ZKTeco PL10D User manual

Installation Instruction
Version: 1.0
Date: Nov., 2014
PL10D/ML10D

Before Installation
Diagram
B
A
C
C
D
E
F
I
H
G
K
J
L
MN
1

64mm 7 2mm
35mm 40mm
30mm 35mm
Mounting Hardware Package Mounting Hardware Package
39-46mm door thickness 47-54mm door thickness
A
H
E
L
M
J
H
E
L
M
J
G
F
K
Packing List
B
D
CI
N
2

Door Preparation
Note: The standard lock includes 2 mounting hardware package only, which is used for the door
thickness of 39-46mm and 47-54 mm separately.
Note: Please refer the above picture to adjust the direction of strike plate F and latch D.
1. Check door thickness and prepare the mounting hardware
package.
2. Check door open direction.
F
F
F
F
DD
DD
30~38 56 20 10 25
39~46 64 30 10 35
47~54 72 35 10 40
55~60 80 45 10 50
H Spindle Length
(mm)
J Screw Length
(mm)
M Screw Length
(mm)
L Screw Length
(mm)
Door Thickness
(mm)
Left inward Right inward
Left outward Right outward
3

3. Change Latch (D) Direction.
Fix the latch trim panel by using screw.
Remove screw from the latch trim panel with a
screwdriver and rotate the latch bolt at 180°.
Hexagon Screw
NA
How To Use Mechanical Key And Change Handle Direction?
How To Use Mechanical Key And Change Handle Direction?
4

Cautions
1. New lock is configured to grant ANY fingerprint access to unlock.
2. The lock is equipped with mechanical keys for manual unlocking. Remove mechanical keys from the
package and keep them in a safe place.
3. To power on the lock, four alkaline AA batteries (not included) are required. Non-alkaline and
rechargeable batteries ARE NOT RECOMMENDED.
4. Please avoid strong light direct to the fingerprint holder, otherwise the infrared sensor might be
disturbed.
5. The operation of setting lock has a stand-by time limit of 10 seconds; Without any activity, lock will shut
off after 10 seconds.
6. Keep your fingers clean when using this lock.
5

Note1: Align the template along the vertical center line of
the latch(D) at the desired handle height, and tape it
to the door.
Note2: Mark the holes first, then star t drilling.
1.Drilling holes on the door. 2.Install the latch (D).
E
E
D
center line of the
handle
desired handle
height
Installation
70mm
6

Correct Position: T he small triangle
must be vertically upward.
This position is W rong !
3.Install outdoor unit(B) with gasket(C) and spindle(H) on the
door.
B
H
C
7

4.Install mounting plate (I) with gasket (C) on the door.
J
5.Install indoor unit (K).
M
Note : Push cable into the hole .
L
B
C
I
IC
J
8

6.Install the battery.
K
EG
F
7.Mark and drill holes for strike.
8. Testing the lock by rotating back handle and using mechanical
key(A).
Note :
1) W hen the door is locked, the clutch is in idle position, the front handle will be
turned. However, the door will remain locked.
2) At home, turn the handle upward to lock the deadbolt for more security. W hen
you go out, verify your fingerprint first, then turn the handle up to lock the
door for the safety of your property.
28.5mm
[1 1/8"]
[4 19/64"]
21mm
[53/64"]
18mm
[45/64"]
18mm
[45/64"]
22mm
[55/64"]
3.5mm
[9/64"]
13mm
[33/64"]
109mm
9
