Advantech EPD Series User manual

User Manual
EPD Device
EPD-023 System
Solution
Wireless ePaper Display Solution

EPD-023 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2019
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
ARM is trademarks of ARM Corporation.
TI is trademarks of Texas Instruments Inc..
ITE is trademarks of ITE Tech Inc..
Eink is trademarks of E ink holding Inc..
Microsoft Windows are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Part No. 2006D02300 Edition 1
August 2019

iii EPD-023 User Manual
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.

EPD-023 User Manual iv
Declaration of Conformity
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipmt.t.
This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
IMPORTANT NOTE:
FOR MOBILE DEVICE USAGE (>20cm/low power)
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncon-
trolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
FOR COUNTRY CODE SELECTION USAGE (WLAN DEVICES)
Note: The country code selection is for non-US model only and is not available to all
US model. Per FCC regulation, all Wi-Fi product marketed in US must fixed to US
operation channels only.

v EPD-023 User Manual
USER MANUAL OF THE END PRODUCT:
In the user manual of the end product, the end user has to be informed to keep at
least 20cm separation with the antenna while this end product is installed and oper-
ated. The end user has to be informed that the FCC radio-frequency exposure guide-
lines for an uncontrolled environment can be satisfied.
The end user has to also be informed that any changes or modifications not
expressly approved by the manufacturer could void the user's authority to operate
this equipment.
If the labelling area is small than the palm of the hand, then additional FCC part 15.19
statement is required to be available in the user manual: This device complies with
Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference and (2) this device must accept any inter-
ference received, including interference that may cause undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains
TX FCC ID: M82-EPD-023 ".
If the labelling area is larger than the palm of the hand, then the following FCC part
15.19 statement has to also be available on the label: This device complies with Part
15 of FCC rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NCC
低功率電波輻射性電機管理辦法
第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者
均不得擅自變更頻率、加大功率或變更原設計之特性及功能。
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有
干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指
依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學
及醫療用電波輻射性電機設備之干擾。
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

EPD-023 User Manual vi
Packing List
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table, please contact your dealer
immediately.
EPD-023 System Device
Ordering Information
Optional Accessories
Safety Instructions
1. Read these safety instructions carefully.
Part No. Description
EPD-023B2AG-NTC02 2.9" Wireless ePaper displays system solution in 2.4G
EPD-023B2AG-NTC12 EPD-023B2AG-NTC02 for 50 pcs solution kit
EPD-023B2AG-NTC22 EPD-023B2AG-NTC02 for 100 pcs solution kit
EPD-023B2AG-NTC32 EPD-023B2AG-NTC02 for 500 pcs solution kit
EPD-023B2AG-NTC42 EPD-023B2AG-NTC02 for 3000 pcs solution kit
Part No. Description
1760002692-01 4 pcs CR2450 battery

vii EPD-023 User Manual
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. Danger of explosion if battery is incorrectly replaced. Replace only with same or
equivalent type recommended by the manufacture. Discard used batteries
according to the manufacturer’s instructions.
replacement of a battery with an incorrect type that can defeat a safeguard
(for example, in the case of some lithium battery types);
disposal of a battery into fire or a hot oven, or mechanically crushing or cut-
ting of a battery, that can result in an explosion;
l leaving a battery in an extremely high temperature surrounding environment
that can result in an explosion or the leakage of flammable liquid or gas;
a battery subjected to extremely low air pressure that may result in an explo-
sion or the leakage of flammable liquid or gas.
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

EPD-023 User Manual viii
Consignes de Sécurité
1. Lisez attentivement ces instructions de sécurité.
2. Conservez ce manuel de l'utilisateur pour référence ultérieure.
3. Débranchez cet appareil de toute prise secteur avant le nettoyage Utilisez un
chiffon humide. N'utilisez pas de détergents liquides ni en spray pour le nettoy-
age
4. Pour les équipements enfichables, la prise de courant doit être située à proxim-
ité de l'équipement et doit être facilement accessible.
5. Gardez cet équipement à l'abri de l'humidité.
6. Placez cet équipement sur une surface fiable lors de son installation
7. Les ouvertures de l'enceinte sont destinées à la convection de l'air. Protégez le
matériel contre la surchauffe. NE COUVREZ PAS LES OUVERTURES.
8. Assurez-vous que la tension de la source d'alimentation est correcte avant de
connecter l'équipement à la prise de courant.
9. Placez le cordon d'alimentation de sorte que personne ne puisse marcher des-
sus. Ne placez aucun objet sur le cordon
10. Toutes les mises en garde et avertissements sur l'équipement doivent être
notés
11. Si l'équipement n'est pas utilisé pendant une longue période, débranchez-le de
la source d'alimentation pour éviter tout dommage d? à une surtension transit-
oire
12. Ne jamais verser de liquide dans une ouverture sous peine de provoquer un
incendie ou un choc électrique
13. Ne jamais ouvrir l'appareil.Pour des raisons de sécurité, cet équipement ne doit
être ouvert que par du personnel qualifié
14. Si l'une des situations suivantes se produit, faites vérifier l'équipement par le
personnel de service:
Le cordon d'alimentation ou la fiche est endommagé.
Un liquide a pénétré dans l'appareil.
L'équipement a été exposé à l'humidité.
L'équipement ne fonctionne pas bien ou vous ne pouvez pas le faire fonction-
ner conformément au manuel d'utilisation.
Equipment L'équipement est tombé et a été endommagé.
Equipment L'équipement présente des signes évidents de rupture.
AVERTISSEMENT: Cet ensemble d'instructions est donné conformément à la norme
CEI 704-1. Advantech décline toute responsabilité quant à l'exactitude des déclara-
tions contenues dans le

ix EPD-023 User Manual
Contents
Chapter 1 Product Overview................................1
1.1 Introduction ...............................................................................................2
1.2 Specifications............................................................................................2
1.3 System implementation.............................................................................3
1.3.1 Advantech EPD-023 & ePaper Manager Solution........................3
Chapter 2 EPD-023 Network Specification .........5
2.1 System Architecture..................................................................................6
Figure 2.1 EPD-023 Network Topology.......................................6
2.1.1 System Environment.....................................................................6
2.2 System Specification.................................................................................6
2.2.1 ePaper Manager...........................................................................7
2.2.2 WISE Gateway (WISE-3610Z)......................................................7
2.2.3 WISE Router (Built-in WISE-3610Z or WISE-3240) .....................7
2.2.4 EPD Device...................................................................................7
2.3 System Network Specification...................................................................8
2.4 EPD System-Initial Flow in Device side....................................................8
2.4.1 Tag Scan for Router......................................................................8
2.4.2 Registration...................................................................................9
2.4.3 Status report .................................................................................9
2.4.4 Execute actions Cmd....................................................................9
2.4.5 Firmware update...........................................................................9
2.5 White List mechanism...............................................................................9
2.6 Secure key mechanism...........................................................................10
Chapter 3 Hardware Specification.....................11
3.1 SYSTEM Specification............................................................................12
3.1.1 ID Dimension ..............................................................................12
3.1.2 Battery installation.......................................................................12
3.2 Device LED Button Behavior...................................................................14
3.2.1 EPD-023 Button behavior is as below ........................................14
3.2.2 EPD-023 LED behavior is as below............................................14
Chapter 4 EPD-023 in ePaper Manager.............15
4.1 EPD-023 with ePaper Manager Solution ................................................16
Table 4.1: ePaper manager main feature list ............................16
4.2 Preparation..............................................................................................17
4.2.1 Hardware Component List..........................................................17
4.2.2 Software Component List............................................................17
4.2.3 ePaper manager setup on ARK..................................................17
4.2.4 WISE-3610Z setup and connect to ARK with ePaper manager .33
4.2.5 EPD-023,053 setup and connect to ARK with ePaper manager 35
4.3 Hands-on the EPD Device on ePaper Manager .....................................36
4.3.1 ePaper Manager Login ...............................................................36
4.3.2 Add Group & device into ePaper Manager.................................37
4.3.3 Import Item Data to ePaper manager .........................................48
4.3.4 Design your own template ..........................................................51
4.3.5 Combine the Template and Item Data........................................53
4.3.6 EPD Controller for EPD device management.............................57

EPD-023 User Manual x
4.3.7 Final Association between EPD device, target product and product
data............................................................................................. 66
4.3.8 Smart Warehouse pick to light scenario..................................... 67
4.3.9 Clear Events and Data of MongoDB........................................... 68
4.4 Integrate EPD APIs into Your System .................................................... 76
4.5 Control EPD Data through ePaper Manager API.................................... 77
4.6 ePaper Manager Feature list .................................................................. 81
4.6.1 Component list............................................................................ 81
Chapter 5 WISE-EC EPD Design-in Service..... 97
5.1 The Acquisition of Information ................................................................ 98
5.1.1 Concept ...................................................................................... 98
5.1.2 Design......................................................................................... 99
5.1.3 Integration................................................................................. 100
5.1.4 Production................................................................................. 100
5.2 Contact Information............................................................................... 101
5.3 Global Service Policy............................................................................ 101
5.3.1 Warranty Policy......................................................................... 101
5.3.2 Repair Process......................................................................... 102

Chapter 1
1Product Overview

EPD-023 User Manual 2
1.1 Introduction
EPD-023 is the ePaper device which support ultra low power 2.4GHz RF wireless
protocol integrated with 2.9” EPD in ARM Cortex-M3 processor. The device can sup-
port hospital, pharmacy, factory, warehouse and retail application. With optimization
on the power consumption and device management, your applications with low data
rate requirement can be achieved years battery lifetime and thousand devices con-
nection. Advantech EPD-023 provide multi interface for application control which is
highly integrated with EPD driver and low power consumption system. EPD-023 can
auto join and binding the network group with IoT Gateway (WISE-3610Z) and Router
(WISE-3240). Data can be quickly and easily acquired and transformed into a differ-
ent format to communicate with ePaper Manager Server (ARK-2250L). System inte-
gration and application provider can focus on application development and system
management.
The main features of EPD-023 are:
ARM Cortex-M3 Core Processor
Support IEEE 802.15.4 / 2.4 G networks
2.9" e-Paper panel display
Great for Low Consumption, achieved years battery life time
Rich I/O control with 3 button & 3 LED
Support temperature 0 ~ 50 °C
High Performance integrated system with RTOS
Support over-the-air upgrade (OTA)
Available solution kit for various applications easy deploys.
1.2 Specifications
Computing System MCU TI 32-bit ARM Cortex-M3 Processor
Memory RAM 28KB
Display Screen Size 79 x 36.7 mm
Resolution 296 x 128 pixels
Storage Internal Flash: 128 KB
External SPI Flash: 512KB
Network
Standard IEEE 802.15.4
Frequency Band 2.4-GHz
Channels 11~26
Channel Separation 5MHz
Transmit Power -21dBm~ +5dBm
Receiver Sensitivity -100dBm
RF Data Rate 250 Kbps
Function End node
Antenna On-board Antenna
Interface LED x3
Function Key x3
Power Battery CR2450 x4

3 EPD-023 User Manual
Chapter 1 Product Overview
1.3 System implementation
EPD device can be apply to different application and system integrator can control
the RESTful API to build up different scenario
1.3.1 Advantech EPD-023 & ePaper Manager Solution
Wireless EPD System consists of ePaper Manager, Gateway, Router and EPD
device.
The ePaper manager on ARK2250L provide Web GUI to management the wire-
less EPD system.
The Gateway (WISE-3610Z) are responsible for communication between ePa-
per manager and EPD device.
The Router (built-in WISE-3610Z) can extend wireless range of Gateway.
The EPD device is a device with ePaper, EPD controller and wireless connectiv-
ity.
Advantech provide the total solution for development to select the different architec-
ture according to the end customer’s system requirement.
From below system architecture, EPD-023 is at the end node of the system. Devel-
oper can apply Advantech WISE-3610Z /3240 to connect to ePaper manager which
installed in Advantech Embedded Computer /ARK2250L. There are multi-function
RESTful API open on ePaper Manager for developer to integration with vertical mar-
ket application. E.g. Retail, smart warehouse, factory, hospital and transportation.
Environment
Operational
Temperature B/W: 0 ~ 50 °C
Non-Operational
Temp. -25 ~ 60 °C
Operating
Humidity 5 ~ 80% Relative Humidity, non-condensing
Physical Characteris-
tics Dimensions 100 x 47 x17.9 mm
Weight 80g
Operating System RTOS
Note! The image for EPD need to follow below instruction.
1. Image need to set as 296 x 128 pixels, do not resize it after com-
plete the image which will cause toothing border
2. 24 bits / BMP format for EPD-023
3. Black: (0,0,0) / White (255, 255, 255)

EPD-023 User Manual 4

Chapter 2
2EPD-023 Network
Specification

EPD-023 User Manual 6
2.1 System Architecture
Figure 2.1 EPD-023 Network Topology
2.1.1 System Environment
2.2 System Specification
1. One Single network can be built by WISE-3610Z or WISE-3240.
2. One WISE-3610Z can support up to 400 EPD devices in one channel.
3. One WISE-3240 can support up to 400 EPD devices in one channel.
4. Support 11 channels in this system.
5. Support up to 10000 EPD devices in one system by 25 pcs routers.
6. System support white list to join the system from ePaper manager.
7. Support changeable encrypted key
No Device1 OS Version
1 ARK 2250L/ePaper manager WIN7, WIN10 (2019,Q3) 64 bit, V1.0.0
2 WISE Gateway: 3610Z OpenWRT V1.0.0
4 WISE Router: WISE3240 OpenWRT V1.0.0
6 EPD Device CC2650 TI RTOS V1.0.0

7 EPD-023 User Manual
Chapter 2 EPD-023 Network Specification
2.2.1 ePaper Manager
GUI to operate the system, EPD device and gateway.
Through RESTFul API, the external system can operate the whole system as
below list:
1.ePaper manager can perform WISE Gateway actions and control WISE Gate-
way.
2.ePaper manager can perform WISE Router actions and control WISE Router.
3.ePaper manager can perform EPD device actions and control EPD series
device.
4.ePaper manager can import EPD device list which can be the white list to join
the network.
5.ePapaer manager can deliver the image/Firmware to EPD device through
WISE Gateway.
6.Device can periodical report status back to ePaper manager.
2.2.2 WISE Gateway (WISE-3610Z)
1) Support MQTT broker Server.
2) Execute EPD-Gateway actions from ePaper manager.
3) Wireless control router and EPD device.
2.2.3 WISE Router (Built-in WISE-3610Z or WISE-3240)
Transfer command to control EPD device.
Wireless control EPD device.
2.2.4 EPD Device
Device can join router when the corespondent LQI value can be detected and
qualified.
Support router re-scan: if EPD device keep join fail after 2 mins and EPD device
will start look for new router.
Support report status every 1 mins after device join network.
Support sending data request every 20 secs after device join network.
Support emergency and event status report very 1 mins after join network
–Battery status report
–Hardware mal-funciton report for panel error and external-flash error
–exception handling: image CRC failing
Tag power consumption: Battery CR2450 x 4 pcs
–1)Use EPD-023 to transfer image from gateway to EPD device in 25 degree
environment and the battery life time is for 35000 times image flash.
Support multi-image storage.
–Full size image: EPD-023: 20 pages in total. The first 3 pages is mapping to
the 3 buttons. (refer to #3.2) Rest 17 pages can be controlled from ePaper
manager directly, if application would like have different user scenario.
–Support de-compression in tag side.
Support to execute device actions from router.

EPD-023 User Manual 8
2.3 System Network Specification
Physical transmission data rate 250 Kbps
Network join performance
a.1 pcs EPD device join network in 6 secs.
b.400 pcs EPD device join network in 30 minutes by 1 host WISE-1840 on
WISE-3610Z
Data transfer Performance from Gateway
–Update 400pcs EPD-023 in 1 hours
–2 way communication
–Communication with encrypted AES128
2.4 EPD System-Initial Flow in Device side
This section will explain how the end device to join, register and communicate with
the gateway and router. User may know and understand what performance can be
reach in our specification. Indeed, user may change some parameter to fit their user
scenario.
2.4.1 Tag Scan for Router
Initial scan: EPD device scan each available channel. If EPD device still can’t
find the router after 2 mins, it will change the status to “lost connect”.
Reconfirm scan: The EPD device will start scan channel to look for another
router every 2 mins. If EPD device still can’t find the router after 5 times, it will
change Scan channel frequency from 2, 4, 8, 16, 32, 64, 64, 64, 64……mins.
And then the device will move to deep sleep mode after scanning for 5 days.
Stop scan and deep sleep: If EPD device still can’t find the router finally, it will
stop RF Scanning and back to deep sleep until the button of the Tag has been
pressed. Then tag will start the scanning from the beginning.
Note! The performance will be adjusted according the environmental limita-
tion.
IniƟal Scan 1-ReconĮƌm
scan
2-ReconĮƌm
scan Stop scanning

9 EPD-023 User Manual
Chapter 2 EPD-023 Network Specification
2.4.2 Registration
Router
–Router Power on
–System get cache file and set GW cmd
–Router connect to gateway
EPD Device
–Default setting for shipping: Support 11 channel.
–Power on auto check if there is router exist and ask to join the network.
–Router permit join if the EPD device is in the white list
–EPD device join the network
2.4.3 Status report
Router (WISE-3610Z or WIS-3240) will report status every 1 mins
EPD device will report status every 1 mins
2.4.4 Execute actions Cmd
Router will receive action command from gateway in real-time .
EPD device send data request every 20 secs from sleep mode to router to
check if there is any action command.
EPD device will send back the ACK turn result if the action command is exe-
cuted.
2.4.5 Firmware update
WISE-1840 network control card in Router will receive FW upgrade command
from router in real-time and execute automatically. System will reboot after FW
upgrade complete.
EPD device send data request every 20 secs from sleep mode to router to
check if there is any action command. EPD device receive FW upgrade com-
mand if there is FW upgrade action. After upgrade, EPD device will re-register
network.
2.5 White List mechanism
Before import white list, user need to setup router channel which can provide optimal
performance. User can setup the channel from ePaper manager and the router chan-
nel is from channel: 11 13 14 15 20 21 22 23 24 25 26. If channel has not been set,
all the router will be set in the default channel 15.
(1). When user receive all goods, it comes with the EPD device list which is white list.
User need to import the list from ePaper manager.
(2).ePaper manager can dispatch the list to the connected system daemon in Gate-
way.
(3) EPD device can auto join the network after the white list properly setup in ePaper
manager and Gateway.
Note! Normally, deployed people need to detect what channel of 2.4G wi-fi
has been used in the application field. we need to avoid to use the same
channel distribution.

EPD-023 User Manual 10
2.6 Secure key mechanism
Advantech EPD-023 provides user to change secure key when data exchange
between devices. User can setup the new secure key from ePaper manager and the
gateway will start pass the new key to connected device. As long as the key has
been changed, the device could not been operated in original system which has the
different secure key in setting.
Data communication is encrypted by AES128
User can defined 128 bit secure key
Gateway exchange key devices automatically
