AEMC MN261 User manual

AC CURRENT
OSCILLOSCOPE PROBE MN261
ENGLISH User Manual
OUTPUT:
20 A Range : 100 mV/AAC
200 A Range : 10 mV/A AC
200 A
20 A
MN 261
AC CURRENT PROBE
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
certifies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
An NIST traceable certificate may be
requested at the time of purchase, or obtained
by returning the instrument to our repair and
calibration facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer.
Serial #: ________________________________
Catalog #: 2115.82
Model #: MN261
Please fill in the appropriate date as indicated:
Date Received: _________________________________
Date Calibration Due: _______________________
Chauvin Arnoux®, Inc.
d.b.a AEMC®Instruments
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Table of Contents
1. INTRODUCTION............................................................................... 2
1.1 International Electrical Symbols................................................2
1.2 DenitionofMeasurementCategories .....................................3
1.3 ReceivingYourShipment..........................................................3
1.4 OrderingInformation.................................................................3
1.4.1 AccessoriesandReplacementParts............................3
2. PRODUCT FEATURES ...................................................................... 4
2.1 Description................................................................................4
2.2 Compatibility .............................................................................4
2.3 ControlFeatures .......................................................................5
3. SPECIFICATIONS............................................................................. 6
3.1 ElectricalSpecications ............................................................6
3.2 MechanicalSpecications ........................................................7
3.3 EnvironmentalSpecications....................................................7
3.4 SafetySpecications ................................................................7
3.5 TypicalResponseCurves .........................................................8
4. OPERATION .................................................................................. 10
4.1 CurrentMeasurement.............................................................10
5. MAINTENANCE ............................................................................. 11
5.1 Maintenance ...........................................................................11
5.2 Cleaning.................................................................................. 11
Limited Warranty ...................................................................................13
WarrantyRepairs...................................................................................13
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

2 ACCurrentOscilloscopeProbeModelMN261
CHAPTER 1
INTRODUCTION
WARNING
Thesesafetywarningsareprovidedtoensurethesafetyofperson-
nelandproperoperationoftheinstrument.
• Connect the probe to the oscilloscope or voltage measuring
instrumentbeforeclampingtheprobearoundaconductor.
• Neverusetheprobeoncircuitsratedhigherthan600V,CatIII.
• Neverleavetheprobeclampedaroundaconductorwhilenot
connectedtoanoscilloscopeorvoltagemeasuringinstrument.
• Carefullycentertheconductorinsidetheprobejawsandascer-
tainthattheprobeisperpendiculartotheconductor.
• Avoid,ifpossible,theproximityofotherconductorswhichmay
create noise.
• Checkthemagneticmatingsurfacesoftheprobejaws;these
shouldbefreeofdirt,rust,orotherforeignmatter.
• Donotuseaprobewhichiscracked,damaged,orhasdefec-
tive leads.
1.1 International Electrical Symbols
Thissymbol signiesthat the instrument is protectedby doubleor
reinforced insulation. Use only specied replacement parts when
servicingtheinstrument.
Thissymbolon the instrumentindicatesa WARNINGandthat the
operatormustrefertotheusermanualforinstructionsbeforeoperat-
ingtheinstrument.Inthismanual,thesymbolprecedinginstructions
indicatesthatiftheinstructionsarenotfollowed,bodilyinjury,instal-
lation/sampleandproductdamagemayresult.
Risk of electric shock. The voltage at the parts marked with this
symbolmaybedangerous.
ThisisatypeAcurrentsensor.Thissymbolsigniesthatapplication
aroundandremovalfromHAZARDOUSLIVEconductorsispermitted.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

ACCurrentOscilloscopeProbeModelMN261 3
1.2 Definition of Measurement Categories
Cat. I: Formeasurementsoncircuits notdirectlyconnectedto theAC
supply wall outlet such as protected secondaries, signal level,
andlimitedenergycircuits.
Cat. II: For measurements performed on circuits directly connected to
the electrical distribution system. Examples are measurements
onhouseholdappliancesorportabletools.
Cat. III: For measurements performed in the building installation at
the distribution level such as on hardwired equipment in xed
installationandcircuitbreakers.
Cat. IV: For measurements performed at the primary electrical supply
(<1000V) such as on primary overcurrent protection devices,
ripplecontrolunits,ormeters.
1.3 Receiving Your Shipment
Uponreceivingyourshipment,makesurethatthecontentsareconsistent
withthepackinglist.Notifyyourdistributorofanymissingitems.Iftheequip-
mentappearstobedamaged,leaclaimimmediatelywiththecarrierand
notifyyourdistributoratonce,givingadetaileddescriptionofanydamage.
Savethedamagedpackingcontainertosubstantiateyourclaim.
1.4 Ordering Information
ACCurrentOscilloscopeProbeModelMN261 ................... Cat. #2115.82
1.4.1 Accessories and Replacement Parts
MaleBanana-FemaleBNCAdaptor(XF-SS) .................... Cat. #2111.32
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

4 ACCurrentOscilloscopeProbeModelMN261
CHAPTER 2
PRODUCT FEATURES
2.1 Description
TheACCurrentOscilloscopeProbeModelMN261expandsoscilloscope
applicationsinindustrialorpowerenvironments,andisidealforanalysis
andmeasurementofdistortedcurrentwaveformsandharmonics.
TheModelMN261permitsaccuratedisplayandmeasurementofcurrents
from0.1to240Arms,40Hzto10kHz(withcurrentderating)withoutbreak-
ingintothecircuit.Apassiveltereliminatesnoise,ringonrapidrising(di/
dt)waveforms,andensuresaccuratescreendisplays.
Theprobeconnectsdirectlytoanoscilloscopethroughaninsulatedcoax-
ialcablewithaninsulatedBNC.
2.2 Compatibility
TheModelMN261iscompatiblewithanyanalogordigitaloscilloscopeor
othervoltage-measuringinstrumentwhichhasthefollowingfeatures:
• BNCinputconnector
• Rangecapableofdisplaying0.2to0.5Vperdivision,or2Vrange
• Minimuminputimpedanceof1MΩ
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

ACCurrentOscilloscopeProbeModelMN261 5
2.3 Control Features
2.56" (65 mm)
5.31" (135 mm)
.83" (21 mm)
.73"
2.01" (51 mm)
(18.5 mm)
.1.18" (30 mm)
1
2
3
4
5
1. JawOpening:0.83"(21mm)
2. Maximumdimensionofconductor:0.78"(20mm)
3. Twopositionswitch
4. 6.5ft(2m)outputcable
5. Arrow indicates direction of current ow. Current ows in a positive
directionwhenittravelsfromsupplytoload.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

6 ACCurrentOscilloscopeProbeModelMN261
CHAPTER 3
SPECIFICATIONS
3.1 Electrical Specifications
*Referenceconditions:23°C±3°K,20to75%RH,48to65Hz,externalmagneticeld
<40A/m,noDCcomponent,noexternalcurrentcarryingconductor,testsamplecentered.
Current Range: 0.1 to 24Arms
0.5 to 240Arms
Output Signal:mVoutputsignal; 2rangeswitchselectableonhandle
100mV/A: 0.1 to 24Arms
10mV/A: 0.5 to 240Arms
Load Impedance: ≥1MΩ@ ≤100pF
Range:10mV/A(2Vat200A)
PrimaryCurrent 0.5 to 10A 10 to 40A 40 to 100A 100 to 240A
Accuracy ≤3.5%±5mV ≤3%±5mV ≤2.5%±5mV ≤1.5%±5mV
PhaseShift N/A ≤6° ≤4° ≤3°
Overload: 240Afor10mnON,30mnOFF
Range:100mV/A(2Vat20A)
Overload: 120Acontinuous
Accuracy:2%±50mV
Phase Shift: notspecied
Frequency Range (with current derating):40Hzto10kHz(@-3dB)
SeeTypicalResponseCurves(§3.5)
Load Impedance: 100kΩmin
Working Voltage:600VCat.III
Common Mode Voltage:600VCat.III
Inuence of Adjacent Conductor: <15mA/AAC@50Hz
Inuence of Conductor Position in Jaw Opening:
0.5%ofReading@50/60Hz
Inuence of Frequency:
Range20A: 40Hzto1kHz:10%ofmVoutput
 1to10kHz:15%ofmVoutput
Range200A: 40Hzto1kHz:3%ofmVoutput
 1to10kHz:12%ofmVoutput
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

ACCurrentOscilloscopeProbeModelMN261 7
3.2 Mechanical Specifications
Dimensions:5.47x2.00x1.18"(139x51x30mm)
Weight:6.5oz(150g)
Maximum Cable Diameter:0.78"(20mm)
Jaw Opening:0.83"(21mm)max
Maximum Conductor Size:0.78"(20mm)
Envelope Protection:IP40(IEC529)
Drop Test:1m(IEC68-2-32)
Mechanical Shock:100g(IEC68-2-27)
Vibration:10/55/10Hz@0.15mm(IEC68-2-6)
Output:6ft(2m)insulatedleadwithinsulatedBNCConnector
3.3 Environmental Specifications
Operating Temperature/RH:14°to131°F(-10°to55°C);RH<85%
Storage Temperature:-40°to158°F(-40to70°C)
Inuence of Temperature: ≤0.15%/10K
Inuence of Humidity:10to90%;0.2%
Altitude: ≤2000m
3.4 Safety Specifications
Indoor Use
Electrical:
Doubleinsulationorreinforcedinsulationbetweentheprimaryorsecond-
aryandtheoutercaseofthehandleperEN61010-2-032.
Common Mode Voltage:600V,CategoryIII,PollutionDegree:2
Dielectric Strength: 5550V, 50/60Hz between primary, secondary, and
theoutercaseofthehandle
Electromagnetic Compatibility:
EN 50081-1 Class B
EN50082-2Electrostaticdischarge
IEC 1000-4-2
RadiatedeldIEC1000-4-3
Fast transients IEC 1000-4-4
Magneticeldat50/60HzIEC1000-4-8
*Specications are subject to change without notice
E192383
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

8 ACCurrentOscilloscopeProbeModelMN261
3.5 Typical Response Curves
10mV/A Range
-10.00
-8.00
-6.00
-4.00
-2.00
0.00
2.00
10.00 100.00 1000.00 10000.00 100000.00
-15.00
-20.00
-25.00
-10.00
-5.00
0.00
5.00
10.00
15.00
10.00 100.00 1000.00 10000.00 100000.00
Accuracy vs. Frequency
Phase Shift vs. Frequency
Frequency in Hz
Frequency in Hz
Accuracy in %Phase in °
100 A
200 A
100 A
200 A
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

ACCurrentOscilloscopeProbeModelMN261 9
100mV/A Range
10.00
-25.00
-30.00
-15.00
-5.00
-20.00
-10.00
0.00
5.00
100.00 1000.00 10000.00 100000.00
10.00
-20.00
-40.00
-30.00
-10.00
0.00
10.00
20.00
30.00
40.00
100.00 1000.00 10000.00 100000.00
Accuracy vs. Frequency
Phase Shift vs. Frequency
Frequency in Hz
Frequency in Hz
Accuracy in %Phase in °
10 A
20 A
10 A
20 A
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

10 ACCurrentOscilloscopeProbeModelMN261
CHAPTER 4
OPERATION
4.1 Current Measurement
WARNING: Always connect the probe to the instrument before
clampingontothecircuitundertest.
• ConnecttheModelMN261totheproperinputchannelonthe
oscilloscope.
• Beginwiththeleastsensitiverangeonthecurrentprobe(10mV/A).
• Selectthe0.5V/Divisionrangeontheoscilloscope.
• Clamptheprobeontheconductortobemeasuredandreadthe
currentowingdirectlyonyouroscilloscope.
(Remember to unclamp the probe from the conductor before disconnect-
ing it from your meter or instrument.)
You may also use your oscilloscope to amplify the signal while using
the1mV/Aproberange(whichoffersthebestaccuracyandleastphase
shift).
NOTE: Itispossibletochangetherangeonthecurrentprobewith-
outremovingtheprobefromthecurrentcarryingconductor,butitis
importanttoremembernottoexceedthepermissiblepeakratings
of340mVpeakor680mVpeaktopeakmaximum.Thepeakratings
byrangeare:34Apeak@100mV/Aand340Apeak@10mV/A.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

ACCurrentOscilloscopeProbeModelMN261 11
CHAPTER 5
MAINTENANCE
5.1 Maintenance
WARNING
• Toensureoptimumperformance,itisimportanttokeeptheprobe
jawmatingsurfacescleanatalltimes.Failuretodosomayresult
inerrorinreadings.
• Formaintenanceuseonlyspeciedfactoryreplacementparts.
• Toavoidelectricalshock,donotattempttoperformanyservicing
unlessyouarequaliedtodoso.
• Toavoidelectricalshockand/ordamagetotheinstrument,donot
allowwaterorotherforeignsubstancesintothecase.
• Disconnecttheunitfromallcircuitsandtestcablesbeforeopen-
ingthecase.
• Usecautionwithmetallictoolsthatmayshortbatterypacks,power
supplies,etc.
5.2 Cleaning
• Tocleantheprobebody,useasoftclothdampenedinasolution
ofmilddetergentandwater.Tocleanthecore,openthejawand
cleantheexposedcoresurfaceswithacottonswabdampened
withisopropylalcoholorethylalcohol.Lubricatethejawsmating
surfaceswithalightoil.
• Do not use chemicals containing benzine, benzene, toluene,
xylene,acetone,orsimilarsolvents.
• Donotimmersetheprobeinliquidsoruseabrasivecleaners.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

ACCurrentOscilloscopeProbeModelMN261 13
Limited Warranty
TheModelMN261iswarrantedtotheownerforaperiodofoneyearfromthe
dateoforiginalpurchaseagainstdefectsinmanufacture.Thislimitedwarranty
isgivenbyAEMC®Instruments,notbythedistributorfromwhomitwaspur-
chased.Thiswarrantyisvoidiftheunithasbeentamperedwith,abusedorif
thedefectisrelatedtoservicenotperformedbyAEMC®Instruments.
Full warranty coverage and product registration is available on our
website at www.aemc.com/warranty.html.
Please print the online Warranty Coverage Information for your records.
What AEMC®Instruments will do:
Ifamalfunctionoccurswithintheone-yearperiod,youmayreturntheinstrument
tousforrepair,providedwehaveyourwarrantyregistrationinformationonle
oraproofofpurchase.AEMC®Instrumentswill,atitsoption,repairorreplace
thefaultymaterial.
Warranty Repairs
What you must do to return an Instrument for Warranty Repair:
First, request a Customer ServiceAuthorization Number (CSA#) by phone
orbyfaxfromourServiceDepartment(seeaddressbelow),thenreturnthe
instrumentalongwiththesignedCSAForm. Please writetheCSA#onthe
outsideoftheshippingcontainer.Returntheinstrument,postageorshipment
pre-paidto:
Ship To: ChauvinArnoux®,Inc.d.b.a.AEMC®Instruments
 15FaradayDrive•Dover,NH03820USA
 Phone:(800)945-2362(Ext.360)
  (603)749-6434(Ext.360)
 Fax: (603)742-2346or(603)749-6309
 E-mail:[email protected]
Caution:Toprotectyourselfagainstin-transitloss,werecommendyouinsure
yourreturnedmaterial.
NOTE: You must obtain a CSA# before returning any instrument.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

08/13
99-MAN100144v6
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664
