2N 9152101W User manual

www.2n.cz
2N IP Safety
®
Emergency IP Intercom
Installation Manual
Version: 2.13

The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of
telecommunications equipment.
The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways,
private branch exchanges (PBX), and door and lift communicators. 2N
TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years
and represented a symbol of stability and prosperity on the telecommunications
market for almost two decades. At present, we export our products into over 120
countries worldwide and have exclusive distributors on all continents.
2N is a registered trademark of 2N TELEKOMUNIKACE a.s. Any product and/or other
®
names mentioned herein are registered trademarks and/or trademarks or brands
protected by law.
2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find
information and to answer your questions about 2N products and services. On www.
faq.2n.cz you can find information regarding products adjustment and instructions for
optimum use and procedures „What to do if...".
2N TELEKOMUNIKACE a.s. hereby declares that the 2N product complies with all
basic requirements and other relevant provisions of the 1999/5/EC directive. For the
full wording of the Declaration of Conformity see the CD-ROM (if enclosed) or our
website at www.2n.cz.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.

The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All
development, production and distribution processes of the company are managed by
this standard and guarantee a high quality, technical level and professional aspect of
all our products.

2N TELEKOMUNIKACE a.s., www.2n.cz 4/85
Content:
1. Product Overview
1.1 Components and Associated Products
1.2 Terms and Symbols
2. Description and Installation
2.1 Before You Start
2.2 Mechanical Installation
2.3 Electric Installation
2.3.1 Overvoltage Protection
2.4 Extending Module Connection
3. Function and Use
3.1 Configuration
3.2 Maintenance
3.3 Downloads
4. Technical Parameters
4.1 General drawings
5. Supplementary Information
5.1 Troubleshooting
5.2 Directives, Laws and Regulations
5.3 General Instructions and Cautions

2N TELEKOMUNIKACE a.s., www.2n.cz 5/85
1. Product Overview
Here is what you can find in this section:
1.1 Components and Associated Products
1.2 Terms and Symbols

2N TELEKOMUNIKACE a.s., www.2n.cz 6/85
Basic Features
2N IP Safety
®is a highly resistant and reliable IP door access intercom provided with a
lot of useful above-standard functions. Supporting the SIP standard and being
compatible with the leading IP PBX and telephone suppliers, can make 2N IP Safety
®
use of all VoIP services. can work as a standard or emergency door 2N IP Safety
®
access intercom for buildings, entrances to premises or garages, manufacturing halls,
highways and so on.
2N IP Safety
® is equipped with two very sensitive microphones and an up to 10 W
loudspeaker. Thanks to an integrated acoustic echo cancelling (AEC) system, the
product provides mutual audibility even of persons talking at the same time under
normal conditions.
2N IP Safety
®can be provided with pre-programmed buttons. You can set up to three
telephone numbers and time profiles for each of the buttons to increase the
accessibility of the called party.
2N IP Safety
®is equipped with an electric lock switch. You can control the switch
using a numerical keypad or, during a call, using any telephone set. An additional
switch module can be installed if necessary. A wide range of settings allow for a
variety of applications.
2N IP Safety
®is very easy to install. All you have to do is connect the system into your
LAN via a network cable and feed it from a 12 V power supply or your PoE supporting
LAN.
Configure using your PC via any web browser. Use the2N IP Safety
®
to manage extensive systems easily and 2N Access Commander
® 2N IP Safety ®
quickly.

2N TELEKOMUNIKACE a.s., www.2n.cz 7/85
Advantages of Use
Uncompromising Antivandal design
High coverage level – up to class IP69K
Variable mounting options (brick/plasterboard flush mounting, surface
mounting)
Sensitive microphone and powerful loudspeaker
Bidirectional communication – acoustic echo cancelling
Optional dial buttons including backlight
Integrated electronic lock switches with wide setting options
LAN (PoE) or external 12 V power supply
Configuration via web interface or dedicated PC application
SIP 2.0 support
Up to 1999 telephone directory positions
Up to 20 user time profiles
Video codecs (H.263, H.263+, H.264, MPEG-4, JPEG)
Audio codecs (G.711, G.729, G.722, L16/16 kHz)
HTTP server for configuration
SNTP client for time synchronisation with server
RTSP server for video streaming
SMTP client for e-mail sending
TFTP client for automatic configuration and firmware update

2N TELEKOMUNIKACE a.s., www.2n.cz 8/85
1.1 Components and Associated Products
Basic Units
9152101W 2N Part No.
Axis Part No. 01353-001
1 button
10 W loudspeaker
extra robust version
control of two electric locks
possibility of connecting additional switch
9152102W 2N Part No.
Axis Part No. 01354-001
2 buttons with „INFO“ and „SOS“ labels
10 W loudspeaker
extra robust version
control of two electric locks

2N TELEKOMUNIKACE a.s., www.2n.cz 9/85
9152101MW2N Part No.
Axis Part No. 01355-001
1 red emergency button
10 W loudspeaker
extra robust version
control of two electric locks
possibility of connecting additional switch
2N IP Safety
®units can wall mounted without requiring any additional accessories.
Use the appropriate mounting box (see below) for plasterboard and flush mounting.

2N TELEKOMUNIKACE a.s., www.2n.cz 10/85
Flush Mounting Box
91520002N Part No.
Axis Part No. 01356-001
Mounting frame
Orange
Aluminum
edge Good to cover the of the intercom in flush or
plasterboard installation.
91510012N Part No.
01348-001Axis Part No.
Brick flush mounting box
Stainless steel
Dimension: 132 x 223 x 83 mm

2N TELEKOMUNIKACE a.s., www.2n.cz 11/85
91510022N Part No.
01349-001Aixs Part No.
Plasterboard flush mounting box
Dimension: 237 x 129 x 70 mm
Hole: 237 x 118 mm

2N TELEKOMUNIKACE a.s., www.2n.cz 12/85
Mounting Accessories
91510052N Part No.
01351-001Axis Part No.
Gooseneck stand
Height 120 cm (47 inch) to the top of the
intercom
91510072N Part No.
Axis Part No. 01550-001
Gooseneck stand double
Height 115 cm (45”) and 203 cm (80”)

2N TELEKOMUNIKACE a.s., www.2n.cz 13/85
2N Part No. 9151006
Axis Part No. 01352-001
Installation adapter (US only)
2N Part No. 9151018
Axis Part No. 01345-001
Security screws
An alternative that is safer than regular screws.
Torx with a pin. Supplied with the appropriate
handle.

2N TELEKOMUNIKACE a.s., www.2n.cz 14/85
Internal Units and Accessories
Part Numbers:
913783752N Part No.
01668-001Axis Part No.
913783752N Part No.
01670-001Axis Part No.
2N Indoor Touch 2.0
® – black
WiFi version (second part no.)
The elegant internal touch panel, 2N Indoor Touch 2.0
®
, is suitable for all . On the panel’s 2N IP intercoms
display not only can you find out who is at the door,
but also start a conversation with the visitor, open the
lock or turn on the light in the entrance hall.
2N Part No. 91378382
Axis Part No. 01425-001 2N Indoor Touch
® desk stand black

2N TELEKOMUNIKACE a.s., www.2n.cz 15/85
Part Numbers:
2N Part No. 91378375WH
Axis Part No. 01669-001
91378376WH2N Part No.
Axis Part No. 01671-001
2N Indoor Touch 2.0
® – white
WiFi version (second part no.)
The elegant internal touch panel, 2N Indoor Touch
®
, is suitable for all . On the panel’s 2.0 2N IP intercoms
display not only can you find out who is at the door,
but also start a conversation with the visitor, open the
lock or turn on the light in the entrance hall.
2N Part No. 91378382W
Axis Part No. 01426-001 2N Indoor Touch
® desk stand white

2N TELEKOMUNIKACE a.s., www.2n.cz 16/85
VoIP Telephones
913783572N Part No.
Axis Part No. 01422-001
Grandstream GXV3240 VoIP video telephone
GXV3240 is the successor to the popular GXV3140 model,
which allows comfortable video calls in the IP network.
Touchscreen and keyboard control.
913783582N Part No.
Axis Part No. 01421-001
Grandstream GXV3275 VoIP telephone
GXV3275 is the successor to the popular GXV3175 model,
which allows comfortable video calls in the IP network.
Touchscreen control.

2N TELEKOMUNIKACE a.s., www.2n.cz 17/85
Electric Locks
932071EPart No. BEFO 11211
12 V / 230 mA DC
low consumption
932081EPart No. BEFO 11221 with momentum pin
12 V / 230 mA DC
low consumption
For opening of the lock a short electrical impuls is sufficient,
which unlocks the lock. Lock is then open until someone
closes the door.
932091EPart No.
BEFO 11211MB with mechanical blocking
12 V / 230 mA DC
low consumption
Enables mechanically close or open the lock. When opened,
the lock is open all the time. When closed, it behaves as
standart electrical lock.

2N TELEKOMUNIKACE a.s., www.2n.cz 18/85
Part No. 932061E BEFO 211211 door signalling, low consumption
12 V / 230 mA
A regular lock with a built-in contact to indicate whether the
door is open or closed.
Part No. 932072E BEFO 31211
fail-safe
12 V / 170 mA DC
The failsafe lock is closed when electricity is switched on.
When electricity is interrupted, the lock is opened.
Part No. 932062E BEFO 321211
fail-safe, door signalling
12 V / 170 mA
The failsafe lock is closed when electricity is switched on.
When electricity is interrupted, the lock is opened.
It contains a built-in contact to indicate whether the door is
open or closed.
Tip
FAQ: Electric locks – Difference between locks in 2N IP intercoms
accesories

2N TELEKOMUNIKACE a.s., www.2n.cz 19/85
Power Supply
Part Numbers:
91378100E2N Part No.
91378100US2N Part No.
01403-001Axis Part No.
PoE injetor – with EU cable
PoE injector – with US cable
ethernet For power supply of intercom via cable when
PoE switch is not available.
91341481EPart No. Stabilised 12 V / 2 A power supply needs to be used
when no PoE is available.
932928Part No. 12 V transformer
For 230 V mains voltage.
For external power supply of the lock with 12 V AC
voltage.

2N TELEKOMUNIKACE a.s., www.2n.cz 20/85
Additional Modules
91510102N Part No.
Axis Part No. 01350-001
Additional switch with normally open/closed
contact and 12 V switched output.
Includes tamper switch.
Enables control of a secondary device, passive time
unlimited switching up to 48 V / 2 A or active
switch 12 V / 700 mA. Also includes tamper switch
to signal opening of the front panel. Another one
input is available.
91590102N Part No.
Axis Part No. 01386-001 2N
®Security Relay
A handy add-on that significantly enhances door
entry security as it prevents tampering with the
intercom and forced opening of the lock. To be
installed between intercom and lock, powered by
the intercom.
9137410E2N Part No.
Axis Part No. 01397-001
External IP Relay – 1 output
Standalone IP device which can be controlled by
HTTP commands sent by , which can 2N IP intercom
thus control devices on unlimited distance.
