Advantech FPM-2120G Series User manual

User Manual
FPM-2120G/2150G/
2170G Series
12"SVGA/15" XGA/17" SXGA
Industrial LED Monitor with
Resistive Touchscreen, VGA
Display Port and DC12 V Input

FPM-2120G/2150G/2170G Series User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2013
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows® are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
This manual includes the following products:
FPM-2120G Series
FPM-2150G Series
FPM-2170G Series
Part No. 2003212010 Edition 1
Printed in China January 2013

iii FPM-2120G/2150G/2170G Series User Manual
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.

FPM-2120G/2150G/2170G Series User Manual iv
Declaration of Conformity
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

v FPM-2120G/2150G/2170G Series User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to the
user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. The sound pressure level at theoperator's position according to IEC 704-1:1982
is no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

FPM-2120G/2150G/2170G Series User Manual vi
NOTE
Warning
If the customer user DC power by oneself for this product may cause
the radio interference in which case, the customer must be to take
adequate measures.
Warning
If the customer needs to use power adapter, please use the power
adapter listed on the product datasheet. If the customer use the power
adapter not listed on the product datasheet, it may cause the radio
interference in which case, the customer must be to take adequate
measures

vii FPM-2120G/2150G/2170G Series User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ...............................................................................................2
1.2 Specifications............................................................................................2
1.2.1 General.........................................................................................2
1.2.2 Touchscreen (Optional) ................................................................2
1.3 LCD Specification......................................................................................3
1.4 Connectors................................................................................................3
1.5 Dimensions ...............................................................................................4
Figure 1.1 FPM-2120G Dimensions............................................4
Figure 1.2 FPM-2150G Dimensions............................................5
Figure 1.3 FPM-2170G Dimensions............................................6
Appendix A Touchscreen ........................................7
A.1 Introduction ...............................................................................................8
A.2 Touchscreen Specifications (12”/15”/17”) .................................................8
A.2.1 Typical Optical Features ...............................................................8
A.2.2 Electrical Specifications................................................................8
A.2.3 Environment Specifications...........................................................8
A.3 Installing Driver for Windows OS ..............................................................8
Appendix B OSD Operation Keypad.......................9
B.1 OSD Board Overview..............................................................................10
B.1.1 OSD Button Description..............................................................10
Table B.1: OSD Button Description ...........................................10
B.1.2 LED Function..............................................................................10
Table B.2: LED Function............................................................10

FPM-2120G/2150G/2170G Series User Manual viii

Chapter 1
1General Information
Sections include:
Introduction
Specifications
LCD Specification
Power Consumption
Connectors
Dimensions

FPM-2120G/2150G/2170G Series User Manual 2
1.1 Introduction
Advantech's FPM-2120G/2150G/2170G is a 12"/15”/17” color TFT LED flat panel
monitor built specifically for industrial applications. With the optional touchscreen,
FPM-2120G/2150G/2170G is an excellent and user-friendly system control interface.
In addition to its usual application as an LED panel monitor,FPM-2120G/2150G/
2170G comes standard with direct VGA control signal inputs, making it compatible
with Industrial PCs and Workstations. Its OSD (On Screen Display) function allows
you to adjust display factors such as brightness, contrast, colors and VGA signal
information. Functions that are more and more critical as HMI users become aware
of the benefits of flat panel monitors. The whole chassis is of stainless steel, and the
front panel is of aluminum with NEMA4/IP65 compliance.
FPM-2120G/2150G/2170G also comes in a touch screen version (FPM-2120G-R/
FPM-2150G-R/FPM-2170G-R). With an 5-wire resistive type touchscreen, this
monitor can be immediately transformed into a remote control system. The
Advantech FPM-2120G/2150G/2170G is the ultimate HMI solution for your industrial
application.
1.2 Specifications
1.2.1 General
1.2.2 Touchscreen (Optional)
Specifications FPM-2120G FPM-2150G FPM-2170G
Construction Heavy-duty aluminum and steel chassis
Front panel Aluminum, NEMA4 / IP65 Compliant
Control OSD (On Screen Display) control pad on rear panel
Mounting Panel, wall, desktop, VESA ARM or rack
Dimensions
(W x H x D)
311 mm x 237 mm x
40.63 mm (12.24'' x
9.33'' x 1.60'')
383 mm x 307 mm x
48.13 mm (15.08'' x
12.09'' x 1.89'')
413.72 mm x 347.22
mm x 52.13 mm (16.29''
x 13.67 x 2.05'')
Weight 4 kg (8.81 lbs) 6 kg (13.22 lbs) 8 kg (17.63 lbs)
Specifications FPM-2120G FPM-2150G FPM-2170G
Type 5 wire, analog resistive
Resolution 2048*2048
Light
Transmission 80%
Controller USB & RS-232 interface

3 FPM-2120G/2150G/2170G Series User Manual
Chapter 1 General Information
1.3 LCD Specification
1.4 Connectors
The following connectors are situated on the bottom side of the FPM-2120G/2150G/
2170G series:
VGA Port (DB-15)
This DB-15 connector can be connected to the system via the external 15-pin
DB-15 connector located on the left side of the system unit.
RS-232 Touchscreen Connector (DB-9) (FPM-2120G/2150G/2170G-R)
This connector will be present only if a touchscreen is installed. It must be con-
nected to the RS-232 port of the PC. The touchscreen cable is included with all
orders which include the touchscreen option.
Touchscreen Connector (USB)
This connector will be present only if a touchscreen is installed. It must be con-
nected to the USB port of the PC. The touchscreen cable is included with all
orders.
DC 12 V Power Input Connector
This connector must be connected to DC 12 V power switch.
Specifications 12” LCD
(LED Backlight) 15” LCD (LED Backlight) 17” LCD (LED Backlight)
Display Type SVGA TFT LCD XGA TFT LCD SXGA TFT LCD
Display Size 12” 15” 17”
Max. Colors 16.2 M 16.7 M 16.7 M
Max. Resolution 800 x 600 1280 x 1024 1280 x 1024
View Angle
(H/V°) 160°(V), 140°(H) 160°(V), 140°(H) 170°(V), 160°(H)
Luminance 450 cd/m2400 cd/m2350 cd/m2
Storage
Temperature -30 ~ 85°C -30 ~ 80°C -30 ~ 85°C
Operating
Temperature -30 ~ 85°C -40 ~ 85°C -30 ~ 85°C
Contrast Ratio 700:1 (Typical) 700:1 (Typical) 1000:1 (Typical)
Lamp Life Time
(MTBF) 50,000 hrs. 50,000 hrs. 50,000 hrs.
Warning! Please note before connect the monitor and PC with VGA cable:
1. If PC has installed operation system, please confirm its portrait fre-
quency is within the acceptable range.
2. If PC has installed operation system, users need to adjust the por-
trait frequency to be within the acceptable range.

FPM-2120G/2150G/2170G Series User Manual 4
1.5 Dimensions
Figure 1.1 FPM-2120G Dimensions
 
 
 
 
   
 
 
 
 
 
   
 
 
 
 
 
Panel Cut-out Dimensions: 303.3x229.3mm (11.94"x9.03")
Unit:mm

5 FPM-2120G/2150G/2170G Series User Manual
Chapter 1 General Information
Figure 1.2 FPM-2150G Dimensions
Unit: mm
Panel Cut-out Dimensions: 374.6 x 298.6 mm (14.75" x 11.75")
372.60 [14.67]
4.50 [0.18]
18.50 [0.73]
48.13 [1.89]
15.00 [0.59]
214.10 [8.43]
75.00 [2.95]
100.00 [3.94]
121.70 [4.79]
75.00 [2.95]
100.00 [3.94]
130.00 [5.12]
296.60 [11.68]
308.26 [12.14] 270.59 [10.65] 383.00 [15.08]
307.00 [12.09]

FPM-2120G/2150G/2170G Series User Manual 6
Figure 1.3 FPM-2170G Dimensions
 
 
 
     
 
 
 
 
 
 
 
   
 
 
 
Panel Cut-out Dimensions: 400.92x334.42mm (15.78"x13.17")
Unit:mm

Appendix A
ATouchscreen

FPM-2120G/2150G/2170G Series User Manual 8
A.1 Introduction
The FPM-2120G/2150G/2170G Series touchscreen uses advanced 5-wire resistive
technology. It provides more accurate sensing capacity than other technologies. The
touchscreen is specially designed for tough industrial environments, and has been
approved to FCC Class A standards.
A.2 Touchscreen Specifications (12”/15”/17”)
A.2.1 Typical Optical Features
A.2.2 Electrical Specifications
A.2.3 Environment Specifications
A.3 Installing Driver for Windows OS
The touchscreen has drivers for Win 2000/2003/Vista. You should read the
instructions in CD-ROM Disk carefully before you attempt installation. The FPM-
2120G/2150G/2170G-R series need to install Penmount 6000 driver. Please find
Penmount 6000 folder and install the driver into your system.
Specification 12” 15” 17”
Light Transmission > 80%
Haze < 13%
Specification 12” 15” 17”
Operation Voltage 5.5 V or below
Contact Current 70 mA (Maximum)
规格 12” 15” 17”
工作温度 -10 ~ +60°C
储存温度 -40 ~ +80°C
湿度 ≥ 20°C, humidity < 80% RH
<20°C, humidity < 90% RH, Non-condensing
Note! The driver manual are examples only. You must follow the flow chart
instructions and pay attention to the instructions which then appear on
your screen.
Note! If there is any other OS driver need, you could download at the web
site: http://www.penmount.com.tw (Penmount 6000)

Appendix B
BOSD Operation
Keypad

FPM-2120G/2150G/2170G Series User Manual 10
B.1 OSD Board Overview
The OSD keypad, including six keys and a two color indicator, is designed as the
OSD operation interface.
B.1.1 OSD Button Description
B.1.2 LED Function
Auto Adjustment
Select/
Decrease
Increase
rightness
Exit
Brightnss
Power LED
ignal
Confirm
Table B.1: OSD Button Description
Power Turn the monitor power ON or OFF.
Exit Exit menu.
Increase Brightness Increase the monitor backlight brightness.
Decrease Brightness Decrease the monitor backlight brightness.
Select/Confirm Enter/confirm the selected option.
Auto Adjustment Automatically adjust the monitor brightness.
Table B.2: LED Function
ON Green
StandBy/OFF Green Blinking
No Signals Orange

11 FPM-2120G/2150G/2170G Series User Manual
Appendix B OSD Operation Keypad

www.advantech.com
Please verify specifications before quoting. This guide is intended for reference
purposes only.
All product specifications are subject to change without notice.
No part of this publication may be reproduced in any form or by any means,
electronic, photocopying, recording or otherwise, without prior written permis-
sion of the publisher.
All brand and product names are trademarks or registered trademarks of their
respective companies.
© Advantech Co., Ltd. 2013
