INSTALLATION AND
OPERATION MANUAL
Vacuum Products Division
DRAFT 10/9/14
TriScrollTM 800
Inverter Dry Scroll
Vacuum Pump
Manual No. 699904435
Revision B
October 2014

Copyright 2014
Agilent, Inc.
DRAFT 10/9/14
TriScroll™800 Inverter
Dry Scroll Vacuum Pump
TriScroll is a trademark of Agilent, Inc.

iii
TriScroll 800 Inverter Vacuum Pump
Table of Contents
Warranty ....................................................................vii
Warranty Replacement and Adjustment...............vii
Instructions for Use ..................................................... 1
General Information ................................................. 1
Storage ................................................................. 1
Unpacking and Inspection........................................ 1
Installation Requirements ......................................... 2
Safety ................................................................... 2
Mechanical Connections.......................................... 4
Pump Location ..................................................... 4
Vacuum Pump Isolation Valve.............................. 4
Pump Inlet............................................................ 4
Pump Exhaust....................................................... 4
Gas Ballast ........................................................... 4
Bearing Purge ....................................................... 4
Operation................................................................. 5
Startup Procedure ................................................. 5
Shutdown Procedure ............................................ 5
Maintenance ............................................................ 5
TriScroll 800 Inverter Pump Components View ........ 6
Technical Information ................................................. 7
Pump Electrical Controller........................................ 9
Technical Specifications ....................................... 9
Serial Interface Specification RS485 and RS232.. 10
Purge Kit ................................................................ 12
Exhaust Silencer Kit ................................................ 12
Vibration Isolation Kit............................................. 12
HEPA Inlet filter...................................................... 12
Troubleshooting ..................................................... 13
Maintenance .......................................................... 14
General Information ........................................... 14
Related TriScroll Manuals................................... 14
Maintenance and Tooling Kits ............................ 14
Factory Service Options...................................... 15
Accessories......................................................... 15
Contacting Agilent.............................................. 15
Request for Return Health and Safety Certification

TriScroll 800 Inverter Vacuum Pump
This page intentionally left blank.

v
TriScroll 800 Inverter Vacuum Pump
List of Figures
Figure Caption Page
1 TriScroll 800 Inverter Vacuum Pump . . . . . . . 6
2 Interface Drawing with Dimensions . . . . . . . 8
3 Pumping Speed Curves . . . . . . . . . . . . . . . . . 8
4 Driving Frequency vs. Analog Input . . . . . . . . 9
5 T+ Pumps List . . . . . . . . . . . . . . . . . . . . . . . 11
6 T-Unknown Pump . . . . . . . . . . . . . . . . . . . . 11
List of Tables
Table Title Page
1 Power Cord Selection . . . . . . . . . . . . . . . . . . 3
2 Circuit Breaker Requirements . . . . . . . . . . . . 3
3 Specifications . . . . . . . . . . . . . . . . . . . . . . . . 7
4 P1 I/O-1 Interlock . . . . . . . . . . . . . . . . . . . . . 9
5 J1 - Serial Port . . . . . . . . . . . . . . . . . . . . . . . 10
6 P2 I/O-2 Port on DB9 Male Connector . . . . 10
7 T-Plus Software Variables . . . . . . . . . . . . . . 10
8 Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . 11
9 Troubleshooting Chart . . . . . . . . . . . . . . . . 13
10 Other Related Manuals . . . . . . . . . . . . . . . . 14
11 Maintenance and Tooling Kits . . . . . . . . . . 14
12 Factory Service Options . . . . . . . . . . . . . . . 15
13 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . 15

TriScroll 800 Inverter Vacuum Pump
This page intentionally left blank.

vii
TriScroll 800 Inverter Vacuum Pump
Warranty
Products manufactured by Seller are warranted against
defects in materials and workmanship for twelve (12)
months from date of shipment thereof to Customer, and
Seller’s liability under valid warranty claims is limited, at
the option of Seller, to repair, to replace, or refund of an
equitable portion of the purchase price of the Product.
Items expendable in normal use are not covered by this
warranty. All warranty replacement or repair of parts shall
be limited to equipment malfunctions which, in the sole
opinion of Seller, are due or traceable to defects in
original materials or workmanship. All obligations of
Seller under this warranty shall cease in the event of
abuse, accident, alteration, misuse, or neglect of the
equipment. In-warranty repaired or replaced parts are
warranted only for the remaining unexpired portion of the
original warranty period applicable to the repaired or
replaced parts. After expiration of the applicable warranty
period, Customer shall be charged at the then current
prices for parts, labor, and transportation.
Reasonable care must be used to avoid hazards. Seller
expressly disclaims responsibility for loss or damage
caused by use of its Products other than in accordance
with proper operating procedures.
Except as stated herein, Seller makes no warranty, express
or implied (either in fact or by operation of law), statutory
or otherwise; and, except as stated herein, Seller shall
have no liability under any warranty, express or implied
(either in fact or by operation of law), statutory or
otherwise. Statements made by any person, including
representatives of Seller, which are inconsistent or in
conflict with the terms of this warranty shall not be
binding upon Seller unless reduced to writing and
approved by an officer of Seller.
Warranty Replacement and Adjustment
All claims under warranty must be made promptly after
occurrence of circumstances giving rise thereto, and must
be received within the applicable warranty period by
Seller or its authorized representative. Such claims should
include the Product serial number, the date of shipment,
and a full description of the circumstances giving rise to
the claim. Before any Products are returned for repair
and/or adjustment, written authorization from Seller or its
authorized representative for the return and instructions
as to how and where these Products should be returned
must be obtained. Any Product returned to Seller for
examination shall be prepaid via the means of
transportation indicated as acceptable by Seller. Seller
reserves the right to reject any warranty claim not
promptly reported and any warranty claim on any item
that has been altered or has been returned by
non-acceptable means of transportation. When any
Product is returned for examination and inspection, or for
any other reason, Customer shall be responsible for all
damage resulting from improper packing or handling, and
for loss in transit, notwithstanding any defect or
non-conformity in the Product. In all cases, Seller has the
sole responsibility for determining the cause and nature of
failure, and Seller’s determination with regard thereto
shall be final.
If it is found that Seller’s Product has been returned
without cause and is still serviceable, Customer will be
notified and the Product returned at its expense; in
addition, a charge for testing and examination may be
made on Products so returned.

TriScroll 800 Inverter Vacuum Pump
This page intentionally left blank.

1
TriScroll 800 Inverter Vacuum Pump
DRAFT 10/9/14
Instructions for Use
General Information
This equipment is designed for use by professionals. The
user should read this instruction manual and any other
additional information supplied by Agilent before
operating the equipment. Agilent will not be held
responsible for any events that occur due to
non-compliance with these instructions, improper use by
untrained persons, non-authorized interference with the
equipment, or any action contrary to that provided for by
specific national standards.
The TriScroll™ 800 is a dry scroll vacuum pump. This
pump is suitable for pumping air or inert gases. The pump
is not intended to pump toxic, corrosive, explosive, or
particulate-forming gases.
The following paragraphs contain all the information
necessary to guarantee the safety of the operator when
using the equipment. Detailed information is supplied in
“Technical Information” on page 7.
This manual uses the following standard safety protocol:
Storage
When transporting and storing the pump, the following
environmental requirements should not be exceeded:
Unpacking and Inspection
The shipping container is a double carton.
1. After opening the outer box, remove the foam packing.
2. Slit open the inner box.
3. Lift the pump with the plywood base out of the inner
box. Attach a hoist cable capable of lifting 250 lbs
onto the eye bolt on top of the pump.
4. Remove the four bolts securing the pump frame to
the plywood base.
5. Locate the NW25 exhaust fitting and set it aside.
6. Inspect the pump for damage.
If there is shipping damage, contact the freight carrier
and your local Agilent sales office immediately.
7. Save the carton and packing materials.
Total weight of the package, including the pump, is
approximately 42 kg (92 lbs).
WARNING The warning messages are for
attracting the attention of the opera-
tor to a particular procedure or prac-
tice which, if not followed correctly,
could lead to serious injury.
CAUTION The caution messages are displayed
before procedures, which if not fol-
lowed, could cause damage to the
equipment.
NOTE The notes contain important
information taken from the text.
Temperature: –20 °C to 60 °C (–4 °F to 140 °F)
Relative humidity: 0 to 95% (non-condensing)
WARNING When unpacking the pump, be sure
not to drop it, and avoid any kind of
sudden impact or shock vibration
to it.
WARNING The TriScroll 800 weighs 32 kg
(71 lbs). To avoid injury, use proper
lifting techniques when moving the
pump.
NOTE Normal exposure to the environ-
ment cannot damage the pump.
Nevertheless, it is advisable to keep
the pump inlet closed until the
pump is installed in the system.

DRAFT 10/9/14
TriScroll 800 Inverter Vacuum Pump
2
Installation Requirements
Safety
Do not remove or modify any safety or insulating
equipment from the pump. To do so may create a serious
safety hazard and may void the warranty.
During operation, the following environmental
conditions should not be exceeded:
WARNING ❑This pump is designed to pump
and exhaust air and inert gases only;
it is not designed to pump explosive,
flammable, toxic, or corrosive gases.
They can cause bodily injury,
explosion, or fire.
❑Install in an area that is not
exposed to rain, steam, or excessive
humidity. They can cause electric
shock, short circuits, and severe
bodily injury.
❑Before inspecting or servicing the
pump, be sure the electrical supply
is disconnected.
❑Consult a qualified electrician
whenever wiring the pump.
❑An exhaust silencer option is
available for those applications in
which it is desirable to diminish the
sound level produced by the pump.
❑To prevent bodily injury, avoid
exposing any part of the human
body to vacuum.
❑The pump is a heavy object. To
avoid muscle strain or back injury,
use lifting aides and proper lifting
techniques when removing or
replacing.
CAUTION Although the pump can pump trace
particulates normally found in the
atmosphere, it is not designed for
process solids, chemicals, powders,
solvents, condensates, or other par-
ticulates. They can damage the
equipment, degrade its performance,
or shorten its useful life.
The pump operates in a clockwise
direction when viewed from the
motor end. (Note the arrow on the
pump frame.) Improper rotation can
cause permanent damage to the
pump.
Temperature: +5 °C to +40 °C (41 °F to 104 °F)
Relative humidity: 0 to 95% (non-condensing)
CAUTION Do not block the fan ducts because the
pump can become overheated. A pump
surface temperature in excess of 55 °C
(131 ° F) is potentially damaging. If such
conditions are observed, turn pump off
and allow to cool. Disassemble, inspect
for damage, and repair if necessary.
CAUTION To reduce the risk of electric shock,
do not expose to rain; store indoors.

3
TriScroll 800 Inverter Vacuum Pump
DRAFT 10/9/14
Power Cord
Several power cord options are available from your
Agilent dealer. Descriptions of the available power cords
and their ordering numbers are given in Table 1.
Grounding Instructions
This product should be grounded. In the event of an elec-
trical short circuit, grounding reduces the risk of electric
shock by providing an escape wire for the electric current.
This pump is equipped with a power cord that has a
grounding wire with an appropriate grounding plug. The
plug must be inserted into an outlet that is properly
installed and grounded in accordance with all local codes
and ordinances.
Extension Cords
If you must use an extension cord with this product:
❑Agilent recommends using only extension cords
with a minimum of 16-gauge wire and a
maximum length of 25’ (7.6 m).
❑Use only a 3-wire extension cord that accepts the
plug.
❑Ensure the extension is in good condition.
❑Ensure the extension cord is rated high enough to
carry the current the products draws. An
undersized cord causes a drop in line voltage,
resulting in loss of power and overheating.
Circuit Breakers
Table 2 lists the circuit breaker capacity required for the
pump. Locate the switch or circuit breaker near the pump.
NOTE The pump must be connected to the
power supply using a high voltage
IEC-320 type power cord of at least 10
A capacity.
Table 1 Power Cord Selection
Country Power Cord Specification Order
Europe 10 A / 220-230 VAC, 2.5 m 656494220
Denmark 10 A / 220-230 VAC, 2.5 m 656494225
Switzerland 10 A / 230 VAC, 2.5 m 656494235
UK/Ireland 13 A / 230 VAC, 2.5 m 656494250
India 10 A / 220-250 VAC, 2.5 m 656494245
Israel 10 A / 230 VAC, 2.5 m 656494230
North
America
10 A / 230 VAC, 2.5 m 656494255
WARNING Check with a qualified electrician or
serviceman if the grounding instructions
are not completely understood, or if
you are in doubt as to whether the
product is properly grounded.
Do not modify the plug provided; if it
does not fit the outlet, have the proper
outlet installed by a qualified electrician.
Connect the product only to an outlet
that has the same configuration as the
plug.
Do not use an adapter with this
product.
WARNING ❑Protect against short circuits by
installing a circuit breaker of the
proper capacity.
❑The circuit breaker must be suit-
ably located and easily reached.
❑The circuit breaker must be
marked at the disconnecting device
for the equipment with the on/off
symbol I/O and meet the relevant
requirements of IEC60947-1 and
IEC60947-3.
Table 2 Circuit Breaker Requirements
PTS08001INV 200-240 VAC
50/60 Hz
Breaker capacity 10 Amperes

DRAFT 10/9/14
TriScroll 800 Inverter Vacuum Pump
4
Mechanical Connections
Pump Location
Locate the pump on a firm, level surface.
Clearance mounting holes provided in the frame can be
used to provide permanent attachment. Attach the
provided rubber mounts to the threaded holes at the
frame base to minimize vibration.
Do not to position the equipment so that it is difficult to
operate the disconnecting device.
Vacuum Pump Isolation Valve
Scroll pumps return to atmospheric pressure quickly
when shut off. Thus, an integrated fast acting, automatic,
normally closed isolation valve is standard equipment to
prevent pump debris from being transported back into the
vacuum chamber when the pump is turned off:
❑The opening of this valve must occur 350 ms
after pump startup.
❑Valve closing must occur 250 ms after pump
shut off.
The VPI Valve status is controlled by motor
operation. The VPI Valve:
❑Opens when the pump is running and
❑Closes when it is stopped due to switch off or
overload protection.
This TriScroll 800 Inverter Scroll pump includes the
necessary communication cable, needed to operate the
pump.
Pump Inlet
Use NW40, or larger, clean vacuum hardware with as
short a length as practical between the pump inlet and the
vacuum chamber.
Use a bellows to provide both vibration isolation and
strain relief between the pump and vacuum chamber.
Pump Exhaust
A female 3/8 National Pipe Thread exhaust fitting is
located underneath the scroll module. This fitting swivels
360°. Additionally, a NW25 adapter is provided with a
3/8 National Pipe Thread male thread.
Gas Ballast
The pump incorporates an automatic gas ballast to
prevent water and other condensates from accumulating
within the pump. The standard configuration is a sintered
filter installed in the 1/4" National Pipe Thread gas ballast
port (item 8 on Figure 1 on page 6). This allows enough
atmospheric air to enter the pump in order to purge
condensates while not affecting pump ultimate pressure
or pumping speed.
For applications where the ingress of atmospheric air is
undesirable, dry nitrogen at a flow rate of  5 lpm can be
bled into the gas ballast port. See item 8 on Figure 1 on
page 6. Blocking of the gas ballast port is not
recommended.
Bearing Purge
A 1/4" National Pipe Thread bearing purge port (item 5 on
Figure 1 on page 6) protects the main crankshaft bearings
in applications where large amounts of water are being
pumped. In the standard configuration, this port is sealed.
To enable the bearing purge, dry nitrogen at a flow rate of
5 lpm can be bled into the bearing purge port. This gas
supply should be maintained at 2 psig or less and must be
kept below 5 psig.
See “Purge Kit” on page 12.

5
TriScroll 800 Inverter Vacuum Pump
DRAFT 10/9/14
Operation
In order to reach ultimate vacuum, the pump must be left
running for about one hour with the inlet sealed.
Unlike conventional oil-sealed pumps, Agilent’s dry scroll
pumps do not have fluid to cleanse them of accumulated
dust and debris. Run the pump periodically at atmosphere
for a minute or two to flush out the pump. Flush the pump
regularly and adjust this schedule according to your
specific conditions.
Startup Procedure
1. Be sure that the vacuum system isolation valve is
closed.
2. Turn on power to the pump.
3. Open the isolation valve.
Shutdown Procedure
1. Close the vacuum system isolation valve. This
prevents debris in pump from being transported into
the vacuum system.
2. Turn off power to the pump.
Maintenance
Personnel responsible for pump operation and
maintenance must be well-trained and aware of the
accident prevention rules.
If a pump is to be discarded, it must be disposed of in
accordance with specific national and local standards.
NOTE Pump operation is interlock depen-
dent. The provided mating connec-
tor must be plugged into P1 to start
the pump.
NOTE The integrated VPI solenoid must be
connected to I/O P2 with the pro-
vided communications cable prior
starting the pump.
NOTE When the controller is switched on,
an electronic self-test occurs, during
which an orange LED illuminates for
one second and the turns off for two
seconds. During this time, the pump
will not start.
This self-test time is not required if
the pump is already powered, as
when remotely or serially operated.
WARNING ❑Death may result from contact
with high voltages. Always take
extreme care and observe the acci-
dent prevention regulations in force.
❑When the machine is powered
up, be careful of moving parts and
high voltages.
❑If you have to perform mainte-
nance on the pump after a consider-
able time in operation, allow the
pump to cool as the temperature of
the outer surface may be in excess of
55 °C (131 °F).
❑Always disconnect your power
supply to the pump before beginning
maintenance work.
NOTE Before returning the pump to the
factory for repair, the Return Autho-
rization sheet attached to this
instruction manual must be com-
pleted and sent to the local sales
office. A copy of the sheet must be
inserted in the pump package before
shipping.

DRAFT 10/9/14
TriScroll 800 Inverter Vacuum Pump
6
TriScroll 800 Inverter Pump Components View
Figure 1 TriScroll 800 Inverter Vacuum Pump
2
1
1
3
4
5
7
8
16
15 14
13 12
11
10
6
9
Cowling Screws; M5 (3) (two shown)
Cowling
Inlet (NW40)
Inlet Screen
Bearing Purge Port (1/4” NPT)
Gas Ballast Port (1/4” NPT)
Mounting Holes; 11 mm diameter thru (8)
Rubber Feet (4)
Integrated VPI Valve
VPI Solenoid
VPI Communication Cable
Power Connector (IEC 320)
On/Off Switch
Serial Port J1
Interlock Port P1 I/O-1
Interlock Port P2 I/O-2
NW25 Exhaust Adapter (Not Shown)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

7
TriScroll 800 Inverter Vacuum Pump
DRAFT 10/9/14
Technical Information
Table 3 Specifications
Model TriScroll™ 800 Inverter Dry Scroll Vacuum Pump (PTS08001INV)
Interface dimensions See Figure 2
Peak pumping speed 800 l/m, 48m3/hr (28.3 cfm)
See Figure 3
Media Clean air. No toxic, corrosive, explosive or particulate forming gases
Ultimate pressure (Torr) 10.0 x 10-3 Torr (13.3 x 10-3 mbar)
Maximum inlet pressure 1.0 atmosphere (0 psig)
Maximum continuous inlet pressure 100 Torr
Maximum outlet pressure 1.1 atmosphere (1.5 psig)
Inlet connection NW40
Exhaust connection Female 3/8" National Pipe Thread (NW25 adapter provided)
Gas ballast Female 1/4" National Pipe Thread (40 Micron sintered filter provided)
Ambient operating temperature 5 °C to 40 °C (41 °F to 104 °F)
Storage temperature –20 °C to 60 °C (–4 °F to 140 °F)
Motor rating 1.0 HP (0.75 kW)
Operating voltage 50-60 Hz:200-240 VAC Single-phase ±10%, 1200 VA
Maximum line current 200 VAC; 6 A
240 VAC; 5A
Motor Thermal Protection Automatic
Operating speed 35-65 Hz Factory setting: 62 Hz, 1800 RPM
Cooling system Air-cooled
Weight Pump only: 32 kg (71 lbs)
Shipping weight: 42 kg (92 lbs)
Noise level (per ISO 11201) Variable with frequency, 58-71 dB(A)
Vibration level at inlet (per ISO 10816-1) Variable with frequency
Main fuse 12.5 A, 250 V
Installation and storage Installation category 2, indoor usage and storage
Pollution degree 2
Altitude 2000 m

DRAFT 10/9/14
TriScroll 800 Inverter Vacuum Pump
8
Figure 2 Interface Drawing with Dimensions
Figure 3 Pumping Speed Curves

9
TriScroll 800 Inverter Vacuum Pump
DRAFT 10/9/14
Pump Electrical Controller
The pump is powered by an inverter that converts single
phase line power into 3-phase power that drives an
induction motor at a user selectable frequency.
Several operational variables are modifiable through the
J2 serial port when using Agilent T-Plus software. A
number of additional system variables are also viewable.
Pump operation is interlocked through the P1 connector.
Pins 4 and 5, and Pins 8 and 9, must be connected
together to enable operation. A prewired connector is
supplied with the pump and should be plugged into P1.
The maximum power output of the inverter is 950 Watts.
At pump inlet pressures above approximately 20 Torr, the
pump will be power limited and the output frequency
will be reduced. This mode is known as autotuning.
At pump start, the drive frequency is ramped up over
several seconds. This provides for smooth starting and
eliminates large in-rush currents.
Technical Specifications
❑Input voltage: 200 V-240 V / 50-60 Hz
❑Max frequency: 65 Hz, factory set @ 62Hz
❑Normal Operation maximum power: 850 W
❑Protection level: IP 20
Remote speed setting allows you to control rotational
speed using a 0-10 V analog input:
❑Vin > 9 V: Driving frequency will be the full
speed (factory set @62 Hz)
❑Vin <1 V: Driving frequency will be the minimum
speed (35 Hz)
Figure 4 Driving Frequency vs. Analog Input
Table 4 P1 I/O-1 Interlock
PIN
#
SIGNAL NAME IN/OUT
1 Interlock contact 1 Out
2 0-10Vdc, with reference
to pin 5 remote control
In
3 No Connection
4 Start/Stop (-): Connect to
Pin 5
In
5 Groundout Out
6 Interlock contact 2 Out
7 No Connection
8 Start/Stop (+): Connect to
Pin 9
In
9 +24V ±5% 50mA, with
reference to pin 5
Out
NOTE Pump operation is interlock depen-
dent. The provided mating connec-
tor must be plugged into P1 to start
the pump.
Table 4 P1 I/O-1 Interlock
PIN
#
SIGNAL NAME IN/OUT

DRAFT 10/9/14
TriScroll 800 Inverter Vacuum Pump
10
Serial Interface Specification RS485 and
RS232
Physical level: RS232 or RS485
Maximum baud: 9600, 8 data bit, no parity, 1 stop bit.
Table 5 J1 - Serial Port
PIN
#
SIGNAL NAME
1 +5V ±5%, 50mA, with reference to pin 5
2RS232TX
3RS232RX
4 No Connection
5 GND
6RS485A
7 No Connection
8RS485B
9 No Connection
Table 6 P2 I/O-2 Port on DB9 Male Connector
PIN
#
SIGNAL NAME
1 No Connection
2 No Connection
3 No Connection
4 No Connection
5 GND
6 No Connection
7 No Connection
8 No Connection
9 VPI output +24V ±5% 400mA, with
reference to pin 5
Table 7 T-Plus Software Variables
WIN TYPE DESCRIPTION
000 Logical Start/Stop
(1=START; 0=STOP)
001 Logical Low Speed
[0=OFF / 1=ON]
008 Logical Remote/Serial Configuration
(1=REMOTE; 0=SERIAL)
102 Numerical Set Point Value
(Hz)
105 Numerical Set Point Hysteresis (%)
[0-100]
108 Numerical Baud Rate
(0-4)
[600-1200-2400-4200-9600]
117 Numerical Low Speed Adjust
(Hz)
120 Numerical Rotational Frequency Setting
[Hz] (High speed adjust)
200 Numerical Bus Current
[mA]
201 Numerical 3 Phase Voltage
[Vrms]
202 Numerical Power
[W]
203 Numerical Driving Frequency
[Hz]: (current driving
frequency)
205 Numerical Status:
❑0=stop
❑2=ramp
❑3=autotuning
❑5=normal
❑6=fail

11
TriScroll 800 Inverter Vacuum Pump
DRAFT 10/9/14
Using T-Plus Software To Change The Target
Frequency
1. Install T-Plus software on your PC by running
setup.exe.
2. Using a 9-pin serial cable, connect your PC to the J2
serial port on the inverter (Figure 5).
3. Start the pump using the On/Off switch. The provided
Interlock Connector must be installed in P1.
4. Start the T-Plus software and Figure 5 appears.
Figure 5 T+ Pumps List
5. Click Open Control Panel and Figure 6 appears.
6. Open the Speed Settings directory, and click Target
Frequency.
Figure 6 T-Unknown Pump
7. Enter the desired operating frequency into Insert New
Value. This must be an integer between 35 and 65.
8. Click Send. The pump immediately tries to change to
the new target frequency. If the pump requires more
than 750 Watts to attain the target frequency, the
206 Numerical Error Code:
❑Bit 7: motor block
❑Bit 6: short circuit
❑Bit 5: undervoltage
❑Bit 4: spare
❑Bit 3: power fail
❑Bit 2: controller overt
❑Bit 1: pump overt
❑Bit 0: spare
211 Numerical Controller Temperature
[°C]
216 Numerical Environment Temperature
[°C]
300 Numerical Cycle Time
[min]
301 Numerical Cycle Number
302 Numerical Pump Life
[h]
319 Alphanumeric Controller Model
323 Alphanumeric Controller Serial Number
325 Alphanumeric Electrical Modification Level
500 Logical Monitor Mode (write only)
503 Numerical RS485 Serial Address Setting
[0-31]
504 Logical Serial Type Select
(0=RS323; 1=RS485)
Table 8 Status LEDs
LED STATUS CONTROLLER STATUS
Off Stop
Green flashing Ramp or Autotuning
Green Normal Operation
Red Fail
Orange + Off Reset + selftest
Table 7 T-Plus Software Variables (Continued)
WIN TYPE DESCRIPTION
NOTE When the controller is switched on,
an electronic self-test occurs, during
which an orange LED illuminates for
one second and the turns off for two
seconds. During this time, the pump
will not start.
This self-test time is not required if
the pump is already powered, as
when remotely or serially operated.

DRAFT 10/9/14
TriScroll 800 Inverter Vacuum Pump
12
pump is power limited and will run at a lower
frequency (auto-tuning mode). This condition
continues until the power required drops below 750
Watts.
The target frequency is stored in the inverter even
when power to the pump is removed.
Purge Kit
A purge kit (Agilent part number PTSPURGEKIT) is
available to properly purge either the bearing purge or the
gas ballast. This kit contains a flowmeter and all
necessary valving and tubing.
Exhaust Silencer Kit
In certain applications it is desired to lower the noise
level emitted by the pump. For these cases, Agilent offers
Exhaust Silencer Kits (P/N EXSLRTRISCROLL, Manual
P/N: 699904380), which breaks up noise pulsation in the
discharge line.
The Exhaust Silencer Kits contain two basic components,
as well as installation hardware. A cylindrical resonator
chamber has been selected to attenuate the frequencies
associated with the exhaust gas pulsation noise. The
resonator is then plumbed to an exhaust muffler/filter.
This muffler provides the majority of the actual noise
reduction. It also contains an integral 5-micron paper
filter element to capture any tip seal debris. This paper
filter is replaceable; the recommended service interval is
whenever the pump tip seal or module maintenance is
performed.
Replacement polyester filter element rated 99% efficient
at the 5-micron particle size, P/N: REPLSLRFILTER,
Vibration Isolation Kit
A set of vibration isolation mounts (P/N PTSVIBISOKIT,
Manual P/N: 699904385) are available for Agilent scroll
pumps. These are used in place of the standard feet
installed on the pump for applications that require
minimal vibration transmission from the pump to the
installation. They can be used alone, or with inlet flexible
bellows to provide pump isolation.
The vibration isolation mounts in the Vibration Isolation
Kit have been designed to ensure the lowest vibration
level transmitted at the base of the pump.
Vibration level in every direction (axis), transmitted to the
surface the pump sits on, is reduced by a significant
amount. Typical vibration reduction levels are 75% for
the TriScroll 800 pump.
The TriScroll Vibration Isolation Kit consists of (4)
vibration isolation mounts. They have a M6 metric
threaded screw to attach to the TriScroll frame; the screw
is provided.
These mounts increase the height of the TriScroll pumps
by 0.75" compared to the standard mounting feet.
HEPA Inlet filter
Agilent now offers inlet filters for the scroll pumps, which
protect the pump from ingested particles, and keep
particles from migrating out of the pump. These HEPA
filters provide a rated 99.97% efficiency in trapping
particles > 0.3 microns.
NW 40 Inlet Trap with HEPA filter insert: P/N#:
SCRINTRPNW40.
Replacement HEPA filter element P/N#: RPLHEPAFILTER1
