AGFA DRYSTAR AXYS User manual

Drystar AXYS
5367/100
User Manual
2852D EN 20161128 1416

Contents
Legal Notice ..........................................................................5
About the safety notices in this document .............................. 6
Drystar AXYS .........................................................................7
Scope .........................................................................8
Intended use ..............................................................9
Available Software versions ..................................... 10
Film types ................................................................ 11
Labeling the input trays ................................11
Specifications .......................................................... 13
Disclaimer ................................................................17
Introduction ........................................................................ 18
Intended user ...........................................................19
Features ...................................................................20
Network features ......................................... 22
Options and accessories ............................... 22
Equipment Classification ......................................... 23
Safety precautions ................................................... 24
Labels .......................................................... 26
Transport after installation .......................... 29
Environmental protection ............................ 31
Restriction of the Use of Certain Hazardous
Substances (RoHS) ......................................32
For U.S.A. .................................................... 33
Security precautions ................................................ 34
Installation .............................................................. 35
Training ...................................................................36
Product Complaints ................................................. 37
Compliance ............................................................. 38
General ........................................................39
Safety .......................................................... 40
Electromagnetic Compatibility ..................... 41
Seismic (earthquake) requirements ............. 42
Connectivity ............................................................ 43
Safety compliance ........................................43
Labels ......................................................................44
Viewing the System info area on a film ........ 44
Patient data security ................................................ 46
Privacy and security .....................................47
Node authentication, certificates and Certification
Authority ..................................................... 48
Operating modes ..................................................... 49
Control modes (local and remote) ................50
Operator mode .............................................51
Key-operator mode ...................................... 52
Service mode ...............................................53
2 | Drystar AXYS | Contents
2852D EN 20161128 1416

Specialist mode ............................................54
Administrator mode .....................................55
The local user interface ............................................56
Messages ..................................................... 58
The status indicator LED .............................. 59
The control buttons ......................................60
Rear panel ....................................................61
Audio signals ............................................... 63
The keypad ..................................................64
The display .................................................. 66
Switching on the printer .......................................... 69
Cooling down the printer ......................................... 71
Switching off the printer ..........................................72
Basic Operation (operator mode) .........................................73
Managing the print queue ........................................ 74
Checking the print queue .............................75
The local print queue screen .........................76
Pausing the print queue ........................................... 77
Viewing the film count info ......................................78
Viewing the printer status ........................................79
Deleting print jobs ................................................... 80
Changing the film format of the trays .......................81
Loading films ...........................................................84
When the printer is printing or calculating and an
input tray is empty ....................................... 85
When the printer is in the ready state and an input
tray is empty ................................................ 86
Film loading procedure ................................87
Checking the correct position of a film in the input
tray ..............................................................91
Advanced Operation (key-operator mode) ...........................92
The menu structure ................................................. 93
Quality Control for general radiography applications ...
94
Establishing the reference values and verifying
image quality ...............................................95
QC test image .............................................. 96
Establishing the daily operating reference density
levels ........................................................... 98
Establishing the image geometry reference values
........................................................................101
Verifying Acceptable Spatial Resolution, Artifact
Levels and Low Contrast Visibility .............. 102
Performing quality control (QC) tests .........103
Quality Control for mammography application ...... 107
Establishing the reference values and verifying
image quality for mammography application ...
109
QC test image for mammography application ...
110
Drystar AXYS | Contents | 3
2852D EN 20161128 1416

Establishing the daily operating reference density
levels for mammography application ..........112
Establishing the image geometry reference values
for mammography application ................... 115
Verifying Acceptable Spatial Resolution, Artifact
Levels and Low Contrast Visibility for
mammography application .........................116
Performing quality control (QC) tests for
mammography application .........................117
Preventive maintenance schedule ...................................... 121
Safety guidelines ....................................................122
Recurrent safety tests .............................................122
Cleaning and disinfection ...................................... 123
Cleaning the print head ......................................... 124
Quality Control Charts .......................................................127
Charts for general radiography QC .........................128
Charts for mammography QC ................................133
Plug & Play Installation Manual ......................................... 138
Contents of the packages ....................................... 139
Remove the packing materials ................................140
Remove the printer from the pallet .........................142
Unpack the accessories ...........................................144
Environment specifications .................................... 145
Remove the transport protections .......................... 146
Connect the cables ................................................. 151
Verify film position tabs ......................................... 152
Load film in the input trays .................................... 154
Startup the printer .................................................156
Configure network settings .................................... 157
4 | Drystar AXYS | Contents
2852D EN 20161128 1416

Legal Notice
Agfa HealthCare NV, Septestraat 27, B-2640 Mortsel - Belgium
For more information on Agfa products and Agfa HealthCare products, please
visit www.agfa.com.
Agfa and the Agfa rhombus are trademarks of Agfa-Gevaert N.V., Belgium or
its affiliates. Drystar is a trademark of Agfa HealthCare N.V., Belgium or one
of its affiliates. All other trademarks are held by their respective owners and
are used in an editorial fashion with no intention of infringement.
Agfa HealthCare N.V. makes no warranties or representation, expressed or
implied, with respect to the accuracy, completeness or usefulness of the
information contained in this document and specifically disclaims warranties
of suitability for any particular purpose. Products and services may not be
available for your local area. Please contact your local sales representative for
availability information. Agfa HealthCare N.V. diligently strives to provide as
accurate information as possible, but shall not be responsible for any
typographical error. Agfa HealthCare N.V. shall under no circumstances be
liable for any damage arising from the use or inability to use any information,
apparatus, method or process disclosed in this document. Agfa HealthCare
N.V. reserves the right to make changes to this document without prior notice.
The original version of this document is in English.
Copyright 2016 Agfa HealthCare N.V
All rights reserved.
Published by Agfa HealthCare N.V.
B-2640 Mortsel - Belgium.
No part of this document may be reproduced, copied, adapted or transmitted
in any form or by any means without the written permission of Agfa
HealthCare N.V.
Drystar AXYS | Legal Notice | 5
2852D EN 20161128 1416

About the safety notices in this document
The following samples show how warnings, cautions, instructions and notes
appear in this document. The text explains their intended use.
DANGER:
A danger safety notice indicates a hazardous situation of direct,
immediate danger for a potential serious injury to a user,
engineer, patient or any other person.
WARNING:
A warning safety notice indicates a hazardous situation which
can lead to a potential serious injury to a user, engineer, patient
or any other person.
CAUTION:
A caution safety notice indicates a hazardous situation which
can lead to a potential minor injury to a user, engineer, patient
or any other person.
An instruction is a direction which, if it is not followed, can
cause damage to the equipment described in this manual or any
other equipment or goods and can cause environmental
pollution.
A prohibition is a direction which, if it is not followed, can cause
damage to the equipment described in this manual or any other
equipment or goods and can cause environmental pollution.
Note: Notes provide advice and highlight unusual points. A note is
not intended as an instruction.
6 | Drystar AXYS | About the safety notices in this document
2852D EN 20161128 1416

Drystar AXYS
Topics:
•Scope
•Intended use
•Available Software versions
•Film types
•Specifications
•Disclaimer
Drystar AXYS | Drystar AXYS | 7
2852D EN 20161128 1416

Scope
The user manual contains general safety instructions, system information and
instructions for performing a basic workflow. Refer to the reference manual of
the printer for information for the advanced operation of the printer.
Figure 1: Example of the type label
Type label
8 | Drystar AXYS | Drystar AXYS
2852D EN 20161128 1416

Intended use
The Drystar AXYS is a dry digital tabletop printer for producing medical
diagnostic images. It can print multiple formats of blue-based (8x10 inch,
10x12 inch, 11x14 inch, 14x14 inch and 14x17 inch), clear-based (8x10 inch,
10x12 inch, 11x14 inch, 14x14 inch and 14x17 inch) or Mammo film (8x10
inch, 10x12 inch, 11x14 inch) and offers crisp, dense grayscale images. The
Drystar AXYS can be used for general radiography and optionally for the
mammography application. The Drystar Axys is designed for high-throughput
and for use as a central printer.
Drystar AXYS | Drystar AXYS | 9
2852D EN 20161128 1416

Available Software versions
The table below lists the available software versions and the type of printer
they require:
Software version
(SW)
Printer
1.60 Drystar AXYS (RoHS compatible)
2.0 supports both Drystar 5302 & Drystar AXYS
2.1 and 2.2 support new PCBs on Drystar 5302 & Drystar Axys
2.3 maintenance software version
3.x supporting first Private label printer
3.1 maintenance software version
3.1.1 patch solving Dicom attribute issue
4.0 supports Drystar 5302 XL, AXYS XL & DRY 2.4
5.0 • support for single tray models Drystar 5301 and
Drystar 5301 XL
• Supports Sata Dom
• Supports Spare-Parts without E-lables
5.1 supports DRY 2.4M
10 | Drystar AXYS | Drystar AXYS
2852D EN 20161128 1416

Film types
Film type Film base Application Film sizes Average optical
density
(X-Rite 310
densitometer)
DT 2 B
DT 5000 B
DT 5000I B
DT 5 B
DT 10 B
blue-
transparent
General
Radiography
8x10”,
10x12”,
11x14”,
14x14”,
and
14x17”
3.2
DT 2 C clear-
transparent
3.0
DT 2 M
DT 5000I
MAMMO
DT 5
MAMMO
DT 10
MAMMO
blue-
transparant
Mammography 8x10”,
10x12”
and
11x14”
3.8
The printer has 2 input trays. Both trays can handle all listed film types and
formats.
When a new film pack is loaded, the Film Identification tag is read and the
printer settings are automatically adjusted.
The Key-operator can overrule the film settings for the input tray.
Labeling the input trays
Note: If you want to change the film format, the tray
configuration must be modified.
Drystar AXYS | Drystar AXYS | 11
2852D EN 20161128 1416

Appropriate labels have been applied on the input tray(s) by the service
personnel at installation of the printer, indicating the type of new film to be
loaded when the tray is empty.
12 | Drystar AXYS | Drystar AXYS
2852D EN 20161128 1416

Specifications
Product description
Type of product Printer
Commercial name Drystar AXYS
Original seller/manufacturer Agfa HealthCare N.V.
Labelling
TÜV cNRTLus-Certification Mark,
CE-marking
Dimensions
Dimensions (approx. values in
cm) • Unpacked: width 72.8, length 71.5,
height 67.6
• Packed: width 89, length 100,
height 80
Weight • Unpacked: approx. 90 kg
• Packed: approx. 128 kg
RAM memory 512 Mb
Internal mass storage media Hard disk or equivalent media
External mass storage media Compact Flash Type II
Electrical connection
Rated voltage 100-120 V; 220-240 V AC
Rated current 4.7 A (100-120 V); 2.3 A (220-240 V)
No external main fuses
Mains frequency 50-60 Hz
Network connectivity
Ethernet / connectors RJ45 twisted pair for 10/100Base-TX;
Serial RS232 connection
Network protocols (TCP/IP
services)
FTP, Telnet, HTTP
Drystar AXYS | Drystar AXYS | 13
2852D EN 20161128 1416

Image formats DICOM (Default)
TIFF
Postscript Not available
Power consumption - heat dissipation
During operation 250 W - 900 kJ/h
In stand-by 70 W - 252 kJ/h
Peak power (absolute max.
rating)
530 W - 1908 kJ/h
Protection against
Electrical shocks Class 1 (grounded)
Ingress of water IPXØ
Environmental conditions (operation)
Room temperature Between +15°C and +30°C
Relative humidity Between 20% and 75%
Note: Films may not become wet!
Atmospheric pressure 70 kPa - 106 kPa
Related altitude on site 3000 m to 0 m
Environmental storage conditions
Climate conditions for storage are in accordance with EN60721-3-1-class 1K4.
Room temperature Between -25°C and 55°C (storage)
Relative humidity Between 10% and 100%
Absolute humidity Between 0.1 g/m3 and 35 g/m3
Rate of change of temperature 1°C/min
Atmospheric pressure 70 kPa - 106 kPa
Environmental transport conditions
Climate conditions for transport are in accordance with EN60721-3-2-class
2K4.
Temperature Between -40°C and 70°C (transport)
14 | Drystar AXYS | Drystar AXYS
2852D EN 20161128 1416

Relative humidity not combined
with rapid temperature changes
95% at +45°C
Noise emission (method of measurement in accordance with DIN
45635 part 19)
During operation Max. 64 dBA
In stand-by Max. 54 dBA
Total acoustic A-weighted noise power
During operation 62 dB ( = 6.4Bel = 6.4B)
In stand-by 53 dB ( = 5.3Bel = 5.3B)
Print technology
Direct thermal printing
Reliability
Estimated product life
(if regularly serviced and
maintained according to Agfa
instructions)
> 5 years
Service interventions Max. 2 interventions / 3 years
Earthquake (standard) Meets the CA requirements
Imaging Array - Diagnostic area - General radiography
8x10” 8” dimensions 10” dimensions
pixels mm pixels mm
3852 192,6 4880 244
10x12” 10” dimensions 12” dimensions
pixels mm pixels mm
4880 244 5860 293
11x14” 11” dimensions 14” dimensions
pixels mm pixels mm
5376 268,8 6922 346,1
14x14” 14” dimensions 14” dimensions
Drystar AXYS | Drystar AXYS | 15
2852D EN 20161128 1416

pixels mm pixels mm
6882 344,1 6882 344,1
14x17” 14” dimensions 17” dimensions
pixels mm pixels mm
6922 346,1 8368 418,4
Imaging Array - Diagnostic area - Mammography
8x10” 8” dimensions 10” dimensions
pixels mm pixels mm
3828 191,4 4958 247,9
10x12” 10” dimensions 12” dimensions
pixels mm pixels mm
4892 244,6 5810 290,5
11x14” 11” dimensions 14” dimensions
pixels mm pixels mm
5376 268,8 6922 346,1
16 | Drystar AXYS | Drystar AXYS
2852D EN 20161128 1416

Disclaimer
Agfa assumes no liability for use of this document if any unauthorized
changes to the content or format have been made.
Every care has been taken to ensure the accuracy of the information in this
document. However, Agfa assumes no responsibility or liability for errors,
inaccuracies or omissions that may appear in this document. To improve
reliability, function or design Agfa reserves the right to change the product
without further notice. This manual is provided without warranty of any kind,
implied or expressed, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Note: In the United States, Federal law restricts this device to sale
by or on the order of a physician.
Drystar AXYS | Drystar AXYS | 17
2852D EN 20161128 1416

Introduction
Topics:
•Intended user
•Features
•Equipment Classification
•Safety precautions
•Security precautions
•Installation
•Training
•Product Complaints
•Compliance
•Connectivity
•Labels
•Patient data security
•Operating modes
•The local user interface
•Switching on the printer
•Cooling down the printer
•Switching off the printer
18 | Drystar AXYS | Introduction
2852D EN 20161128 1416

Intended user
This manual is written for trained users. Users are considered as the persons
who actually handle the equipment as well as the persons having authority
over the equipment. Before attempting to work with this equipment, the user
must read, understand, note and strictly observe all warnings, cautions and
safety markings on the equipment.
Drystar AXYS | Introduction | 19
2852D EN 20161128 1416

Features
Note: The printer is a DICOM-only network printer.
The printer offers the following features:
• Dry technology for printing diagnostic quality hard copies in full daylight
offers important advantages: no chemistry, no wet processing, simple
cleaning procedures, no time-consuming adjustments, no darkroom and
no chemical disposal costs. The consumables can be loaded in full
daylight.
• With its compact design, the printer needs little work space and allows
easy customer access. Maintenance and service activities are reduced to
the minimum.
• The direct thermal printing system provides grayscale images with high
quality: 508 pixels per inch resolution, each pixel with 14 bit contrast
resolution.
• Multiple film formats can be used. Any combination of two film formats
can be used “on line”. Both input trays can be adjusted for all film formats.
• The input trays are equipped with an RF-tag reader, which automatically
traces the films used in the printer and protects the printer when detecting
non-identified media.
• Number of input trays.
The printer is delivered with two input trays. The input trays can use
multiple format films.
• Number of output trays
The printer is delivered with one output tray, which is suitable for the
multiple formats without any adjustment.
• A Quality Control software module is available for the Key-operator. The
QC procedure for general radiography applications has been designed to
comply with the grayscale reproduction constancy test, according to the
international standard IEC 1223-2-4.
The QC procedure for the optional mammography application has been
designed to comply with the NEMA Standards Publication XR 23-2006.
• Integrated A#sharp technology
A#sharp is a technology that enhances image sharpness. An A#sharp label
on the lower tray shows that the imager is equipped with this technology.
20 | Drystar AXYS | Introduction
2852D EN 20161128 1416
