Advantech FPM-3190G Series User manual

i
FPM-3190G
Industrial Flat Panel Monitor
with 19” TFT LCD Display
User Manual

FPM-3190G User Manual ii
Copyright
This document is copyrighted by Advantech Co., Ltd. 2005. All rights are
reserved. Advantech Co., Ltd. reserves the right to make improvements to
the products described in this manual at any time. Specifications are thus
subject to change without notice.
No part of this manual may be reproduced, copied, translated, or transmit-
ted in any form or by any means without the prior written permission of
Advantech Co., Ltd. Information provided in this manual is intended to
be accurate and reliable. However, Advantech Co., Ltd., assumes no
responsibility for its use, nor for any infringements upon the rights of
third parties which may result from its use.
All brand and product names mentioned herein are trademarks or regis-
tered trademarks of their respective holders.
This Manual Covers the Following Models:
• FPM-3190G-XBE Industrial 19" SXGA Flat Panel Monitor with
Direct-VGA Port, DVI, Video, S-Video
• FPM-3190G-RBE FPM-3190G-XBE with resistive touchscreen
(RS-232 interface)
• FPM-3190G-UBE FPM-3190G-XBE with resistive touchscreen
(USB interface)
Part No. 2003319003 4th Edition
Printed in Taiwan July 2006

iii
Product Warranty (1 year)
Advantech warrants to you, the original purchaser, that each of its prod-
ucts will be free from defects in materials and workmanship for one year
from the date of purchase.
This warranty does not apply to any products which have been repaired or
altered by persons other than repair personnel authorized by Advantech,
or which have been subject to misuse, abuse, accident or improper instal-
lation. Advantech assumes no liability under the terms of this warranty as
a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous test-
ing, most of our customers never need to use our repair service. If an
Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will
be billed according to the cost of replacement materials, service time and
freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware
and software used, etc.) Note anything abnormal and list any
onscreen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your man-
ual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows
us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for war-
ranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

FPM-3190G User Manual iv
FCC Class B
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interfer-
ence when the equipment is operated in a residential environment. This
equipment generates, uses and can radiate radio frequency energy. If not
installed and used in accordance with this user's manual, it may cause
harmful interference to radio communications. Note that even when this
equipment is installed and used in accordance with this user’s manual,
there is still no guarantee that interference will not occur. If this equip-
ment is believed to be causing harmful interference to radio or television
reception, this can be determined by turning the equipment on and off. If
the interference is occurring, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment to a power outlet on a circuit different from
that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Additional Information and Assistance
1. Visit the Advantech web site at www.advantech.com where you can
find the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer
service center for technical support if you need additional assistance.
Please have the following information ready before you call:
• Product name and serial number
• Description of your peripheral attachments
• Description of your software (OS, version, application software, etc.)
• A complete description of the problem
• The exact wording of any error messages

v
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User's Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or let-
ting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power
source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to
the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW
-20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY DAMAGE THE
EQUIPMENT.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70dB(A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advan-
tech disclaims all responsibility for the accuracy of any statements contained
herein.

FPM-3190G User Manual vi

vii Table of Contents
Contents
Chapter 1 Introduction ......................................................2
1.1 Introduction ....................................................................... 2
1.2 Specifications .................................................................... 3
1.3 LCD Specifications ........................................................... 4
1.4 Connectors......................................................................... 4
1.5 Dimensions........................................................................ 6
Figure 1.1:FPM-3190G Cutout Dimensions................... 6
Chapter 2 System Setup.....................................................8
2.1 Mounting the Monitor ....................................................... 8
2.1.1 Wall Mounting................................................................ 8
Figure 2.1:Wall Mounting .............................................. 8
2.1.2 Panel Mounting............................................................... 9
Figure 2.2:Panel Mounting ............................................. 9
2.1.3 Rack Mounting ............................................................. 10
Figure 2.3:Rack Mounting............................................ 10
2.2 Desktop, Swing-ARM Mounting .................................... 11
2.2.1 Desktop Stand ............................................................... 11
Figure 2.4:Desktop Stand for the FPM-3190G series... 11
2.2.2 Swing-ARM.................................................................. 12
Figure 2.5:Swing-ARM for the FPM-3190G series ..... 12
Appendix A Touchscreen Installation ...............................14
A.1 Introduction ..................................................................... 14
A.1.1 Resistive Type............................................................... 14
A.1.2 Capacitive Type ............................................................ 15
A.2 Resistive Touchscreen Driver Installation ...................... 17
A.2.1 Hardware....................................................................... 17
A.2.2 Software ........................................................................ 18
Appendix B Supported Input Timing Modes ..................28
B.1 Supported Input Timing Modes ...................................... 28
Appendix C OSD Operation Keypad................................30
C.1 OSD Board Overview ..................................................... 30
C.1.1 OSD Button Description............................................... 30
C.1.2 LED Function ............................................................... 30
C.2 OSD Key Functions ........................................................ 31
C.2.1 Menu Start..................................................................... 31
C.2.2 Input Source Select ....................................................... 32
C.2.3 Contrast/ Brightness Setting ......................................... 33
C.2.4 Geometry Menu – For DVI Input ................................. 34
C.2.5 Color Temperature Menu.............................................. 36

FPM-3190G Series User Manual viii
C.2.6 RGB Color Menu.......................................................... 37
C.2.7 Language Menu ............................................................ 38
C.2.8 OSD Manager ............................................................... 39
C.2.9 Auto Configuration Menu............................................. 40
C.2.10 Mode Information Menu............................................... 41
C.2.11 Memory Recall Menu ................................................... 42
C.2.12 Exit Menu ..................................................................... 43
C.2.13 Hot Keys ....................................................................... 44

CHAPTER
1
Introduction
This chapter includes:
• Introduction
• Specifications
• LCD Specification
• Connectors
• Dimensions

FPM-3190G User Manual 2
Chapter 1 Introduction
1.1 Introduction
Advantech's FPM-3190G Series is a 19" color TFT LCD flat panel moni-
tor built specifically for industrial applications. With the optional touch-
screen, the FPM-3190G Series is an excellent and user-friendly system
control interface.
In addition to its usual application as an LCD panel monitor, the FPM-
3190G comes standard with Direct-VGA interface, which connects
directly with popular PC VGA cards and also supports DVI-D, S-video
and CVBS connectors. With the FPM-3190G, Advantech is taking a more
aggressive initiative to penetrate the industrial HMI market. Its OSD (On
Screen Display) function allows you to adjust the display factors and turn
the backlight on and off for the front view, functions which become criti-
cal as more and more industrial HMI users become aware of the benefits
of flat panel monitors. The whole chassis is of stainless steel, and the
front panel is of aluminum with NEMA4/IP65 compliance. An optional
stainless steel front panel is also available.
The FPM-3190G Series has an optional resistive touchscreen. With a
resistive touchscreen, the monitor can be immediately transformed into a
remote control system.

3 Chapter1
1.2 Specifications
General
•Control: OSD (On Screen Display) control pad on front side
•Mounting: Rack/panel/wallmount, desktop, and VESA arm
•Front Panel: Aluminum, NEMA4/IP65 compliant
•I/O Ports: VGA, DC power input and RS-232/USB port
(Touchscreen version only)
•Power Adapter: External 60 W power adapter, with AC 100~240 V
input and DC +12 V @ 5 A output
•Operating Temperature: 0 ~ 50° C (32 ~ 122 ° F)
•Storage Temperature: -20 ~ 60° C (-4 ~ 140 ° F)
•Storage Humidity: 5 ~ 90% non-condensing
•Vibration (operating): Random, 5 ~ 500 Hz, 1.0 Grms
•Dimensions: (W x H x D): 482 x 399 x 66 mm (19" x 15.7" x 2.6")
•Weight: 10.65kg (23.46 lb)
•Certifications: CE, FCC, BSMI, CCC certified
Touchscreen (Optional)
•Type: resistive sensor
•Resolution: 4096*4096 for resistive model.
•Light transmission: 78% (resistive), 88%
•Operating Pressure:30~45 gram for stylus, contact bounce < 10 ms
•Controller: RS-232 (for -R or -C model) or USB (for -U model)
•Power Consumption: +5 V @ 260 mA
•OS Support: Windows 2000/XP
•Life Span: Resistive: 35 million activations (typical) at single point
with a 5/8" diameter silicone finger at 350g load at 2 touches per sec.
Capacitive: 225 million activations (typical) at a single point with a
5/8" diameter silicone finger at 350g load at 2 touches per sec.

FPM-3190G User Manual 4
1.3 LCD Specifications
•Display type: SXGA TFT LCD
•Display size: 19"
•Max colors: Full color (16.7 million)
•Max resolution: 1280 x 1024
•Dot pitch: 0.294 x 0.294 mm
•Viewing Angle: 178° (H), 178° (V)
•Luminance: 300 cd/m2
•Storage Temperature: -20 ~ 60° C (-4 ~ 140 ° F)
•Operating Temperature: 0 ~ 50° C (32 ° ~ 122 ° F)
•Backlight Lifetime: 50,000 hrs
•Contrast Ratio: 1000:1
1.4 Connectors
The following connectors are situated on the left hand side of the
FPM-3190 Series:
VGA Port
(DB-15) This DB-15 connector can be connected to the system via the
external 15-pin DB-15 connector thru the I/O from this unit.
(DVI) Connected with a standard DVI connector thru I/O port of this
unit. Only supports digital signals
(S-Video) Connected with a standard S-Video connector with 4-pins thru
I/O port of this unit
(Video) Connected with a standard video connector of analog. It supports
NTSC and PAL_B/G/I/H mode.

5 Chapter1
Touchscreen Connector (RS-232) (Optional)
This connector will be present only if a touchscreen is installed. It must
be connected to the RS-232 port of the PC. The touchscreen cable is
included with all orders which include the RS-232 touchscreen option.
Touchscreen Connector (USB) (Optional)
This connector will be present only if a touchscreen is installed. It must
be connected to the USB port of the PC. The touchscreen cable is
included with all orders which include the USB touchscreen option.
DC 12V Power in
This connector will be connected to a DC 12V Switching Power Supply.

FPM-3190G User Manual 6
1.5 Dimensions
Figure 1.1: FPM-3190G Cutout Dimensions
444 x 376 mm (17.48" x 14.84")

CHAPTER
2
System Setup
This chapter includes:
• Mounting the Monitor
- Wall/Panel/Rack Mounting
- Desktop Stand/Swing-ARM Mounting

FPM-3190G User Manual 8
Chapter 2 System Setup
2.1 Mounting the Monitor
The FPM-3190G Series can be placed as you require. The versatility of
the FPM-3190G mounts enable it to be mounted on your desk or any-
where else.
2.1.1 Wall Mounting
With wall brackets, the FPM-3190G can be mounted directly to a wall.
If you need to install the FPM-3190G in different ways, release the
mounting brackets by detaching the four screws on the rear side.
Figure 2.1: Wall Mounting

9 Chapter2
2.1.2 Panel Mounting
If you need to install the FPM-3190G series on a panel mount, please
release the mounting brackets by detaching four screws on rear side and
fix them on up and bottom side by screws.
Figure 2.2: Panel Mounting
(Cutout Dimensions: 444 x 376 mm)

FPM-3190G User Manual 10
2.1.3 Rack Mounting
FPM-3190G series products could be directly mount to the industrial
standard 19" rack. There are four screw holes on each side of the panel.
Figure 2.3: Rack Mounting

11 Chapter2
2.2 Desktop,Swing-ARMMounting
The FPM-3190G Series can be mounted in other ways. You can place the
desktop stand for desktop use or attach it on a swing-arm bracket.
2.2.1 Desktop Stand
The desktop stand brackets are attached to the rear of FPM-3190G.
First loosen the screw in point C. Then unscrew the screw in point A. Pull
down the bracket and use the screw from point A to fasten the bracket in
point B. There should be no screws in point A and point D. Only point B
and C.
Figure 2.4: Desktop Stand for the FPM-3190G series
A
B
CD

FPM-3190G User Manual 12
2.2.2 Swing-ARM
Detach the mounting brackets on the rear side, then attach the FPM-
3190G series onto the Swing-ARM mount (75mm or 100mm square
bracket).
Figure 2.5: Swing-ARM for the FPM-3190G series
