ACME LED-RC8 User manual

1. General Instructions
 A profession remote controller with 4Ch. /8Ch. Switchable
 Can connect witch LED-CC or LED-PC300/100 to control passive LED fixtures
 9 different hold-color buttons for instant colors
 12 different color chases triggered by music
 32 different mix colors, including color fade
 Speed and dimmer adjustable by fader
 Full on and blackout functions
 Power supply: DC 9V 300 mA
 Dimension: 180X 130 X 50 mm
 Weight: 1 kg
Function Instructions:
Mode select Use to select Fixed Color / Chase 1 / Chase 2 / Spectrum mix mode
Fixed color
/ chase
1. In Fixed Color mode, use to select color on Red /Orange / Yellow / Green /
cyan / Blue / Purple / Magenta /White
2. In Chase 2 mode (the LED blinking), use to select 8 chase or random chase.
Chase 1 fader
In Chase 1 (the LED on) mode, use the fader to select color chases on
Standard chase / Bright chase / Mood chase / spectrum random chase /
Spectrum sequence chase / Dynamic chase / Red-Green+ Blue / Green-Red +
Blue / Blue-Red / Yellow-Blue / Red-Green / Yellow-Green
Spectrum Mix
fader Use to select 32 spectrum mix colors in Spectrum mix mode.
Speed fader Use to adjust chase speed in the range of 0.1 to 2.5 seconds
Fade Time
fader Use to adjust fade time. Fade time is amount of one color to fade in or fade out
Master fader Use to dimmer / shutter the fixture
Black out Blackout the fixture
Full on All lighting effect at once
Sound to
chase Use to receive audio signal for sound activated

Rear View:
Power Switch Turn On/Off the power
Channel Mode Switch Translate between 4 channels mode and 8 channels mode
DC Input DC 9V 300mA min
DMX Output Output DMX signal to the connected fixture
2. Address setting
Each fixture needs to have an address set to receive the data sent by the controller. There are 8
addresses that you can set for LED lightings.
Please follow the instructions below to set the address:
 Set LED-RC8 to 4 Ch. or 8 Ch. mode.
 Connecting all LED lightings to the LED-RC8 and power them on.
 Hold the “black out” button for about 5seconds until the LED blinking.
 The first lighting will be on.
 Set address for the LED lightings by pressing the chase 1-8 buttons.
 Press the “sound to chase” or “ full on” button to select other fixtures,
and addressing for them.
 Press the “black out” button for about 5 seconds to quit address setting.
3. How to Connect the unit
Please refer to the following diagram to connect the fixtures:
A. Connect with COLOR BALL/COLOR SPOT
B. Connect with COLOR PAR
Button address
Chase 1 1
Chase 2 2
Chase 3 3
Chase 4 4
Chase 5 5
Chase 6 6
Chase 7 7
Chase 8 8
