Advantech FPM-212 Series User manual

User Manual
FPM-212/215/217
Series
12" XGA/ 15" XGA/ 17" SXGA
Industrial Monitor with
Resistive Touch Screen,
VGA, DP, or HDMI Display Port,
and 12 V DC input
顯示器
申請商：研華股份有限公司
地址：台北市內湖區瑞光路 26 巷 20 弄
1 號
電話：[phone]

FPM-200 Series User Manual ii
限用物質含有情況標示聲明書
Declaration of the Presence Condition of the Restricted Substances Marking
設備名稱：顯示器
Equipment name
型號 （型式）：FPM-212
Type designation (Type)
單元
Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl
ethers (PBDE)
電路板 － ○ ○ ○ ○ ○
液晶面板 － ○ ○ ○ ○ ○
內外殼
( 外殼、內部框架
…等)
○ ○ ○ ○ ○ ○
其它固定組件
( 螺絲、夾具、卡
榫 )
－ ○ ○ ○ ○ ○
線材 － ○ ○ ○ ○ ○
觸控模組 － ○ ○ ○ ○ ○
電源供應器 － ○ ○ ○ ○ ○
備考 1.“ 超出 0.1 wt %” 及 “ 超出 0.01 wt %” 係指限用物質之百分比含量超出百分比含
量基準值。
Note 1:“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the
percentage content of the restricted substance exceeds the reference percentage
value of presence condition.
備考 2.“ ○ ” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2:“ ○ ” indicates that the percentage content of the restricted substance
does not exceed the percentage of reference value of presence.
備考 3.“ － ” 係指該項限用物質為排除項目。
Note 3:The “-” indicates that the restricted substance corresponds to the
exemption.

iii FPM-200 Series User Manual
限用物質含有情況標示聲明書
Declaration of the Presence Condition of the Restricted Substances Marking
設備名稱：顯示器
Equipment name
型號 （型式）：FPM-215
Type designation (Type)
單元
Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl
ethers (PBDE)
電路板 － ○ ○ ○ ○ ○
液晶面板 － ○ ○ ○ ○ ○
內外殼
( 外殼、內部框架
…等)
○ ○ ○ ○ ○ ○
其它固定組件
( 螺絲、夾具、卡
榫 )
－ ○ ○ ○ ○ ○
線材 － ○ ○ ○ ○ ○
觸控模組 － ○ ○ ○ ○ ○
電源供應器 － ○ ○ ○ ○ ○
備考 1.“ 超出 0.1 wt %” 及 “ 超出 0.01 wt %” 係指限用物質之百分比含量超出百分比含
量基準值。
Note 1:“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the
percentage content of the restricted substance exceeds the reference percentage
value of presence condition.
備考 2.“ ○ ” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2:“ ○ ” indicates that the percentage content of the restricted substance
does not exceed the percentage of reference value of presence.
備考 3.“ － ” 係指該項限用物質為排除項目。
Note 3:The “-” indicates that the restricted substance corresponds to the
exemption.

FPM-200 Series User Manual iv
限用物質含有情況標示聲明書
Declaration of the Presence Condition of the Restricted Substances Marking
設備名稱：顯示器
Equipment name
型號 （型式）：FPM-217
Type designation (Type)
單元
Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl
ethers (PBDE)
電路板 － ○ ○ ○ ○ ○
液晶面板 － ○ ○ ○ ○ ○
內外殼
( 外殼、內部框架
…等)
○ ○ ○ ○ ○ ○
其它固定組件
( 螺絲、夾具、卡
榫 )
－ ○ ○ ○ ○ ○
線材 － ○ ○ ○ ○ ○
觸控模組 － ○ ○ ○ ○ ○
電源供應器 － ○ ○ ○ ○ ○
備考 1.“ 超出 0.1 wt %” 及 “ 超出 0.01 wt %” 係指限用物質之百分比含量超出百分比含
量基準值。
Note 1:“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the
percentage content of the restricted substance exceeds the reference percentage
value of presence condition.
備考 2.“ ○ ” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2:“ ○ ” indicates that the percentage content of the restricted substance
does not exceed the percentage of reference value of presence.
備考 3.“ － ” 係指該項限用物質為排除項目。
Note 3:The “-” indicates that the restricted substance corresponds to the
exemption.

v FPM-200 Series User Manual
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgments
Intel® and Pentium® are trademarks of Intel® Corporation.
Microsoft Windows® is a registered trademark of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
This manual details information on the following products:
FPM-212-R8AE
FPM-212
FPM212R8A2001-T, FPM212R8A2002-T, FPM212R8A2003-T,
FPM212R8A2004-T, FPM212R8A2005-T, FPM212R8A2006-T,
FPM212R8A2101-T, FPM212R8A2102-T, FPM212R8A2103-T,
FPM212R8A2104-T, FPM212R8A2105-T, FPM212R8A2106-T,
FPM212R8A2201-T, FPM212R8A2202-T, FPM212R8A2203-T,
FPM212R8A2204-T, FPM212R8A2205-T, FPM212R8A2206-T,
FPM212R8A2301-T, FPM212R8A2302-T, FPM212R8A2303-T,
FPM212R8A2304-T, FPM212R8A2305-T, FPM212R8A2306-T,
FPM212R8A2401-T, FPM212R8A2402-T, FPM212R8A2403-T,
FPM212R8A2404-T, FPM212R8A2405-T, FPM212R8A2406-T,
FPM212R8A2501-T, FPM212R8A2502-T, FPM212R8A2503-T,
FPM212R8A2504-T, FPM212R8A2505-T, FPM212R8A2506-T,
FPM212R8A2601-T, FPM212R8A2602-T, FPM212R8A2603-T,
FPM212R8A2604-T, FPM212R8A2605-T, FPM212R8A2606-T
FPM-215-R8AE
FPM-215
FPM215R8A2001-T, FPM215R8A2002-T, FPM215R8A2003-T,
FPM215R8A2004-T, FPM215R8A2005-T, FPM215R8A2006-T,
FPM215R8A2101-T, FPM215R8A2102-T, FPM215R8A2103-T,
FPM215R8A2104-T, FPM215R8A2105-T, FPM215R8A2106-T,
FPM215R8A2201-T, FPM215R8A2202-T, FPM215R8A2203-T,
FPM215R8A2204-T, FPM215R8A2205-T, FPM215R8A2206-T,
FPM215R8A2301-T, FPM215R8A2302-T, FPM215R8A2303-T,
Part No. 2003021200 Edition 1
Printed in China September 2020

FPM-200 Series User Manual vi
FPM215R8A2304-T, FPM215R8A2305-T, FPM215R8A2306-T,
FPM215R8A2401-T, FPM215R8A2402-T, FPM215R8A2403-T,
FPM215R8A2404-T, FPM215R8A2405-T, FPM215R8A2406-T,
FPM215R8A2501-T, FPM215R8A2502-T, FPM215R8A2503-T,
FPM215R8A2504-T, FPM215R8A2505-T, FPM215R8A2506-T,
FPM215R8A2601-T, FPM215R8A2602-T, FPM215R8A2603-T,
FPM215R8A2604-T, FPM215R8A2605-T, FPM215R8A2606-T
FPM-217-R8AE
FPM-217
FPM217R8A2001-T, FPM217R8A2002-T, FPM217R8A2003-T,
FPM217R8A2004-T, FPM217R8A2005-T, FPM217R8A2006-T,
FPM217R8A2101-T, FPM217R8A2102-T, FPM217R8A2103-T,
FPM217R8A2104-T, FPM217R8A2105-T, FPM217R8A2106-T,
FPM217R8A2201-T, FPM217R8A2202-T, FPM217R8A2203-T,
FPM217R8A2204-T, FPM217R8A2205-T, FPM217R8A2206-T,
FPM217R8A2301-T, FPM217R8A2302-T, FPM217R8A2303-T,
FPM217R8A2304-T, FPM217R8A2305-T, FPM217R8A2306-T,
FPM217R8A2401-T, FPM217R8A2402-T, FPM217R8A2403-T,
FPM217R8A2404-T, FPM217R8A2405-T, FPM217R8A2406-T,
FPM217R8A2501-T, FPM217R8A2502-T, FPM217R8A2503-T,
FPM217R8A2504-T, FPM217R8A2505-T, FPM217R8A2506-T,
FPM217R8A2601-T, FPM217R8A2602-T, FPM217R8A2603-T,
FPM217R8A2604-T, FPM217R8A2605-T, FPM217R8A2606-T

vii FPM-200 Series User Manual
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.

FPM-200 Series User Manual viii
Declaration of Conformity
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

ix FPM-200 Series User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE DROPS BELOW 0 °C (32 °F) OR ABOVE 50 °C
(122 °F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. The sound pressure level at the operator's position according to IEC 704-1:1982
is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.
By means of a power cord connected to a socket-outlet with a grounded connection.
Note! This product is intended to be supplied by an UL certified power supply
or DC
source suitable for use at minimum Tma 50 °C (122 °F) whose
output meets SELV or
ES1, LPS or PS2 and is rated 12Vdc, 4A min., if
users need further assistance they should contact
Advantech for further
information.

FPM-200 Series User Manual x
Warning! Using an exclusively DC current for the solution may cause radio inter-
ference. Users choosing this option must adapt accordingly and take
adequate precautions.
Warning! If the user needs to use a power adapter, please use the one listed on
the product datasheet. If the user chooses a power adapter not listed on
the product datasheet, it may cause the radio interference. In these
cases, the customer should take adequate precautions.
Warning! Avoid exposing FPM-200 to direct sunlight for long periods of time.
Exposing the LCD screen to direct sunlight can cause it to become very
hot and cause physical damage. LCD components are not designed to
tolerate high heat. High heats can shorten LCD lifespans.
Warning! The wire of the protective bonding conductor should be green-and-yel-
low, 22 AWG / 0.3 (mm2) min.

xi FPM-200 Series User Manual
Consignes de Sécurité
1. Lire attentivement les instructions de sécurité
2. Conserver ce manuel pour utilisation ultérieure
3. Débranchez cet équipement de toute prise secteur avant de le nettoyer. Utilisez
seulement un chiffon humide. N'utilisez pas de détergent liquide ou pulvérisé
pour le nettoyage.
4. Gardez cet équipement à l'abri de l'humidité.
5. Placez cet équipement sur une surface fiable pendant l'installation. Le faire ou
bien le laisser tomber peut causer des dégâts.
6. Les ouvertures sur l'enceinte servent à la convection de l'air. Protégez l'équipe-
ment contre la surchauffe. NE COUVREZ PAS LES OUVERTURES.
7. Assurez-vous que la tension de la source d'alimentation est correcte avant de
connecter l'équipement à l'alimentation.
8. Placez le câble d'alimentation de manière à ce que personne ne puisse marcher
dessus. Ne placez rien sur le câble d'alimentation.
9. Toutes les mises en garde et tous les avertissements sur l'équipement doivent
être notés.
10. Si l'équipement n'est pas utilisé pendant une longue période, débranchez-le de
la source d'alimentation pour éviter tout endommagement dû à une surtension
transitoire.
11. Ne jamais verser de liquide dans une ouverture. Cela pourrait provoquer un
incendie ou un choc électrique.
12. N'ouvrez jamais l'équipement. Pour des raisons de sécurité, l'équipement doit
être ouvert uniquement par du personnel qualifié.
13. Si l'une des situations suivantes se présente, faites vérifier l'équipement par le
personnel de service:
Un liquide a pénétré dans l'équipement.
L'équipement a été exposé à l'humidité.
L'équipement ne fonctionne pas bien, ou vous ne pouvez pas le faire fonction-
ner selon le manuel de l'utilisateur.
L'équipement est tombé et endommagé.
L'équipement présente des signes évidents de rupture.
14. NE LAISSEZ PAS CET ÉQUIPEMENT DANS UN ENVIRONNEMENT OU LA
TEMPÉRATURE DE STOCKAGE PEUT ÊTRE INFÉRIEURE À 0 ° C (32 ° F)
OU BIEN SUPÉRIEURE À 50 ° C (122 ° F). CECI POURRAIT ENDOMMAGER
L'EQUIPEMENT. L'ÉQUIPEMENT DEVRAIT ÊTRE DANS UN ENVIRONNE-
MENT CONTRÔLÉ.
15. ATTENTION: DANGER D'EXPLOSION SI LA BATTERIE EST INCORRECTE-
MENT REMPLACÉE. REMPLACER SEULEMENT AVEC LE MÊME TYPE OU
ÉQUIVALENT RECOMMANDÉ PAR LE FABRICANT, JETER LES BATTERIES
USÉES SELON LES INSTRUCTIONS DU FABRICANT. VEUILLEZ CON-
TACTER LE FABRICANT, ADVANTECH, POUR LE REMPLACER.
16. Le personnel concerné doit savoir qu'il ne faut pas heurter la section d'angle de
l'appareil afin d'éviter tout risque de blessure.
Remarque! Ce produit est destiné à être alimenté par une source d'alimentation cer-
tifiée UL ou par une source de courant continu adaptée à une utilisation
à une température minimale de 50 degrés Celsius (Tma 50 ° C) et dont
la sortie est conforme à la norme SELV ou ES1, LPS ou PS2 et à une
tension nominale de 12Vcc, 3A min. assistance, veuillez contacter
Advantech pour plus d'informations.

FPM-200 Series User Manual xii
Attention! Si l’utilisateur client utilise exclusivement l’alimentation en courant con-
tinu pour ce produit, il peut provoquer des interférences radio, auquel
cas, le client doit prendre les mesures appropriées.
Attention! Si le client doit utiliser un adaptateur secteur, veuillez utiliser l’adapta-
teur secteur figurant sur la fiche technique du produit. Si le client utilise
un adaptateur secteur non répertorié dans la fiche technique du produit,
il peut provoquer des interférences radio, auquel cas il doit prendre les
mesures appropriée.
Attention! Évitez d'exposer le FPM-200 à la lumière directe du soleil pendant de
longues périodes. Les rayons directs du soleil sur un écran LCD peu-
vent devenir très chauds et endommager physiquement l’écran car les
composants ne sont pas conçus pour tolérer une chaleur intense, ce qui
raccourcit la durée de vie de l’écran.
Attention! MISE EN GUARD : le fil du conducteur de protection doit ? tre verte et
jaune, 22 AWG / 0.3 (mm2) min.

xiii FPM-200 Series User Manual
安全指示
1. 請仔細閱讀此安全操作說明。
2. 請妥善保存此用戶手冊供日後參考。
3. 用濕抹布清洗設備前，請確認拔除電源線。請勿使用液體或去污噴霧劑清洗設備。
4. 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。
5. 請勿在潮濕環境中試用設備。
6. 請在安裝前確保設備放置在可靠的平面上，意外摔落可能會導致設備損壞。
7. 設備機殼的開孔適用於空氣對，從而防止設備過熱。請勿覆蓋開孔。
8. 當您連接設備到電源插座前，請確認電源插座的電壓符合要求。
9. 請將電源線佈置在人們不易絆倒的位置，請勿在電源線上覆蓋任何雜物。
10. 請注意設備上所有的警告標示。
11. 如果長時間不使用設備，請拔除與電源插座的連結，避免設備被超標的電壓波動損
壞。
12. 請勿讓任何液體流入通風口，以免引起火灾或短路。
13. 請勿自行打開設備。為了確保您的安全，請透過經認證的工程師來打開設備。
14. 如遇下列情况，請由專業人員維修：
電源線或插頭損壞；
設備內部有液體流入；
設備曾暴露在過度潮濕環境中使用；
設備無法正常工作，或您無法透過用戶手冊來正常工作；
設備摔落或損壞；
設備有明顯外觀損；
15. 請勿將設備放置在超出建議溫度範圍的環境，即不要低於 0℃ （32 ℉）或高於 50
℃ （122 ℉），否則可能會造成設備損壞。
16. 注意：若電池更換不正確，將有爆炸危險。因此，只可以使用製造商推薦的同一種或
者同等型號的電池進行替換。請按照製造商的指示處理舊電池。
17. 根據 IEC 704-1:1982 規定，操作員所在位置音量不可高於 70 分貝。
18. 限制區域：請勿將設備安裝於限制區域使用。
19. 免責聲明：請安全訓示符合 IEC 704-1 要求。研華公司對其內容之準確性不承擔任何
法律責任。
注！ 此项提供其它额外信息。

FPM-200 Series User Manual xiv
警告使用者：
1. 使用過度恐傷害視力
2. 使用 30 分鐘請休息 10 分鐘
3. 未滿 2 歲幼兒不看螢幕，2 歲以上每天看螢幕不要超過 1 小時
4. [ 甲類警語 ]
警告使用者：此為甲類資訊技術設備，於居住環境中使用時， 可能會造成
射頻擾動，在此種情況下，使用者會被要求採取某些適當的對策。
警告！ 如果客戶自行為本產品用戶直流電源可能會造成無線電干擾，在這種情
況下，客戶必須採取適當的措施
警告！ 如果客戶需要使用電源適配器，請使用產品數據表中列出的電源適配
器。 如果客戶使用產品數據表中未列出的電源適配器，可能會造成無線
電干擾，在這種情況下，客戶必須採取適當的措施
警告！ 請避免將 FPM-200 長時間暴露在直射陽光下。 直射陽光照射到 LCD 屏幕
上會導致 LCD 變得非常熱並對 LCD 造成物理損壞，因為這些組件的設計
不能承受高溫，從而縮短了 LCD 的使用壽命
警告！ 保護連接線的導線應為綠色和黃色 , 22 AWG / 0.3 (mm2)min

xv FPM-200 Series User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications............................................................................................ 2
1.2.1 General ......................................................................................... 2
1.2.2 Touchscreen (Optional) ................................................................ 2
1.3 LCD Specification...................................................................................... 3
1.4 Connectors................................................................................................ 3
1.5 Interface .................................................................................................... 4
Figure 1.1 FPM-200 - I/O Port Arrangement ............................... 4
1.6 Dimensions ............................................................................................... 4
1.6.1 12” Model...................................................................................... 4
Figure 1.2 FPM-212 Dimensions................................................. 4
1.6.2 15” Model...................................................................................... 5
Figure 1.3 FPM-215 Dimensions................................................. 5
1.6.3 17” Model...................................................................................... 5
Figure 1.4 FPM-217 Dimensions................................................. 5
Chapter 2 Mounting Methods...............................7
2.1 Mounting the Monitor / Monter le Moniteur ............................................... 8
2.1.1 Panel Mounting / Montage Sur Panneau...................................... 8
Figure 2.1 Panel Mounting........................................................... 8
2.1.2 Wall Mounting / Montage mural .................................................... 9
Figure 2.2 Wall Mounting............................................................. 9
2.1.3 Desktop Stand Mounting / Montage du support de bureau ........ 10
Figure 2.3 Desktop Stand Mounting .......................................... 10
2.1.4 VESA Mounting / Montage VESA............................................... 11
Figure 2.4 VESA Mounting ........................................................ 11
2.1.5 Power Adapter Bracket Mounting (Optional) .............................. 12
Figure 2.5 Power Adapter Bracket Mounting............................. 12
Appendix A Touchscreen ......................................13
A.1 Introduction ............................................................................................. 14
A.2 Touchscreen Specifications (12”/15”/17”) ............................................... 14
A.2.1 Typical Optical Features ............................................................. 14
A.2.2 Electrical Specifications .............................................................. 14
A.2.3 Environment Specifications......................................................... 14
A.3 Installing Drivers for Windows OS........................................................... 14

FPM-200 Series User Manual xvi

Chapter 1
1General Information
Sections include:
 Introduction
 Specifications
 LCD Specification
 Connectors
 Dimensions

FPM-200 Series User Manual 2
1.1 Introduction
Advantech’s FPM-212/215/217 are a series of industrial-grade monitors with sleek,
simple lines, and true-flat touchscreens.
Equipped with durable resistive touch control and an IP66-rated front bezel, FPM-
212/215/217 series is designed for intuitive operation in industrial environments such
as smart factories and machine automation display applications.
1.2 Specifications
1.2.1 General
1.2.2 Touchscreen (Optional)
Specifications FPM-200 series
Construction Die-cast aluminum
Front Panel Die-cast aluminum - IP66
Video Port HDMI/VGA/DP
Mounting Panel Stand, Wall, Panel and VESA arm (75 x 75 mm/ 2.95 x 2.95 in)
FPM-212 Dimensions (W x H x D) 311 x 238 x 53 mm (12.27 x 9.37 x 2.08 in)
FPM-215 Dimensions (W x H x D) 383 x 307 x 53.2 mm (15 x 12 x 2 in)
FPM-217 Dimensions (W x H x D) 410 x 343 x 54 mm (16.1 x 13.5 x 2.12 in)
Specifications FPM-200 series
Type 5-wire analog resistive
Interface USB
Light Transmission Above 75%
OS Support Windows XP, Vista,7, 8,10,XPe and Linux

3 FPM-200 Series User Manual
Chapter 1 General Information
1.3 LCD Specification
1.4 Connectors
The following connectors are situated on the bottom of FPM-212/215/217:
DP or HDMI port
DP or HDMI port are connected with a standard DP or HDMI connector through
unit I/O port located on the bottom side of the system.
VGA Port (DB-15)
DB-15 connector can be connected to the system via the external 15-pin DB-15
connector located on the bottom side of the system.
Touchscreen Connector (USB)
This connector will be present only if the touchscreen is installed. It must be
connected to the PC’s USB port. A touchscreen cable is included with all orders.
DC 12 V Power Input Connector
This connector must be connected to 12 Vdc power supply.
Specifications 12” LCD
(LED Backlight)
15” LCD
(LED Backlight)
17” LCD
(LED Backlight)
Display Type XGA TFT LCD XGA TFT LCD SXGA TFT LCD
Display Size 12” 15” 17”
Max. Colors 16.2M Max 16.2M Max 16.7M Max
Resolution 1024 x 768 1024 x 768 1280 x 1024
View Angle (H/V°) 178°(V), 178°(H) 176°(V), 176°(H) 170°(V), 170°(H)
Luminance 600 cd/m2300 cd/m2250 cd/m2
Storage Temperature -20 ~ 60 °C(-4 ~ 140
°F)
-20 ~ 60 °C (-4 ~
140 °F)
-20 ~ 60 °C(-4 ~
140 °F)
Operating Temperature 0 ~ 50 °C (32 ~ 122
°F)
0 ~ 50 °C (32 ~ 122
°F)
0 ~ 50 °C (32 ~ 122
°F)
Contrast Ratio 1000:1 2000:1 1000:1
Backlight Life 50,000 hr 50,000 hr 30,000 hr
Warning! Please note before connecting the monitor and PC with a HDMI / DP or
VGA cable:
1. If the PC has an installed operation system, please confirm its por-
trait frequency within an acceptable range.
2. If the PC has an installed operation system, users need to adjust
the portrait frequency within an acceptable range.

FPM-200 Series User Manual 4
1.5 Interface
The I/O port arrangement is demonstrated below:
Figure 1.1 FPM-200 - I/O Port Arrangement
1.6 Dimensions
1.6.1 12” Model
FPM-212-R8AE Dimensions
Figure 1.2 FPM-212 Dimensions
VESA Mount
DC Jack 12VDC
HDMI Port VGA Port
Display Port Touch Screen(USB)
GND
Panel Mount
238
150
180
180
7
27
53
150
75
75
