3M PPS Series 2.0 User manual

Assembly
1Attach the supplied air flow valve to the bottom of the gun.
2Attach the nozzle to the spray gun with the locking collar fully connected. Note: It
is easier to install the nozzle while pulling the trigger backward toward the spray
gun handle. To remove the nozzle from the spray gun, reverse the process.
3Attach 3M™PPS™Series 2.0 spray cup to nozzle. See back for directions.
4Once the spray gun is properly assembled you may attach the air line.
For additional questions, contact your local 3M representative
or email: aaduk[email protected].
See manual for additional use and health and safety information.
Recommended set up starting points
Fan control knob: Open 1.5 turns for HVLP nozzles, 2.5 turns for Fine Finish
nozzles from closed position
Fluid control knob: Open 4 rotations from closed position
See recommended pressure setting on Atomising Head Air Cap.
Nozzle recommendation
* Starting points only, refer to Paint Manufacture for recommendation
onfluid tip size.
2.0 1.8 1.6 1.4 1.3 1.2 0.9
High viscosity coatings • •
Sprayable fillers • •
High build primer • • •
Primer surfacer • • •
Wet on wet primer • •
Primer sealer • •
Direct gloss •
Single stage top coat •
Solvent base colour • •
Clearcoat • • •
Waterborne base coat • •
UV Primers • • •
Midcoat / Effect Coats • • •
Smart / Spot repair •
WARNING! Do not immerse spray gun or nozzles in cleaning solvents or gun washers.
*Operating Pressure Range (OPR) is the inlet pressure range for safe function of the spray gun.
3M™Performance Spray Gun – Gravity
Operating Pressure Range* is between 7 psi - 37 psi (0.5 bar - 2.6 bar)

Adding the 3M™PPS™Series 2.0 SprayCup
SystemComponents
1Insert the 3M™PPS™Series 2.0 Spray Cup System
disposable liner into the 3M™PPS™Series 2.0 Spray
Cup System mixing cup.
2Pour material to be sprayed into the 3M™PPS™
Series 2.0 Spray Cup System mixing cup. Stir
asneeded.
3Place the 3M™PPS™Series 2.0 Spray Cup System
lid with built-in filter on top of the 3M™PPS™mixing
cup with liner and snap into place.
4Turn until tight. Insert 3M™PPS™Series 2.0 Spray
Cup System sealing plug prior to shaking or sealing.
5Attach spray gun to filled 3M™PPS™Series 2.0
Spray Cup System cup.
Cleaning
1Once coating application is complete, disconnect the air hose
fromthegun.
2To drain back paint into cup – invert cup, pull trigger, and tap
the3M™PPS™Series 2.0 cup on a table 3 times.
3Rinse out nozzle spout and flush cleaning solvent through the nozzle
by pulling trigger with fluid tip pointed straight down into receptacle
tocollect waste solvent.
4Store spray gun with a clean nozzle attached to protect the needle.
3M™Performance Spray Gun – Gravity
Operating Pressure Range* is between 7 psi - 37 psi (0.5 bar - 2.6 bar)
ATTENTION
Note: Do not put Spray Gun/Spray Gun Body in Gun Washer.
© 3M 2022. 3M and PPS are trademarks of 3M Company. All rights reserved.
For additional questions, contact your local 3M representative
or email: [email protected].
See manual for additional use and health and safety information.
