Mount, from
bottom)
16 x #10 x 1-1/4” Pan Screw
16 x #8 x 1-1/2” Wood Screw
Post
Mount
(902)
Pergola Post
F2.3
Post
Mount
#10 x 1-1/4” Pan Screws
(x 2 per Post Mount, from
inside)
#10 x 1-1/4” Pan Screws
(x 2 per Post Mount, from
inside)
#8 x 1-1/2” Wood Screws
(x 2 per Post Mount, from
bottom)

13 [email protected]
Step 2
Plinth to post 16 - #8x 1½ wood screw
F2.4
Step 2
Plinth to post 16 - #8x 1½ wood screw
E: Place one (422) Plinth ush to the bottom and tight to the Post Mounts on each side of the (902) Pergola Post
and attach with four #8 x 1-1/2” Wood Screws per plinth. Rounded edges on top. (F2.4 and F2.5)
F: Repeat Steps A - E three more times to make four Post Assemblies.
Step 2: Post Assemblies, Part 3
HardwareWood Parts
(422) Plinth
16 x (422) Plinth
#8 x 1-1/2”
Wood Screws
(x 4 per Plinth)
Rounded
Edge on
Top
F2.5
Post
Mount
(902)
Pergola
Post
64 x #8 x 1-1/2” Wood Screw
Tight
(422) Plinth
(422)
Plinth
(422) Plinth
(902) Pergola
Post

14 [email protected]
Step 3
Post Block to post 2 - 5/16 x 6 Hex bolt (5/16 flat, lock washer and t-nut)
Step 3
Post Block to post 2 - 5/16 x 6 Hex bolt (5/16 flat, lock washer and t-nut)
Step 3: Attach Post Block
HardwareWood Parts
A: In all four Post Assemblies, place one (920) Post Block inside the top of each (902) Pergola Post. Make sure
holes in (920) Post Block align with holes in (902) Pergola Post then attach with two 5/16 x 6” Hex Bolts (with 5/16”
lock washer, 5/16” at washer and 5/16” t-nut). (F3.1 and F3.2)
F3.1
8 x 5/16 x 6” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
5/16” Flat
Washer
5/16 x 6”
Hex Bolt
5/16”
T-nut
Flush
(920) Post
Block
4 x (920) Post Block
5/16” Lock
Washer
Notice hole
orientation
(902)
Pergola
Post
F3.2
Top

15 [email protected]
Step 4
Trellis Joist A and Trellis Joist B Assembly
4 -5/16 x 1½ Hex Bolt (5/16 flat, lock washer and t-nut)
Attach Trellis Bracket to Trellis Joist B 1- ¼ x 2Hex bolt (1/4 lock nut)
Step 4
Trellis Joist A and Trellis Joist B Assembly
4 -5/16 x 1½ Hex Bolt (5/16 flat, lock washer and t-nut)
Attach Trellis Bracket to Trellis Joist B 1- ¼ x 2Hex bolt (1/4 lock nut)
HardwareWood Parts
A: Interlock the cut-outs on two (913) Trellis Joist A and attach using four 5/16 x 1-1/2” Hex Bolts (with 5/16” lock
washer, 5/16” at washer and 5/16” t-nut) as shown in F4.1. Repeat three more times to make four Trellis Joist A
Assemblies.
B: Repeat Step A using (914) Trellis Joist B to make four Trellis Joist B Assemblies. (F4.2)
C: On each Trellis Joist B Assembly attach two Trellis Brackets to each end with one 1/4 x 2” Hex Bolts (with 1/4”
lock nut) per set of brackets. (F4.2)
8 x (913) Trellis Joist A
8 x (914) Trellis Joist B
F4.1
32 x 5/16 x 1-1/2” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
8 x 1/4 x 2” Hex Bolt (1/4” lock nut)
F4.2
5/16 x 1-1/2”
Hex Bolt (x4)
5/16”
T-nut
(913) Trellis
Joist A
Step 4: Trellis Joist Assembly, Part 1
5/16 x 1-1/2”
Hex Bolt (x4)
5/16” Lock
Washer
5/16” Flat
Washer
Components
16 x Trellis Bracket
(913) Trellis
Joist A
5/16” Flat
Washer
5/16”
T-nut
1/4” Lock
Nut
1/4” Lock
Nut
5/16” Lock
Washer
1/4 x 2”
Hex Bolt
1/4 x 2”
Hex Bolt
Trellis
Bracket
Trellis
Bracket
(914) Trellis
Joist B
(914) Trellis
Joist B

16 [email protected]
Step 5
Attach Splice to Trellis Joist A & B (center on the short side)
4 - #8 x 3 wood screw
Predrill 2 - 5/16x3, ¼ shank hex lag screw (5/16 flat washer)
Hardware
32 x #8 x 3” Wood Screw
16 x 5/16 x 3” Lag Screw (5/16” at washer)
F4.3
D: On the short side of each Trellis Joist A Assembly and each Trellis Joist B Assembly centre one (918) Splice
and attach with four #8 x 3” Wood Screws per assembly. (F4.3 and F4.4)
E: In the centre holes of each (918) Splice, pre-drill with a 1/8” drill bit, then attach (918) Splices to each
assembly with two 5/16 x 3” Lag Scew (with 5/16” at washer). (F4.3 and F4.4)
#8 x 3” Wood
Screws
Tellis
Joist A
Assembly
(918) Splice
Step 4: Trellis Joist Assembly, Part 2
Wood Parts
8 x (918) Splice
F4.4
Tellis
Joist B
Assembly
(918) Splice
#8 x 3”
Wood
Screws
#8 x 3”
Wood
Screws
#8 x 3”
Wood
Screws
5/16” Flat
Washer
5/16” Flat
Washer
5/16 x 3”
Lag Screw
5/16 x 3”
Lag Screw

17 [email protected]
A: At each end of one (921) Beam Middle connect one (905) Beam End using one (912) Connector Block as
shown in F5.1. Notice pilot holes in (921) Beam Middle are facing up and detail in (905) Beam Ends are facing
down. Repeat for a second Beam Assembly.
B: On each Beam Assembly loosely attach (921) Beam Middle and (905) Beam Ends to (912) Connector Blocks
with four 5/16 x 4” Hex Bolts (with 5/16” lock washer, 5/16” at washer and 5/16” t-nut) per end, as shown in F5.2.
Step 5: Beam Assembly, Part 1
Hardware
16 x 5/16 x 4” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
Wood Parts
2 x (921) Beam Middle
4 x (905) Beam End
4 x (912) Connector Block
Step 6
Attach Beam end to Beam Middle with connector Block. (screw holes to the top of beam’s)
8 - 5/16 x 4 hex bolt (5/16 flat, Lock washer and T-nut)
8 - #8 x 3 wood screw
Step 6
Attach Beam end to Beam Middle with connector Block. (screw holes to the top of beam’s)
8 - 5/16 x 4 hex bolt (5/16 flat, Lock washer and T-nut)
8 - #8 x 3 wood screw
F5.1
F5.2
5/16 x 4”
Hex Bolt
5/16” Lock
Washer
5/16” Flat
Washer
5/16”
T-nut
(921)
Beam
Middle
(921)
Beam
Middle
(912)
Connector
Block
(912)
Connector
Block
(905)
Beam End
(905)
Beam End
(905)
Beam End

18 [email protected]
Step 6
Attach Beam end to Beam Middle with connector Block. (screw holes to the top of beam’s)
8 - 5/16 x 4 hex bolt (5/16 flat, Lock washer and T-nut)
8 - #8 x 3 wood screw
C: Make sure (905) Beam Ends and (921) Beam Middles are tight together and ush on the top for each Beam
Assembly then attach (921) Beam Middle and (905) Beam Ends to (912) Connector Blocks with four #8 x 3” Wood
Screws per end, as shown in F5.3.
D: Tighten all bolts.
Step 5: Beam Assembly, Part 2
Hardware
16 x #8 x 3” Wood Screw
F5.3
#8 x 3”
Wood
Screws
(921)
Beam
Middle
(905)
Beam End
Tight
Flush

19 [email protected]
Step 7
Lay 2 post on flat surface and attach beam assembly and Gusset (make sure post are square to
beam before attaching Gusset) Create 2 post to beam assemblies
Attach Beam assembly to post (overhang post by 12” )
4 - 5/16 x4 Hex bolt (5/16 flat, lock washer and T-nut)
Attach gusset Put 2 - #8 x 3 wood screw in first,
Predrill 1 - 5/16 x3, ¼ shank hex lag screw (5/16 flat washer)
Step 7
Lay 2 post on flat surface and attach beam assembly and Gusset (make sure post are square to
beam before attaching Gusset) Create 2 post to beam assemblies
Attach Beam assembly to post (overhang post by 12” )
4 - 5/16 x4 Hex bolt (5/16 flat, lock washer and T-nut)
Attach gusset Put 2 - #8 x 3 wood screw in first,
Predrill 1 - 5/16 x3, ¼ shank hex lag screw (5/16 flat washer)
Step 6: Post and Beam Assembly
A: Lay two Post Assemblies on a at surface with the the bolt heads facing up. Place one Beam Assembly over
(920) Post Blocks then attach with two 5/16 x 4” Hex Bolts (with 5/16” lock washer, 5/16” at washer and 5/16”
t-nut) per end. Make sure Beam Assembly overhangs the Post Assemblies by 12”, the assembly is square and the
bolts are tight. (F6.1 and F6.2)
B: Place one (899) Gusset, centred on Post and Beam Assemblies, in each corner, pre-drill with a 1/8” drill bit and
attach to post and beam with two 5/16 x 3” Lag Screws (with 5/16” at washer) per gusset. (F6.1 and F6.2)
C: Repeat Steps A and B to create a second Post and Beam Assembly.
Hardware
8 x 5/16 x 3” Lag Screw (5/16” at washer)
8 x 5/16 x 4” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
Wood Parts
4 x (899) Gusset
F6.1
Post
Assembly
(899)
Gusset
Post
Assembly
Post
Assembly
Beam
Assembly
Beam
Assembly
(920) Post
Block
(920) Post
Block
(899)
Gusset
(899)
Gusset 5/16 x 4”
Hex Bolt
5/16” Lock
Washer
5/16” Flat
Washer
5/16”
T-nut
5/16” Flat
Washer
5/16”
Flat
Washer
5/16 x 4”
Hex Bolt
5/16” Lock
Washer
5/16” Flat
Washer
5/16”
T-nut
5/16 x 3”
Lag Screw
5/16 x 3”
Lag Screw
5/16 x 3”
Lag Screw
12”
F6.2
Centred
Centred

20 [email protected]
Step 8
Stand up both Post to beam assemblies attach Trellis A Assembly to post
(over hang Beam assembly 13”)
4 - 5/16 x 5¼ hex bolt (5/16 flat, lock washer and T-nuts) per side
Step 8
Stand up both Post to beam assemblies attach Trellis A Assembly to post
(over hang Beam assembly 13”)
4 - 5/16 x 5¼ hex bolt (5/16 flat, lock washer and T-nuts) per side
Step 7: Attach Trellis Joist A Assemblies
A: Stand both Post and Beam Assemblies then place four Trellis Joist A Assemblies on Beam Assemblies, two
at each end, tight to each side of (920) Post Blocks. Ends of each Trellis Joist A Assembly to overhang Beam
Assemblies by 13”. Attach trellis assemblies to (920) Post Block with two 5/16 x 5-1/4” Hex Bolts (with 5/16” lock
washer, 5/16” at washer and 5/16” t-nut) per corner. Make sure bolt head face out. (F7.1 and F7.2)
Hardware
8 x 5/16 x 5-1/4” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
13”
F7.1
F7.2
Beam
Assembly
Post
Assembly
Post
Assembly
Trellis
Joist A
Assembly
Trellis
Joist A
Assembly
(920) Post
Block
5/16 x
5-1/4”
Hex Bolt
5/16” Lock
Washer
5/16” Flat
Washer
5/16”
T-nut
Trellis
Joist A
Assembly
