ACME Junior Series User manual

1A

0Introduction
Thank you for purchasing Junior Series, the unit is a powerful 100W effect lights, Plug & play
and easy to use, any where enjoys the pleasurable light show. Selector switch for 3 sets of auto,
sound activation or static function mode to dynamic emotion applications. Junior series without
any duty cycle, equip with super cooling fan built up a fantastic light show to dancing all night.
Safety with thermo switch ensures auto power disconnection when errors or defects happen.
This fixture is perfect for clubs, pubs, bars, parties, and mobile DJs.
Junior series
for
Hallucination, Fascination and Orbiter
2A

7TABLE OF CONTENTS
Introduction...…………………………………………………………………………………………….2
Safety Instruction………………………………………………………………………………………..4
Description..……………………………………………………………………………………………..5
Operation and Technical Specification..……………………………………………………………….7
Installation.……………………………………………………………………………………………….7
Exchange Lamp.………………………………………………………………………………………..8
Exchanging Rotating Gobos.………………………………………………………………………….10
Exchange Fuse.………………………………………………………………………………………..12
Troubleshooting………………………………………………………………………………………..13
Fixture Cleaning.……………………………………………………………………………………….14
3A

1Safety Instruction
Please read carefully the instruction which includes important information
WARNING about the installation, usage and maintenance.
Please keep this User Manual for future consultation.
Unpack and check carefully there is no transportation damage before using the unit.
Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
The unit is for indoor use only and only in a dry location.
Disconnect mains power before fuse/lamp replacement or servicing.
Replace fuse/lamp only with the same type.
Make sure there are no flammable materials close to the unit while operating as it is fire
hazard.
Maximum ambient temperature is TA: 40℃. Don’t operate it where the temperature is higher
than this.
Turn off the power and allow about 15 minutes for the unit to cool down before replacing bulb
or serving.
In the event of serious operating problem, stop using the unit immediately. Never try to repair
the unit by yourself. Repairs carried out by unskilled people can lead to damage or
malfunction. Please contact the nearest authorized technical assistance center. Always use
the same type spare parts.
Do not touch any wire during operation as high voltage might be causing electric shock.
4A

9Warning
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or
moisture.
Never touch bulb with bare fingers as it is very hot after using.
Hot lamp explosion hazard. Do not open the unit within five minutes after switching off.
Do not start on the unit without bulb enclosure or housing is damaged.
The housing, the lenses must be replaced if they are visibly damaged.
Do not look directly at the light while the bulb is on.
10Caution
There are no user serviceable parts inside the unit. Do not open the housing or attempt any
repairs by yourself.
11Rigging the fixtures
The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is
firmly fixed to avoid vibration and slipping while operating. Always ensure that the structure to
which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s
weight. Also always use a safety cable that can hold 12 times of the weight of the unit when
installing the fixture.
5A

Description
1. Optical lens with manual focus adjustment
2. Hanging bracket with one knob to fasten the unit
3. Power cord comet only to a matching power outlet
4. Build-in fuse
5. Lamp accessory door
6. Internal microphone
7. Cooling fan
8. Reflector mirror
9. Selector switch to select between auto, sound activation or static function
6A

2Operation and Technical Specification
•Plugging into the mains power and it will start running. The unit runs in automatic, sound
activated or static mode.
•Focus adjustable by manual.
Specification:
•Voltage: AC 120V 60Hz (US)
AC 230V /240V /250V 50Hz / 60Hz (EU)
•Fuse: 20 mm glass 120V T5A (US)
20 mm glass 250V T3.15A (EU)
•Lamp: EFP 12V 100W
•Dimension: 266 X 142 X 144 mm
•Weight: 1.7 kgs
Installation
The unit could be mounted on the wall or under ceiling. If the buyer installs the unit under
ceiling, please use a clamp (optional) to fix the unit under ceiling. Always ensures that the unit is
firmly fixed to avoid vibration and slipping while operating. Always ensures that the structure to
which you are attaching the unit is secure.
7A

3Exchange Lamp
DANGER!
In case of replacement of the lamp, do not open the lamp accessory door
within 15 minutes until the unit cools down after switching off.
LAMP: EFP 12V 100W
1.Always switch off the main supply and never handle the lamp or luminaries when is hot.
2.Do not touch the bulb with bare hands. If this happens, clean the lamp with denatured
alcohol and wipe it with a lint free cloth before installation.
3.Never operate the lamp without appropriate shielding.
4. Make sure the lamp is located in the center for the best spot.
1. Unscrew the screw from the lamp accessory door
2. Remove the cover
8A

3. Take off the lamp with carefully
4. Replace the new lamp
5. Push gently with thumb and make sure the lamp
was located on the central zone with tight for
best light effects.
6．Reverse step 2 to step 1.
9A

4Exchanging Rotating Gobos
Warning: the function for Junior-Fascination only!
DANGER!
Install the gobo when the power is off for 15 minutes only.
If you wish to use other patterns as the standard-gobo, please follow the below steps with
carefully.
1. Unscrew the screw from the lamp accessory door
2. Remove the cover and unscrew from the gobo
plate
3. Remove the gobo wheel
10A

4. Notice the front and reverse side!
5. Remove steel ring from front side then take off the
gobo
6. Exchange to new gobo and fasten with steel ring
7. CAUTION!
Please make sure the gear wheel is correct
8. Reverse step 2 to step 1
11A

5Exchange Fuse
DANGER!
In case of replacement of fuse, please awaiting 15 minutes until the unit
cools down after switching off.
1. Push and rotate with arrow by thumb
2. Remove the protect tube of fuse
3. Exchange new fuse with same model
4. Plug in the protect tube
5. Push and rotate with arrow by thumb
6. Finished
12A

Troubleshooting
Problem Feature Remedy
No power to the fixture Check power connections
Fuse please check and replace fuse if
power is on
Burned out of lamp Install new lamp
No light
Fixture too hot Allow to cool down and improve air
flow around the unit
Sound sensitivity Increase volume
No action Electrical malfunction Refer to service technician.
13A

6Fixture Cleaning
The cleaning of internal and external optical lenses or mirror must be carried out periodically
to optimize light output. Cleaning frequency depends on the environment in which the fixture
operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt
on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean external optics at least every 20 days and internal optics at least every 30/60 days.
12EC Declaration of Conformity
We declare that our products (lighting equipments) comply with the following
specification and bears CE mark in accordance with the provision of the
Electromagnetic Compatibility (EMC) Directive 89/336/EEC.
EN55014-2: 1997 A1:2001, EN61000-4-2: 1995; EN61000-4-3:2002;
EN61000-4-4: 1995; EN61000-4-5: 1995, EN61000-4-6:1996,
EN61000-4-11: 1994.
&
8Harmonized Standard
EN60598-1: 2000+ALL:2000+A12:2002
Safety of household and similar electrical appliances
Part 1 : General requirements
