3M Aqua-Pure AP801B User manual

Under Sink Water Filtration Reference the pink circles on the map for this setup
Under sink water filtration systems are great
solutions to provide cleaner, clearer and
great tasting drinking and cooking water by
reducing a wide range of contaminants
that may be present in the local water.
Full Flow System
• Use the existing primary
faucet to enjoy a high flow rate
• For strongest water flow,
use 3M™ Aqua-Pure™ Full Flow
Water Filter System 3MFF100
• One year replacement
interval1for Aqua-Pure Water
Filter System 3MFF100
Aqua-Pure Full Flow Water Filter System 3MFF100 is certified
by the Water Quality Association to WQA/ASPE/ANSI S-803 for
sustainability attributes and NSF/ANSI 372 for low lead content.
3MFF100
High Flow
Rate
6,000 Gallon
Capacity
Particulate/CTO/Lead/Cyst/Select VOCs2
Scale Inhibition System Reference the orange circle on the map for this setup
The 3M™ Aqua-Pure™ Whole House Scale
Inhibition Water Treatment System AP430SS
is a great add on to your tank and tankless
water heater sale.
This water treatment system helps
protect tank and tankless water heaters
by providing a consistent, controlled
dose of polyphosphate scale inhibitor,
plus it helps protect the piping system
from corrosion.
Scale Inhibition System
• Helps maintain efficiency and
extend the life of tank and
tankless water heater system
• Stainless steel head
• ¾" inlet/outlet connection
AP430SS
Scale3inhibition at 10 gpm
Typical Installation
Important: Diagram shown is for reference purposes only.
Read installation and operation manual prior to installing the unit.
Bathroom
Public
Water
Supply
Water Meter
Water
Heater
Pressure Tank
Pump
Well
Supply
Only
Well
Water
Supply
Kitchen
Utility
Room
Whole House Water Filtration Reference the green circle on the map for this setup
Whole house water filter systems are
great solutions to help protect your
pipes and appliances as well as offer
you great tasting drinking water from
anywhere in the home.
3M™ Aqua-Pure™ AP800
Series Whole House Water
Filtration System
• High flow designed with
1" NPT connections
• Two year limited warranty to help
provide long-term operation,
superior factory support and service
• Designed with built-in pressure relief
for convenient cartridge change out
3M™ Aqua-Pure™ AP900
Series Whole House Water
Filtration System
• Three levels of filtration available
for different water quality issues
• Stainless steel head with
limited 25 year warranty
• Easy SQC replacement
change-out style
AP801B AP801T AP802B AP802T
Particulate/Chlorine Taste Odor/Chloramines/Cyst/Scale/
Lead/Mercury/Select VOCs/Asbestos
AP902
Particulate
AP903
Particulate/CTO3
AP904
Particulate/
CTO3/Scale3
1Filter life depends on local water quality. Replace filter
cartridge no later than at the indicated intervals, or earlier
if there is a drop in flow rate or change in odor or taste.
2For additional performance claims please visit NSF.org.
3As tested and verified by manufacturer’s laboratory.

Find the Right Filter
Which 3M
™
Aqua-Pure
™
filter best suits your needs?
AP717 AP430SS AP801B / AP801T AP802B / AP802T AP902 AP903 AP904 AP Easy
Complete
3MDW301 AP Easy
Cyst-FF
3MFF100
AP Easy
Complete
Cooler
Where Located Refrigerator Water
Heater Whole House / Point of Entry Under Sink, Dedicated
Faucet Under Sink, Full Flow Water
Coolers
Replacement
Cartridge
AP717 AP431 AP810 AP811 AP817 AP810-2 AP811-2 AP817-2 AP910R AP917HD AP917HD-S AP Easy
C-Complete 3MDW311 AP Easy
C-Cyst-FF 3MFF101 AP Easy
C-Complete
Filter Life
1
6 months 6 months 6 months 6 months 6 months 6 months 6 months 6 months Up to 12
months
Up to 12
months
Up to 12
months 6 months 12 months 6 months 12 months 6 months
Micron Rating 5N/A 5 25 25 5 25 25 5 5 5 0.5 0.2 0.5 0.2 0.5
Reduction Claims
Sediment/Particulate ✓ ✓✓✓✓✓✓✓✓✓✓✓✓✓✓
Chlorine Taste/Odor ✓ ✓ ✓ ✓✓✓✓✓✓✓
Chloramines ✓
Cyst ✓✓✓✓✓
Scale ✓ ✓ ✓
Lead ✓ ✓ ✓ ✓
Mercury ✓ ✓
Select VOCs ✓ ✓ ✓
VOCs ✓
Asbestos ✓
Enjoy healthy, great tasting water
straight from the tap. Our products
are designed for a variety of homes
and requirements.
3M Water Filters can reduce the following from your water supply
2
:
Sediment: Can damage plumbing and appliances over time. It includes rust particles that
can cause brown, yellow or orange spots on clothing, fixtures and toilets.
Taste/Odor: Chlorine is used by water treatment plants to kill harmful bacteria and
organisms. Chlorine has a recognizable taste and odor that can be unpleasant.
Cysts: Encapsulated forms of certain single cell parasites like oocysts of Cryptosporidium
that may be present in drinking water and resistant to normal chlorination.
Hardness/Scale: Scale can cause water to fail to generate a lather with soap, and can build-up on and create the failure
of heating elements, piping, valves, solenoids and more. This is caused by the presence of calcium and magnesium ions.
Lead: Water is naturally a solvent and can leach lead and other heavy metals from brass taps and plumbing fittings.
Lead may be present in pipes and the solder used to connect pipes.
Chemicals/VOCs: Contaminants resulting from pesticide runoff and gasoline leakage into ground water (VOCs —
Volatile Organic Chemicals).
1
Filter life depends on local water quality. Replace filter cartridge no later than at the indicated
intervals, or earlier if there is a drop in flow rate or change in odor or taste.
2
Depending on the filter media selected.© 3M 2023. All rights reserved. 3M and Aqua-Pure are trademarks of 3M Company.
