2N Helios IP User manual

2n Helios IP
INSTRUCTION MANUAL
Versiyon 1.0
www.yonnet.com.tr

2N®Helios
General Assembly & Wiring Diagram
2
9
www.yonnet.com.tr
2 Overview and Settings
I have written this script is ready written OK to extension in real time the status of
negotiations. UNKNOWN those written inaccessible.
.
POWER SUPPLY
• 802.3af (PoE) 48 V / 380 mA DC
• Adaptor 230 V10%,
50/60 Hz / 12V DC
DC POWER SUPPLY
• 12 V / 1A DC
VOIP Communication
SIP
VOICEC0DEC
G.711 PCM, 64 kbps
G.729
VIDE0 C0DECS
H.264, 64 –2048 kbit/s
H.263
H.263+
INTERFACE
• Ethernet
• Ethernet speed 10/100 BASE-T
• RöleÇıkışı
Max voltaj 30 V DC
Max current 1 A DC
OTHER
•Dimensions
210x100x29 mm (h×w×d)
• Weight
max. 500 g
• Operating Temperatures
-–20 with 55 ºC between

10
www.yonnet.com.tr
2N®Helios
General Assembly & Wiring Diagram 2.1
2.1 / 2.2
2.1 General Assemblyand Wiring Diagram
The Allen key in the screw on the bottom of
the product box with the metal surface is
removed.
The screws in the 4 corners of the plastic
plate is removed with a screwdriver
through the star before us.
After removing the plastic plate is held on the connection specified in the figure below.
2.2 General Operating Principles and Architecture
•The product display, the buttons on the left and right of the screen is used as a shortcut to
search for assigning apartments.
• The product at the bottom of the display is reserved for use only finds the last two button
menu. So this can’t be performed by pressing the search button.
• Perform the screen display menu settings in the phone book can be defined. This interface
design process is set through 2N Helios IP Manager Program.
• Numbering of the office being sought is identified In addition, it opens the door lock with a
defined password.
• There RTSP feature on the camera. In this way, it is externally accessible to the camera
image.
• For unlock to the door;,sending signals or short circuit in the device, which relays are
provided
• The card access model;Opening the card by defining the door lock is provided.

11
www.yonnet.com.tr
2N®Helios
Static & DHC IP Settings
2.3
2.3 Over DeviceStaticand DHCP IP settings
• For static IP to;
StandardIP:192.168.1.100 ıt is set.
• 2N Helios’ power connection is made.
• Work is expected that the first warning tone.
• According to the model applied the following button combination.
• 1 for push-button models;
• 15 times within 30 seconds of the single button needs to be pressed.
• 3-button models for;
• 1, 1, 1, 2, 2, 3 button must be pressed to include in 30 seconds.
• 6-button models for;
• 4, 4, 4, 5, 5, 6 button must be pressed to include in 30 seconds.

12
www.yonnet.com.tr
2N®Helios
Static & DHC IP Settings
2.3
• Givetothe DHCP IP;
• 2N®Helios’power connection is made.
• Work is expected that the first warning tone.
• According to the model applied the following button combination.
• 1 button models for;
• 15 times within 30 seconds of the single button needs to be pressed.
• 3 button models for;
• 2, 1, 1, 2, 2, 3 button must be pressed to include in 30 seconds.
• 6 button models for;
• 5, 4, 4, 5, 5, 6 button must be pressed to include in 30 seconds.

13
www.yonnet.com.tr
2N®Helios
Access Device
2.4
2.4 Access Devices
Devices in the open position at the factory have come DHCP.Modem or access point
distributes the IP the device can receive IPs. IP through the device defined screening
programs with mac address, the IP can be found in a comfortable way.If the IP does not
deploy, a system that is not performed, above static IP settings.The IP with which the
device is connected to interface.
User Name : admin
Password
Information
: 2n
:

14
www.yonnet.com.tr
2N®Helios
Access Device
2.4
The first screen contains information about the device.
Product name
Bootloader version
Hardware version
Serial number
MAC address
Uptime
RegistrationStatus:?
SIP number
Registration at
Registration time
DHCP status
IP address
Net mask
Default gateway
Primary DNS
Secondary DNS
Camera
Display
Card reader
Number of buttons
Numeric keypad
:
:

15
www.yonnet.com.tr
2N®Helios
Basic Settings
2.5.1
2.5.1 Phonebook

16
www.yonnet.com.tr
2N®Helios
Basic Settings
2.5.1
As shown in the above image from the first 10 and the arrow keys are called even numbers
going forward position.
Each position corresponds to the desired each number dialed.
Position enabled:Position aktif/pasif
Position name
E-mail
: Position name
: The email address of the person to be searched in this section is defined
position.
If the mail can’t get an answer at the door to allow you to send mail as a picture of who's
Calling. It is importantthatdetailsof 2NHeliosemergenceofthe Internetand SMTP(Simple
MailTransfer Protocol)server tobeaneed forsupport.
Number 1,2,3
Time Profile
Group Call
: Andtelephone numbers ofpeopleyou want to searchis definedhere.
: Number 1, determined time profile also ıf responding in rangeNumber 2’
either provide the call through.
: Defined Number 1, 2, 3 the addresses of all provide simultaneous to
play.

17
www.yonnet.com.tr
2N®Helios
Basic Settings
2.5.2
2.5.2 Switch
