ZCS 1PH 1100TL User manual

Identification: MD-AL-GI-00 Rev. 1.1 of 12/03/2021 - Application: GID
Reg. Pile IT12110P00002965 - Share Capital € 100,000.00 fully paid up
Reg. Impr. AR n.03225010481 - REA AR - 94189
ISO 9001 Certified Company - Certificate no. 9151 - CNS0 - IT-17778
Zucchetti Centro Sistemi S.p.A. - Green Innovation Division
Via Lungarno, 248 - 52028 Terranuova Bracciolini - Arezzo, Italy
tel. [phone] - fax. [phone]
[e-mail] - [email protected] –www.zcsazzurro.com
Grid-connected inverter
1PH 1100TL-3300TL-V3
User Manual

2 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
Table of Contents
1. Preliminary safety instructions ..............................................................................................................................................................7
1.1. Safety instructions ....................................................................................................................................................................7
1.2. Symbols and icons..................................................................................................................................................................10
2. Product features.........................................................................................................................................................................................12
2.1. Product presentation............................................................................................................................................................12
2.2. Description of functions ......................................................................................................................................................14
2.3. Efficiency curve.......................................................................................................................................................................16
3. Installation....................................................................................................................................................................................................17
3.1. Installation process ...............................................................................................................................................................17
3.2. Checks before installation...................................................................................................................................................17
3.3. Installation tools.....................................................................................................................................................................19
3.4. Installation position ..............................................................................................................................................................21
3.5. Moving the 1PH 1100TL-3300TL-V3 inverter...........................................................................................................23
3.6. Installing the 1PH 1100TL-3300TL-V3 inverter.......................................................................................................23
4. Electrical connections..............................................................................................................................................................................25
4.1. Electrical connections ..........................................................................................................................................................26
4.2. Ground cable connections (PGND) .................................................................................................................................26
4.3. Connecting the DC input power cables .........................................................................................................................28
4.4. Connecting the AC output power cables.......................................................................................................................32
4.5. Connecting the communication cables .........................................................................................................................37
5. Commissioning the inverter..................................................................................................................................................................41
5.1. Safety inspection before commissioning......................................................................................................................41
5.2. Starting the inverter..............................................................................................................................................................41
6. Operating interface ...................................................................................................................................................................................43
6.1. Operating panel and display..............................................................................................................................................43
6.2. Main interface..........................................................................................................................................................................44
6.3. Main menu.................................................................................................................................................................................46

3 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
7. Troubleshooting and maintenance ....................................................................................................................................................62
7.1. Troubleshooting......................................................................................................................................................................62
7.2. Maintenance .............................................................................................................................................................................70
8. Uninstalling ..................................................................................................................................................................................................71
8.1. Uninstallation steps...............................................................................................................................................................71
8.2. Packaging...................................................................................................................................................................................71
8.3. Storage ........................................................................................................................................................................................71
8.4. Disposal ......................................................................................................................................................................................71
9. Technical specifications ..........................................................................................................................................................................72
10. Monitoring systems.........................................................................................................................................................................73
10.1. External Wi-Fi adapter.........................................................................................................................................................73
10.1.1. Installation ................................................................................................................................................................................73
10.1.2. Configuration ...........................................................................................................................................................................74
10.1.3. Verification................................................................................................................................................................................83
10.1.4. Troubleshooting......................................................................................................................................................................87
10.2. Ethernet adapter.....................................................................................................................................................................92
10.2.1. Installation ................................................................................................................................................................................92
10.2.2. Verification................................................................................................................................................................................94
10.2.3. Troubleshooting......................................................................................................................................................................96
10.3. 4G adapter.................................................................................................................................................................................97
10.3.1. Installation ................................................................................................................................................................................98
10.3.2. Verification.............................................................................................................................................................................100
11. Warranty terms and conditions..............................................................................................................................................103

4 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
General instructions
This manual contains important safety instructions that must be followed during installation and
maintenance of the equipment.
Please keep these instructions!
This manual must be considered an integral part of the equipment, and must be available at all times to
everyone who interacts with the equipment. The manual must always accompany the equipment, even when
it is transferred to another user or plant.
Copyright statement
Copyright of this manual belongs to Zucchetti Centro Sistemi S.p.A. No part of this manual (including the
software, etc.) may be copied, reproduced or distributed in any form or by any means without the
permission of Zucchetti Centro Sistemi S.p.A. All rights reserved. ZCS reserves the right to final
interpretation. This manual is subject to change based on feedback from users, installers or customers.
Please check our website at http://www.zcsazzurro.com for the latest version.
Technical support
ZCS offers a support and technical consultancy service accessible by sending a request directly from the
website https://www.zcsazzurro.com/it/support.
The following toll-free number is available for the Italian territory: 800 72 74 64.

5 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
Preface
General information
Please read this manual carefully before installation, operation or maintenance.
This manual contains important safety instructions that must be followed during installation and
maintenance of the system.
Scope
This manual describes the assembly, installation, electrical connections, commissioning, maintenance and
troubleshooting of the following AZZURRO inverters:
1PH 1100TL-V3 / 1PH 1600TL-V3 / 1PH 2200TL-V3 / 1PH 2700TL-V3 / 1PH 3000TL-V3 /
1PH 3300TL-V3
Keep this manual so that it is accessible at all times.
Recipients
This manual is intended for qualified technical personnel (installers, technicians, electricians, technical
support personnel or anyone who is qualified and certified to operate a photovoltaic system), who are
responsible for installing and starting the inverter in the photovoltaic energy system and for operators of
the photovoltaic system.
Symbols used
This manual provides information for safe operation and uses certain symbols to ensure the safety of
personnel and materials, and for efficient use of the equipment during normal operation.
It is important to understand this information to avoid accidents and damage to property. Please take note
of the following symbols used in this manual.

6 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
Danger: indicates a hazardous situation which, if not resolved or avoided,
could result in serious personal injury or death.
Danger
Warning: indicates a hazardous situation which, if not resolved or avoided,
could result in serious personal injury or death.
Warning
Caution: indicates a hazardous situation which, if not resolved or avoided,
could result in minor or moderate personal injury.
Caution
Attention: indicates a potentially hazardous situation which, if not resolved
or avoided, could result in damage to the system or other property.
Attention
Note: provides important tips on the correct and optimal operation of the
product.
Note

7 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
1. Preliminary safety instructions
If you have problems or questions regarding the reading and
understanding of the following information, please contact Zucchetti
Centro Sistemi S.p.A. through the appropriate channels.
Note
General information in this chapter
Safety instructions
Highlights the safety instructions to be followed during installation and use of the equipment.
Symbols and icons
Introduces the main safety symbols on the inverter.
1.1. Safety instructions
Before installing and using the equipment, make sure you read and understand the instructions in this
manual and familiarise yourself with the relative safety symbols shown in this chapter.
Depending on national and local requirements, permission must be obtained from your local provider before
connecting to the electrical grid, making sure that the connections are carried out by a qualified electrician.
Contact the nearest authorised service centre for any repairs or maintenance. Contact your distributor for
information on the nearest authorised service centre. DO NOT carry out repairs yourself, as this may result
in injury or damage.
Qualified personnel
Ensure that the operator has the necessary skills and training to operate the equipment. Personnel
responsible for use and maintenance of the equipment must be qualified and capable of performing the
activities described, and must also have appropriate knowledge on how to correctly interpret the contents
of this manual. For safety reasons, this inverter can only be installed by a qualified electrician with the
necessary training and/or skills and knowledge. Zucchetti Centro Sistemi S.p.A. declines all responsibility
for damage to property or personal injury caused by incorrect use of the device.

8 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
Installation requirements
Install and start the inverter according to the following instructions. Place the inverter on suitable load-
bearing supports with sufficient load capacity (such as walls or photovoltaic racks) and make sure that the
inverter is positioned vertically. Choose a suitable location for the installation of the electrical equipment.
Make sure there is sufficient space for heat dispersion and to accommodate future maintenance. Maintain
adequate ventilation and ensure that there is enough air circulation for cooling.
Figure 1 –Do not lose or damage this manual
Transport requirements
If you have problems with the packaging that could damage the inverter or if you find any visible damage,
immediately notify the transport company. If necessary, request assistance from an installer of photovoltaic
systems or from Zucchetti Centro Sistemi SpA. Transport of the equipment, especially by road, must be
carried out with vehicles suitable to protect the components (in particular, electronic components) against
violent knocks, humidity, vibrations, etc.
Electrical connections
Please pay attention to the electrical regulations on accident prevention when dealing with photovoltaic
inverters.
Before connecting the mains power, be sure to disconnect the photovoltaic
modules by disconnecting all the DC switches of the generator. When
exposed to the sun, the photovoltaic panels produce a voltage that can be
dangerous!
Danger

9 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
All installation operations must be carried out by a professional electrician, who
must:
be prepared.
carefully read this manual and understand its contents.
Warning
Before connecting the inverter to the grid, make sure that all the necessary
permits have been obtained from the local grid operator and that all the
electrical connections are made by a professional electrician.
Attention
Do not remove the information label or open the inverter.
Otherwise, ZCS will not provide any warranty or maintenance.
Note
Operation
Contact with the electrical grid or the terminal of the equipment may cause
electrocution or fire!
Do not touch the terminal or the conductor connected to the electrical grid.
Follow all the instructions and safety requirements relating to the mains connection.
Danger
Some internal components reach very high temperatures when the
inverter is in operation. Wear protective gloves!
Attention

10 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
Maintenance and repair
Before carrying out any repairs, disconnect the inverter from the mains network (AC
side) and from the photovoltaic system (DC side).
After switching off the AC and DC switches, wait 5 minutes before carrying out any
repairs or maintenance on the inverter!
Danger
The inverter should start working again after any faults have been fixed. For any
repairs, contact your local authorised service centre;
Do not disassemble the internal components of the inverter without permission. This
will void the warranty. Zucchetti Centro Sistemi S.p.A. shall not be responsible for any
damage or loss caused by improper use or maintenance.
Attention
1.2. Symbols and icons
Safety signals
Pay attention to possible burns due to hot parts. Only touch the screen or
press the keys while the inverter is in operation.
Caution
The PV strings should be connected to the ground in accordance with the local
regulations.
To ensure the safety of the system and people, the inverter and photovoltaic
strings must be securely connected to the ground.
Attention
Ensure the correct DC input voltage; this must be below the maximum
allowable DC voltage. Overvoltage can cause permanent damage to the
inverter that is not covered by the warranty!
Warning

11 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
Symbols on the inverter
Some safety symbols are located on the inverter. Read and understand the contents of the symbols before
installing the inverter.
Residual voltage may be present on the inverter! Before opening the
inverter, wait 5 minutes to ensure that the capacitors are completely
discharged.
Beware of high voltage
Beware of high temperatures
Complies with the European Standards (CE)
Ground connection point
Read this manual before installing the inverter.
Indication of the allowable temperature range
Degree of protection of the equipment according to the IEC 70-1 standard
(EN 60529 June 1997).
Positive and negative polarities of the input voltage (DC).
’Smin"“’"
There is residual voltage in the inverter! Before opening the equipment,
wait five minutes to ensure that the capacitance has been completely
discharged.
Be careful of high voltage.
Be careful of high temperature.
Complies with European standards.
Ground connection point.
This indicates the allowed temperature range.
This indicates the degree of protection of the equipment according to
IEC standard 70-1 (EN 60529 June 1997).
Positive and negative polarities of the input voltage (DC).

12 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
2. Product features
General information in this chapter
Product dimensions
The field of use and overall dimensions of the 1PH 1100TL-3300TL-V3 inverters are indicated in this
section.
Description of functions
Describes how the 1PH 1100TL-3300TL-V3 inverters and their internal operating modules work.
Efficiency curve
Describes the efficiency curves of the inverter.
2.1. Product presentation
Field of use
The 1PH 1100TL-3300TL-V3 inverters are grid-connected photovoltaic inverters with a single MPPT
channel, capable of converting the direct current generated by the photovoltaic strings into single-phase
sine wave alternating current and feeding the energy to the public electricity grid. An AC circuit breaker
(see chapter 4.4) must be used as a disconnecting device and must always be easily accessible.
Figure 2 –Grid-connected photovoltaic system
The 1PH 1100TL-3300TL-V3 inverters can only be used with photovoltaic modules that do not require one
of the polarities to be grounded. The input current and voltage of the PV strings must not exceed the limits
specified in the technical specifications. Only photovoltaic modules can be connected to the input of the
inverter (do not connect batteries or other power supply sources).
• Accessories and optional components of the inverter should be chosen by a qualified technician who is
familiar with the installation conditions.
• Overall dimensions 1PH 1100TL-3300TL-V3 : LxWxH = 303 mm x 260.5 mm x 118 mm

13 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
Figure 3 –Front, side and back view of the inverter and bracket
• Overall dimensions 1PH 2700TL-3300TL-V3 : LxWxH = 321 mm x 260.5 mm x 131.5 mm
Figure 4 –Front, side and back view of the inverter and bracket

14 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
Labels on the inverter
Figure 5 –Do not remove the label on the side of the inverter
2.2. Description of functions
The DC power generated by the PV modules is filtered through the input board before entering the power
board. The input board also has the function of detecting the insulation impedance and the DC input
voltage/current. The power board converts the DC power into AC power. The current converted into AC is
filtered through the output board and is then fed into the grid. The output board also has the function of
measuring the grid voltage/current, GFCI and acts as an output isolation relay. The control board provides
the auxiliary power supply, controls the operating status of the inverter and shows it on the display. The
display also shows the error codes when the inverter is not functioning properly. At the same time, the
control board can activate the protection relay in order to disconnect the inverter from the grid and protect
the internal components.
Inverter functions
A. Feeding reactive power into the grid
The inverter is able to produce reactive power and feed it into the grid through the setting of the Power
Factor. The feed-in management can be controlled directly by the grid company through a dedicated RS485
interface.
B. Limiting the active power fed into the grid
If enabled, the inverter can limit the amount of active power fed into the grid at the desired value (expressed
as a percentage).

15 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
C. Automatic power reduction when grid is over frequency
When the grid frequency is higher than the limit set, the inverter reduces the output power in order to
ensure the stability of the grid.
D. Data transmission
The inverter (or a group of inverters) can be monitored remotely via an advanced communication system
based on a RS485 interface or via Wi-Fi.
E. Software update
A microSD card is used to update the firmware.
Wiring diagram
Figure 6 –Block diagram of the 1PH 1100TL-3300TL-V3-L inverter

16 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
2.3. Efficiency curve
Efficiency curve for an Azzurro ZCS 1PH 3300 TL-V3 model
Figure 7 –Efficiency curve for an Azzurro ZCS 1PH 3300TL-V3 inverter

17 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
3. Installation
General information in this chapter
This chapter describes how to install the 1PH 1100TL- 3300TL-V3 inverter.
Installation notes:
DO NOT install 1PH 1100TL-3300TL-V3 inverters near flammable materials.
DO NOT install 1PH 1100TL-3300TL-V3 inverters in an area where flammable or
explosive materials are stored.
Danger
The housing and heat sink may become very hot while the inverter is running, DO NOT
install the inverter in places where they may be touched inadvertently.
Warning
Consider the weight of the inverter during transportation and installation.
Choose an appropriate mounting position and surface.
Attention
3.1. Installation process
Figure 8 - Installation steps
3.2. Checks before installation
Checking the outer packaging
Packaging materials and components may be damaged during transport. Therefore, please check the
materials of the outer packaging before installing the inverter. Check the surface of the box for external

18 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
damage such as holes or tears. If any form of damage is detected, do not open the box containing the inverter
and contact the supplier and the courier as soon as possible.
It is recommended to remove the packaged materials from the box 24 hours before installing the inverter.
Checking the product
After removing the inverter from its packaging, check that the product is intact and complete. If any
damage is found or components are missing, contact the supplier and transport company.
Contents of the packaging
Carefully check the contents of the packaging before installation, making sure that no element inside the
packaging is missing or damaged.
The package should contain the following components:
1 Photovoltaic inverter
1 mounting bracket
1 + input terminal
1 - input terminal
1 metal terminal for +
DC power cables
1 metal terminal for -
DC power cables
2 M5 hexagonal screws
10 M6 flat washers
3 expansion plugs (1
spares)
5 self-tapping screws
1 user manual
2 warranty

19 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
1 Warranty
Registration
1 Outgoing inspection
report
1 AC output connector
1 485 terminal
3.3. Installation tools
The following tools are required for installation of the inverter and electrical connections; therefore, they
must be prepared before installation.
No.
Tool
Function
1
Drill
Recommended drill bit: 6mm
To drill holes in the wall for
fixing the bracket
2
Screwdriver
To screw and unscrew screws
for the various connections
3
Wire stripper
To prepare the cables for wiring
4
Adjustable spanner (opening
greater than 32 mm)
To tighten the bolts

20 / 103
Identification: MD-AL-GI-00
Rev. 1.1 of 12/03/2021 - Application: GID
User’s Manual 1PH 1100TL-3300TL-V3
Rev. 1.1 12/03/2021
5
4 mm Allen key
To screw the inverter to the
wall-mounting bracket and to
open the front cover of the
inverter
6
RJ45 crimping tool
To crimp the RJ45 connectors
for the communication cables
7
Rubber hammer
To insert the expansion plugs
into the wall holes
8
MC4 removal tool
To remove the DC connectors
from the inverter
9
Diagonal pliers
To cut and tighten the cable ends
10
Wire stripper
To remove the outer sheath of
the cables
11
Cable cutter
To cut the power cables
12
Crimping tool
To crimp the power cables
13
Multi-meter
To check the voltage and current
values
14
Marker pen
To mark the wall for better
fixing precision
