ABB JSM D23C User manual

REV. D 1/ 5
—
SAFETY PRODUCTS
Installation guide
JSM D23C Mounting kit for Magne on
sliding door
JSM D23C is a mounting kit for Magne 3 and Magne 4 to be used on sliding doors. Designed for use on
both right and left opened doors.
Installation shall be done in accordance with a risk assessment for the individual application.
Installation must be carried out by authorized personnel and in accordance with instructions in this
document and the ‘Magne Product Manual’.
Parts overview
Product ID
Description
2TLA042023R0210
JSM D23C Mounting kit Magne on sliding door
The mounting kit includes all bolts and nuts necessary to mount Magne on ABB Quick-Guard © fencing
system.
Note!
Magne, Eva,
anchor plate and cellular rubber are not included in the kit. These items
must be ordered separately
.
Fitting for Eva and
Anchor plate
Fitting for Magne
Tape (1x) used between
anchor plate fitting and
cellular rubber

INSTALLATION GUIDE
REV. D 2/ 5
Dimensions
All dimensions are in millimeter (mm).
Magne fitting dimensions
Eva and Anchor plate fitting dimensions

INSTALLATION GUIDE
REV. D 3/5
Orientation and mounting of Eva sensor
Depending on which Magne model used, the Eva sensor must be oriented and mounted in different ways
(see figure for details).
Magne 3 has no integrated Adam sensor, i.e. no Eva is used.
Installation tolerances (mm)

INSTALLATION GUIDE
REV. D 4/ 5
Installation and mounting
Read and understand ‘Magne Product manual’ and ‘Eden Product manual’ before starting the
installation.
Note!
In the following step by step i
nstructions, a Magne 4 is mounted on a right opened sliding
door
.
1.
Mount the Magne fitting on to the fence.
Note! Orientation depends on in which
direction the door is opened.
Note! Mount the bracket near to the handle
used for opening the door.
2.
Mount Magne on to the bracket using 2 pcs
M6x20 screws.
Note! If Magne M12-
contact (cable) should be
pointing up, use lower and center M6-installation
holes.
3.
Pre-assemble anchor plate fitting with cellular
rubber,
tape, anchor plate and Eva.
-
Mount anchor plate on to the fitting using a
M8x20 screw
with thread locking paste and
tighten
it smoothly.
-
Insert 2 pcs DA2 distances on the backside of
Eva and mount
it on to the fitting using 2 pcs
M4x14 screws.
Note! Make sure Eva is oriented and
positioned to fit the Magne model that is used.
Note! Do not overtighten the screws. Do not
leave out DA2 distances. This can deform the
anchor plate or Eva, causing reduced or no
holding force.
Note! Attach one tape between the fitting
and cellular rubber and one tape between the
anchor plate and cellular rubber. The tape
prevents the cellular rubber and anchor plate
from rotating.
Anchor plate
and tape
M8x20
max. 3 Nm
M4x14
max. 0.5 Nm
DA2
Cellular rubber
and tape

INSTALLATION GUIDE
REV. D 5 /5
4.
Mount anchor plate fitting on to the front edge
of the door profile.
Note! Before tightening the screws, make
sure the surfaces of Magne electromagnet and
anchor plate are completely parallel, i.e. that full
contact is obtained when the door is
closed.
5.
To see if Magne fitting needs to be adjusted,
mount a separate door stop and close the door.
Magne and anchor plate should only
be in contact
with each other when the door is in closed
position.
Note! To prevent damages on Magne, a
separate door stop must be used.
6.
To ensure that the function is working
correctly, open/close the door several times.
Adjust fittings if needed.
See complete product range and accessories on http://www.abb.com/jokabsafety
