DESCRIPTION
The 10 GigE Small Form-factor Pluggable Long Reach DWDM
XFP (LR-2 XFP) is a fully duplex serial electric, serial optic
device with both transmit and receive functions contained in a
single module that provides a high speed serial link at 10 Gb/s.
the LR-2 XFP operates on Optical Channel 36 (1548.51 nm).
Installed in the appropriate host module, the LR-2 XFP
provides a 10 Gigabit interface to the supporting system.
The transmit side of the LR-2 XFP converts serial NRZ electrical
data at the 10 Gb/s line rate to a standard compliant optical
signal. The receive side converts the incoming DC balanced
serial NRZ optical data at the 10 Gb/s line rate into serial
electrical data.
NOTE
To ensure compatibility, refer to the documentation provided
with the host module.
The following features are supported on the LR-2 XFP:
■1548.51 nm optical signals for up to 80 km reach
■Low power consumption (<3.5 W max)
■Bit error rate 10^–12
CAUTION
!
Due to compliance certification requirements, use only SFPs/
XFPs supplied by ADTRAN with the host module. ADTRAN
cannot certify system integrity with other SFPs.
Small Form-factor Pluggable
10 GigE LR-2 Channel 36 (1548.51 nm)
DWDM 80 km Commercial XFP
OPERATIONAL SPECIFICATIONS
■Transmit Wavelength: 1548.51 nm (Channel 36)
■Receive Wavelength: 1270 to 1600 nm
■Data Rate: 9.95 Gb/s to 11.35 Gb/s
■Optical transmit levels: –1.0 to +3.0 dBm
■Optical receive level: –22.0 to –7.0 dBm
■Minimum Span Attenuation: 10 dB
■Optical distance: 80 km maximum
■Optical connectors: LC
■Environmental Support:
♦Operational temperature range: –5°C to +70°C
♦Storage temperature range: –40°C to +85°C
♦Relative humidity to 85%, noncondensing
INSTALLATION
To install the LR-2 XFP into an appropriate module, complete the
following steps:
1. Inspect the LR-2 XFP. If damaged, file a claim with the carrier
and then contact ADTRAN Customer Support.
CAUTION
!
Do not remove the protective end cap from the XFP until the fiber
optic cable is ready to be connected.
2. Insert the LR-2 XFP into the SFP cage on the module. Ensure
that the manufacturer’s label on the SFP is facing upward for
correct installation.
3. Slide the LR-2 XFP all the way into the receptacle until there is
an audible “click”.
NOTE
The latch on the LR-2 XFP is used to remove the XFP from the cage
on the circuit card.
SAFETY AND REGULATORY COMPLIANCE
CAUTION
!
Electrostatic Discharge (ESD) can damage electronic modules.
When handling modules, wear an antistatic discharge wrist strap to
prevent damage to electronic components. Place modules in
antistatic packing material when transporting or storing. When
working on modules, always place them on an approved antistatic
mat that is electrically grounded.
The LR-2 XFP meets or exceeds all the applicable requirements of
NEBS, Telcordia GR-63-CORE, GR-1089-CORE, and ETSI EN
300368. The LR-2 XFP is intended for deployment in Central Office
type facilities, EEEs, EECs, and locations where the NEC applies (for
example, Customer Premises).
CLEI: BVL3AJ1D_ _
Product P/N: 1442982G7C
Issue Date: August 2015
Document P/N: 61442982G7C-22C

C A U T I O NC A U T I O N !
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
Warranty: ADTRAN will replace or repair this product within the warranty period if it
does not meet its published specifications or fails while in service.
Warranty information can be found online at www.adtran.com/warranty.
Trademarks: Brand names and product names included in this document are
trademarks, registered Warranty:ADTRAN will replace or repair this
product within the warranty period if it does not meet its published
specifications or fails while in service. Warranty information can be found
online at www.adtran.com/warranty.
Trademarks: Brand names and product names included in this document are
trademarks, registered trademarks, or trade names of their respective
holders.
©2015 ADTRAN, Inc. All Rights Reserved.
ADTRAN CUSTOMER CARE:
From within the U.S. 1.800.726.8663
From outside the U.S. +1 256.963.8716
*61442982G7C-22C*
The LR-2 XFP is to be installed in ADTRAN products in
Restricted Access Locations only, and installed by trained service
personnel.
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by ADTRAN
could void the user's authority to operate this equipment.
CAUTION
!
■Per GR-1089-CORE the ADTRAN system that the LR-2 XFP is
being deployed in is designed and intended for installation as
part of a Common Bonding Network (CBN). The ADTRAN
system that the LR-2 XFP is being deployed in is not designed
nor intended for installation as part of an Isolated Bonding
Network (IBN).
■Per GR-1089-CORE Section 9, the LR-2 XFP does not have an
internal DC connection between battery return and frame
ground. The LR-2 XFP can be installed in a DC-I (isolated) or
DC-C (common) installation. For installations where other
cards or the host system have internal connections between
battery return and frame ground, the system would be
intended for deployment only in a DC-C installation.
■The ADTRAN system chassis frame ground terminal must be
connected to a reliable earth ground to ensure that the metal
enclosure of the LR-2 XFP is properly grounded via the
backplane connector.
■The 10 GigE LR-2 Channel 36 (1548.51 nm) DWDM 80 km
Commercial XFP is a Class 1 Laser Product and complies with
Laser Safety requirements of FDA 21 CFR 1040.11, EN60825-1,
and EN60825-2. The LR-2 XFP is NRTL Listed and CB
Certified to all applicable American and European safety
standards.
NOTE
■The Gigabit Ethernet port(s) are optical and therefore are not
classified as any type of port as defined in Appendix B of GR-
1089-CORE Issue 5.
■This LR-2 XFP is compliant with SFF-8472 “Digital Diagnostics
Monitoring Interface for Optical Transceivers,” Revision 9.3.
■This LR-2 XFP is compliant with the XFP Multi-Source
Agreement (MSA).
■This LR-2 XFP is designed to be deployed in GR-3108-CORE
environmental class 1 or 2 as defined in GR-3108-CORE Issue
2.
The LR-2 XFP is designed to meet the following environmental
classes:
■ETSI EN 300 019-1-1 “Classification of environmental
conditions; Storage,” Class 1.2
■ETSI EN 300 019-1-2 “Classification of environmental
conditions; Transportation,” Class 2.3
■ETSI EN 300 019-1-3 “Classification of environmental
conditions; Stationary use at weather-protected locations,”
Class 3.3
The equipment is designed to function without degradation
during exposure to all test severities per Class 3.3.
The 10 GigE LR-2 Channel 36 (1548.51 nm) DWDM 80 km
Commercial XFP meets EU RoHS Directive 2011/95/EU and/or
applicable exemptions. Refer to www.adtran.com for further
information on RoHS/WEEE.
