AEMC 6417 User manual

nCLAMP-ON GROUND
RESISTANCE TESTER 6417
ENGLISH User Manual
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
certifies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
An NIST traceable certificate may be
requested at the time of purchase, or obtained
by returning the instrument to our repair and
calibration facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer.
Serial #: ________________________________
Catalog #: 2141.02
Model #: 6417
Please fill in the appropriate date as indicated:
Date Received: _________________________________
Date Calibration Due: _______________________
Chauvin Arnoux®, Inc.
d.b.a AEMC®Instruments
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Clamp-on Ground Resistance Tester Model 6417 1
(1) Clamp-on Ground Tester
Model 6417
Cat. #2141.02
5WCalibration Loop
Cat. #2141.51
Bluetooth Adapter
Cat. #2126.45
Hard Accessory Case
Cat. #2141.50
Quick Start Guide
USB Stick with
DataView®Software & User Manual
PRODUCT PACKAGING
Shipping Contents:
Also Included:
(4) 1.5V AA Batteries
(1) Wrist Strap
(1) Safety Sheet (20 languages)
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

2Clamp-on Ground Resistance Tester Model 6417
Thank you for purchasing an AEMC Clamp-on Ground Resistance Tester.
For best results from your instrument and for your safety, read the enclosed
operating instructions carefully and comply with the precautions for use. These
products must be only used by qualied and trained users.
WARNING, risk of DANGER! The operator must refer to these instructions whenever
this danger symbol appears.
CAUTION! Risk of electric shock. The voltage at the parts marked with this symbol
may be dangerous.
Application or withdrawal authorized on conductors carrying dangerous voltages.
Type A current sensor as per IEC 61010-2-032.
Equipment is protected by double insulation.
The product has been declared recyclable after analysis of its life cycle in accordance
with the ISO14040 standard.
Important instructions to read and to fully understand.
Useful information or tip to read.
The CE marking guarantees conformity with European directives and with regulations
covering EMC.
The trash can with a line through it means that in the European Union, the product
must undergo selective disposal for the recycling of electric and electronic material,
in compliance with Directive WEEE 2002/96/EC.
Denition of Measurement Categories (CAT)
CAT IV Measurement Category IV corresponds to measurements taken at the
source of low-voltage installations.
Example: power feeders, counters and protection devices.
CAT III Measurement Category III corresponds to measurements on building
installations.
Example: distribution panel, circuit-breakers, machines or xed
industrial devices.
CAT II Measurement Category II corresponds to measurements taken on
circuits directly connected to low-voltage installations.
Example: power supply to domestic electrical appliances and portable
tools.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Clamp-on Ground Resistance Tester Model 6417 3
PRECAUTIONS FOR USE
This instrument and its accessories comply with safety standards EN 61010-1,
EN 61010-030, and EN 61010-2-032 for voltages of 600V in Category IV at an
altitude of less than 2000m with a pollution degree of not more than 2.
Failure to observe the safety instructions may result in electric shock, re,
explosion, and destruction of the instrument and of the installations.
■The operator and/or the responsible personnel must carefully read and clearly
understand the various precautions to be taken in use. Sound knowledge
and a keen awareness of electrical hazards are essential when using this
instrument.
■ If you use this instrument other than as specied, the protection it provides
may be compromised, thereby endangering you.
■Do not use the instrument on networks of which the voltage or category
exceeds those mentioned.
■Do not use the instrument if it seems to be damaged, incomplete, or poorly
closed.
■Before each use, check the condition of the insulation on housing. Any item
of which the insulation is deteriorated (even partially) must be set aside for
repair or scrapping.
■Use personal protection equipment systematically.
■ When handling the instrument, keep your ngers behind the physical guard.
■All troubleshooting and metrological checks must be performed by competent
and accredited personnel.
■Avoid impacts on the measurement head, in particular the air gap.
■Keep the surfaces of the air gap clean; even a little dirt can cause the clamp
to malfunction.
■All metal objects or wires connected to the electrical system should be
assumed to be lethal until tested. Grounding systems are no exception.
■Use extreme caution when using the instrument around energized electrical
equipment.
■Never attempt to use the instrument to twist or pry the ground electrode or
ground wire away from the equipment being grounded.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

4Clamp-on Ground Resistance Tester Model 6417
Table of Contents
1. INTRODUCTION .............................................................................................7
1.1 Receiving Your Shipment......................................................................7
1.2 Ordering Information.............................................................................7
1.2.1 Replacement Parts...................................................................7
2. PRODUCT FEATURES .....................................................................................8
2.1 Description............................................................................................8
2.2 Features................................................................................................9
2.3 Applications...........................................................................................9
2.4 Display................................................................................................10
2.5 Control Features.................................................................................12
2.6 Audible Signals ...................................................................................13
2.7 Rotary Switch Functions.....................................................................13
2.8 Button Functions.................................................................................14
3. PRINCIPLE OF OPERATION ..........................................................................15
4. SET-UP .......................................................................................................17
4.1 Menu Items.........................................................................................17
4.2 SET-UP Menu Displays ......................................................................17
4.3 Selecting a Specic Menu ..................................................................18
4.4 SET-UP Menus ...................................................................................18
5. OPERATION.................................................................................................22
5.1 Inserting the Batteries.........................................................................22
5.2 Setting the Date and Time ..................................................................22
5.3 Display Example.................................................................................23
5.4 Turning the Instrument ON .................................................................23
5.5 Turning Bluetooth ON .........................................................................24
5.6 Turning the Instrument OFF................................................................24
5.7 Standard and Advanced Modes..........................................................24
5.8 Memory...............................................................................................25
5.8.1 Memory Capacity....................................................................25
5.8.2 Storing Measurements into Memory.......................................25
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Clamp-on Ground Resistance Tester Model 6417 5
5.8.3 Reading Stored Data..............................................................25
5.8.4 Erasing the Memory ...............................................................25
5.8.5 Using the ▲ and ▼ Buttons ...................................................26
5.8.6 Exporting Data to a PC...........................................................26
5.9 Alarm Management.............................................................................26
5.9.1 Voltage Alarm .........................................................................26
5.9.2 Current Alarm .........................................................................27
5.9.3 Impedance Alarm...................................................................27
5.9.4 No Alarm Detection.................................................................27
5.9.5 Priority of the Alarms ..............................................................28
6. MEASUREMENT MODES..............................................................................29
6.1 Rotary Position Ω+A...........................................................................29
6.1.1 Standard Mode.......................................................................29
6.1.2 Advanced Mode......................................................................30
6.1.3 General Information................................................................31
6.2 Rotary Position (A)..............................................................................32
6.2.1 Making a Measurement..........................................................33
6.3 Rotary Position - (MR) ........................................................................33
6.3.1 Displaying Stored Measurements...........................................33
7. DATAVIEW®SOFTWARE...............................................................................36
7.1 Installing DataView®............................................................................36
7.2 Connecting the Instrument to a Computer..........................................40
7.2.1 Bluetooth Connection .............................................................40
7.2.2 Pairing using Windows Vista / Windows 7/8/8.1/10................40
7.3 The Control Panel...............................................................................42
7.3.1 Establishing Instrument Communication ................................43
7.4 Conguring the Instrument .................................................................44
8. ANDROID APPLICATION ..............................................................................46
9. SPECIFICATIONS .........................................................................................50
9.1 Reference Conditions .........................................................................50
9.2 Electrical .............................................................................................50
9.2.1 Loop Resistance Measurement..............................................50
9.2.2 Loop Inductance Measurement..............................................51
9.2.3 Contact Voltage (Touch Voltage) ............................................51
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

6Clamp-on Ground Resistance Tester Model 6417
9.2.4 Current Measurement.............................................................51
9.2.5 Power Supply .........................................................................52
9.3 Environmental.....................................................................................52
9.4 Mechanical..........................................................................................52
9.5 Safety..................................................................................................53
10. MAINTENANCE..........................................................................................54
10.1 Cleaning............................................................................................54
10.2 Battery Replacement ........................................................................54
10.5 Limited Warranty...............................................................................56
10.6 Warranty Repairs..............................................................................56
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Clamp-on Ground Resistance Tester Model 6417 7
1. INTRODUCTION
1.1 Receiving Your Shipment
Upon receiving your shipment, make sure that the contents are consistent with
the packing list. Notify your distributor of any missing items. If the equipment
appears to be damaged, le a claim immediately with the carrier and notify
your distributor at once, giving a detailed description of any damage. Save the
damaged packing container to substantiate your claim.
1.2 Ordering Information
Clamp-on Ground Resistance Tester Model 6417 .......................Cat. #2141.02
Includes a hard carrying case, Bluetooth USB adapter, calibration loop, four 1.5V
AA batteries, quick start guide, and USB stick with DataView®software and user
manual.
1.2.1 Replacement Parts
Bluetooth USB Adapter Class 2........................................................Cat. #2126.45
Wrist Strap........................................................................................Cat. #2135.47
Hard Carrying Case..........................................................................Cat. #2141.50
5W Calibration Loop..........................................................................Cat. #2141.51
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

8Clamp-on Ground Resistance Tester Model 6417
2. PRODUCT FEATURES
2.1 Description
The Clamp-on Ground Resistance Tester Model 6417 measures grounding
electrodes and grid resistance without the use of auxiliary rods. Clamp-on ground
resistance testers can be used in multi-grounded systems without disconnecting
the ground system under test. The Model 6417 simply clamps around the
ground conductor or rod and measures the resistance to ground. By performing
measurements on intact ground systems, the user also veries the quality of the
grounding connections and bonds. Resistance and continuity of grounding loops
around pads and buildings can also be measured.
The Model 6417 includes a current measurement function. The ground tester’s
high sensitivity enables measurement of leakage current owing to ground or
circulating in ground loops from 0.2mA to 40A and resistances from 0.01 to
1500W.
Battery life information is displayed at power-up and the Auto Power OFF feature
can be enabled for power management. Additional features include the large
OLED (Organic Light Emitting Diode) display that ensures high readability of
data. The Buzzer and Auto Power OFF features can be disabled at any time.
The Model 6417 is equipped with an alarm function and a data storage function.
In the Alarm mode, the probe will audibly and visually indicate when the reading
is beyond an input set point. You can also have the alarm activate above or
below the set point. This alarm feature permits quick eld checks where only
“pass” or “fail” readings are required.
The data storage function logs up to 2000 measurements (Wand/or A). This
enables you to conduct eld surveys, and to retrieve and analyze the readings at
a later time. The alarm settings and stored data are saved on the ground tester
and remain stored even when the instrument is turned OFF. You can retrieve and
analyze the results at a later time with DataView®software or with an Android app
through the Bluetooth communication port.
Two new features unique to AEMC®are test frequency selection and touch
voltage indication.
The ability to select the test frequency provides more accurate measurements in
inductive environments.
Displaying voltage derived from current and resistance measurements provides
an extra level of safety for the user, indicating a potentially dangerous touch
condition.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]
