AFL FR1 Series User manual

OTDR Fiber Rings
Measuring an insertion loss of the near-end and/or far-end connection of a ber optic
link with an OTDR requires a launch and/or receive test cable. A launch cable, which
connects the OTDR to the link under test, reveals the insertion loss and reectance of
the near-end connection. A receive cable, which connects to the far-end of the link,
reveals the insertion loss and reectance of the far-end connection. Launch and receive
test cables can range from 150 m to 1km (or longer) in length. Because very long
test cables are impractical to transport and use, AFL offers coiled lengths of 50 µm
multimode, 62.5µm multimode, or single-mode ber packaged in compact rings.
Fiber Rings of 150 m of ber are ideal for premises ber network test applications.
Fiber Rings of 500m and 1 km of single-mode ber are designed for broadband,
long haul ber network test applications.
Fiber Ring Models
CONFIGURATION FIBER TYPE FIBER LENGTH AFL NO.
Standard, one ber Multimode, 50 µm, OM2 150 m (492 ft) FR1-M5-150- x1- x2
Standard, one ber, Laser Optimized Multimode, 50 µm, OM3 150 m (492 ft) FR1-OM3-150-x1-x2
Standard, one ber, Laser Optimized Multimode, 50 µm, OM4 150 m (492 ft) FR1-OM4-150-x1-x2
Standard, one ber Multimode, 62.5 µm 150 m (492 ft) FR1-M6-150- x1- x2
Standard, one ber Single-mode 150 m (492 ft) FR1-SM-150-y1-y2
Standard, one ber Single-mode 500 m (1640 ft) FR1-SM-500-y1-y2
Standard, one ber Single-mode 1000 m (3280 ft) FR1-SM-1000-y1-y2
Standard, one ber, Bend Insensitive Single-mode, G.657.A2 BIF 150 m (492 ft) FR1-BIF-150-y1-y2
Standard, one ber, Bend Insensitive Single-mode, G.657.A2 BIF 500 m (1640 ft) FR1-BIF-500-y1-y2
Standard, one ber, Bend Insensitive Single-mode, G.657.A2 BIF 1000 m (3280 ft) FR1-BIF-1000-y1-y2
x1, x2 — connectors for multimode cables, specify type [ST, SC, ASC (angled SC), FC, AFC (angled FC), LC]
y1, y2 — connectors for single-mode cables, specify type [ST, SC, ASC (angled SC), FC, AFC (angled FC), LC]
Other connector types, ber types, and ber lengths will be quoted upon request.
FR1-M6-150-SC-ST
FR1-SM-150-SC-SC
FR1-SM-1000-SC-ST
© 2014, AFL, all rights reserved. FR00-00-2000 Revision 1D, 2014-10-24
Specications are subject to change without notice.
1

OTDR Fiber Rings
How to Generate a Baseline Trace Using Fiber Rings
• Use the Fiber Ring as a launch cable.
Connect the Fiber Ring between your OTDR and the ber link under test. This will allow
you to measure the loss of the near-end connection.
• Use the Fiber Ring as a receive cable.
Connect the Fiber Ring to the far-end connector of your ber link under test. This will
allow you to measure the loss of the far-end connection.
• By using Fiber Rings as both launch and receive cables, as shown in the diagram below,
you can measure total insertion loss of the ber link under test.
OTDR Trace Made using Launch and Receive Cables
Example OTDR Test Conguration with Launch and Receive Cables
Fiber ring - launch cable
Fiber ring connector
OTDR port
Fiber ring - receive cable
OTDR
Fiber link under test
Near-end connection
Fusion splice
Far-end connection End of receive cable
OTDR port
Fiber ring - launch cable
Near-end connection
Fusion splice
End of receive cable
Far-end connection
Fiber link under test
Fiber ring -
receive cable
2
2
1
1
4
4
3
3
5
5
6
6
7
7
8
8
